HealTech Electronics GIPRO X Instructions and recipes
GIPRO X-TYPE GEAR INDICATOR
Supplementary Manual
Husqvarna FS450 2015- (GPXT + GPX-WSS)
www.healtech-electronics.com 2/3
Mount the wheel speed sensor at the
rear wheel.
(Any rotating metal targets will work, but
the targets must be spaced at equal
distances. Adjust and tighten the sensor so
that the tip of the sensor will be in-line with
the center of the target. The air-gap should
be about 1mm.)
Connect GPX Black wire to the electric
starter button connector Brown wire.
Connect GPX Red wire to the FI warning
lamp connector Orange wire.
GIPRO X-TYPE GEAR INDICATOR
Supplementary Manual
Husqvarna FS450 2015- (GPXT + GPX-WSS)
www.healtech-electronics.com 3/3
Connect the GPX Black/Green wire to the
Yellow/White wire of the Crankshaft
Position Sensor connector.
(Blue, 2-pole connector below the seat on
the left side.)
Connect the 3-pole sensor connector to
the GPX wiring harness connector and
coil up the excess length.
Typical position for the Gear Indicator.
Secure the unit properly.
(Shown with the optional GIpro Mount, part
no.: GIPRO-M-BK.)
