HDL Buspro HDL-MWM70B.12 User manual

User Manual
BUS Enabled Motorized Curtain
HDL-MWM70B.12
HDL-MWM70S.12
www.hdlautomation.com
● Valid also for version 12.22
● Functions are the same for wireless version
MWM70-RF.12.
● Version MWM70S.12 does not exist anymore.
● Manual describes the snapshots taken in the
previous version of the module and using older
HBST program. In HBST2, the graphic
appearance is slightly different but the functions
remain the same

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual
Document updates:
Version
Date
Description
V1.0
2015.05.06
Finish new document

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual
INDEX
1. Overview....................................................................................................................................1
1.1 General Information.......................................................................................................... 1
1.1.1 Description.............................................................................................................. 1
1.1.2 Serial Numbers.......................................................................................................1
1.2 Function Qualities Description........................................................................................ 1
1.3 Device Description............................................................................................................ 2
2. Technical Data.......................................................................................................................... 2
3. Curtain Rail Installation........................................................................................................... 3
3.1 Characteristic..................................................................................................................... 3
3.2 Notice...................................................................................................................................4
3.3 Connecting..........................................................................................................................4
3.4 Curtain Rail Accessories.................................................................................................. 5
3.5 The dimensions of ceiling bracket.................................................................................. 6
3.6 Installation steps................................................................................................................ 6
3.7 HDL BUS Pro Description................................................................................................9
4. Curved Rail................................................................................................................................9
5. LED Indication........................................................................................................................ 10
6. Software Configuration......................................................................................................... 10
6.1 Workflow......................................................................................................................10
6.2 Modify address of motor........................................................................................... 10
6.3 Confirm motor running mode................................................................................... 11
6.4 Testing for Installation (very important).................................................................. 12
6.5 Set position of open and close................................................................................ 13
6.5.1 Position open setting...........................................................................................13
6.5.2 Position close setting.......................................................................................... 14
6.6 Set the curtain mode................................................................................................. 14
6.7 Set curtain’s action after power on......................................................................... 15
6.8 Panel Setting.............................................................................................................. 16
6.9 Easy programming mode......................................................................................... 17
7. FAQ.......................................................................................................................................... 17
8. NOTES.....................................................................................................................................19

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual 1
1. Overview
1.1 General Information
1.1.1 Description
HDL-MWM70B.12, HDL-MWM70S.12 the motorized curtain contains master and slave. It
is a professional curtain controller, the master is enabled by HDL Buspro. Support manual
mode, it has the function of over load protection and over heat protection.
1.1.2 Serial Numbers
1.2 Function Qualities Description
Test the distance of the curtain automatically
Manual mode: long drag, short drag, drag no action
Percentage control
Control by HDL Buspro
Support HDL Buspro online upgrading
Support easy programming
Built-in new generation clutch, precise planetary reduce, noise level 40dB.
Be suitable for all small to medium-scale curtain applications, linear and arched,
one-and two-side opening
MWM70B.12
Master
MWM70S.12
Slave

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual 2
1.3 Device Description
2. Technical Data
Electric Parameter :
Type
MWM70B.12
MWM70S.12
Rated voltage
AC220V 50Hz
Voltage range
AC220±20% 50Hz
Working voltage
DC24V (Master)
DC12V (Slave) from Master
Bus power consumption
40mA/DC24V (Master)
33mA/DC12V (Slave)
○
a
○
b
a. latch
b. Master: HDL Buspro interface
Slave: invalid
c. AC230V Power cable, 1 meter
(Brown for L, Blue for N, Y/G for PE)
d. RJ11 6P6C network port, connect to the
master and slave. It supplies the control
signal from Master to Slave
e. Motor terminal: pull the latch to unlock
direction, and then insert the motor terminal
into the Drive Unit. Finally, switch the latch
back to the locket position
f. unlock
g. latch
h. locked
○d
○
e
○f
Slave: MWM70S.12
Master: MWM70B.12
○g
○h
○c

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual 3
Slave interface
6P network port
Rated power
70W
Rated torque
1.0Nm
Rated speed
112rpm
Rail belt speed
16cm/s
Communication
HDL Buspro (Master)
Environmental Condition:
Working temperature
0℃~45℃
Working relative humidity
Up to 90%
Storage temperature
-20℃~+60℃
Storage relative humidity
Up to 93%
Approved
CE
RoHS
Production information:
Dimensions
284×70×50 (mm)
Weight
1554g (Master)
1543g (Slave)
Housing material
ABC, aluminum
Installation
Wall Hanging
Protection degree
IP41
Insulation degree
E
3. Curtain Rail Installation
3.1 Characteristic
AC power input, make the operation more stable and reliable

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual 4
Built-in a new generation of clutch, system operating noise no more than 40dB
The curtain’s horizontal pull reaches 8KG
Use HDL-BUS port as interface, DLP panel to control the curtain, easy to use
3.2 Notice
Read all instructions in detail before use
Non-Contact with the liquids or inflammable gas and object when using
Make sure there is no short-circuits or wiring errors before power on
Power off before install and uninstall
When install the motor to the drive unit, please check and make sure that the latch
has switched back to the locket position.
After the installation, please don’t pull the curtain forcibly, don’t put any additional
weight on the curtain rail; please don’t climb the curtain or hang anything on it;
otherwise the rail and the motor will fall down then lead to personal injury and product
damage
Pay attention to water-proof, steam-proof
Please use the dry cloth to wipe when cleaning, can’t use the damp or corrosive stuff
for wiping
Has any abnormal situation, please stop the operation and turn off the power, then
contact with the technical service or our company
3.3 Connecting
Please follow the connecting showed below strictly.
Rail
Drive Unit
Ceiling Bracket
Latch
Carrier
Drive Unit
Fixed Hole
Hook Unit
Roller Runner
Ceiling Bracket
RJ11 Cable
RJ11 Cable

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual 5
Master, Slave:
The Master is connected to the Buspro port and AC220V, and it provides DC12V to
the Slave by the RJ11 6P6C. HDL provides the 1 meter RJ11 cable.
Ceiling Bracket’s mounting distance:
On the top of rail, recommend every 600 mm installing a Ceiling Bracket.
3.4 Curtain Rail Accessories
Hook Unit Belt Roller Runner Fixture Rubber
Ceiling Bracket Insertion Clamp Carriers and its handles
Motor Motor Base Socket Master Slave
Drive Unit and Roller Runner Drive Unit and Hook Unit Motor Lock
RJ11 6P6C Track Joiner

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual 6
3.5 The dimensions of ceiling bracket
3.6 Installation steps
a) The length of the rail and the belt need to customize according to the size of the
window.
b) Turn to the reverse side of the rail, put the Track Joiner to the rail.
c) Turn to the forward side of the rail. Take the Belt, thread it into one of the rails (left
side), drag it to the Drive unit, then pull it out. At the end of the Belt, insert the Clamp1,
then plug the Fixture1.
d) Adjust the Belt’s position of the Fixture1 (as shown in figure), and insert the Clamp2
to the other side of the belt, next to the Fixture1.
e) Adjust the Belt’s position, insert the Clamp3 between the Fixture1 and the Clamp2,
next to the Clamp2.
Clamp1
Fixture1
固定卡 1
Clamp2
Fixture1
Fixture1
left part
left part
Track Joiner

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual 7
f) Adjust the Belt’s positions according to the figure, put the Carrier1 onto the Clamp2、
3, its handle should point to the Fixture1.
g) Thread the other side of the belt into the right path rail, drag it to the Drive unit, then
pull it out. At the same time, push the carrier1 into the rail.
h) At the end of the belt, insert the Clamp4, then plug the Fixture2.
i) Adjust the belt, make the Fixture1 and Fixture2 closer, and place the Rubber (the
Rubber can buffer the collision between two Handles of the Carrier)
j) Insert an Insertion between the Fixtue1 and Fixture2, and install the Handle onto the
Insertion.
Fixture1
Fixture2
Rubber
Fixture1
Fixturer2
carrier1
Fixture1
Clamp2
Clamp3
Fixed-Caliper1
Insertion
Carrier1
Carrier1
Insertion
Handle
Fixture2
Fixture1
Clamp2
Fixeture1
Clamp3
left part
left part
固定卡 1
固定卡 1
carrier1
carrier1
Fixture1
Fixture1
left part
right part
Fixture2
Carrier1
Clamp4
Carrier1
left part
left part
left part

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual 8
k) Face to the reverse side of the rail, adjust the position of the Track Joiner, make its
middle part located in the gap of two rails, then outward stretch the rails with hands
(Purpose: to let the belt running smoothly), meanwhile tighten the screws of the track
joiner.
l) Turn to reverse side of the rail, can install in more than one Ceiling Brackets
(Recommended every 600 meters using one Ceiling Bracket), install the Ceiling
Brackets on the wall, need to use other fixed devices, about the fixed devices, need
to turn to 3rd party.
m) Screw the motor into the Drive Unit, then clamp tightly and lock it ( Notice: the Master
motor should be installed to the side with the power supply; need to connect the
master and slave by the RJ11 6P6C, HDL provides the RJ11 cable is 1 meter. If this 1
meter of RJ11 cable is not suit for you project, you can make the other RJ11 cable,
about the Clamping Tool of RJ11, please see this:
http://www.alibaba.com/product-detail/Round-LAN-Wire-Stripper-6P6C-RJ11_60076
618303.html
n) Hang the Hook Unit on these two Drive Units( Notice: each Drive Unit has four holes,
the Hook Units make the curtain better to shield the window, as well as the motor,
make it look beautiful). Install the curtain rail on the wall, and hang the curtain to the
corresponding position. Finish the installation.
Unlocked
Locked
接驳条
Track Joiner
Track Joiner
left part
F
F

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual 9
3.7 HDL BUS Pro Description
Connector Information
buspro
DC24V
Red
COM
Black
DATA-
White
DATA+
Yellow
4. Curved Rail
HDL provides the curved rail. But has some limits.
θ<=90°and R>=300mm curtain rail is available.
Motor

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual 10
5. LED Indication
Function
LED status
enter into the status
exit the status
Working fine
LED turns ON 1 time
per 2s
--
--
Modify the
address of
motor
LED turns on
long press the button 3s
long press the button 3s
/ no operation 2minutes
Testing for
installation
LED turns OFF 1
time per 2s
long press the button 5s
long press the button 5s
/ no operation 20minutes
Easy
programming
LED Turns OFF 2
times per 2s
long press the button 10s
long press the button
10s / no operation
20minutes
Note: the above operations are carried out in normal work.
6. Software Configuration
6.1 Workflow
a) When power on, test the distance of the curtain by itself, then, short press PROG
button and control the curtain, make sure the curtain is working properly.
b) Change the address of curtain by HDL-BUS pro or HDL Easy Engineering Editor
software.
c) Confirm the motor’s running mode, forward or reverse.
d) Set the work mode: long drag, short drag, drag no action.
e) Set the reserved distance. (Don’t change after setting.)
f) Set the panel’s target and control the curtain.
Note: the Step c), d), e) are set by HDL Easy Engineering Editor software.
6.2 Modify address of motor
Long press the button 3s, the LED will turn ON, then you can modify the address by HDL
Easy Engineering Editor software. Press the button 3s again or has no action after 2min, it

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual 11
will exit the programming mode.
6.3 Confirm motor running mode
Motor running mode:Forward or Reverse
Confirm motor running mode by HDL Easy Engineering Editor software.
A. Input motor’s Subnet ID and Device ID
B. Download the information of Curtain, the default running mode is FWD.
C. Select OPEN,
D. Click Test, then to observe the Curtain’s open direction is correct or not.
There are two results:
a)If the curtain opens, that means the setting (Step B) is right, no need to change.
b)if the curtain closes, that means you have to set REV in Step B.
E. Save and upload the setting.
①
②
③The ID is display here and you can modify it.

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual 12
6.4 Testing for Installation (very important)
Long press the PROG button 5s, the LED will turn OFF 1 time per 2s, the curtain
enters the installation mode. It will measure movable distance for the rail
automatically; short press the button to manually open and close after the measuring
is done. (short press: open->stop->close->stop->open…)
Press the button 5s to exit the installation mode and enter the normal working mode,
it will also exit the installation mode after 20min without operating.
①
②
③
④
⑤

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual 13
Automatic detection (see Section 6.4) User setting (see Section 6.5)
6.5 Set position of open and close
6.5.1 Position open setting
a) Select Drag NO Action mode, then manually drag the curtain to the limit position of
curtain-open which is the end-user wants.
b) Select Open, then click OK, now the limit position of Open is saved, it is a new
different position from the detected limit position in Section 6.4.
①
②
③
Installation mode length
User run-time length

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual 14
6.5.2 Position close setting
a) Select “Drag NO Action” mode, Save and Upload, then manually drag the curtain
fabric to the limit position of curtain-close which is the end-user wants.
b) Select Close, then click OK, now the limit position of Close is saved, it is a new
different position from the detected limit position in Section 6.4.
6.6 Set the curtain mode
Select drag mode
Set the safe distance

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual 15
Manual mode:long drag,short drag,drag no action.
Long drag:Drag the certain fabric for certain distance (longer than the setting Length)
and let go, the curtain will fully open or close automatically according to the direction you
drag, the default Long drag Length is 20cm.
Short drag:Drag the certain fabric for certain distance, (the distance shall be more than
the protect Length and less than the short drag Length), the curtain will open or close
automatically according to the direction you drag, the default protect Length is 5cm,in
order to avoid misoperation or curtain flap, you can set the protect Length. The default
Short drag Length is 20cm.
Drag no action:free mode, end-user can manually drag the curtain to any position freely.
Note: long drag and short drag are depend on you habit. When pulley moving, the
length should longer than protect Length, and no more than half of total length.
6.7 Set curtain’s action after power on
Even there is power failure, you still can control the curtain manually, the curtain is not
locked mechanically.
Set the curtain’s action after power on: Auto close or no action.
Auto OFF when power on:If this option is checked, after power on, the curtain will close
automatically. If this option is unchecked, when power on, it will stay still, and wait for the
end-user’s command, say 40%, the curtain will fully close automatically(to initialize the
curtain position), and then it reaches the desired position, 40%.

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual 16
6.8 Panel Setting
The curtain can be controlled by 2 different kinds of commands.
1:The button’s setting as following. (HDL-BUS software)
Operation:
Long press the button, open or close the curtain, when loosen the button, it will stop
running (If the curtain reaches the fully open or close position, and you have not loosen
the button, it will stop automatically for protection.)
Short press the button, it will go to the desired position, 45%. Short press again, the
curtain will stop.
2:The button’s setting as following. (HBST software)

User Manual
HDL-MWM70B.12/MWM70S.12
Curtain Motors – User Manual 17
Operation: With only one button, you can control the curtain’s open, close and stop.
6.9 Easy programming mode
Long press the button 10s, the LED will turn OFF 2 times per 2s to indicate the curtain. It
has entered into easy programming mode.
Now, the panel appears “programming”, then keep pressing the page up, page down
button (button 9 and 10) of DLP switch together, the panel will appears “external
programming”.
In this mode, you can control the curtain by PROG button, and switch panel can record
the status from curtain motor by long press or short press buttons in panel. Long press the
panel’s button, it will cover the original targets and it is only controlling the curtain. Short
press the button, it will add the curtain control.
Long press the button of motor for 10s, it can exit this status. If it is no action, it will exit
automatically after 20min without operation.
This function is to be used with new generation of DLP, HDL-MPL8.48.
7. FAQ
7.1 CurtainFAQ001_Buspro
Q:
How does the Master Motor control the Slave Motor?
A:
The Master is connected to the HDL Buspro port and AC220V, and it provides DC12V to
the Slave motor by the RJ11 6p6c. When the Master is forwarding or reversing, will control
the Slave via the RJ11 line at the same time.
7.2 CurtainFAQ002_Buspro
Q:
Are all fixing accessories provided by HDL?
A:
No, HDL just provides the Ceiling Brackets (See section 3.4), you need to find other fixing
accessories from 3rd party providers.
This manual suits for next models
1
Table of contents
Popular Heater manuals by other brands

vienybe
vienybe VIENYBE-PK7.1 Technical certificate, instruction for installation and use

bewello
bewello BW2101 user manual

Siemens
Siemens 2ND3 004 Installation and operating instructions

DeLonghi
DeLonghi HSX4324E manual

Sanitas
Sanitas SHK 18 Instructions for use

Etherma
Etherma HOME-DUO 325 Assembly and operating instructions

Monogram
Monogram ZKMV installation instructions

Vermont Castings
Vermont Castings The Intrepid 1695CE Installation and operating manual

Goldair
Goldair GPPH500 operating instructions

Atlantic
Atlantic Compact 200 L ELECTRIC DIAGRAM

Kasanova
Kasanova KOE000020 instruction manual

TECO
TECO Seachill TR30 installation guide
