FROST 06.2010 User manual

FC Frost Limited
Bankside Works Benfield Way
Braintree Essex CM7 3YS
United Kingdom
T: [phone]
F: [phone]
E: [email protected]
W: www.fcfrost.com
Soap Dispenser
06.2010/06.2020
19098 FC Frost Ltd reserves the right to amend the design or dimensions without formal notice. © FC Frost Ltd 2009
06.2010 Standard fill (Shown)
06.2020 Top fill
Counter top thickness
Minimum 19mm
Maximum 80mm
Specification
Liquid soap dispenser. Model number 06.2010/06.2020* in polished chrome finish with bent spout, tapered
body and supplied with 500ml polypropylene bottle. Manufactured by FC Frost Ltd. *Delete one reference
Material
Body: Polished chrome plated brass
Spout and plunger: Polished chrome plated brass
Fixing stem: Black plastic with ½” bsp thread
Flanged back nut: White plastic
Soap bottle: 500ml capacity polypropylene bottle with dip tube (bottle supplied empty)
Operation
Press plunger head downwards to dispense liquid soap into palm of hand. Plunger and spout can rotate
360º. Each stroke delivers approximately 1ml of liquid soap per activation. Recommended for light to
medium use areas. For high traffic areas see model number 06.4010 for use with 5.0L multi-feed system.
Standard fill soap dispensers are filled by unscrewing the bottle mounted under the countertop.
Top fill soap dispensers are filled by loosening the screw located in the rear of the body and removing the
spout and plunger assembly.
Liquid Soap
We recommend using Frost ‘Pearlised’ liquid soap (Product code 06.8305). We do not recommend using
high viscosity liquid soaps or gels, which may impair function. Warning: Liquid soap with high sodium
chloride content can cause corrosion and may invalidate the product warranty.

FC Frost Limited
Bankside Works Benfield Way
Braintree Essex CM7 3YS
United Kingdom
T: [phone]
F: [phone]
E: [email protected]
W: www.fcfrost.com
Soap Dispenser
06.2010/06.2020
19098 FC Frost Ltd reserves the right to amend the design or dimensions without formal notice. © FC Frost Ltd 2009
Installation
See diagram opposite
Prepare a Ø23mm mounting hole through
worktop
Unscrew the soap bottle (6), adaptor cap (5)
and locking nut (3) from the soap dispenser
assembly (1) (Do not remove the dip tube (7))
Pass fixing stem (4) through mounting hole
ensuring washer (2) is on worktop surface
Under the worktop, re-fit the locking nut and
tighten
Re-fit the adaptor cap securely to the stem
Fill the soap bottle with a suitable liquid soap
and carefully screw the bottle into the adaptor
cap. The dip tube should reach the base of the
soap bottle
Prime the soap dispenser by pumping the
plunger head until liquid soap is dispensed from
the nozzle
For best results always use Frost ‘Pearlised’
liquid soap (part No. 06.8305)
Spares
Contact FC Frost for spares requirements: [e-mail]
Care and Maintenance
If the soap dispenser fails to function correctly, firstly check all connections are tight and free from air
leaks. If dispenser still fails to function, empty the liquid soap from the bottle and re-fill with warm water.
Pump the warm water through the dispenser to dislodge any dried soap residue and then re-fill the bottle
with fresh liquid soap.
Water marks and soap residue on polished chrome surfaces are best cleaned using warm water and a
mild detergent. Never use an abrasive cloth to remove stubborn stains. Dry with a soft clean cloth.
Warranty
This product is covered by a 12-month warranty from the date of purchase to be free from defects if
installed and maintained in accordance with these instructions. FC Frost will replace or repair (as
appropriate) free of charge any product with a proven manufacturing defect if reported within the warranty
period.
