10
TRANSMITTER SAFETY FEATURES
Itisrecommended that theTRANSMITTERS always be lo-
catedwithina 20 footoperating range of thefireplace, pref-
erably in the same room in which the fireplace system is
located.TheTRANSMITTERfeaturesseveralsafetyfeatures
that alert the user when the TRANSMITTER is placed out-
sidethe20 foot normaloperating range.
Thermo-Safety and Communication-Safety Features
This remote control has both a THERMO-SAFETY and
COMMUNICATION-SAFETYfunctionbuiltintoitssoftware.
Itprovides an extra margin of safety whentheTRANSMIT-
TER is out of the normal 20 foot operating range of the re-
ceiver. It is also activated when the batteries becomeweak
orareremovedfromthetransmitter.
Inthe THERMO-SAFETY feature (onlyin the THERMOor
TIMER modes) the transmitter normally reads the ROOM
temperature every 2 minutes. In addition to checking the
temperature, the transmitter sends a signal to the receiver
indicating that the transmitter and its batteries are still ac-
tive.
IntheCOMMUNICATION-SAFETYfeature, at all times and
in all OPERATING MODES the transmitter sends a signal
everyfifteen(15)minutesto the receiver,indicating that the
transmitteris within thenormal operating range of 20feet.
Should the receiver NOT receive a transmitter signal every 2
minutes(THERMO-SAFETYfeature)or15minutes(COMMU-
NICATION-SAFETY feature), the RECEIVER will begin a 2
HOUR(120minute)countdowntimingfunction.Ifduringthis2
hour period, the receiver does not receive a signal from the
transmitter,theRECEIVERwillshutdownthefireplacebeing
controlledbythereceiver.TheRECEIVERwillthenemitase-
ries of rapid “beeps”. Then, after 10 rapid “beeps”, the RE-
CEIVERwillcontinueto emitasingle“beep”every4seconds
until a transmitter signal is again received. The intermittent 4
secondbeeping willgoonindefinitely until reset.
To“reset”theRECEIVERandoperatethefireplacesystem:
1. Press the MODE button on the transmitter. The word
ON must display on the LCD screen. The THERMO-
SAFETYand COMMUNICATION -SAFETYoperationis
overriddenand the systemwillreturntonormaloperation
depending on the MODE selected at the transmitter.
WerecommendtheusercheckthebatteriesintheTRANS-
MITTER to make sure the voltage is no less than 2.7 volts.
Auto Shutdown
Thisremote control has anAuto Shutdown feature incorpo-
rated into its system. When the transmitter MODE is in the
ONpositionthefireplacewillcontinuouslyoperatefor9hours.
After 9 hours, the fireplace will shut down. To relight the
fireplace:
1. Press the MODE button.
The transmitter must be positioned within a 20 foot operat-
ingrangefor theAutoShutdownfeaturetooperate.
Child Proof Lockout (CP)
Thetransmittercontainsa “Child Proof” lockout feature that
preventsunauthorizeduseoftheremotecontrol.To access
the“ChildProof”activationbutton,removecoveronBACKof
transmitter.ToactivateLOCKOUT:
1. Press and hold in the “setting button” for 5 seconds.
Theletters CP will display onthe LCDscreen (see Fig-
ure13). This preventsthe activation offireplace. When
any function button is pressed ON/OFF etc. the letter
CP will display on the LCD screen.
TodeactivateLOCKOUT:
1. Press and hold in the “setting button” for 5 seconds.
TheLCD will display CP until 5 seconds have elapsed,
andthen the LCD screen will return to its normal state.
SYSTEM CHECK
Millivolt Valves
Light the appliance following the lighting instructions that
camewith the fireplace.Confirm that thepilot flame ison. It
mustbe in operationfor the maingas valve tooperate.
1. Slidethe3-position button on the remote receiver tothe
ON position. The main gas flame (i.e., the fire) should
ignite.
2. SlidethebuttontoOFF.The flame should extinguish (the
pilotflame will remainon).
3. Slide the button to REMOTE (the center position), then
presstheMODE button onthetransmitter to changethe
system to ON. The main gas flame should ignite.
4. PresstheMODEbuttonon the transmitter tochangethe
system to OFF. The flame should extinguish (the pilot
flamewillremain on).
5. PresstheMODEbuttonon the transmitter to changethe
system to THERMO.
6. Advance the SET temperature on the transmitter to a
temperature of at least 20F(10 C)abovetheROOMtem-
perature displayed on the LCD screen and the system
flamewill ignite.
7. SettheSET temperature toat least 20 F(10 C)belowthe
room temperature and the system flame will extinguish.
Thereafter, it should continuetocycleon and off thermo-
staticallyapproximatelyeverytwominutesastheROOM
temperaturechanges,but only when the temperature dif-
ferential between ROOM and SET temperatures differs
atleast 20 F (10 C).The 20 Fdifferential isthe factory set-
ting.
Electronic Ignition System
1. Slidethe3-position button on the remote receiver tothe
ONposition. The sparkelectrode should begin sparking
toignitethepilot(thepilotmayigniteafteronlyonespark).
Afterthepilotflameis lit, the main gas valveshouldopen
and the main gas flame should ignite.
2. Slide the button to OFF. The main gas flame and pilot
flameshouldBOTH extinguish.
3. Slide the button to REMOTE (the center position).
