Healthstream Emerald User manual

www.goldfitness.com.au.
0
EMERALD TREADMILL

www.goldfitness.com.au.
1
IMPORTANT SAFETY INSTRUCTIONS
Important-: Please read all instructions carefully before using your treadmill. Retain this
owner’s manual for your future reference:
WARNING:
1. Position the treadmill on a clear level surface. Do not place the treadmill on thick carpet as it may
interfere with proper ventilation. Do not place the treadmill near water or outdoors.
2. Position treadmill so that the wall plug is visible and accessible.
3. Never start the treadmill while you are standing on the walking belt. After turning the power on and
adjusting the speed control, there will be a 3 second pause before the walking belt begins to move,
always stand on the foot rails on the sides of the frame until the belt is moving.
4. Wear appropriate clothing when exercising on the treadmill. Do not wear long, loose fitting clothing
that may be caught in the treadmill. Always wear running or aerobic shoes with rubber soles.
5. Always unplug the power cord before removing the treadmill motor cover.
6. Keep small children away from the treadmill during operation.
7. Always hold the handrails when initially walking or running on the treadmill until you are comfortable.
8. Always attach the safety cord to your clothing when using the treadmill. If the treadmill should
suddenly increase in speed due to an electronics failure or the speed being inadvertently increased, the
treadmill will come to a sudden stop when the safety cord is disengaged from the console.
9. When the treadmill is not being used the safety cord should be unplugged and removed.
10. Before starting any exercise program, consult with your physician or health professional. He or she
can help establish the exercise frequency, intensity (target heart zone) and time appropriate for your
particular age and condition. If you have any pain or tightness in your chest, an irregular heartbeat,
shortness of breath, feel faint or have any discomfort while you exercise, STOP! Consult your physician
before continuing.

www.goldfitness.com.au.
2
TOOLS:
5# ALLEN WRENCH 5mm 1pcs、
WRENCH W/SCREW DRIVERS=13、14、15 1pcs
Note: Do not plug into the mains power before completing the assembly
ASSEMBLY STEP 1：
ASSEMBLY STEP 2:
ASSEMBLY STEP 3:
Lift up the computer section and upright
posts as arrow direction.
Notice: When you insert the pole
sections ensure that the wires do not
get caught and become damaged.
Slide left upright (3) onto MAIN FRAME
(1)
To attach the upright posts (3) to the
frame use bolt (41) and lock washer (60)
using the 5# Allen wrench
Note: Support the Left upright with your
hand to avoid injury.
Open the carton and remove all foam and
cardboard packaging. Place the treadmill on
the ground as per diagram.

www.goldfitness.com.au.
3
ASSEMBLY STEP 4:
ASSEMBLY STEP 5:
ASSEMBLY STEP 6:
Slide right upright (4) onto MAIN
FRAME (1)
To attach the upright posts (4) to the
frame use bolt (41) and lock washer (60)
using the 5# Allen wrench
Note: Support the right upright with your
hand to avoid injury.
ATTENTION: complete the assembly as pictured above and tighten all bolts.
Before you use the treadmill read the instructions carefully.
Take bolt (41) and Lock washer (60) and
insert them into R&L upright (3,4). Using
the 5# Allen wrench
Then lock the COMPUTER (64)
Insert the UPRIGHT COVER (22) onto
the L&R handle bar (5)

www.goldfitness.com.au.
4
FOLDING INSTRUCTION
Pulling up:
Pulling down:
Hold Support place A with hand, then
pull up based on the arrow direction,
until the hydraulic bar (10) slide into the
tube
Hold support place A, use your feet
firmly at place B to release the hydraulic
mechanism

www.goldfitness.com.au.
5
TECHNICAL PARAMETER
BUILT UP SIZE (mm) 1600*730*1370 INCLINE LEVELS 12%
FOLDABLE SIZE (mm) 700*730*1530 SPEED RANGE 1.0-16KM/h
RUNNING BOARD
SIZE (mm)
1255*420
NET WEIGHT 55KG
MAX WEIGHT 120KG
3 LCD DISPLAY SPEED TIME DISTANCE CALORIES PULSE INCLINE

www.goldfitness.com.au.
6
OPERATION GUIDE
WINDOW DISPLAY:
1、“INCL/PULSE”window: This will display the user’s incline level and user’s pulse; the incline range is
from 0 to 12%. The default setting will start at 0%. When the user places both hands over the palm
pulse, it can track and display the user’s pulse after 5 seconds, the LED will indicate the pulse
function. The pulse range will be from 40-200 b/pm.
2. “TIME/ DIST/CAL”,”TIME’’ window will alternate every five seconds; this is indicated via the LED. The
time is measured in minutes and seconds. During a Pre Set program the window will show a count
down phase, in the default manual setting the time will count on. “DIST’” window is measured in
kilometers. The default setting will start at 1km/h. ‘’CAL’’, in the default manual setting and also during
the Pre Set programs you will have a calorie count available. This will automatically count upward for
the duration of use.
3、“SPEED” window: Display speed, show range: 1.0-16 KM/h.
BUTTON FUNCTION:
1、“PROGRAM” Button：When the treadmill is not running, press the SELECT button and choose the

www.goldfitness.com.au.
7
exercise time and program from “0：00”、“ P1-P2-P3-P4-P5-P6-P7-P8-P9-P10-P10-P12 -FAT”. Manual
mode is the default program, the default speed in kilometer is 1KM/H. (0:00 is manual mode,pre-set
program :P1-P12 ).
2、“MODE” Button：Press this button to choose circle modes: “0：00” “15：00”、“1.0”、“50” (“0：00” is
manual model, “15：00” is the time count down, “1.0” is distance count down and “50” calorie count
down); when you choose every mode, you can press the speed button and incline button to set count,
after that, press the START button to start this treadmill.
3、“START”button：Be sure you have the safety key attached to magnetic connection before commencing
a manual/pre set program.
4、“STOP” button: This can be pressed during any program or alternatively pull safety key from unit.
5、“SPEED+”、“SPEED-” Button：This will adjust your speed during any program setting in 0.1km/h
intervals.
6、“INC+”、“INC-” Button：This will adjust your speed during any program setting in 1-section intervals.
7、“SPEED：”Walk, Jog, Run” speed shift button：set speed quickly
8、“INCLINE：”Low, Mid, High ” incline shift button：Set incline quickly
START-UP QUICKLY (MANUAL)
1、Switch the unit on, and attach the safety cord on magnetic connection.
2、Press START button，the system will enter into 3 seconds count down, the unit will beep and the
speed window display count down, the speed will run 1.0km/hour after 3 seconds.
3、After start-up, the speed function can be adjusted manually via the arrows.
MANUAL MODE:
1. If you do not make any setting and press START button directly, the treadmill will start to run from the
speed 1.0km/h, the other windows will start to count from positive direction from windows default,
press “INCLINE+”,”INCLINE-”, “SPEED+”, “SPEED-” change the speed.
2. Set up the Time, press “MODE” button to enter into time count down, the TIME window will
display“15：00” and glittering. Press “INCLINE+”,”INCLINE-”, “SPEED+”, and “SPEED-” to set up the
time what you need. The setting range is 5:00-99:00.
3. In Time setting model, press “ MODE “ button to enter into distance count down, the DISTANCE
window will display “1.0” and illuminates. Press “INCLINE+”,”INCLINE-”, “SPEED+”, and “SPEED-” to
set up the distance what you need. The setting range is 0.5—99.9.
4、To set up the Calories, press “MODE” button to enter into calories count down, the CAL window will
display “50’ and glittering. Press “INCLINE+”,”INCLINE-”, “SPEED+”, and “SPEED-” to set up the
calories what you need. The setting range is 10-999.

www.goldfitness.com.au.
8
5、When setting is finished, press “START” button to start up, the treadmill will run after 3 seconds, press
“INCLINE+”,”INCLINE-”, “SPEED+”, “SPEED-” to adjust the speed and the incline; press the PAUSE,
the treadmill will stop.
PRE SET PROGRAMS
Press “PROGRAM ”button“ SPEED”window will display P1-P12 to choose the program you like. Setting
of running time, then the SPEED window display illuminating. Display the advance setting time10:00,
press “INCLINE+”,”INCLINE-”, “SPEED+”, “SPEED-” to set up the exercise time what you need. Press
“START” button to start the inner install program, the inner install program is divided into 10 sects. Each
exercise time=the setting time/10. When the system enters into the next section it will beep 3 times and
the speed will be changed according to the setting program, then press “INCLINE+”,”INCLINE-”,
“SPEED+”, “SPEED-” to change the INCLINE and SPEED, When the program selection is made it will
come back to the current speed, and run the one program, the system will beep three times and change
to the manual program automatically.
Program exercise chart
Each program will divide into 10 grades for the exercise time and each time sect has the speed and
inclines accordingly.
TIME MODE TIME INTERVAL
1 2 3 4 5 6 7 8 9 10
P1 SPEED 2 4 3 4 3 5 4 2 5 3
INCLINE 1 2 3 3 1 2 2 3 2 2
P2 SPEED 2 5 4 6 4 6 4 2 4 2
INCLINE 1 2 3 3 2 2 3 4 2 2
P3 SPEED 2 5 4 5 4 5 4 2 3 2
INCLINE 1 2 2 3 1 2 2 2 2 1
P4 SPEED 3 6 7 5 8 5 9 6 4 3
INCLINE 2 2 3 3 2 2 4 6 2 2
P5 SPEED 3 6 7 5 8 6 7 6 4 3
INCLINE 1 2 4 3 2 2 4 5 2 1
P6 SPEED 2 8 6 4 5 9 7 5 4 3
INCLINE 2 2 6 2 3 4 2 2 2 1
P7 SPEED 2 6 7 4 4 7 4 2 4 2
INCLINE 4 5 6 6 9 9 10 12 6 3

www.goldfitness.com.au.
9
P8 SPEED 2 4 6 8 7 8 6 2 3 2
INCLINE 3 5 4 4 3 4 4 3 3 2
P9 SPEED 2 4 5 5 6 5 6 3 3 2
INCLINE 3 5 3 4 2 3 4 2 3 2
P10 SPEED 2 3 5 3 3 5 3 6 3 3
INCLINE 4 4 3 6 7 8 8 6 3 3
P11 SPEED 2 6 7 4 4 7 4 2 4 2
INCLINE 4 5 6 6 9 9 10 12 6 3
P12 SPEED 2 5 5 4 4 6 4 2 3 4
INCLINE 3 5 6 7 12 9 11 11 6 3
RANGE OF PROGAMS
PROGRAM BEGIN SET UP
RANGE
DISPLAY
RANGE
TIME (MIN:
SECOND) 0:00 15:00 5:00-99:00
0:00－99:59
INCLINE (%) 0 0 0-12 0-12
SPEED (K/h) 1.0 1.0 1.0-16 1.0-16
DISTANCE (K) 0 1.0 0.5-99.9 0.00－99.9
PULSE (hypo/min) P N/A N/A 40-200
CALORIE (THERM) 0 50 10-999 0－999
BODY FAT PROGRAM:
To begin, press “ PROGRAM” until you reach the ‘’FAT’’ setting, press “ MODE “ enter F-1、F-2、F-3、
F-4、F-5 ( F-1 SEX, F-2 AGE, F-3 HEIGHT, F-4 WEIGHT, F-5 BODY FAT TESTER ),

www.goldfitness.com.au.
10
Press “SPEED+”、“SPEED -” to set F-1 – F4 ( refer to the following chart), after that, press “ MODE” to
set F-5, grasp the palm pulse, the window will then display your body fat index (BMI) after 3 seconds.
The body fat index is testing the relationship between height and weight. The body FAT test is suited to
males and females. The ideal (BMI) should be 20-25, if under 19, it would mean you may be too thin. If
you are between 25 and 29, it could mean you are overweight, if over 30, it is indicating obesity. (The
data is just for reference, and cannot be as medicinal data)
F-1 Seg 01 male 02 female
F-2 Age 10------99
F-3 Height 100----200
F-4 Weight 20-----150
F-5
FAT ≤19 Underweight
FAT =(20---25) Normal weight
FAT =(25---29) Overweight
FAT ≥30 Obesity
SAFETY FUNCTION:
In any state, pull out the safety key can be an emergency stop running treadmill, it will urgently stop
when all the windows show buzzer sounded "---", "BB" of the alarm sound 3; the treadmill can’t carry out
any operation except it is to be turned off, the safety lock on re-loaded correctly, the treadmill to re-enter
the standby mode, waiting for input.
POWER SAVE FUNCTION:
Without any operation for ten minutes the unit will begin to hibernate, and the display will dim. Press
any button to wake ups the display.
CAUTION:
1. We recommend that you maintain a slow speed at the beginning of a session and hold on to the
handrails until you become comfortable and familiar with the treadmill.
2. Attach the magnet end of the safety pulling rope to the computer and also attach the clip of the safety
pulling rope to your clothing.
3. To end your workout safely, press the PAUSE button or pull out the safety cord, then the treadmill will
stop immediately.

www.goldfitness.com.au.
11
EXERCISE INSTRUCTIONS
1. The Warm Up Phase
This stage helps get the blood flowing around the body and the muscles working properly. It will also
reduce the risk of cramp and muscle injury. It is advisable to do a few stretching exercises as shown
below. Each stretch should be held for approximately 30 seconds, do not force or jerk your muscles into
a stretch - if it hurts, STOP.
2. The Exercise Phase
This is the stage where you put the effort in. After regular use, the muscles in your legs will become
Stronger. Work to your but it is very important to maintain a steady tempo throughout. The rate of work
should be sufficient to raise your heartbeat into the target zone shown on the graph below.
This stage should last for a minimum of 12 minutes though most people start at about 15-20 minutes
3. The Cool Down Phase
This stage is to let your Cardio-vascular System and muscles wind down. This is a repeat of the warm up
exercise e.g. reduce your tempo, continue for approximately 5 minutes. The stretching exercises should
now be repeated, again remembering not to force or jerk your muscles into the stretch.
As you get fitter you may need to train longer and harder. It is advisable to train at least three times a
week, and if possible space your workouts evenly throughout the week.
To tone muscle while on your Treadmill you will need to have the resistance set quite high. This will put
more strain on our leg muscles and may mean you cannot train for as long as you would like. If you are
also trying to improve your fitness you need to alter your training program. You should train as normal
during the warm up and cool down phases, but towards the end of the exercise phase you should
increase resistance, making your legs work harder than normal. You may have to reduce your speed to
keep your heart rate in the target zone.
The important factor here is the amount of effort you put in. The harder and longer you work the more

www.goldfitness.com.au.
12
calories you will burn. Effectively this is the same as if you were training to improve your fitness, the
difference is the goal.
MAINTENANCE INSTRUCTIONS
WALKING BELT CENTERING AND TENSION ADJUSTMENT
DO NOT OVERTIGHTEN the walking belt. This may cause reduced motor performance and excessive
roller wears.
TO CENTER WALKING BELT:
●Place treadmill on a level surface
●Run treadmill at approximately 5KPH
●If the belt has drifted to the right, turn the right adjusting bolt 1/2 turn clockwise and the left adjusting
bolt 1/2 turn counterclockwise See pic A
●If the belt has drifted to the left, turn the left adjusting bolt 1/2 turn clockwise and the right adjusting bolt
1/2 turn clockwise and the right adjusting bolt 1/2 turn counterclockwise See pic B
Picture A If the belt has drifted to the LEFT PictureBif the belt has drifted to the RIGHT
WARNING: ALWAYS UNPLUG THE TREADMILL FROM THE ELECTRICAL OUTLET BEFORE
CLEANING OR SERVICING THE UNIT CLEANING
General cleaning or the unit will greatly prolong the treadmill. Keep treadmill clean by dusting regularly.
Be sure to clean the exposed part of the deck on either side of the walking belt and also the side rails.
This reduces the build up of foreign material underneath the walking belt.
The top of the belt may be cleaned with a wet, soapy cloth. Be careful to keep liquid away from inside the
motorized treadmill frame or from underneath the belt.
Warning：Always unplug the treadmill from the electrical outlet before removing the motor cover.
At least once a year remove the motor cover and vacuum under the motor cover. Be careful not to
interfere with any of the wires or circuits.
PIC A PIC B

www.goldfitness.com.au.
13
WALKING BELT AND DECK LUBRICATION
This treadmill is equipped with a pre-lubricated, low maintenance deck system. The belt/ deck
friction may play a major role in the function and life of your treadmill, thus requiring periodic
lubrication. We recommend a periodic inspection of the deck.
We recommend lubrication of the deck according to the following timetable:
Light use (less than 3 hours/ week) annually
Medium use (3-5 hours/ week) every six months
Heavy use (more than 5 hours/ week) every three months
NOTE: APPLY HEALTHSTREAM TREADMILL LUBRICANT AS INSTRUCTED ABOVE.
EXPLODED DRAWING

www.goldfitness.com.au.
14
PARTS L I ST
#. DESCRIPTION REMARK QTY #. DESCRIPTION REMARK QTY
1 MAIN FRAME 1 36 INNER END CAP 2
2 BASE FRAME 1 37 FOAM 2
3 LEFT UPRIGHT 1 38 LOCK NUT M10 2
4 RIGHT UPRIGHT 1 39 LOCK NUT M6 8
5 COMPUTER BRACKET 1 40 LOCK NUT M8 6
6 MOTOR BRACKET 1 41 BOLT M8*16 10
7 BASE FRAME TURN
AXES 2 42 BOLT M8*25 L15 3
8 FRONT ROLLER 1 43 BOLT M4*12 4
9 REAR ROLLER 1 44 BOLT M8*40 length
of thread 20 9
10 CYLINDER 1 45
FLAT WASHER 10 2
11 WRENCH W/SCREW
DRIVER
S=13、14、15 1 46
BILT M10*45 2
12 5#ALLEN WRENCH 5mm 1 47
SAFETY MAT M6*55 1
13 INCLINE FRAME 1 48 BOLT M6*55 2

www.goldfitness.com.au.
15
14 PULSE UPPER WIRE 2 49 BOLT M8*35 5
15 COMPUTER
UPPER WIRE 1 50 BOLT M8*45 1
16 MOTOR TOP COVER 1 51 BOLT M6*35 8
17 BOTTOM BOARD 1 52 BOLT M3*8 2
18 COMPUTER TOP
COVER 1 53 BOLT M5*8 7
19 COMPUTER BOTTOM
COVER 1 54 BOLT M6*16 4
20 COMPUTER PANEL 1 55 SCREW ST2.9*6.5 19
21 BOTTLE BRACKET 2 56 SCREW ST4.2*12 33
22 UPRIGHT COVER 2 57 BOLT M4*16 4
23 LEFT BACK COVER 1 58 SCREW ST4.0*20 2
24 RIGHT BACK COVER 1 59 LOCK WASHER 6 3
25 SIDE RAIL 2 60
LOCK WASHER 8 14
26 RUNNING BELT 1 61
LOCK WASHER 10 2
27 BELT 1 62 SPRING WASHER 8 6
28 BLUE CUSHION PAD 4 63 FLAT WASHER 8 6
29 BLACK CUSHION PAD 4 64 COMPUTER 1
30 TRANSPORT WHEEL 2 65 LOWER CONTROL
BOARD 1
31 FOOT PAD 6 66 PULSE WITH SWITCH 1
32 ADJUSTIVE IDLER
WHEEL 2 67 PULSE WITH SPEED 1
33 RING PROTECTING
WIRE PLUG 2 68 MAGNETIC SENSOR 1
34 POWER WIRE BUCKLE 1 69 COMPUTER UP WIRE 1
35 SAFETY KEY SPRING
BALL 1 70
COMPUTER MIDDLE
WIRE 1
71 COMPUTER BOTTOM
WIRE 1 84 AC SINGLE LINE 1
72 PULE WITH SWITCH
UP WIRE 1 85 AC SINGLE LINE 1
73 PULSE SPEED UP
WIRE 1 86 AC SINGLE LINE 1
74 LABLE 2 87
MOTOR BOTTOM
COVER 1
75 SAFETY KEY 1 88 INCLINE MOTOR 1
76 TRANSFORMER 1 89
WHEEL PROTECT
COVER 2
77 POWER WIRE 1 90 SWITCH BOARD 1
78 SWITCH 1 91
SAFETY KEY IRON
SLIP 1
79 OVERLOAD
PROTECTER 1 92 SCREW ST2.9*8 2

www.goldfitness.com.au.
16
80 DC MOTOR 1 93 BOLT M10*25 2
81 RUNNING BOARD 1 94 BOLT M10*45
thread L15 1
82 MAGNETIC CORE 1
95 BOLT M10*55
thread L15 1
83 MAGNETIC RING 1
96 Speaker board （Optional）
2
97 SPEAKER （OPTIONAL）
2
98 AUDIO BOARD （OPTIONAL）
1
99 BOLT
ST4.2*12
（OPTIONAL）
4
100 BOLT
ST2.9*6.5
（OPTIONAL）
4
101 MP3 connector wire （optional）1
102 Filter
1
103 BOLT
M4*8
（optional）4
TROUBLESHOOTING GUIDE
1、Probable reason for the computer not working: The wire from computer to bottom control board is
not correctly connected. Check the each wire from computer to control board, make sure they are
connected well. If the wire is destroyed, change it. If the above cannot fix the problem call our
service center on 1300 796 636.
2、E01: Message failure. Probable reason: The wires from computer and bottom control board are not

www.goldfitness.com.au.
17
connected well, please check each wire.
3.”E02” ：You may not have enough voltage going to the machine. Turn the machine off and on
again at the switch at the rear of the treadmill. If this does not fix the problem you may have
damaged the lower circuit board. Contact our service centre on 1300 796 636
4、“E03’: No sensor signal. Sensor wire is faulty, replace the sensor wire. Magnetic sensor wire is
not working change the magnetic wire or reset the magnet.
5、“E04”: Incline motor wrong, check if the VR of the incline motor connects well or replug it. The
mark of the DC motor and control board should be matched connected. Sometimes you also
need to check the wires of the motor and restart the whole treadmill again.
6、“E05”: Current overload protecting. Power surge or the motor is seized which will cause
excessive current. At this time the treadmill will start its self-protecting system. Adjust the
machine and restart; Check if the motor is noisy or if the motor / bottom control board is burnt
out, if burnt out, change the motor and/or bottom control.
7、If the motor does not work after pressing the START button, the probable reason: the motor wire
is broken; the safety pipe is broken or disconnected; the motor wire is not connected well; the
IGBT on bottom control board is burnt out. Test the above reasons and change the relevant part.
If this does not fix the problem call our service number 1300 796 636.
