Heat & Glo NORTHSTAR-BK User manual

Installationandserviceofthisreplaceshouldbe
performedbyqualiedpersonnel.Hearth&Home
TechnologiesrecommendsNFIcertiedprofes-
sionals,ortechnicianssupervisedbyan
NFIcertiedprofessional.
EPA CERTIFIED WOODBURNING
FIREPLACE
Fire Risk.
WARNING
Forusewithsolidwoodfuelonly.
Otherfuelsmayoverreandgenerate
poisonousgases(i.e.carbonmonoxide).
O-T L
Tested and
Listed by
Portland
Oregon USA
OMNI-Test Laboratories, Inc.
CUS
Model(s):
Installation Manual
Installation and Fireplace Setup
WARNING
HOT SURFACES!
Glassandothersurfacesarehotduring
operationANDcooldown.
Hot glass will cause burns.
• DO NOTtouchglassuntilitiscooled
• NEVERallowchildrentotouchglass
• Keepchildrenaway
• CAREFULLY SUPERVISE children in same room as
replace.
• Alertchildrenandadultstohazardsofhightemperatures.
High temperatures may ignite clothing or other  ammable
materials.
• Keep clothing, furniture, draperies and other ammable
materialsaway.
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NORTHSTAR-BK
NORTHSTAR-GT
NORTHSTAR-NT
NOTICE: DO NOT discard this manual!
• DO NOTstoreorusegasolineorotheram-
mablevaporsandliquidsinthevicinityofthis
oranyotherappliance.
• DO NOT overre.Overringwillvoidyour
warranty.
• Complywithallminimumclearancestocom-
bustiblesasspecied.Failuretocomplymay
causehousere.
WARNING: If the information in these
instructions is not followed exactly, a  re
or explosion may result causing property
damage, personal injury, or death.
Pourdemanderunexemplaire
enfrançaisdeceManuel
dupropriétaire,visitezwww.
heatnglo.com/translations.
1
Heat&Glo•NORTHSTAR•480-2360InstallationManual•RevH•8/20/14

Safety Alert Key:
• DANGER! Indicatesahazardoussituationwhich,ifnotavoidedwillresultindeathorseriousinjury.
• WARNING!Indicatesahazardoussituationwhich,ifnotavoidedcouldresultindeathorseriousinjury.
• CAUTION! Indicatesahazardoussituationwhich,ifnotavoided,couldresultinminorormoderateinjury.
• NOTICE:Indicatespracticeswhichmaycausedamagetothereplaceortoproperty.
Table of Contents
1 Product Specic & Important Safety Information
A.FireplaceCertication 4
B.GlassSpecications 4
C.Non-CombustibleMaterials 4
D.CombustibleMaterials 4
E.ElectricalCodes 5
2 Getting Started
A.TypicalFireplaceSystem 6
B.DesignandInstallationConsiderations 7
1.SelectingFireplaceLocations 7
2.LocatingFireplace&Chimney 8
C.ToolsandSuppliesNeeded 9
D.InspectFireplaceandComponents 9
E.FireplaceSystemRequirements 9
3 Framing and Clearances
A.FireplaceDimensions 10
B.Clearances 11
1.MinimumClearances 12
C.ConstructtheChase 13
D.FrametheFireplace 14
E.SecureandLeveltheFireplace 14
F. ProtectiveMetalHearthStrips 15
G.FacingMaterial 15
H.OutsideAirKit 16
I. HeatZoneKit(Optional) 18
4 Electrical Wiring
5 Chimney and Termination Requirements
A.ChimneyRequirements 22
B.Offsets/Returns 23
C.TerminationRequirements 24
6 Chimney Installation
A.TypicalChimneySystem 25
B.AssembleChimneySections 26
C.InstallChimneyAirkit(CAK4A) 26
D.SecureOffset/Return 28
E.InstallCeilingFirestops 28
F. InstallAtticInsulationShield 29
G.RoofPenetration 30
H.ManufacturedHomeInstallation 30
I. InstallChase/ChaseTop 31
J. TerminationCapRequirements 32
K.InstallTerminationCap 32
7 Finishing
A.Template 34
B FinishtheWall 34
1.Stone,BrickFinish 34
2.Tile,Granite,MarbleFinish 34
C.MantelandWallProjections 35
D.FinishingtheHearthExtension 35
E.Non-CombustibleSealantMaterial 37
8 Fireplace Setup
A.FirebrickPlacement 38
B.BafeandBlanketPlacement 39
9 Reference Materials
A.ChimneyComponents 40
B.Accessories 44
MESH-HHTFirescreen 44
2Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14
►

Customer:
Lot/Address
Model (circle one): NORTHSTAR-BK NORTHSTAR-NT
NORTHSTAR-GT
Fireplace Install YES IF NO, WHY?
Verifiedthatthechaseisinsulatedandsealed.(Pg.13)
Requirednon-combustibleboardisinstalled.(Pg.15)
Verifiedclearancestocombustibles.(Pg.11)
Fireplaceisleveledandsecured.(Pg.14)
Hearthextensionsize/heightdecided.(Pg.14&37)
Outsideairkitinstalled.(Pg.16)
OptionalHeatZonehasbeeninstalledbyaqualifiedservicetechnician.(Pg.18)
Chimne
y
Section 5 (Pg. 22)
Chimneyconfigurationcomplieswithdiagrams.
Chimneyinstalled,lockedandsecuredinplacewithproperclearance.
Chimneyairkitinstalled.
Firestopsinstalled.
Atticinsulationshieldinstalled.
Roofflashinginstalledandsealed.
Terminationsinstalledandsealed.
Electrical Section 4 (Pg. 21)
Switchwiresproperlyinstalled.
Finishing Section 7 (Pg. 34)
Combustible materials not installed in non-combustible areas
Dealer/Distributor Phone #
Serial #:
WARNING! Risk of Fire or Explosion! Failure to install fireplace acording to these instructions can lead to a fire or
explosion.
ATTENTION INSTALLER:
Follow this Standard Work Checklist
Thisstandardworkchecklististobeusedbytheinstallerinconjuctionwith,notinsteadof,theinstructionscontainedinthis installation
manual.
Date Installed:
Location of Fireplace:
Installer:
Combustible materials not installed in non
-
combustible areas
.
Verifiedallclearancesmeetinstallationmanualrequirements.
Mantelsandwallprojectionscomplywithinstallationmanualrequirements.
Protectivehearthstripsandhearthextensioninstalledpermanualrequirements.
Fireplace Setup Section 8 (Pg. 38)
Allpackagingandprotectivematerialsremoved.
Firebrick,baffleandceramicblanketinstalledcorrectly.
Faciaanddoorsproperlyinstalled.
Allpackagingmaterialsareremovedfrominside/underthefireplace.
Hearth & Home Technologies recommends the following:
•Photographingtheinstallationandcopyingthischecklistforyourfile.
•Thatthischecklistremainvisibleatalltimesonthefireplaceuntiltheinstallationiscomplete.
Commentscommunicatedtopartyresponsible
Part4017-256•RevB•1/29/13
__________________________by______________________on_________
(Builder/Gen.Contractor)(Installer)(Date)
Comments:Furtherdescriptionoftheissues,whoisresponsible(Installer/Builder/OtherTrades,etc.)andcorrectiveactionneeded:
_________________________________________________________________________________________________
Manualbagandallofitscontentsareremovedfrominside/underthefireplaceand
giventothepartyresponsibleforuseandoperation.
________________________________________________________________________________________________________
________________________________________________________________________________________________________
3
Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14

1 Product Specic & Important Safety Information
A. Fireplace Certication
Thisreplacesystemhasbeentestedandlistedinac-
cordancewithUL127andULC-S610-M87and(UM)84-
HUDstandardsforinstallationandoperationintheUnited
StatesandCanadaasdescribedinthismanual.
Checkwithyourlocalbuildingcodeagencybeforeyou
beginyourinstallationtoensurecompliancewithlocal
codes,includingtheneedforpermitsandfollow-upin-
spections.Besurelocalbuildingcodesdonotsupersede
ULspecicationsandalwaysobtainabuildingpermitso
thatinsuranceprotectionbenetscannotbeunexpectedly
cancelled.
Heat&GloisaregisteredtrademarkofHearth&Home
Technologies.
C. Non-Combustible Materials
• Materialswhichwillnotigniteand burn, composed of
anycombinationofthefollowing:
- Steel - Iron
- Brick - Tile
- Concrete - Slate
- Glass - Plasters
• MaterialsreportedaspassingASTM E 136, Standard
Test Method for Behavior of Metals, in a Vertical Tube
Furnace at 750° C
B. Glass Specications
Thisreplaceisequippedwith5mmceramicglass.Re-
placeglassonlywith5mmceramicglass.Pleasecontact
yourdealerforreplacementglass.
NOTICE: This installation must conform with local codes. In the
absence of local codes you must comply with the UL127, (UM)
84-HUD and NFPA211 in the U.S.A. and the ULC 610-M87
and CAN/CSA-B365 Installation Codes in Canada.
WARNING! Risk of Fire! Hearth & Home Technologies
disclaims any responsibility for, and the warranty and agen-
cy listing will be voided by the following actions.
DO NOT:
• installoroperatedamagedreplace
• modifyreplace
• install other than as instructed by Hearth & Home
Technologies
• operate the fireplace without fully assembling all
components
• overre
• installanygaslogset
• installanycomponentnotapprovedbyHearth&Home
Technologies
• installpartsorcomponentsnotListedorapproved
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. For
assistance or additional information, consult a qualied
installer, service agency or your dealer.
Model: NorthstarEPACertied
WoodburningFireplace
Laboratory: OMNITestLaboratories,Inc.
Report No: 061-S-50-2
Type: WoodFireplace
Standard: UL127andULC-S610-M87and
(UM)84-HUD,Manufactured
HomeApproved.
EPA# and Original Date: #5714-1-03
EPA Certied:
3.25gramsper
hour
Efciency: upto77.8%
BTU Output
with EPA test fuel: 51,400/hr.
with Cord Wood: 70,000/hr.
Heating Capacity: upto3,500sqft
Chimney Size: 8inches
HHT SL300Series
DuraVent DuraPlus
Max Wood Length: 24inches
Fuel: CordWood
Shipping Weight: 650lbs
Firebox Size 2.7cubicfeet
WARNING! Risk of Fire!
Hearth & Home Technologies is not responsible for
discoloration, cracking or other material failures of
nishingmaterialsduetoheatexposureorsmoke.
 • Choosenishingmaterialscarefully.
4Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14

E. Electrical Codes
NOTICE: This replace must be electrically wired and
grounded in accordance with local codes or, in the
absence of local codes, with National Electric Code ANSI/
NFPA 70-latest edition or the Canadian Electric Code
CSA C22.1.
• A110-120VACcircuitforthisproductmustbeprotected
with ground-fault circuit-interrupter protection, in
compliancewiththeapplicableelectricalcodes,when
itisinstalledindamplocations.
WARNING! Improper installation, adjustment, alteration,
service or maintenance can cause injury or property dam-
age.
D. Combustible Materials
• Materialsmadeoforsurfacedwithanyofthefollowing
materials:
- Wood - Compressedpaper
- Plantbers - Plastic
- Plywood/OSB - Sheetrock(drywall)
• Anymaterialthatcanigniteandburn;ameproofedor
not,plasteredorun-plastered
5
Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14

2 Getting Started
A. Typical Fireplace System
Non-combustible
roof flashing maintains
minimum clearance
around chimney
Additional lateral
support for chimney
above roof (or enclosed
in chase) if needed
Enclosed space above
and around fireplace
Support straps
on rafter supports
chimney (not shown)
Outside
combustion air
Outside
combustion air
Termination Cap
Chimney penetrates roof
preferably without affecting
roof rafters
Storm Collar
Offset/Return
(with hanger straps)
Attic insulation shield
must be used here to
keep insulation away
from chimney if
attic is insulated
Framing headed
off in ceiling joists
Mantel
Decorative facing
and trim
Factory-built fireplace
Chimney system
Combustible
framing/header
on top of V-shaped
standoffs (spacers)
Hearth extension
Protective metal
hearth strip(s)
Chimney Air kit required for
SL chimney
Figure 2.1 Typical Fireplace System
6Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14

D
C
A
E
F
A
H
G
B
A
B
B
A
I
In an exterior chase
or projecting into a
garage
Across a corner
Along a wall
As a
room
divider
24 in.
(610mm)
24 in.
(610mm)
24 in.
(610mm)
48 in.
(1219mm)
24 in.
(610mm)
I
A
Figure 2.2 Fireplace Locations
NOTICE:
• Illustrationsandphotosreecttypicalinstallationsand
are FOR DESIGN PURPOSES ONLY.
• Illustrations/diagramsarenotdrawntoscale.
• Actualinstallation/appearancemayvaryduetoindividual
design preference.
• Hearth&HomeTechnologiesreservestherighttoalter
its products.
NOTICE: In addition to these framing dimensions, also
reference the following section:
• Clearances (Section 3).
NOTICE:
A minimum 1 in. air clearance at the back and a
minimum 1 in. air clearance to the sides of the
replaceassemblymustbemaintained.
Chimney sections at any level require a 2 in. mini-
mum air space clearance between the framing
and chimney sections.
B. Design and Installation Considerations
NOTICE: Check building codes prior to installation.
• InstallationMUSTcomplywithlocal,regional,stateand
nationalcodesandregulations.
• Consultinsurancecarrier,localbuildinginspector,re
ofcialsorauthoritieshavingjurisdictionoverrestrictions,
installationinspectionandpermits.
1. Selecting Fireplace Locations
Thisreplacemaybeusedasaroomdivider,installed
alongawall,acrossacornerorusedinanexteriorchase.
SeeFigure2.2.
Locatingthereplaceinabasement,nearfrequently
openeddoors,centralheatoutletsorreturns,orother
locationsofconsiderableairmovementcanaffectthe
performance.
Outsideairmustbeusedforcombustion.TheNorthStar
comesequippedwithanoutsideairinlettofeedcombus-
tionairfromoutsidethehome,alongwithanoutsideair
terminationcap;therigidmetalductisrequiredbutnot
supplied.Considerationshouldbegiventothesefactors
beforedecidingonalocation.
Model # A B C D E F G H I
NorthStar(dimensions
fornishedwalls)
in. 41-7/8 16 89-1/2 63-5/16 22-7/16 44-3/4 14-1/16 55-15/16 50-7/8
mm 1063 406 2273 1608 570 1137 357 1421 1292
7
Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14

2. Locating Fireplace & Chimney
Locationofthereplaceandchimneywillaffectperfor-
mance.
• Installwithinthewarmairspaceenclosedbythebuilding
envelope.Thishelpstoproducemoredraft,especially
duringlightinganddie-downofthere.
• Penetratethehighestpartoftheroof.Thisminimizes
theeffectsofwindloading.
• Locate termination cap away from trees, adjacent
structures,unevenrooflinesandotherobstructions.
• Minimizetheuseofchimneyoffsets.
• Considerthereplacelocationrelativetooorandceiling
andatticjoists.
• Takeintoconsiderationtheterminationrequirementsin
Sections5and6.
Marginal Location:
• Below peak
Location NOT recommended:
• Not the highest point of the roof
• Wind loading possible
Multi-level Roofs
Windward
Leeward
Recommended Location:
• Above peak
Recommended:
• Insulated exterior chase
in cooler climates
Recommended Location:
• Above peak
• Inside heated space
Location NOT recommended:
• Too close to tree
• Below adjacent structure
• Lower roof line
• Avoid outside wall
Marginal Location:
• Wind loading possible
Figure 2.3 Recommended Chimney Locations
• Installtheoutsideairkitwiththeintakefacingprevailing
windsduringtheheatingseason.
• Ensure adequate outdoor air for all combustion
appliancesandexhaustequipment.
• Ensurefurnaceandairconditioningreturnventsarenot
locatedintheimmediatevicinityofthereplace.
• Avoidinstallingthereplaceneardoors,walkwaysor
smallisolatedspaces.
• Recessedlightingshouldbea“sealedcan”design.
• Attichatchesweatherstrippedorsealed.
• Atticmountedductworkandairhandlerjointsandseams
tapedorsealed.
8Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14

C. Tools and Supplies Needed
Beforebeginningtheinstallationbesurethefollowing
toolsandbuildingsuppliesareavailable:
Reciprocatingsaw Framingmaterial
Pliers Non-combustiblesealant
Hammer Gloves
Phillipsscrewdriver Framingsquare
Flatbladescrewdriver Electricdrillandbits
Plumbline Safetyglasses
Level Tapemeasure
1/2-3/4in.length,#6or#8self-drillingscrews
Misc.screwsandnails
D. Inspect Fireplace and Components
WARNING! Risk of Fire and/or Explosion! Damaged
parts could impair safe operation. DO NOT install dam-
aged,incompleteorsubstitutecomponents.Keepre-
place dry.
• Removereplaceandcomponentsfrompackagingand
inspectfordamage.
• Vent system components and doors are shipped in
separatepackages.
• Reporttoyourdealeranypartsdamagedinshipment.
• Read all the instructions before starting the
installation. Follow these instructions carefully
during the installation to ensure maximum safety
and benet.
E. Fireplace System Requirements
Thereplacesystemrequirementsconsistofthefollow-
ing:
• Fireplace
- Firebrick(includedwithreplace)
- Door(includedwithreplace)
- Non-combustible facing material (included with
replace)
- HearthExtension
• OutsideAir System (hood and collars included with
replace)
• Fascia(includedwithreplace)
• ChimneySystem
- Chimneyairkit(includedwithreplace,requiredwith
SL300serieschimney)
- AtticInsulationShield(includedwithreplace)
- Chimneyterminationcap
• Non-combustiblenishmaterial
Optionalcomponentsinclude:
• Firescreen
• LintelBar
• HeatZoneKit
9
Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14

3 Framing and Clearances
A. Fireplace Dimensions
Fan Electrical Access
(right side of fireplace)
(283 mm)
(587 mm)
(25 mm)
(89 mm)
(1111 mm)
(1022 mm)
(791 mm)
(149 mm)
(743 mm)
(940 mm)
(1016 mm)
(1066 mm)
(422 mm)
(305 mm)
(25 mm) (248 mm)
(175 mm)
Figure 3.1 Fireplace Dimensions
►
10 Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14

B. Clearances
WARNING! Risk of Fire!
YoumustcomplywithallminimumairspaceclearancestocombustiblesasspeciedinFigure3.2.DO NOT pack required
airspaceswithinsulationorothermaterials.Framingornishingmaterialusedonthefrontof,orinfrontof,thereplace
closer than the minimums listed must be constucted entirely of non-combustible materials (i.e., steel studs, concrete board,
etc.).Failuretocomplymaycausere.
Figure 3.2 Clearances to Combustible Materials
2 in. (51 mm) min.
Attic
Insulation
Shield
Ceiling Firestop
(ceiling)
(roof)
(attic)
(ceiling)
Ceiling Firestop Offset/Return with
hanger straps
Storm Collar
Roof Flashing
2 in. (51 mm) min.
2 in. min.
(51 mm)
Must have 2 in. (51 mm)
minimum clearance
to header
2 in. (51 mm) min.
2 in. (51 mm) min.
2 in. (51 mm) min.
1 in. (25mm) to side of appliance
(except at nailing flanges where it is 1/2 in. [13 mm])
1 in. (25 mm) to back
of appliance
0 in.
to floor
0 in. to level
of standoffs
2 in.
(51 mm)
min.
36 in. (914 mm)
standoffs to ceiling
Chimney air kit required
with SL chimney
11
Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14

1. Minimum Clearances
Position combustible/
non-combustible mantel:
see table above.
12 in.
(305 mm)
43-7/8 in.
(1114 mm)
24 in.
(610 mm)
2 in.
(51 mm)
48-1/4 in.
(1226 mm)
42-1/4 in.
(1073 mm)
The finished cavity depth must
be no less than 24 in. (610 mm)
from the finished backwall to
the outside of front wall framing.
Figure 3.3 Framing the Fireplace
WITHIN ENCLOSURE AREA
Fireplacetobackwall 1/2in.(13mm)
Fireplacetosidewall 1in.(25mm)
Ductbootstoframing 0in.(0mm)
Topstandoffstoheader 0in.(0mm)
Dooropeningtosidewall 22-7.8in.(581mm)
EXPOSED SURFACES
Faceplatetosidewall 16in.(406mm)
Heatzoneairgrillstoceiling 12in.(305mm)
MANTEL
Non-combustiblemantel
(Non-combustibleframing
materialsabovethereplace
toceiling) 46in.(1168mm)
Combustiblemantel
(Combustibleframing
materialsabovethereplace
toceiling) 60in.(1524mm)
Maximummanteldepth 12in.(305mm)
12 Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14
►

C. Construct the Chase
Achaseisaverticalboxlikestructurebuilttoenclosethe
replaceand/oritsventsystem.Verticalchimneysthat
runontheoutsideofabuildingmustbeinstalledinsidea
chase.
Incoldclimates,Hearth&HomeTechnologiesrecom-
mendsthatthechasebewellinsulatedusingbatttype
insulationbetweenthejoists.
Constructionofthechasemayvarywiththetypeofbuild-
ing.Theseinstructionsarenotsubstitutesfortherequire-
mentsoflocalbuildingcodes.LocalbuildingcodesMUST
bechecked.
Chasesshouldbeconstructedinthemannerofalloutside
wallsofthehometopreventcoldairdraftingproblems.
Thechaseshouldnotbreaktheoutsidebuildingenvelope
inanymanner.Allouterwallsneedtobeinsulated.
Buildingcodesrequirefalseceilingandceilingrestops/
atticshieldsateachoorofthechaseorevery10ft(3048
mm)ofclearspacetocontrolspreadofre.
Walls,ceiling,baseplateandcantileveroorattherst
levelofthechaseshouldbeinsulated(seeFigure3.4.)
Vaporandairinltrationbarriersshouldbeinstalledinthe
chaseasperregionalcodesfortherestofthehome.Ad-
ditionally,Hearth&HomeTechnologiesrecommendsthat
theinsidesurfacesbedrywalledandtaped(ortheuseof
anequivalentmethod)formaximumairtightness.
Holesandotheropeningsshouldbecaulkedwithhigh
temperaturecaulkorstuffedwithunfacedberglass
insulation.
Ceiling
Firestop
Metal Chase Top
Round Termination Cap
False Ceiling
Insulation in the
outside walls
of the chase
Attic
Insulation
Shield
Chimney
Ceiling
Firestop
Tabs
False Ceiling
False Ceiling
Insulation
Insulation
Storm Collar
Figure 3.4 Chase Assembly
1 2 3
All outside walls should be insulated.
Figure 3.5 Chase Constructions
1. Fireplaceandchimneyenclosedinanexteriorchase.
 2. Chimneyoffsetthroughexteriorwallandenclosedinchase.
 3. Chaseconstructedonroof.
• Thechaseisconstructedusingframingmaterialsmuch
thesameasthewallsinyourhome.Avarietyofsiding
materials may be used including brick, stone, veneer
brick,orstandardsidingmaterials.
• In constructing the chase, several factors must be
considered:
- Maintain a 2 in. (51 mm) air space around the
chimney.
- The chase top must be constructed of non-
combustiblematerial.
- Incoldclimates,arestopspacerandatticinsulation
shieldshouldbeinstalledinaninsulatedfalseceiling
at the 8 ft. (2438 mm) level above the replace
assembly.Thisreducesheatlossthroughthechase.
- Incold climates, the walls of the chase should be
insulatedtothelevelofthefalseceilingasshownin
Figure3.4.Thiswillhelpreduceheatlossfromthe
homearoundthereplace.
ThreeexamplesofchaseapplicationsareshowninFig-
ure3.5.
WARNING! You must install false ceilings and ceil-
ing restops at each oor of the chase or every 10 ft
(3.05 m) to control spread of re.
WARNING! Risk of Fire! DO NOT sealareabetweenre
stop opening and chimney pipe except where they enter
the attic or leave the warm air envelope of the home (use
600° F sealant).
WARNING! Risk of Fire! You must maintain a minimum
2 in. (51 mm) air space clearance to insulation and other
materials surrounding the chimney system.
• Insulationandothermaterialsmustbermlysecuredto
prevent accidental contact with chimney system.
• Thechasemustbeproperlyblockedtopreventblown
insulation or other combustibles from entering and
makingcontactwithreplaceorchimney.
• Failuretopreventcontactbetweeninsulationorother
materials and chimney system may cause overheating
andre.
13
Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14

D. Frame the Fireplace
NOTICE: Hearth extension design must be determined
beforeinstallationofreplace.
Ifthereplaceisplacedontheoorthemaximumheight
ofanishedraisedhearthis5-3/4”,ifyouwantahigher
raisedhearththereplacemustbeplacedonaplatform.
NOTICE: Wiring for fans must be done before framed
enclosure is completed. If using a Heat Zone Kit, it
also must be installed before enclosure is complete.
TheNorthStarwilltaframedopeningheightof 43-7/8in.
(1114mm)talland42-1/4in.(1073mm)wide.
WARNING! Risk of Fire! You must comply with all
minimum air space clearances to combustibles. DO NOT
pack required air spaces with insulation or other materi-
als.
WARNING! Risk of Fire! Comply with all minimum clear-
ancesspecied.
• A minimum 1 in. (25 mm) air clearance must be
maintained at the back and 1 in. (25 mm) to the sides
ofthereplaceassembly.
• Chimneysectionsatanylevelrequirea2in.(51mm)
minimum air space clearance between the framing and
chimney section.
Figure3.3showsatypicalframing(using2x4lumber)
ofthereplace,assumingcombustiblematerialsare
used.Allrequiredclearancestocombustiblesaroundthe
replacemustbeadheredto.SeeFigure3.2.Anyframing
acrossthetopofthereplacemustbeabovethelevelof
thetopstandoffs.(Norecessabovestandoffs.)
The nished cavity depth must be no less than 24 in.
(610mm)fromthenishedbackwalltotheoutsideoffront
wallframing.Framingmustextendstraightupalltheway
totheceiling.
CAUTION! Risk of Cuts/Abrasions. Wear protective gloves
and safety glasses during installation. Sheet metal edges
are sharp.
WARNING! Risk of Fire! Prevent contact with sagging,
loose insulation.
• DO NOT install against vapor barriers or exposed
insulation.
• Secureinsulationandvaporbarriers.
• Provideminimumairspaceclearancesatthesidesand
backofthereplaceassemblyasoutlinedinSection3.
E. Secure and Level the Fireplace
Thisreplacemaybeplacedoneitheracombustibleor
noncombustiblecontinuousatsurface.Followthein-
structionsforframinginSection3.Slidethereplaceinto
position.Besuretoprovidetheminimum1in.airclear-
anceatthesidesand1in.atthebackofthereplace.
Thereplaceshouldbepositionedsothefaceofthenon-
combustiblematerialonthereplacewillbeushwiththe
faceofthedrywallonthewalls.SeeFigure3.6.
Levelthereplaceandshimasnecessary.Securethe
replace(usingthepalletmountingbracketslocatedon
eithersideofthereplace)tothesuboor.
These surfaces
must be even!
Drywall Non-combustible
facing material
Figure 3.6 Drywall - Non-combustible Facing Material
14 Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14

1in. (25 mm) Overlap
Metal strips 2 in. (51 mm) under edge of Fireplace
and Hearth Extension and extended 2 in. (51 mm)
beyond both sides of fireplace opening.
Nail or screw metal strips in place.
Pallet Mounting/Floor
Brackets
Raised Platform
Floor
2 in.
(51 mm)
1 in. (25 mm) min.
overlap
2 in.
(51 mm)
Top piece must overlap
bottom piece
Figure 3.8 Protect the Front of an Elevated Platform
F. Protective Metal Hearth Strips
Figure 3.7 Position the Protective Metal Hearth Strips
• Locatethetwoprotectivemetalhearthstripsmeasuring
approximately26in.x4in.(660mmx102mm)included
withthisreplace.
• Slideeachmetalstrip2in.(51mm)underfrontedgeof
replace.
• Overlapstripsinthemiddleofreplaceopeningby1in.
(25mm)minimum.
• Metal strips must extend beyond the frontand sides
of the replace opening by at least 2 in. (51 mm),
Figure3.7).
• Protectthefrontofaplatformelevatedabovethehearth
extensionwithmetalstrips(notincludedwithreplace)
per Figure 3.8. See Section 6 for hearth extension
instructions.
WARNING! Risk of Fire! Protective metal hearth
strips MUST be installed on combustible surfaces. DO
NOT cover metal strips with combustible materials.
Sparksorembersmayigniteooring.
WARNING! Risk of re! High temperatures, sparks,
embers or other burning material falling from the
replacemayigniteooringorconcealedcombustible
surfaces.
• ProtectivemetalhearthstripsMUSTbeinstalled.
• Hearth extensions MUST be installed exactly as
specied.
WARNING! Risk of Fire!
Follow these instructions exactly.
Facing materials must be installed properly to prevent
re.
No materials may be substituted without authorization by
Hearth & Home Technologies
G. Facing Material
TOOLS NEEDED: Powered drill with #2 Phillips head bit;
caulkinggun.
Onlynon-combustiblematerials(suppliedwithreplace)
maybeusedtocoverthemetalreplacefront.
NOTE: All boards are pre-drilled for your convenience.
Boards MUST be attached in the following order:
bottom, top, and then the two sides, red-painted side
out. The top and bottom board should each have a hang
tag attached. Leave them attached for referral for the
nishingoperation.
• Attach the bottom board to the bottom of the outer
replacecanwithenclosedscrews,ensuringtheboard
iscentered.DO NOT remove hang tags.
• Centerandattachthetopboardtotheoutercanand
framingmembers. DO NOT remove hang tags.
• Using the Super Calstick, run a light bead (1/8 in.
minimum) between the metal surface of the replace
andthebuttedgesofthetopboard.SeeFigure3.9.
• Ensuringthetopofthesidepiecesandthetopboard
align,attachthesidepiecestotheoutercanandframing
members.
Figure 3.9 Apply Non-combustible Materials
Side
Board
Bottom
Board
Side
Board
Top
Board
DO NOT
remove hang
tags
Apply bead of
Super Calstick to
edge here
NOTICE: 1/8 in. of the facing material may be visible
afternishingmaterialsareapplied.This1/8in.must
be painted or the red will show.
15
Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14

H. Outside Air Kit
Anoutsideairkitmustbeusedforcombustion.Hearth&
HomeTechnologiesrecommendsyouutilizetheshortest
ductruntooptimizetheperformanceoftheoutsideair
kit.Theoutsideairinlethoodshouldbepositionedina
mannerthatwillnotallowsnow,leaves,etc.toblockthe
inlet.Insomeinstallationstheairductmayneedtoberun
vertically.Insuchaninstallation,a3ft(914mm)height
differencemustbemaintainedfromthetopoftheupper-
mostchimneysectiontotheoutsideairinlethood.
RefertoFigures3.10and3.11whenplacingtheoutside
airinlethood.
Theoutsideairkitisinstalledontherighthandsideofthe
replace.SeeFigure3.12forhandlelocation/operation.
• Cuta6in.(152mm)holeinoutsidewalltoaccommodate
airpiping.
• Use6in.(152mm)metalexorrigidpiping(notsupplied)
todirectlyconnectoutsideairtoreplaceintake.Insulate
thepipetopreventfrostcondensation.
• Usethesuppliedoutsideairinlethood.
• Seal between the wall and the pipe with silicone to
preventmoisturepenetrationandairleaks.
• Sealbetweentheoutsideairinlethoodandthehouse
withsiliconetopreventairinltration.
CAUTION! Risk of Cuts/Abrasions. Wear protective
gloves and safety glasses during installation. Sheet metal
edges are sharp.
CAUTION! Risk of Fire or Asphyxiation! DO NOT draw
outsidecombustionairfromwall,oororceilingcavity,or
enclosed spaces such as an attic or garage.
• DO NOT place outside air inlet hood close to exhaust
vents or chimneys. Fumes or odor could be drawn into
theroomthroughthereplace.
• Locateoutsideairinlethoodtopreventblockagefrom
leaves, snow/ice, or other debris. Blockages could cause
combustion air starvation.
Attic insulation shield
must be used to keep
insulation away from
chimney.
Ceiling firestop
on floor of attic.
3 ft min. from top of
uppermost chimney
section to air inlet.
Figure 3.10 Outside Air Inlet Locations
16 Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14

Outlet blocked by
snow, leaves, etc.
NO
Garage or
combustible
liquids storage
NO
Attic space
NO
Outlet placed
higher than 3 ft
below the
termination cap
NO
UL181 Listed Class 0
or Class 1 metal flex or
rigid duct
Figure 3.11 Outside Air Installation
Figure 3.12 Outside Air
Termination Cap
supplied with
fireplace
UL 181 Listed Class 0 or
Class 1 metal flex or rigid
duct
Open/Close
Knob for
outside air
CLOSE
OPEN
17
Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14

DUCT RUN REQUIREMENTS
MAXIMUMDuctRun=40-ft.(12m)
MINIMUMDuctRun=36in.(914mm)
DUCTING MATERIAL
6in.(152mm)B-VentOnly
DONOTductintoexistingfurnaceplenum
MINIMUM CLEARANCE TO COMBUSTIBLES
1in.(25mm)fromtheB-Vent
1 /2in.(13mm)fromtop&bottomofoutletbox
0in.(0mm)fromthesidesofoutletbox
12in.(305mm)fromwallregistertoceiling
RefertoFigure3.13.
CAUTION! ALLwiringshouldbedonebyaqualiedelec-
trician and shall be in compliance with local codes and
with the National Electric Code NFPA/NEC No. 70-current.
CSC22.1 Canadian Electric Code.
Possible Air Duct Runs / Locations
Figure 3.13 Minimum Clearances to Combustibles
Ceiling Register
Wall Register
Floor Register
Two Duct Kits
Ceiling Register
12 in. (305mm) minimum clearance
from register to ceiling
I. Heat Zone Kit (Optional)
TheHeat-Zoneaccessorykitconveyswarmairfromthe
replacethroughairduct(s)toremotelocationsinthe
sameroomorotherroomsofthebuilding.Youmayinstall
1or2Heat-Zonekitsonthereplace.Installationofthis
kitMUSTbeperformedbyaqualiedservicetechnician.
Ifanypartsaremissingordamaged,contactyourlocal
dealerbeforestartinginstallation.DONOTinstalladam-
agedkit.
Thiskitistestedandsafewheninstalledinaccordance
withthisinstallationmanual.Itisyourresponsibilityto
readallinstructionsbeforestartinginstallationandtofol-
lowtheseinstructionscarefullyduringinstallations.
TheHeat-Zone®Woodkitiscarefullyengineeredand
mustbeinstalledonlyasspecied.Ifyoumodifyitorany
ofitscomponentsyouwillvoidthewarrantyandyoumay
possiblycausearehazard.Installationmustbedone
accordingtoapplicablelocal,state,provincialand/or
nationalcodes.
Planthelocationofthereplaceandwarmairductrun(s).
18 Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14

Installation
• Removetheknockoutorcoverplatefromthetopofthe
replaceanddiscardit.SeeFigure3.14.
• Cuta3in.(76mm)holeintheinsulationboardasper
thedimensionsshowninFigure3.14.
Adapter
Mounting
Plate
Starter Pipe
Knockout
Cut a 3 in. (76 mm)
hole in insulation board
3-13/16 in.
(97 mm)
3-1/8 in. (79 mm)
C
L
Run Length Cut Pipe
20 - 40 ft (6-12 m) 2 in. (51 mm)*
*A minimum of 2 in. (51 mm) pipe must be used to
cover the raw insulation to prevent it from blowing
out through the return air grille.
10 - 20 ft (3 - 6 m) 8 in. (203 mm)
3 - 10 ft (1 - 3 m) No cut needed**
**Use full 16 in. (406 mm) as supplied
• Determinethenecessarylengthofstarterpipefromthe
Table3.1andcutasrequired.
Figure 3.14
• Slide the starter pipe into the replace, matching the
holesintheplatetotheholesinthereplace.
• Placetheadapteronthemountingplateliningupholes.
Usingfoursheetmetalscrewsincludedinthekit,secure
the adapter and mounting plate into replace.After
securingtothereplace,tapedowntheadapteredges
tothetopofthereplacewithaluminumtapetoprevent
leakage.
• Determine the location for the air register and fan
housingassembly.Cuta7-5/8in.x13-5/8in.(143mm
x346mm)holebetweenframingmembers(wallstuds
oroorjoists).Thebracketscan berotated180°and
mountedtothebacksideofthe2x4ifnecessary.See
Figure3.16.
NOTICE: The fan and electrical connections must be
accessible for servicing per local code requirements.
NOTICE: If the fan housing is installed in a 2 x 4 wall,
the front of the housing will protrude approximately 1/4
in.(6mm)fromthenishedwall.
• Attachenough 6 in. (152mm) B-Vent as required for
yourinstallationtothefanhousing.A maximum of (4)
90° elbows is recommended. Securely twistlockthe
B-Venttotheadapter.
 AlsoscrewtheB-Venttotheoutletboxonthefan
housing.SeeFigure3.17. Supportductatintervals
ofnogreaterthan4ft(1m)asrequiredbylocalcode.
Figure 3.15
WARNING! Risk of Fire! Comply with all minimum
clearancesspecied.
• A minimum 1 in. (13 mm) air clearance must be
maintained at the back and 1 in. (25mm) to the sides
ofthereplaceassembly.
NOTE: It is important the pipe length be adhered to
or it will affect the performance of your replace.
• Onthemountingplate,handbendthetabsdownward.
Slidethetabsovertheoutsideofthestarterpipe.Secure
with four sheet metal screws included in fasteners
package.Figure3.15.
Table 3.1
19
Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14

Securely Twist
Lock B-Vent to
Adapter
Secure B-Vent to Fan Housing
with sheet metal screws
Return Air Grille
Install with Louvers
pointed down
Bracket
Can rotate
180
o
2 x 4 Wall
Fan Housing
1/2 in. (13mm)
clearance to
combustibles
must be
maintained.
2 x 4 wall
Sheet Rock
Leave 1/4" (6mm) clearance
from all 4 outer edges
Seal grille using gasketing supplied with the kit
• Installthevariablespeedwallrheostat(withsettingon
“OFF”)inaconvenientlocation.Thisswitchwillcontrol
theHeat-Zonefanoperation.
• Remove the junction box. Wire 110 VAC serviceTO
the wall rheostat and FROM the wall rheostat to the
fanjunctionbox.Usewirenutstosecurethe110VAC
servicewirestothehot(black)andneutral(white)fan
wiresandscrewthe110VACgroundwiretothejunction
box.SeeFigure3.19.
• Securethereturnairgrilletothefanhousingmaking
sure it is ush. The grille must be installed with the
louverspointingdown.
NOTICE: DO NOT USE ADJUSTABLE REGISTERS.
Junction Box Removed
Wire Clamp
Wire Nuts
Junction Box
Black
White
NOTICE: Secure the duct so that clearance to the re-
place outer wrap is maintained. Tape all seams with alumi-
numtape1-1/4in.(32mm)minimumwidthorasspecied
by local codes.)
• Sealallthewayaroundtheinsideofthereturnairgrilleto
preventhotairbeingdrawnbackintotheventingsystem
usinggasketingsuppliedwiththekit.Leave1/4in.(6
mm)clearancefromallfourouteredges.Trimexcess
gasketing.SeeFigure3.18.
Figure 3.16
Figure 3.17
Figure 3.18
Figure 3.19
20 Heat & Glo • NORTHSTAR • 480-2360 Installation Manual • Rev H • 8/20/14
