PH-LINEAR
Models: COSMO-IFT-B Series, RAVE-IFT-B Series, JADE-B, DVLINEAR36, B41IL-AU Series
Passive Heat Kit Installation Instructions
Leave this manual with party responsible for use
and operation.
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during instal-
lation. Sheet metal edges are sharp.
DANGER
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and must be installed for
the protection of children and other at-risk
individuals.
CAUTION! Do not install damaged components.
If any parts are missing or damaged, contact your dealer before
starting installation. DO NOT install a damaged kit.
Introduction
The Passive Heat (PH-LINEAR) Heat Management Sys-
tem conveys warm air from the replace into the same room
through either one front discharge slot, two side discharge
heat registers or an open top discharge.
Installation of the Passive Heat kit must be done in con-
junction with the appliance installation. Installation of this
kit MUST be performed by a qualied service technician.
WARNING! Risk of Fire! DO NOT install the Passive
Heat (PH-LINEAR) Heat Management System with mod-
els that are not approved. Overheating will occur.
The Passive Heat Trim Kit is also available for installation
with the Front Discharge Passive Heat systems and must
be purchased separately. Contact your dealer to order
the appropriate kit: PH-FRTTRIM-32, PH-FRTTRIM-36
or PH-FRTTRIM-48.
The Passive Heat Trim kit is required with the side dis-
charge Passive Heat system and must be purchased sepa-
rately. Contact your dealer to order the PH-SIDETRIM kit.
Follow instructions included with the trim kit to complete
installation of the Passive Heat system.
The Passive Heat kit is tested and safe when installed in
accordance with this installation manual. It is your respon-
sibility to read all instructions before starting installation
and to follow these instructions carefully during installation.
The Passive Heat kit is carefully engineered and must
be installed only as specied. If you modify it or any of
its components you will void the warranty, and you may
possibly cause a re hazard. Installation must be done
according to applicable local, state, provincial, and/or
national codes.
Table of Contents
Introduction .......................................1
Preparation .......................................1
Kit Contents.......................................2
Clearances .......................................3
Good Faith TV Guidelines ............................4
Framing Dimensions- Passive Heat Front
Discharge (PH-LINEAR). . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Framing Dimensions - Passive Heat Side
Discharge (PH-LINEAR). . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Framing Dimensions - Passive Heat Open Top
Discharge (PH-LINEAR). . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Adapter Installation - Front, Side and Open Top Discharge ..8
Passive Heat Template - Front and Side Discharge ........8
Finishing ........................................10
Mantel Projections.................................12
Installation of Passive Heat with Other Optional Heat
Management Systems ...........................12
Maintenance .....................................12
Preparation
Plan the location of the appliance.
Determine whether front, open top or side discharge is
to be installed and follow instructions for the appropriate
application.
CAUTION! Risk of Burns!
• The replace should be turned o and cooled before
kit is installed.
• Shut o gas supply.

2Hearth & Home Technologies • PH-LINEAR Instructions • 2616-970 Rev. i • 10/21
Figure 1 Passive Heat Kit Components
FRONT/OPEN TOP DISCHARGE KIT
DESCRIPTION SERVICE PART NO. QTY
Passive Heat Adapter 2617-302 2
Screw 030-860/8 1
Passive Heat Template 2617-137 4
Kit Contents
Verify and remove contents from packaging before
beginning installation. See Figure 1.
2617-302
Passive Heat Adapter
030-860/8
Screw
Power Vent Option
If an optional power vent will be installed in conjunction
with the Passive Heat Kit (PH-LINEAR), Hearth & Home
Technologies recommends the PVLP-SLP power vent
option. If the application does not allow for the PVLP-SLP
to be used, the PVI-SLP-B may be used. The PVI-SLP-B
must be mounted outside the chase due to the higher noise
level created.
The Passive Heat Kit is not compatible with a Smart-
Wall™ TV Kit , GFK-160A, GFK-240 or other fan.
For AU models, PVLP-SLP-AU is approved to be used in
conjunction with the Passive Heat Kit.
2617-137
Passive Heat Template
Contents of PH-LINEAR Kit
PH-LINEAR

3
Hearth & Home Technologies • PH-LINEAR Instructions • 2616-970 Rev. i • 10/21
Clearances
Ensure all clearances are maintained.
• Maintain minimum distance from top of appliance
opening to the room ceiling. Refer to the gures in the
Framing section of this instruction.
• An open space, or “cavity,” is allowed up to three inches
above the top of the passive heat discharge opening. A
chase ceiling is required when the open space “cavity”
exceeds three inches above the discharge opening.
Construct the false ceiling from material such as metal,
drywall or plywood.
WARNING! Risk of Fire! Maintain clearances to
combustibles as specied.
INTERIOR WALL
FLOOR
CEILING
36 IN.
36 IN.
6 IN.
18 IN.
18 IN.
PASSIVE HEAT FRONT DISCHARGE OPENING
(Clearances for front and side discharge installations)
FIREPLACE
*CEILING
INTERIOR WALL
6 IN.
36 IN.
= SPRINKLER HEAD
PASSIVE HEAT OPEN TOP DISCHARGE OPENING
(914 mm)
(914 mm)
(457 mm)
(457 mm)
(15 mm)
(914 mm)
(15 mm)
Clearance - Sprinkler to Passive Heat
Figure 2 references the clearances that must be adhered
to when installing a sprinkler head near a passive heat
discharge opening.
* If the distance from the top of the passive heat front
discharge opening to the ceiling is 36 in. (914 mm) or
greater, then there is no 36 in. (914 mm) clearance
requirement. This is for a ceiling sprinkler head
installation only.
Note: When installing a sprinkler head near a heat
discharge opening, it is recommended to use
a sprinkler head with an Extra High sprinkler
activation temperature rating.
• When installing a sprinkler head exterior of the chase,
maintain the following clearances to discharge openings
(convection slots, passive heat registers, heat zone
registers, etc.): 36 in. (914 mm) top, 18 in. (457 mm)
sides and 6 in. (152 mm) bottom.
• DO NOT install a sprinkler head inside a chase that is
set up for passive heat.
Figure 2

4Hearth & Home Technologies • PH-LINEAR Instructions • 2616-970 Rev. i • 10/21
WARNING! Risk of Fire! Mesh screen required on bottom of discharge opening when discharge
opening is greater than 3 in. (76 mm). Secure mesh to top of framing.
Good Faith TV Guidelines
Figure 3
Measurement from top edge
of opening to bottom of
appliance = 25-7/8 IN. (657 mm)
ROOM CEILING
1-1/2 IN. (2 X 4 FRAMING)
2 IN. MIN.
TV
12 IN. MIN.
4 IN. MIN. 1/2 IN. X 1/2 IN.
(51 mm x 51 mm)
WIRE MESH*
*Wire mesh required for front discharge or open top discharge passive heat installations with discharge
opening of 3 in. (76 mm) or greater.
77-3/8 IN. (1965 mm) MIN.
(Appliance may be
installed off of floor)
FIREPLACE
OPENING
2 X 4 FRAMING
2 X 4 OR 2 X 6
CHASE CEILING - SEE FIGURES 5 and 6
(FRONT AND SIDE DISCHARGE ONLY)
WIRE MESH*
= PASSIVE HEAT
DISCHARGE OPENING
SEE FIGURES 5, 6 and 7
(MINIMUM CLEARANCE TO
DISCHARGE OPENING)
NOTE: The TV installation requirements are the same regardless of whether the Passive Heat kit is installed with a
top discharge, side discharge or open top discharge.
71-7/8 IN. (1826 mm) MIN.
(Appliance may be
installed off of floor)
Good Faith Guidelines for TV Installations
Above a Fireplace with Passive Heat Option
This diagram specific to these models:
COSMO32-IFT-B RAVE32-IFT-B JADE32IN-B
COSMO36-IFT-B RAVE36-IFT-B JADE42IN-B
COSMO42-IFT-B RAVE42-IFT-B JADE42IL-B
DVLINEAR36 B41L-AU
(90 x 35 mm for AU)
(90 x 35 mm for AU)
(90 x 35 mm for AU)
FRAMING
(102 mm)
(51 mm)
(305 mm)

5
Hearth & Home Technologies • PH-LINEAR Instructions • 2616-970 Rev. i • 10/21
Figure 4 Passive Heat Front Discharge Framing Dimensions With and Without a Trim Kit
Framing Dimensions- Passive Heat Front Discharge (PH-LINEAR)
Front Discharge: Air conveyed into the room through one front discharge slot.
FRONT DISCHARGE MINIMUM FRAMING DIMENSIONS
A
B C D E
TRIM KIT*
INSTALLED
(PH-FRTTRIM-XX)
NO TRIM
KIT**
Required Height of
Discharge Opening
Height of
Discharge
Opening
Clearance to
Top of
Discharge
Opening
Width of
Discharge
Opening
Clearance to
Top of Discharge
Opening From
Bottom of
Appliance
Clearance from
Bottom of Appliance
to Bottom of
Discharge Opening
COSMO32-IFT-B
RAVE32-IFT-B
JADE32IN-B
Inches 3-1/2 2 48 31-1/8 73-7/8 71-7/8
millimeters 89 51 1219 791 1876 1826
COSMO36-IFT-B
RAVE36-IFT-B
DVLINEAR36
B41L-AU
Inches 3-1/2 2 48 36-1/2 73-7/8 71-7/8
millimeters 89 51 1219 927 1876 1826
COSMO42-IFT-B
RAVE42-IFT-B
JADE42IN-B
JADE42IL-B
Inches 3-1/2 2 48 48-1/2 73-7/8 71-7/8
millimeters 89 51 1219 1232 1876 1826
WARNING! Risk of Fire! Wire mesh required on
bottom of discharge opening (Dimension A) when
nished discharge opening is greater than 3 in.
(76 mm). Secure mesh to top of framing.
ROOM CEILING
1-1/2 IN. (2 X 4 FRAMING)
2 IN. MIN.
TV
1/2 IN. X 1/2 IN.
(13 mm x 13 mm)
WIRE MESH**
CHASE CEILING REQUIRED
WITHIN 3 IN. (76 mm) OF TOP
OF OPENING
WIRE MESH**
= PASSIVE HEAT
DISCHARGE OPENING
0-3 IN.
= CHASE CEILING ZONE
(0-76 mm)
(51 mm)
(90 x 35 mm for AU)
CHASE DETAIL
A
D
C
B
APPLIANCE MAY BE INSTALLED
OFF OF FLOOR
E
* Measurement for Trim Kit = 3-1/2 in. (89 mm) + Additional Finishing Material Thickness
** Measurement without Trim Kit = 2 in. (51 mm) + Additional Finishing Material Thickness. If nished discharge open-
ing height is greater than 3 in. (76 mm), wire mesh is required.

6Hearth & Home Technologies • PH-LINEAR Instructions • 2616-970 Rev. i • 10/21
Figure 5 Passive Heat Side Discharge Framing Dimensions
Framing Dimensions - Passive Heat Side Discharge (PH-LINEAR)
Side Discharge: Air conveyed into the room through two discharge registers,
one on each side of appliance.
SIDE DISCHARGE FRAMING DIMENSIONS
A B C D E
Height of
Discharge
Opening
Width of
Discharge
Opening
Minimum
Clearance to
Discharge Opening From
Bottom of Appliance
Minimum
Clearance Bottom of
Appliance to Ceiling
Minimum
Clearance to
Combustible
Materials
COSMO32-IFT-B
RAVE32-IFT-B
JADE32IN-B
COSMO36-IFT-B
RAVE36-IFT-B
DVLINEAR36
B41L-AU
COSMO42-IFT-B
RAVE42-IFT-B
JADE42IN-B/
JADE42IL-B
Inches 12-1/4 8-3/4 63-5/8 77-3/8 18
millimeters 311 222 1616 1965 457
WARNING! Risk of Fire! DO NOT place combustible
objects or combustible materials in non-combustible
zone. Appliance and combustible materials will overheat.
E
B
A
D
C
APPLIANCE MAY BE INSTALLED
OFF OF FLOOR
ROOM CEILING
1-1/2 IN. (2 X 4 FRAMING)
= PASSIVE HEAT
DISCHARGE OPENING
0-3 IN.
= CHASE CEILING ZONE
DISCHARGE OPENING
CHASE CEILING ZONE
CHASE CEILING REQUIRED WITHIN 3 IN.
OF TOP OF OPENING
(0-76 mm)
(90 x 35 mm for AU)
CHASE DETAIL

7
Hearth & Home Technologies • PH-LINEAR Instructions • 2616-970 Rev. i • 10/21
C
A
B
Figure 6 Passive Heat Minimum Framing Dimensions Open Top Discharge
OPEN TOP DISCHARGE MINIMUM FRAMING DIMENSIONS
A* B C
Height of
Discharge Opening
Clearance to
Discharge Opening
Width of
Discharge Opening
COSMO32-IFT-B
RAVE32-IFT-B
JADE32IN-B
Inches 2 48 31-1/8
millimeters 51 1219 791
COSMO36-IFT-B
RAVE36-IFT-B
DVLINEAR36
B41L-AU
Inches 2 48 36-1/2
millimeters 51 1219 927
COSMO42-IFT-B
RAVE42-IFT-B
JADE42IN-B
JADE42IL-B
Inches 2 48 48-1/2
millimeters 51 1219 1232
*Mesh screen required for front discharge or open top discharge passive heat installations with discharge
opening of 3 in. (76 mm) or greater.
Framing Dimensions - Passive Heat Open Top Discharge (PH-LINEAR)
WARNING! Risk of Fire! Mesh screen required on bottom of discharge opening when discharge
opening is greater than 3 in, (76 mm). Secure mesh to top of framing.
Open Top Discharge: Both sides and the top are open allowing air to be conveyed into the room.

8Hearth & Home Technologies • PH-LINEAR Instructions • 2616-970 Rev. i • 10/21
Adapter Installation - Front, Side and Open
Top Discharge
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during instal-
lation. Sheet metal edges are sharp.
1. Remove rear stando󰀨s and discard. See Figure 7.
2. Remove both top knockouts from outer wrap as
shown in Figure 7. Discard knockout piece and
ensure no other material or debris is blocking the hole
created by removing the knockout.
3. Center adapter over opening with the solid portion
facing the front of the appliance. Attach both adapters
to appliance by installing three screws per adapter.
See Figure 8.
Note: If installing an additional Heat Management
System, refer to the instructions included with the kit for
further installation instructions.
REMOVE KNOCKOUTS
REMOVE REAR STANDOFFS
Figure 7 Remove Knockouts
Figure 8 Attach Adapters
FRONT OF
APPLIANCE
SOLID PORTION
Passive Heat Template - Front and Side
Discharge
Install the passive heat templates to prevent nishing
material from being installed over passive heat discharge
openings. Use two templates for front discharge and four
templates for side discharge.
1. Hand bend templates as shown in Figure 9.
2. Place one template into the top left corner of the
discharge opening as shown in Figure 10. Align the
outside edge of the framing with the notch in the
template as shown in Figure 11. Attach to framing
using wood screws.
3. Place the second template into the bottom right
corner and attach using the same method as in
Step 2. If installing templates on framing for a side
discharge kit, repeat the process for the additional
two templates on the other side discharge opening.
4. Once the wall nishing material has been installed,
remove the templates and discard. After the
templates have been removed, the trim kit, register,
or other nishing options may be installed.
HAND BEND LINE
Figure 9 Hand Bending the Template

9
Hearth & Home Technologies • PH-LINEAR Instructions • 2616-970 Rev. i • 10/21
TEMPLATES INSTALLED
(FRONT DISCHARGE SHOWN)
Figure 10 Template Installation
Figure 11 Template Notch Alignment
ALIGN NOTCH WITH
EDGE OF FRAMING

10 Hearth & Home Technologies • PH-LINEAR Instructions • 2616-970 Rev. i • 10/21
Painting
Side Discharge:
If desired nishing includes painting of the side discharge
register covers, Hearth & Home Technologies recom-
mends using high temperature paint with a minimum of
300 °F (149 °C) continuous exposure rating.
Finishing
1. Apply wall sheathing material, such as drywall up to
1/2 in. (13mm) thick up to the edge of the discharge
opening.
WARNING! Risk of Overheating! DO NOT apply wall
sheathing past the edge of discharge opening or nishing
templates. Remove nishing templates before appliance
operation. Overheating of appliance and combustible
materials will occur.
Front Discharge and Open Top Discharge:
The location of the Passive Heat discharge opening could
allow for venting and other construction materials to be
visible. It is recommended to paint the vent pipe, restop,
and other visible construction materials, as shown in Fig-
ure 12 using a high temperature paint with a minimum
of 300 °F (149 °C) continuous exposure rating. Hearth
& Home Technologies recommends using black touch
up paint (part number TUP-GBK-12) available from your
Hearth & Home Technologies dealer.
2. Facing Material with Front Trim Kit (PH-FRTTRIM)
1 Inch Thick or Less: When using Non-Combustible fac-
ing material in this thickness range, the Overlap Fit meth-
od may be used. Place facing materials up to the edge of
the discharge opening and install trim kit as instructed.
Facing must not interfere with the air ow through the trim
kit.
Greater than 1 Inch: Non-Combustible facing material
in this thickness range must use the Inside Fit method.
Place facing materials up to ½ in. (13mm) away from the
edge of the trim kit to allow for proper removal of the vent
cover. Install trim kit as instructed. Consult the appliance
Installation Manual to determine maximum facing mate-
rial thickness.
3. Facing Material with Side Discharge (PH-SIDETRIM)
1 Inch Thick or Less: When using Non-Combustible
facing material in this thickness range, the Overlap Fit
method may be used. Place facing materials up to the
edge of the discharge opening and install register covers
as instructed. Facing must not interfere with the air ow
through the trim kit.
Greater than 1 Inch: Non-Combustible facing material
in this thickness range must use the Inside Fit method.
Place facing materials up to the edge of the register cov-
ers. Install register covers as instructed. Consult the units
Installation Manual to determine maximum facing mate-
rial thickness.
4. Install trim kit (PH-FRTTRIM or PH-SIDETRIM) as in-
structed.
Side Discharge: The PH-SIDETRIM kit is required to
complete installation.
Front Discharge: The PH-FRTTRIM kit is an optional
nishing method. Other standard nishing methods may
be used as well.
PAINT FRAMING AROUND
PASSIVE HEAT OPENING
PAINT CEILING FIRESTOP
PAINT VENT PIPE
Figure 12 Painting Visible Components

11
Hearth & Home Technologies • PH-LINEAR Instructions • 2616-970 Rev. i • 10/21
2 IN. MIN.*
DO NOT INSTALL
FINISHING MATERIAL
ON THIS SURFACE.
2 IN. (51 mm) MIN.
OPENING MUST
NOT BE BLOCKED
CEILING
CEILING
2 IN. MIN.*
DO NOT INSTALL
FINISHING MATERIAL
ON THIS SURFACE.
2 IN. (51 mm) MIN.
OPENING MUST NOT
BE BLOCKED
CEILING
12-1/4 IN.
(311 mm)
8-3/4 IN.
(222 mm)
SIDE DISCHARGE
(DISCHARGE SLOTS ON BOTH SIDES OF APPLIANCE)
FRONT DISCHARGE
OPEN TOP DISCHARGE
= COMBUSTIBLE MATERIAL ALLOWED
*= Mesh screen required for front discharge or open top discharge passive heat installations with
discharge opening of 3 in. (76 mm) or greater.
(51 mm) (51 mm)
REGISTER COVER
SLOTS FACE FRONT
OF APPLIANCE
Figure 14 Finishing Material Installed
NON-COMBUSTIBLE
FINISHING MATERIAL
INSIDE FIT = GREATER THAN
1 IN. THICK
1/2 IN. THICK WALL
SHEATHING
NON-COMBUSTIBLE
FINISHING MATERIAL
OVERLAP FIT = 0-1 IN. THICK
1/2 IN. THICK WALL
SHEATHING
INSIDE FIT OVERLAP FIT
Figure 13 Finishing Material Installed

12 Hearth & Home Technologies • PH-LINEAR Instructions • 2616-970 Rev. i • 10/21
Passive Heat Kit Installed with Optional Heat-Zone-Gas
(Heat-Zone®-240V for B41L-AU)
• Only one Heat-Zone-Gas kit may be installed and used
in conjunction with the Passive Heat Heat Manage-
ment System.
Passive Heat Kit Installed with Optional Heat-Out-Gas
(Not available with B41L-AU)
• One Heat-Out-Gas kit may be installed and used in
conjunction with the Passive Heat Heat Management
System.
There are other heat management options available
for use with the COSMO-IFT-B, RAVE-IFT-B, JADE-B,
DVLINEAR36 and B41L-AU models. Consult the
appliance manual for compatible options.
Installation of Passive Heat with Other
Optional Heat Management Systems
Please contact your Hearth & Home Technologies dealer
with any questions or concerns.
For the location of your nearest Hearth & Home
Technologies dealer,
please visit www.hearthnhome.com.
Hearth & Home Technologies
7571 215th Street West, Lakeville, MN 55044
www.hearthnhome.com
Maintenance
Service and maintain the gas replace per instructions.
Keep the air register(s) clean and free of any blockage.
The Passive Heat Kit is not compatible with the Smart-
Wall™ TV Kit, GFK-160A or any other fan.
Mantel Projections
Refer to the appliance Installation Manual.
NOTICE: Cap must be removed from adapter prior to
attaching venting for the heat management kit. Heat-
Zone®-Gas and Heat-Out-Gas system will not function
properly if cap remains attached.
Figure 15 Adapter Prepared for Venting to be Attached
ATTACH VENTING HERE
ADAPTER
• Remove cap from the Passive Heat adapter and dis-
card the cap. The venting for the Heat-Zone-Gas kit
will attach directly on top of the Passive heat adapter.
See Figure 15.
• Refer to the instructions included with the Heat-Zone-
Gas kit for more information.
WARNING! Risk of Overheating! Be sure the venting
does not does not extend past the rib on Passive Heat
adapter. If venting or insulation is blocking holes in the
Passive Heat adapter overheating of chase could occur.
• Remove cap from the Passive Heat adapter and dis-
card the cap. The venting for the Heat-Out-Gas kit will
attach directly on top of the Passive heat adapter. See
Figure 16.
• Refer to the instructions included with the HEAT-OUT-
GAS kit for more information.
WARNING! Risk of Overheating! Be sure the venting
does not does not extend past the rib on Passive Heat
adapter. If venting or insulation is blocking holes in the
Passive Heat adapter overheating of chase could occur.
