Hayward AQL-CHEM4-CHLOR User manual

USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
Hayward Industries
400 Connell Drive, Suite 6100
Berkeley Heights, NJ 07922
Phone: [phone]
www.hayward.com
LIQUID CHLORINE
FEED SYSTEM
Owner’s Manual
AQL-CHEM4-CHLOR
Contents
Installation.................................1
Operation...................................1
Feed Tube Replacement...............1
Replacement Parts......................2
Winterization..............................3
Warranty.....................................3
AQLTCHLOR RevE

USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
Basic safety precautions should always be followed, including the following: Failure to follow instructions can cause death and/or severe
injury.
This is the safety-alert symbol. When you see this symbol on your equipment or in this manual, look for one of the following signal
words and be alert to the potential for personal injury.
WARNING - Warns about hazards that could cause death and/or severe injury or major property damage and if ignored pres-
ents a potential hazard.
CAUTION - Warns about hazards that could cause minor or moderate personal injury and/or property damage and if ignored
presents a potential hazard. It can also make consumers aware of actions that are unpredictable and unsafe.
NOTICE - Indicates special instructions that are important but not related to hazards.
WARNING - Suction Entrapment Hazard. Suction in suction outlets and/or suction outlet covers which are, damaged, broken,
cracked, missing, or unsecured can cause death and/or severe injury due to the following entrapment hazards:
Hair Entrapment - Hair can become entangled in suction outlet cover.
Limb Entrapment - A limb inserted into an opening of a suction outlet sump or suction outlet cover that is damaged, broken, cracked, miss-
ing, or not securely attached can result in a mechanical bind or swelling of the limb.
Body Suction Entrapment - This happens when a negative pressure applied to a large portion of the body or limbs can result in an entrap-
ment.
Evisceration/ Disembowelment - A negative pressure applied directly to the intestines through an unprotected suction outlet sump or suc-
tion outlet cover which is, damaged, broken, cracked, missing, or unsecured can result in evisceration/ disembowelment.
Mechanical Entrapment - There is potential for jewelry, swimsuit, hair decorations, finger, toe or knuckle to be caught in an opening of a
suction outlet cover resulting in mechanical entrapment.
WARNING - To Reduce the risk of Entrapment Hazards:
o When outlets are small enough to be blocked by a person, a minimum of two functioning suction outlets per pump must be installed.
Suction outlets in the same plane (i.e. floor or wall), must be installed a minimum of three feet (3’) [1 meter] apart, as measured from
near point to near point.
o Dual suction fittings shall be placed in such locations and distances to avoid “dual blockage” by a user.
o Dual suction fittings shall not be located on seating areas or on the backrest for such seating areas.
o The maximum system flow rate shall not exceed the flow rating of as listed on Table 1.
o Never use Pool or Spa if any suction outlet component is damaged, broken, cracked, missing, or not attached.
o Replace damaged, broken, cracked, missing, or not securely attached suction outlet components immediately.
o In addition two or more suction outlets per pump installed in accordance with latest ASME, APSP Standards and CPSC guidelines, follow
all National, State, and Local codes applicable.
o Installation of a vacuum release or vent system, which relieves entrapping suction, is recommended.
WARNING - Failure to remove pressure test plugs and/or plugs used in winterization of the pool/spa from the suction outlets can result in
an increase potential for suction entrapment as described above.
WARNING - Failure to keep suction outlet components clear of debris, such as leaves, dirt, hair, paper and other material can result in an
increase potential for suction entrapment as described above.
WARNING - Suction outlet components have a finite life, the cover/grate should be inspected frequently and replaced at least every
seven years or if found to be damaged, broken, cracked, missing, or not securely attached.
!
!
!
!
!
!
!
!

USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
CAUTION - Components such as the filtration system, pumps and heater must be positioned so as to prevent their being used as means
of access to the pool by young children. To reduce risk of injury, do not permit children to use or climb on this product. Closely supervise
children at all times. Components such as the filtration system, pumps, and heaters must be positioned to prevent children from using them
as a means of access to the pool.
WARNING - Hazardous Pressure. Pool and spa water heating and circulation systems operate under hazardous pressure during
start up, normal operation, and after pump shut off. Stand clear of circulation system equipment during pump start up. Failure to follow safety
and operation instructions could result in violent separation of the pump housing and cover, and/or filter housing and clamp due to pressure in
the system, which could cause death, severe personal injury and/or property damage, Before servicing pool and spa water circulation system,
all system and pump controls must be in off position and filter manual air relief valve must be in open position. Before starting system pump,
all system valves must be set in a position to allow system water to return back to the pool. Do not change filter control valve position while
system pump is running. Before starting system pump, fully open filter manual air relief valve. Do not close filter manual air relief valve until a
steady stream of water (not air or air and water) is discharged.
WARNING - Separation Hazard. Failure to follow safety and operation instructions could result in violent separation of pump and/or
filter components. Strainer cover must be properly secured to pump housing with strainer cover lock ring. Before servicing pool and spa cir-
culation system, filters manual air relief valve must be in open position. Do not operate pool and spa circulation system if a system component
is not assembled properly, damaged, or missing. Do not operate pool and spa circulation system unless filter manual air relief valve body is in
locked position in filter upper body. Never operate or test the circulation system at more than 50 PSI. Do not purge the system with com-
pressed air. Purging the system with compressed air can cause components to explode, with risk of severe injury or death to anyone nearby.
Use only a low pressure (below 5 PSI), high volume blower when air purging the pump, filter, or piping.
WARNING - Risk of Electric Shock. All electrical wiring MUST be in conformance with applicable local codes, regulations, and the
National Electric Code (NEC). Hazardous voltage can shock, burn, and cause death or serious property damage. To reduce the risk of electric
shock, do NOT use an extension cord to connect unit to electric supply. Provide a properly located electrical receptacle. Before working on
any electrical equipment, turn off power supply to the equipment. To reduce the risk of electric shock replace damaged wiring immediately.
Locate conduit to prevent abuse from lawn mowers, hedge trimmers and other equipment. Do NOT ground to a gas supply line.
WARNING - Risk of Electric Shock. Failure to ground all electrical equipment can cause serious or fatal electrical shock hazard.
Electrical ground all electrical equipment before connecting to electrical power supply.
WARNING - Risk of Electric Shock. Failure to bond all electrical equipment to pool structure will increase risk for electrocution
and could result in injury or death. To reduce the risk of electric shock, see installation instructions and consult a professional electrician on
how to bond all electrical equipment. Also, contact a licensed electrician for information on local electrical codes for bonding requirements.
Notes to electrician: Use a solid copper conductor, size 8 or larger. Run a continuous wire from external bonding lug to reinforcing rod or
mesh. Connect a No. 8 AWG (8.4 mm2) [No. 6 AWG (13.3 mm2) for Canada] solid copper bonding wire to the pressure wire connector pro-
vided on the electrical equipment and to all metal parts of swimming pool, spa, or hot tub, and metal piping (except gas piping), and conduit
within 5 ft. (1.5 m) of inside walls of swimming pool, spa, or hot tub. IMPORTANT - Reference NEC codes for all wiring standards including,
but not limited to, grounding, bonding and other general wiring procedures.
CAUTION - These heaters are intended for use with permanently-installed pools and may be used with hot tubs and spas if so marked.
Do not use with storable pools. A permanently-installed pool is constructed in or on the ground or in a building such that it cannot be readily
disassembled for storage. A storable pool is constructed so that it is capable of being readily disassembled for storage and reassembled to its
original integrity.
WARNING - Risk of Hyperthermia. To avoid hyperthermia the following “Safety Rules for Hot Tubs” are recommended by the U.S.
Consumer Product Safety Commission.
1. Spa or hot tub water temperatures should never exceed 104°F [40°C]. A temperature of 100°F [38°C] is considered safe for a healthy
adult. Special caution is suggested for young children. Prolonged immersion in hot water can induce hyperthermia.
2. Drinking of alcoholic beverages before or during spa or hot tub use can cause drowsiness, which could lead to unconsciousness and
subsequently result in drowning.
3. Pregnant women beware! Soaking in water above 100°F [38°C] can cause fetal damage during the first three months of pregnancy
(resulting in the birth of a brain-damaged or deformed child). Pregnant women should adhere to the 100°F [38°C] maximum rule.
4. Before entering the spa or hot tub, users should check the water temperature with an accurate thermometer; spa or hot tub thermostats
may err in regulating water temperatures by as much as 4°F (2.2°C).
!
!
!
!
!
!
!
!

USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
5. Persons taking medications, which induce drowsiness, such as tranquilizers, antihistamines or anticoagulants, should not use spas or
hot tubs.
6. If the pool/spa is used for therapy, it should be done with the advice of a physician. Always stir pool/ spa water before entering the pool/
spa to mix in any hot surface layer of water that might exceed healthful temperature limits and cause injury. Do not tamper with controls,
because scalding can result if safety controls are not in proper working order.
7. Persons with a medical history of heart disease, circulatory problems, diabetes or blood pressure problems should obtain a physician’s
advice before using spas or hot tubs.
8. Hyperthermia occurs when the internal temperature of the body reaches a level several degrees above normal body temperature of
98.6°F [37°C]. The symptoms of Hyperthermia include: drowsiness, lethargy, dizziness, fainting, and an increase in the internal
temperature of the body.
The effects of Hyperthermia include:
• Unawareness of impending danger.
• Failure to perceive heat.
• Failure to recognize the need to leave the spa.
• Physical inability to exit the spa.
• Fetal damage in pregnant women.
• Unconsciousness resulting in danger of drowning.
DANGER - Chemical Hazard: Mixing chemicals or adding water to acid may result in explosion, fire, and/or toxic fume release.
To avoid death, serious injury, or major property damage, do not mix chlorine tablets with Calcium Hypochlorite, or with any other form of
concentrated chlorine or other chemicals.
DANGER - Chemical Hazard: Chlorine (liquid and mist) can cause severe burns, may be fatal if swallowed or inhaled. Inhalation can
cause severe lung damage. To avoid death or serious injury:
• Wear eye and skin protection while maintaining or servicing this unit.
• If inhaled, move to an area with fresh air and seek medical attention immediately.
• If swallowed, contact local poison center or physician immediately. Give large amounts of milk or water.
• Wear chemical resistant clothing including chemically resistant gloves. If skin contact occurs, wash with soap and water for at least 20
minutes. Remove contaminated clothing and shoes. Contaminated clothing should be cleaned before reuse.
• Use splash resistant safety goggles. If eye contact occurs, seek immediate medical attention. Flush eyes immediately with clean water
for at least 20 minutes.
• Use in a well-ventilated area only.
WARNING - Hazardous Waste: Chlorine can cause corrosion, which can cause injury or property damage. To avoid, dispose of used
liquid at an approved hazardous waste facility. Call your local fire department or hazardous materials for significant spills.
SAVE THESE INSTRUCTIONS
!
!
!

USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
1
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
Installation
This Chlorine Feed System is designed to be used with a controller such as the Hayward AquaPlus®or ProLogic®or CAT Controllers®. It should be located
within 10 feet of the 110 VAC signal supply and within 12 feet of the location on the return to pool piping. Included in the package is a check valve which
MUST be installed on the return to pool line, downstream of all filters, heaters, and other equipment.
To install the check valve:
1. Shut off the pool system pump. Allow the water to drain from the return to pool line (If this is a flooded suction application, the location for the tapped
hole must be isolated with valving or you will get wet).
2. Locate the desired spot for the liquid chlorine feed line on the return to pool line.
3. Drill a 27/64” hole and tap with a 1/4”-18 NPT. Do not oversize the hole, or run the tap too deep.
4. Facing the threaded end of the fitting, begin wrapping the Tetrafluoroethylene (TFE) tape in a clockwise direction, starting on the section thread nearest
the fitting end. Overlap each wrap by one-half the width of the TFE tape.
5. Carefully screw the check valve into the pipe, hand tight plug 1/2 turn maximum.
Run the 6mm tubing (13 feet of tubing is included) from the discharge of the pump to check valve. Both ends are compression fittings. Loosen the nuts at
each end. Slide the nuts over the tubing. Install the tubing over the short male nipple at each end. Firmly hand tighten the nuts.
Plug the 110 VAC cord into the controller. As long as there is power, the pump will run.
The Liquid Chlorine Feed System should NOT be stored in the same room as other chemicals or chemical tanks.
Operation
The Liquid Chlorine is stored in the 15 gallon storage tank below the pump. DO NOT OVER FILL as the tank only holds 15 gallons. The Liquid Chlorine is
pumped from the tank utilizing a 3/8” pick up tube to the pump, through the small tube, and then to the Return to Pool Line.
This system is designed for: Liquid Chlorine (NaClO) (Sodium Hypochlorite)
Replacing the Feed Tube
The Santoprene feed tube should be replaced every 3 to 6 months
1. Disconnect the pump from the power supply.
2. Remove the faceplate. (Note: the bearing [transaxle] will be seated in front of the roller. Gently pull the faceplate and the bearing assembly until it is
unseated. Be careful not to lose the bearing assembly, attached to the back of the faceplate, or the screws.
3. Turn the roll holder clockwise, so that the bottom roller is equally spaced between the intake and discharge fittings.
DANGER - Chemical Hazard: Chlorine (liquid and mist) can cause burns, may be fatal if swallowed or inhaled. Inhalation can cause lung damage.
To avoid death or serious injury:
• Wear eye and skin protection while maintaining or servicing this unit.
• Wear compatible rubber gloves.
• Use in a well ventilated area.
4. Unscrew the compression nuts over the blue tubing and remove the tubing from the feed tube fittings.
5. Lift and remove the feed tube fitting on the lower left side (inlet) of the pump from its seat by sliding it away from the tank. Lift and remove the feed tube
fitting on the lower right side (outlet) of the pump from its seat by sliding it away from the tank.
6. Manually rotate the roller clockwise, while lifting the feed tube, until the feed tube comes away from the pump.
To install a new feed tube:
1. Manually rotate the roller clockwise until the rollers are at the 3 o’clock and 9 o’clock positions.
2. Insert the curved side of the new feed tube into its seat on the left side of the pump.
3. Manually rotate the roller clockwise while pushing on the feed tube until the right side of the feed tube is easily inserted into its seat. (Curved side first.)
4. Re-install the faceplate, starting at the top and pressing the bearing into the countersink on the roller assembly. Install the two screws.
5. Unscrew the compression nut on the feed tube left side (inlet). Slide the nut over the 6” long blue tubing going to the pickup tube. Install the tubing over
the male compression portion of the feed tube fitting. Firmly hand tighten the nut.
6. Unscrew the compression nut on the feed tube right side (outlet). Slide the nut over the long blue tubing going to the return to pool check valve. Install
the tubing over the male compression portion of the feed tube fitting. Firmly hand tighten the nut.
!

USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
2
Replacement Parts
PART NUMBER DESCRIPTION NO. REQ’D
ACX03590120 PUMP ASSEMBLY WITH 13’ TUBING AND 31.68 GPD SPARE FEED TUBE 1
CAX-3504 PVC BLUE SUCTION TUBE(SOFT) (13 FT ROLL)
CAX-3505 PVC BLUE SUCTION TUBE(SOFT) (300 FT ROLL)
CAX-3508 3X7 SANTOPRENE FEED TUBE 6.14GPD
CAX-3509 ROLLER ASSEMBLY FOR 31.68 GPD
CAX-3511 NEXT GEN. PP 1/4” INJECTION CHECK VALVE
CAX-3512 3X7 SANTOPRENE FEED TUBE-31.68GPD (STANDARD) 1
CAX-3513 CLEAR FRONT HAYWARD COVER LENS FOR THE PUMP
CAX-3514 SECONDARY CATCH BASIN
GLX-LFCAPY WHITE TANK CAP 100MM 1
GLX-LFTUBE PICK UP TUBE ASSEMBLY WITH FITTING, SEAL RING AND INLET FILTER 1
GLX-LFCOVER COVER, RAIN SHIELD 1
GLX-LFTANK 15 GALLON TANK WITH PUMP MOUNTING BRACKET
Tank Cap (White)
GLX-LFCAPY
Check Valve
CAX-3511
Feed Tube
CAX-3512 or
CAX-3508
Pick Up Tube
Assembly
GLX-LFTUBE
Pump - AC03590120

USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
3
Controller Interface
To protect the pool, the AquaRite Pro and the Pro Logic controller will automatically shut down and display a “Check System” message if the AQL-CHEM4-
CHLOR dispensing device runs continuously for more than the selected timeout value. This prevents a situation where the AquaRite Pro or the Pro Logic
controller is constantly feeding Liquid Chlorine because of a probe error or external problem with the pool. This allows the pool or spa owner to evaluate the
pool chemistry before continuing with pH control.
Winterization
1. Remove pump pick up tube from tank.
2. Insert pick up tube into 5 gallon bucket of water.
3. Run the pump to flush water and liquid Chlorine out of the feed lines and into the pool.
4. Use the 5 gallon bucket of water and allow the pump to feed until the bucket is empty. Continue to run the pump for a period of 10-15 minutes after the
bucket is empty. This will run the lines dry by forcing air through them.
5. Backwash the pickup tube and filter. (This cleans the filter)
6. Drain and reinstall pick up tube or secure to side of tank.
Liquid Chlorine can be stored outside or inside a secure and ventilated area/location for the winter. Typical Pool Liquid Chlorine at 12% concentration has a
freezing point of 27° F or 15° C. Typical Pool Liquid Chlorine at 12% concentration has a boiling point of 214° F or 101° C. If disposal of Liquid Chlorine is
required from the tank please contact your local environmental protection agency for instructions.
HAYWARD®Pool Products Limited Warranty
To original purchasers of this equipment, Hayward Pool Products, Inc. warrants its liquid chemical feed systems (excluding the Santoprene Feed
Tube) to be free from defects in materials and workmanship for a period of ONE (1) year from the date of purchase, when used in single family
residential applications.
The limited warranty excludes damage from freezing, negligence, improper installation, improper use or care or any Acts of God. Parts that fail or
become defective during the warranty period shall be repaired or replaced, at our option, within 90 days of the receipt of defective product, barring
unforeseen delays, without charge.
Proof of purchase is required for warranty service. In the event proof of purchase is not available, the manufacturing date of the product will be the
sole determination of the purchase date.
To obtain warranty service, please contact the place of purchase or the nearest Hayward Authorized Service Center. For assistance on your nearest
Hayward Authorized Service Center please visit us at www.hayward.com. Hayward shall not be responsible for cartage, removal, repair or installa-
tion labor or any other such costs incurred in obtaining warranty replacements or repair.
The Hayward Pool products warranty does not apply to components manufactured by others. For such products, the warranty established by the
respective manufacturer will apply.
The express limited warranty above constitutes the entire warranty of Hayward Pool Products with respect to its’ pool products and is in lieu of all
other warranties expressed or implied, including warranties of merchantability or fitness for a particular purpose. In no event shall Hayward Pool
products be responsible for any consequential, special or incidental damages of any nature.
Some states do not allow a limitation on how long an implied warranty lasts, or the exclusion of incidental or consequential damages, so the above
limitation may not apply to you. This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state.
Hayward Pool Products
400 Connell Drive, Suite 6100
Berkeley Heights, NJ 07922
*Supersedes all previous publications.

USE ONLY HAYWARD GENUINE REPLACEMENT PARTSUSE ONLY HAYWARD GENUINE REPLACEMENT PARTSUSE ONLY HAYWARD GENUINE REPLACEMENT PARTS
Hayward is a registered trademark and ProLogic and AquaLogic are registered
trademarks of Hayward Industries, Inc. © 2022 Hayward Industries, Inc.
All other trademarks not owned by Hayward are the property of their respective owners.
Hayward is not in any way affiliated with or endorsed by those third parties.
FOR FURTHER INFORMATION OR CONSUMER
TECHNICAL SUPPORT, VISIT OUR WEBSITE AT
www.hayward.com
