Heat Surge Power Panel User manual

HEATER MANUAL
Genuine Heat Surge
Power Panel

You made a smart choice and improved your life with your new Heat
Surge Power Panel.
Your new Heat Surge Power Panel is the most up-to-date latest technology
that gives you happiness keeping you comfortable and warm. Your Power
Panel saves you money by turning down your household thermostat and
zone heating the rooms your live in the most.
1. Congratulations on your new Heat Surge Power Panel:
Your new Heat Surge Power Panel includes a recessed handle and is easily
portable from room to room and is ideal for transitional heating. Your new
Power Panel features technologically advanced heating elements and your
heater has been designed to be ultra light weight.
Your new Heat Surge Power Panel includes an advanced Turbo Blower for
heating individual rooms. The natural convection as heat rises and extra boost
of healthy warm air circulation is intensified by the Turbo Blower as needed.
Set the thermostat to the desired temperature with the Temperature Control
knob and your Power Panel will economically maintain the temperature. The
Power Panel only uses electricity as needed, saving on your overall energy
usage.
To warm up a cold room, start by turning the Temperature Control knob
clockwise to the highest temperature MAX. Be sure on the 24 Hour On/
Off Multiple Timer that the Large Red Switch is in Position "1" (Continuous
Run) or in Position "Clock" for 24 Hour Multiple Timer Function. If the 24
Hour Multiple Timer is in Position "0" the entire Power Panel is turned off
and will not heat. Be sure the 24 Hour Multiple Timer Large Red Switch is in
Position "1" or Position "Clock" in order to heat. Note: for the Power Panel
to heat when the Large Red Switch is in "Position Clock", you must
set the Small Red Time Selector Sliders towards the outer edge of the
round Timer Circle. The Power Panel will only heat during the times
1

that are selected. If you do not select any times and all the Small Red
Time Selector Sliders are set on the inner circle, the Power Panel will
not heat. Most Power Panel Users simply put the Large Red Switch in
Position "1" Continuous ON Mode, and do not need the 24 Hour On/
Off Timer function. The 24 Hour On/Off Multiple Timer is discussed in
more detail in Section 5.
Use the 5-Position Mode knob to select the Power Panel high/medium heating
function and combination high/medium Turbo Blower function for maximum
heating comfort and air circulation. Select Heat-Only or Heat with Turbo
Blower.
2. Set It and Forget It Temperature Control:
Once the desired temperature is reached, turn the thermostat counterclockwise
until it reaches the thermostat set point and the Power Panel goes into Standby
Heat Mode indicated by an audible "click" and the Active Heat Status Light
going out. The Active Heat Status Light will come back on as needed.
The set room temperature is maintained at this time. As the room temperature
goes down, the Power Panel will automatically actively heat the room again
as the set temperature is maintained.
3. Your new Heat Surge Power Panel’s technical data:
Description Rated Power Voltage Frequency
Power Panel with Turbo
Blower/ 24 Hour Timer
1500W 120V 60Hz
Rated Power Stages:
1. Heating Stage 750W with or without Turbo Blower
2. Heating Stage 1500W with or without Turbo Blower
2

4. Installation & Construction:
Before using your new Heat Surge Power Panel, you must mount the feet :
Simply secure the feet to the bottom with a Phillips head screwdriver.
Air outlet
Mode and
Turbo Blower
Selector
Turbo Blower
Vent
Temperature
Control
Active Heat
Status Light
Handle
24 Hour
Multiple Timer
Feet
3

5. 24 Hour On/Off Multiple Timer:
Large Red Switch: In Position "0" the entire Power Panel is turned OFF and will not
heat. Move the Large Red Switch to Position "Clock" or Position "1" (Continuous
Run). Most times you may simply want to leave the Large Red Switch in Position "1".
With the Power Panel plugged in, the 24 Hour Multiple Timer will always be moving.
If you desire to use the 24 Hour Multiple Timer, set the current time of day by turning
the outside of the Timer Circle with the 24 hours display to the approximate current
time lined up with the Time of Day Triangle Arrow. Your 24 Hour Multiple Timer
is now ready to set times to turn ON the Power Panel, and times to turn OFF the
Power Panel. Multiple ON and Off times can be selected during the day.
With the Large Red Switch in Position "Clock", you can choose which times you
want the Power Panel to turn on and off automatically. Times that the Power
Panel will be turned ON are selected by moving the Small Red Sliders OUT, to
the OUTSIDE of the Timer Circle. Small Red Sliders left IN, to the INSIDE of the
Timer Circle, indicate the times that the Power Panel will be OFF.
Example: Many people choose to have the Power Panel on at 4:55am and turn off
at 9:00am, and back on at 4:55pm and turn off at midnight. This Timer Scenario
looks like this:
Timer Scenario Shown: ON at 4:55 am, OFF at 9:00 am,
ON at 4:55 pm (16:55 military time), OFF at 24:00.
OFF ON
Small Red
Sliders out
ON
OFF
Small Red
Sliders in
OFF
ON
Small Red
Sliders out
ON
OFF
Small Red
Sliders in
Large Red
Switch
Time of Day
Triangle Arrow
Timer Circle
Off
Timer
Continuous
Time of
Day Rotate
4

6. Safety:
The Power Panel is not designed for use in bathrooms, washrooms or other
damp areas.
WARNING: The upper air outlet area and grilles of the unit must not be
covered or near curtains or blankets. Keep a clear space of at least 1 foot
around the Power Panel at all times.
After use, power off the Power Panel. Some sounds of the Turbo Blower
cooling down the unit after turning off is normal.
Children or persons who lack knowledge or experience with the Power Panel,
or who are restricted in their physical, sensory or mental capabilities should
not use without supervision or instruction by a person responsible for their
safety.
7. Care and Maintenance:
Disconnect the Power Panel from the power outlet before cleaning. Wait, if
necessary, until it has cooled to normal temperature. Clean the vents and
Turbo Blower intake with a soft brush or vacuum.
The sides and ends can be wiped off with a soft, dry cloth. If heavily soiled,
use a slightly damp cloth. Do not use abrasive cleaners.
8. One Year Limited Warranty for New Units:
Your 1 year limited warranty applies to replacement of product found to
be defective in material or workmanship. This warranty does not apply to
damage resulting from commercial, abusive, unreasonable use or supplemental
damage. Defects that are the result of normal wear and tear will not be
considered manufacturing defects under this warranty. Heat Surge is not
liable for incidental or consequential damages of any nature. Any implied
warranty of merchantability of fitness for a particular purpose on this product
5

is limited in duration to the duration of this warranty. Some jurisdictions do
not allow exclusion or limitation of incidental or consequential damages or
limitations on how long an implied warranty lasts, so the above limitations or
exclusions may not apply to you. This warranty gives you specific legal rights,
and you may also have other rights which vary from jurisdiction to jurisdiction.
This warranty applies only to the original purchaser of this product from the
original date of purchase.
At its option, Heat Surge will repair or replace this product if it is found to
be defective in material or workmanship. While within the warranty period,
defective product may be returned to Heat Surge. Please use email at:
[e-mail]
Please contact Heat Surge to obtain a return authorization number prior to
returning unit. Please return unit in original packaging to avoid unnecessary
delays and/or fees.
9. Customer Satisfaction
If you experience a problem, please contact Heat Surge Customer Service
at [e-mail] or mail questions or comments to:
Heat Surge Customer Satisfaction Dept., P.O. Box 9902 Canton, OH 44711
10. Congratulations Again on Your New Heat Surge Power Panel:
You now have in your possession a Genuine Heat Surge Power Panel.
Continuing our mission to revolutionize warmth and happiness across America!
www.HeatSurge.com
6

©2021 HS M4636 BR22388R-1
P.O. Box 9902 ■Canton, OH 44711
www.HeatSurge.com
[e-mail]
