Heart of House maldon User manual

Assembly Instructions - Please keep for future reference 379/1921
maldon 4ft6 bed frame
Issue 2 - 15/08/15
Width - 142.6cm
Depth - 216cm
Height - 102cm
Important - Please read these instructions fully before starting assembly
Dimensions
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 640 0800

1
Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
Important - Please read these instructions fully before starting assembly
Care and maintenance
This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
From time to time check that
there are no loose screws on
this unit.
Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
!Safety and Care Advice
Handy Hints
Regularly check and ensure
that all bolts and fittings are
tightend properly.
Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the bolts.
Check you have all the
components and tools listed on
the following pages.
Remove all fittings from the
plastic bags and separate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
During assembly do not stand
or put weight on the product,
this could cause damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
To reduce
the likelihood of
damaging your
product please
ensure that your
power drill is set on a low torque
setting.
Improper use of electrical tools
will crack the components.
Dispose of all packaging
carefully and responsibly.

2
Please check you have all the panels listed below
Components - Panels
Components - Key Diagram
1
2
3
3
5
4
4
If you have damaged or missing components, call the
Customer Helpline: Argos = 0345 640 0800
7
Slat (183.1 x 136.5cm)
Headboard (142.6 x 102cm)
1Footboard (142.6 x 71cm)
2
Side x 2
(190 x 14cm)
3Center rail (191.8 x 5.5cm)
5
Support x 2
(12 x 5.5cm)
4
Center leg x 2
(20.7 x 5cm) 7
6
6
6

Note: The quantities below are correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
Please check you have all the fittings listed below
Components - Fittings
30mm Dowel x 4 30mm Screw x 10
AB
Tools required
3
170
160
150
140
130
120
110
100
9080
70
60
50
40
30
20
10
0
5 15 25 35 45 55 65 75 85 95 105 115 125 135 145 155 165
Ruler - Use this ruler to help correctly identify the screws
The screws length is measured from the head to the point (30mm screw shown).
The bolts length is measured from inside of the head to the
point (60mm bolt shown).
Philips screwdriver
(medium & large)
Ruler/tape
measure
0
10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
Small
hammer
C
70mm Screw x 4
D
Allen key x 1

4
Assembly Instructions
Step 1
Step 2
Attach the supports
to the headboard and
the footboard.
Insert the dowels A into
the holes indicated on the
headboard 1 and the
footboard 2 .
Attach the supports 4 to
the headboard 1 and
the footboard 2 using
the screws B .
B
Side
3
Side
Headboard
1
Footboard
2
3
A
4
1
Headboard
1
Footboard
2
Support
4
A
A
AA
BBB
B
BB
Attach the sides to
the headboard and
the footboard.
Fit the sides 3 into the
holes indicated on the
headboard 1 and
the footboard 2 .
Make sure the hooks are
connected to the bracket
by pressing the sides
firmly.
3
3

5
Assembly Instructions
Step 3
Step 4
5
4
5
4
B
B
B
5
Center rail
Support
4
Attach the center rail to
the supports.
Attach the center rail 5
to the supports 4 using
the screws B . B
C
D
C
CC
Center leg
6Center leg
6
Center rail
5
Mounting the center legs
onto the center rail.
Attach the center legs 6
onto the center rail 5 .
Fix the center legs using
screws C and allen key
D through the holes
indicated.

6
Assembly Instructions
Step 5
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 640 0800
Inserting the slat to
the sides and the center
rail.
Insert the slat 7 into
the holes indicated on
the sides 3 and the
center rail 5 .
Assembly is complete.
7
7
7
3
5
3
Side
3
Slat
7

Please note that the product you have purchased is a
natural living timber.
Just like nature itself, wood varies in shape and colour.
Knots, vein patterns, resin pockets and colour differences
contribute to giving the piece of furniture its beauty and
form - a natural part of solid wood.
Although the tree has been cut down and dried, it is still
alive and therefore will react to high and low
temperatures, light, humidity, drought and time.
In cold and dry periods, the wood contracts which may
lead to small cracks in the piece of furniture. The reverse
happens in warm and humid periods where the wood
expands and this may result in slight unevenness.
The colour of the wood also changes with time,
particularly if the furniture is place in a light place. This
is a natural process and part of owning a piece of
furniture made of solid wood.
Any flexing that has occurred during transport will
re-correct it self once this product is correctly assembled.
Tighten all joints of the furniture after six months.
Please keep these instructions in a safe place for future
use.
