Heatilator MEL36 User manual

1
WOODBURNING FIREPLACE
Manufactured Home Approved
Fire Risk.
WARNING
For use with solid wood fuel only.
Other fuels may overre and generate
poisonous gases (i.e. carbon monoxide).
Model(s): • DO NOTstoreorusegasolineorotheram-
mablevaporsandliquidsinthevicinityofthis
oranyotherappliance.
• DO NOToverre.Overringwillvoidyour
warranty.
• Complywithallminimumclearancestocom-
bustiblesasspecied.Failuretocomplymay
causehousere.
WARNING: If the information in these
instructions is not followed exactly, a re
or explosion may result causing property
damage, personal injury, or death.
Owner’s Manual
Operation and Care
WARNING
HOT SURFACES!
Glassandothersurfacesarehotduring
operationANDcooldown.
Hot glass will cause burns.
• DO NOTtouchglassuntilitiscooled
• NEVERallowchildrentotouchglass
• Keepchildrenaway
• CAREFULLY SUPERVISE children in same room as
replace.
• Alertchildrenandadultstohazardsofhightemperatures.
High temperatures may ignite clothing or other ammable
materials.
• Keep clothing, furniture, draperies and other ammable
materialsaway.
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE: DO NOT discard this manual!
Contact your dealer with questions on installation, operation, or service.
Installation and service of this
appliance should be performed by
qualiedpersonnel.Hearth&Home
Technologies recommends HHT
Factory Trained or NFI certified
professionals.
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15
MEL36
MEL42

2
Safety Alert Key:
• DANGER! Indicatesahazardoussituationwhich,ifnotavoidedwillresultindeathorseriousinjury.
• WARNING!Indicatesahazardoussituationwhich,ifnotavoidedcouldresultindeathorseriousinjury.
• CAUTION! Indicatesahazardoussituationwhich,ifnotavoided,couldresultinminorormoderateinjury.
• NOTICE:Indicatespracticeswhichmaycausedamagetothereplaceortoproperty.
Table of Contents
1 Welcome
A.Congratulations 3
B.LIMITEDLIFETIMEWARRANTY 4
2 Product Specic and General Information
A.ApplianceCertication 6
B.VentedGasLogSets,GasInserts,GasLogLightersand
Wood-burningInserts 6
3 Important Safety and Operating Information
A.FireplaceSafety 7
1.ClearSpace 7
2.Grate 8
3.Refractory 8
4.Firescreen 8
5.FlueDamper 8
6.GlassDoors 8
7.Over-FiringYourFireplace 8
8.ChimneyFire 8
B.GeneralOperatingParts 9
1.FlueDamper 10
2.OutsideAir 10
3.GlassDoors 10
C.Fuel 11
1.Hardwoodvs.Softwood 11
2.Moisturecontent 11
3.Seasoning 12
4.StoringWood 12
5.BurningProcess 12
6.CreosoteFormation 12
7.ProcessedSolidFuelFirelogs 12
D.FirstFire 12
E.LightingInstructions 13
4 Maintenance and Service
A.ChimneyInspection 14
B.Creosote(Chimney)Cleaning 14
C.Grate 15
D.GlassCleaning 15
E.AshRemoval 15
F. Refractory 15
5 Troubleshooting
A.FAQs 18
6 Reference Materials
A.ServiceParts 19
B.ContactInformation 24
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15
►
►

3
Readthismanualbeforeinstallingoroperatingthisreplace.
Pleaseretainthisowner’smanualforfuturereferences.
A. Congratulations
Listing Label Information/Location Themodelinformationregardingyourspecicreplacecanbefoundon
theratingplateusuallylocatedinthecontrolareaofthereplace.
1 Welcome
Brand:________________________________________________ ModelName: ___________________________
SerialNumber:__________________________________________ DateInstalled: __________________________
Fireplace Information:
Local Dealer Information
DEALER: Fill in
your name, address,
phone and e-mail
information here and
replaceinformation
below.
DealerName:________________________________________________________
Address:____________________________________________________________
____________________________________________________________
Phone:_____________________________________________________________
E-mail:_____________________________________________________________
Grate Fireplace
Model
Serial
Number
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15
CongratulationsonselectingaHeatilatorwoodburning
replace.TheHeatilatorreplaceyouhaveselectedis
designedtoprovidetheutmostinsafetyandreliability.
Astheownerofanewreplace,you'llwanttoreadand
carefullyfollowalloftheinstructionscontainedinthis
Owner'sManual.PayspecialattentiontoallCautionsand
Warnings.
ThisOwner'sManualshouldberetainedforfuturerefer-
ence.Wesuggestthatyoukeepitwithyourotherimpor-
tantdocumentsandproductmanuals.
YournewHeatilatorwoodburningreplacewillgiveyou
yearsofdurableuseandtrouble-freeenjoyment.Wel-
cometotheHeatilatorfamilyofreplaceproducts!
HeatilatorisaregisteredtrademarkofHearth&Home
Technologies.
FIREPLACE NO.
MODEL NO.
MODEL NO.
MFG. DATE
WARNING: RISK OF
FIRE DAMAGE. REPLACE
GRATE WITH HEARTH & HOME
TECHNOLOGIES
FIRECHAMBER INTENDED FOR USE WITH HEARTH & HOME TECHNOLOGIES LISTED FIREPLACE PARTS. SEE INSTALLATION AND
OPERATING INSTRUCTIONS FOR THIS MODEL. ONLY HEARTH & HOME TECHNOLOGIES GLASS DOOR KITS CAN BE INSTALLED ON THIS UNIT.
FIREPLACE ALSO FOR USE
IN MANUFACTURED HOMES
YES NO
CLEARANCE TO
COMBUSTIBLES:
CHIMNEY
2 IN. MIN.
FIREBOX
IN.
MIN.
FAN KIT
MODEL NO.
&RATED AT
115 VOLTS, 50/60 Hz., AMP.
DO NOT OVERFIRE. USE ONLY: SOLID WOOD FUEL OR
LISTED DECORATIVE GAS APPLIANCE. DO NOT USE A
FIREPLACE INSERT OR OTHER PRODUCTS NOT
SPECIFIED FOR USE WITH THIS PRODUCT. IF DOORS
ARE USED OPERATE FIREPLACE WITH DOORS FULLY
OPEN OR CLOSED ONLY. WHEN BURNING A
DECORATIVE GAS APPLIANCE IN THE FIREPLACE,
ADJUST DAMPER TO THE FULLY OPEN POSITION.
WARNING! THIS FIREPLACE HAS NOT BEEN TESTED WITH AN UNVENTED
GAS LOG SET. TO REDUCE THE RISK OF FIRE OR INJURY, DO NOT
INSTALL AN UNVENTED GAS LOG SET INTO FIREPLACE.
WARNING! THIS APPLIANCE IS NOT FOR USE AS COOKING EQUIPMENT.
IF INSTALLATION OR OPERATING INSTRUCTIONS ARE MISSING
CONTACT: HEARTH & HOME TECHNOLOGIES,
7571 215th Street West, Lakeville, MN 55044.
THIS APPLIANCE HAS BEEN TESTED WITH GRATE AND DOORS CLOSED AND HAS DEMONSTRATED COMPLIANCE
WITH WASHINGTON STATE AMENDMENT TO THE UBC STANDARD, CHAPTER 31-2 REQUIREMENTS.
COMPLIANCE PERIOD: JANUARY 1, 2009 TO JANUARY 1, 2018.
C US

4
X Moldedrefractorypanels
4021-645G2/15 Page1of2
Hearth & Home Technologies
LIMITED LIFETIME WARRANTY
Hearth&HomeTechnologies,onbehalfofitshearthbrands(“HHT”),extendsthefollowingwarrantyforHHT
gas,wood,pellet,coalandelectrichearthappliancesthatarepurchasedfromanHHTauthorizeddealer.
WARRANTY COVERAGE:
HHTwarrantstotheoriginalowneroftheHHTapplianceatthesiteofinstallation,andtoanytransfereetakingownership
oftheapplianceatthesiteofinstallationwithintwoyearsfollowingthedateoforiginalpurchase,thattheHHTappliance
willbefreefromdefectsinmaterialsandworkmanshipatthetimeofmanufacture.Afterinstallation,ifcoveredcompo-
nentsmanufacturedbyHHTarefoundtobedefectiveinmaterialsorworkmanshipduringtheapplicablewarrantyperiod,
HHTwill,atitsoption,repairorreplacethecoveredcomponents.HHT,atitsowndiscretion,mayfullydischargeallofits
obligationsundersuchwarrantiesbyreplacingtheproductitselforrefundingtheverifiedpurchasepriceoftheproduct
itself.Themaximumamountrecoverableunderthiswarrantyislimitedtothepurchasepriceoftheproduct.Thiswarranty
issubjecttoconditions,exclusionsandlimitationsasdescribedbelow.
WARRANTY PERIOD:
Warrantycoveragebeginsonthedateoforiginalpurchase.Inthecaseofnewhomeconstruction,warrantycoverage
beginsonthedateoffirstoccupancyofthedwellingorsixmonthsafterthesaleoftheproductbyanindependent,
authorizedHHTdealer/distributor,whicheveroccursearlier.Thewarrantyshallcommencenolaterthan24months
followingthedateofproductshipmentfromHHT,regardlessoftheinstallationoroccupancydate.Thewarrantyperiodfor
partsandlaborforcoveredcomponentsisproducedinthefollowingtable.
Theterm“LimitedLifetime”inthetablebelowisdefinedas:20yearsfromthebeginningdateofwarrantycoveragefor
gasappliances,and10yearsfromthebeginningdateofwarrantycoverageforwood,pellet,andcoalappliances.These
timeperiodsreflecttheminimumexpectedusefullivesofthedesignatedcomponentsundernormaloperatingconditions.
Seeconditions,exclusions,andlimitationsonnextpage.
Parts Labor Gas Wood Pellet EPA
Wood
Coal Electric Venting
XXXXXXX
Allpartsandmaterialexceptas
coveredbyConditions,
Exclusions,andLimitations
listed
XXX Igniters,electroniccomponents,
andglass
X X X X X Factory-installedblowers
X Firepotsandburnpots
5years 1year X X Castingsandbaffles
7years 3years X X X Manifoldtubes,
HHTchimneyandtermination
10
years
1year X Burners,logsandrefractory
Limited
Lifetime
3years X X X X X Fireboxandheatexchanger
XXXXXXX Allreplacementparts
beyondwarrantyperiod
WarrantyPeriod HHTManufacturedAppliancesandVenting
1Year
ComponentsCovered
3years
2years
90Days
XIgnitionModules
B. LIMITED LIFETIME WARRANTY
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15
►

5
WARRANTY CONDITIONS:
• ThiswarrantyonlycoversHHTappliancesthatarepurchasedthroughanHHTauthorizeddealerordistributor.Alistof
HHTauthorizeddealersisavailableontheHHTbrandedwebsites.
• ThiswarrantyisonlyvalidwhiletheHHTapplianceremainsatthesiteoforiginalinstallation.
•ThiswarrantyisonlyvalidinthecountryinwhichtheHHTauthorizeddealerordistributorthatsoldtheappliance
resides.
• Contactyourinstallingdealerforwarrantyservice.Iftheinstallingdealerisunabletoprovidenecessaryparts,contact
thenearestHHTauthorizeddealerorsupplier.Additionalservicefeesmayapplyifyouareseekingwarrantyservice
fromadealerotherthanthedealerfromwhomyouoriginallypurchasedtheproduct.
• Checkwithyourdealerinadvanceforanycoststoyouwhenarrangingawarrantycall.Travelandshippingcharges
forpartsarenotcoveredbythiswarranty.
This warranty is void if:
• Theappliancehasbeenover-firedoroperatedinatmospherescontaminatedbychlorine,fluorine,orotherdamaging
chemicals.Over-firingcanbeidentifiedby,butnotlimitedto,warpedplatesortubes,rustcoloredcastiron,bubbling,
crackinganddiscolorationofsteelorenamelfinishes.
• Theapplianceissubjectedtoprolongedperiodsofdampnessorcondensation.
• Thereisanydamagetotheapplianceorothercomponentsduetowaterorweatherdamagewhichistheresultof,but
notlimitedto,improperchimneyorventinginstallation.
LIMITATIONS OF LIABILITY:
• Theowner’sexclusiveremedyandHHT’ssoleobligationunderthiswarranty,underanyotherwarranty,expressor
implied,orincontract,tortorotherwise,shallbelimitedtoreplacement,repair,orrefund,asspecifiedabove.Inno
eventwillHHTbeliableforanyincidentalorconsequentialdamagescausedbydefectsintheappliance.Somestates
donotallowexclusionsorlimitationofincidentalorconsequentialdamages,sotheselimitationsmaynotapplytoyou.
Thiswarrantygivesyouspecificrights;youmayalsohaveotherrights,whichvaryfromstatetostate.EXCEPTTO
THEEXTENTPROVIDEDBYLAW,HHTMAKESNOEXPRESSWARRANTIESOTHERTHANTHEWARRANTY
SPECIFIEDHEREIN.THEDURATIONOFANYIMPLIEDWARRANTYISLIMITEDTODURATIONOFTHE
EXPRESSEDWARRANTYSPECIFIEDABOVE.
WARRANTY EXCLUSIONS:
Thiswarrantydoesnotcoverthefollowing:
• Changesinsurfacefinishesasaresultofnormaluse.Asaheatingappliance,somechangesincolorofinteriorand
exteriorsurfacefinishesmayoccur.Thisisnotaflawandisnotcoveredunderwarranty.
• Damagetoprinted,plated,orenameledsurfacescausedbyfingerprints,accidents,misuse,scratches,melteditems,
orotherexternalsourcesandresiduesleftontheplatedsurfacesfromtheuseofabrasivecleanersorpolishes.
• Repairorreplacementofpartsthataresubjecttonormalwearandtearduringthewarrantyperiod.Theseparts
include:paint,wood,pelletandcoalgaskets,firebricks,grates,flameguides,batteriesandthediscolorationofglass.
• Minorexpansion,contraction,ormovementofcertainpartscausingnoise.Theseconditionsarenormalandcom-
plaintsrelatedtothisnoisearenotcoveredbythiswarranty.
• Damagesresultingfrom:(1)failuretoinstall,operate,ormaintaintheapplianceinaccordancewiththeinstallation
instructions,operatinginstructions,andlistingagentidentificationlabelfurnishedwiththeappliance;(2)failureto
installtheapplianceinaccordancewithlocalbuildingcodes;(3)shippingorimproperhandling;(4)improperopera-
tion,abuse,misuse,continuedoperationwithdamaged,corrodedorfailedcomponents,accident,orimproperly/
incorrectlyperformedrepairs;(5)environmentalconditions,inadequateventilation,negativepressure,ordrafting
causedbytightlysealedconstructions,insufficientmake-upairsupply,orhandlingdevicessuchasexhaustfansor
forcedairfurnacesorothersuchcauses;(6)useoffuelsotherthanthosespecifiedintheoperatinginstructions;(7)
installationoruseofcomponentsnotsuppliedwiththeapplianceoranyothercomponentsnotexpresslyauthorized
andapprovedbyHHT;(8)modificationoftheappliancenotexpresslyauthorizedandapprovedbyHHTinwriting;
and/or(9)interruptionsorfluctuationsofelectricalpowersupplytotheappliance.
• Non-HHTventingcomponents,hearthcomponentsorotheraccessoriesusedinconjunctionwiththeappliance.
• Anypartofapre-existingfireplacesysteminwhichaninsertoradecorativegasapplianceisinstalled.
• HHT’sobligationunderthiswarrantydoesnotextendtotheappliance’scapabilitytoheatthedesiredspace.Informa-
tionisprovidedtoassisttheconsumerandthedealerinselectingtheproperappliancefortheapplication.Consider-
ationmustbegiventoappliancelocationandconfiguration,environmentalconditions,insulationandairtightnessof
thestructure.
4021-645G2/15 Page2of2
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15

6
2 Product Specic and General Information
Warning! Risk of Fire!
For use with solid wood fuel only.
Otherfuelsmayoverreandgeneratepoisonousgases
(i.e. carbon monoxide).
B. Vented Gas Log Sets, Gas Inserts, Gas
Log Lighters and Wood-burning Inserts
• Optional
• Vented gas log sets, gas inserts, gas log-lighters or
wood-burninginsertscanbeinstalledinthisreplace.
Followtheinstructionsprovidedwiththeaccessoryfor
operation.
WARNING! Risk of Fire or Asphyxiation!
• DO NOTinstallunventedgaslogs.
• Dampermustbelockedopen.
• Gasamemaygeneratefumes.
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15
A. Appliance Certication
Thisreplacemaybeinstalledinmanufacturedhomes,
exceptinsleepingrooms.
Ifinstalledwithagaslogset,provisionsfortheNational
FuelGasCodemustbemet.
Thisreplacecomplieswiththeinstallationrequirements
forHUD.
CAUTION!Thestructuralintegrityofthemanufactured
homeoor,wall,andceling/roofmustbemaintained.
HeatilatorisaregisteredtrademarkofHearth&Home
Technologies.
Thisreplacesystemhasbeentestedandlistedinaccor-
dancewithUL127andULC-S610standardsbyUnder-
writersLaboratoriesInc.forinstallationandoperationin
theUnitedStatesandCanada.

7
A. Fireplace Safety
Mostproblemsarecausedbyimproperinstallationandop-
erationofthereplace.Toprovidereasonableresafety,
thefollowingshouldbegivenseriousconsideration:
• Thereshouldbesupervisedwheneverthereplaceis
inuse.
• An annual inspection should be performed on the
replacesystem.
• Installatleastonesmokedetectoroneachoorofyour
hometoensureyoursafety.
• InstallaconvenientlylocatedClassAreextinguisher
nearthereplace.
• Deviseapracticedevacuationplan,consistingofatleast
twoescaperoutes.
• Deviseaplantodealwithachimneyre:
- Evacuate.
- Notifytheredepartment.
3 Important Safety and Operating Information
WARNING! Risk of Fire! Hearth & Home Technologies
disclaims any responsibility for, and the warranty and
agencylistingwillbevoidedbythefollowingactions.
DO NOT:
• operatedamagedreplace
• modifyreplace
• overre
• installanyunventedgaslogset
• installanycomponentnotapprovedbyHearth&Home
Technologies
• installpartsorcomponentsnotListedorapproved
• operate the fireplace without fully assembling all
components
Improper installation, adjustment, alteration, service or
maintenancecancauseinjuryorpropertydamage.
1. Clear Space
Combustiblematerialsmustnotbestoredonthehearth
extension.Roomfurnishingssuchasdrapes,curtains,
chairs or other combustibles must be at least 4ft
(1219mm)fromthefrontofthereplace.
Combustible materials are materials made of or sur-
facedwithanyofthefollowingmaterials:
- Wood - Compressedpaper
- Plantbers - Plastic
- Plywood/OSB - Drywall
- Anymaterialthatcanigniteandburn,ameproofed
ornot,plasteredorun-plastered.
WARNING! Risk of Fire! Keep combustible materials,
gasolineandotherammablevaporsandliquidsclearof
thereplace.
DO NOT:
• storeammablematerialsclosetothereplace
• use gasoline, lantern fuel, kerosene, charcoal lighter
uidorsimilarliquidstostartor“freshenup”areinthis
replace.
48 in. (1219 mm)
Clear Space
Front of Fireplace 12 in. (305 mm)
Clear Space
Sides of Fireplace
(from the FP
opening)
40-1/2 in. (1029 mm)
Clear space bottom of
fireplace to lower edge
of mantel or trim
Figure 3.1 Clear Space
Non-combustiblematerialsarematerialswhichwillnot
igniteandburn,composedofany combinationofthe
following:
- Steel - Iron
- Brick - Tile
- Concrete - Slate
- Glass - Plasters
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15

8
8. Chimney Fire
Intheeventofachimneyre
• Havethechimneyandadjacentstructureinspectedby
qualiedprofessionals.Hearth&HomeTechnologies
recommendsthatNFIorCSIAcertiedprofessionals,
or technicians under the direction of certified
professionals,conductaminimumofanNFPA 211
Level 2 inspectionofthechimney.
• Replacecomponentsofthechimneyandreplace
asspeciedbytheprofessionals.
• Ensure all joints are properly engaged and the
chimneyisproperlysecured.
WARNING! Risk of Fire! A chimney re can perma-
nently damage your chimney system. Failure to re-
placedamagedcomponentsandmakeproperrepairs
cancauseastructurere.
7. Over-Firing Your Fireplace
WARNING! Risk of Fire! Donotover-re.
Over-firing may ignite creosote or will damage the
replaceandchimney.
Symptomsofover-ringmayincludeoneormoreofthe
following:
• chimneyconnectororreplaceglowing
• roaring,rumblingnoises
• loudcrackingorbangingsounds
• metalwarping
• chimneyre
Topreventover-ringyourreplace.DONOT:
• useammableliquids
• overloadwithwood
• burntrashorlargeamountsofscraplumber
• permittoomuchairtothere
2. Grate
Thisreplaceisdesignedtobeusedwiththesupplied
grateoroneapprovedbyHHT.
WARNING! Risk of Fire! Use only the factory-sup-
pliedintegralgrate.
• Keepslogsinplace.
• Allowsproperaircirculationaroundthere.
3. Refractory
Therefractoryissuppliedtocontainheatandprovide
anattractiveinterior.
 Itwillbreakdownovertimeandwillneedoccasional
replacement. Small hairline cracks and discoloration
arenormalanddonotaffectitssafety.
WARNING! Risk of Fire! DO NOT burnreplacewith-
out refractory. Use only refractory supplied by Hearth &
HomeTechnologies.
4. Firescreen
The rescreen is provided to control sparks. Keep it
closedwhenthereplaceinuse.
WARNING! Risk of Fire or Burns!
• Screenwillnotpreventburningmaterialsfromfalling
out.
• Screenpullsorhandlesmaybehot.
5. Flue Damper
Theue dampermustbeinthefully openedposition
duringoperationofthereplace.
WARNING! Risk of Fire and Asphyxiation! Open
damperpriortooperatingreplace.Acloseddamper
overresthereplaceandspillssmokeandames
into the room.
6. Glass Doors
Glassdoorsarerequiredinamanufacturedhomein-
stallation.
WARNING! Risk of Fire! InstallONLYdoorsapproved
byHearth&HomeTechnologies.
WARNING! Risk of Fire and Smoke! Fireplace
equipped with doors should be operated only with
doors fully open or doors fully closed. If doors are left
partlyopen, gas and ame maybe drawnout of the
replaceopening.
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15

9
B. General Operating Parts
WARNING! DO NOT operatereplacebeforereadingandunderstandingoperatinginstructions.Failuretooperatere-
placeaccordingtooperatinginstructionscouldcausereorinjury.
WARNING
Hot glass will cause burns.
• DO NOTtouchglassuntilitiscooled
• NEVERallowchildrentotouchglass
• Keepchildrenaway
• CAREFULLYSUPERVISEchildreninsameroomasreplace.
• Alertchildrenandadultstohazardsofhightemperatures.
High temperatures may ignite clothing or other ammable materials.
• Keepclothing,furniture,draperiesandotherammablematerialsaway.
HOT SURFACES!
GlassandothersurfacesarehotduringoperationANDcooldown.
Open
Close
OpenClose
Outside Air
Control Handle
Flue
Damper
Figure 3.2 General Operating Parts
CAUTION! Ifyouexpectthatchildrenmaycomeintocontactwiththisreplace,werecommendabarriersuchasadecorative
screen.Seeyourdealerforsuggestions.
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15

10
2. Outside Air
NOTICE: Useofoutsideairisrequiredinamanufactured
home installation.
3. Glass Doors
• Glassdoorsarerequired in amanufacturedhome
installation.
• RefertoFigure3.3forhowtoproperlyusethem.
1. Flue Damper
RefertoFigure3.2forlocationandoperationofcontrol.
Theuedampermustbeinthefullyopenedposition
duringoperationofthereplace.
Beforelightingthe replace, verify fullyopenposition
bylookingupfromtheinsideofthereplace.
FULLY OPEN
CORRECT
PARTLY CLOSED
INCORRECT
PARTLY OPEN
INCORRECT
FULLY CLOSED
CORRECT
Figure 3.3 Operating Positions of Bi-fold Doors
RefertoFigure3.2forlocationandoperationofcontrol.
The outside air kit supplies some combustion air for
yourreplace.Itmayhelpreducetheeffectsofnega-
tiveairpressure.
Closetheinlettopreventcolddraftswhenthereplace
isnotbeingused
CAUTION! Outside air control handle may be warm.
Adjustbeforelightingre.
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15

11
WARNING! Risk of Fire!
• DO NOTburnwetorgreenwood.
• Wet, unseasoned wood can cause accumulation of
creosote.
Softwoods Hardwoods
• DouglasFir • Oak
• Pine • Maple
• Spruce • Apple
• Cedar • Birch
• Poplar
• Aspen
• Alder
C. Fuel
1. Hardwood vs. Softwood
Yourreplace’sperformancedependsonthequalityof
therewoodyouuse.Onespeciesofwoodvariesvery
little to the other in terms of energy content.All sea-
soned wood contains about 8,000 BTU’s per pound.
Hardwoods have a greater density than softwoods; a
pieceofhardwoodwillcontainabout60%moreBTU’s
than an equal size piece of softwood.A cord of sea-
sonedoak(hardwood)wouldcontainabout60%more
potential energy than a cord of seasoned pine (soft-
wood).
Most softwoods are coniferous. These are trees with
needle-like leaves that stay green all year and carry
their seeds exposed in a cone. Examples of conifer-
oustreesareDouglasr,pine,spruceandcedar.Soft-
woods, being more porous, require less time to dry,
burn faster and are easier to ignite than hardwoods.
Hardwoods are deciduous trees, broadleaf trees that
lose their leaves in the fall. Their seeds are usually
foundwithin a protectivepod or enclosure.Some ex-
amplesofdeciduoustreesareoak,maple,apple,and
birch.However,itshouldbenotedthattherearesome
deciduoustreesthataredenitelynotconsideredhard-
woods such as poplar, aspen and alder. Hardwoods
requiremoretimetoseason,burnslowerandareusu-
allyhardertoignitethansoftwoods.Obviously,youwill
usethe type ofwood that ismost readily availablein
yourarea.However,ifatallpossiblethebestarrange-
mentistohaveamixofsoftwoodandhardwood.This
wayyoucanusethesoftwoodforstartingthere,giv-
ingoffquickheattobringthereplaceuptooperating
temperature.Addthehardwoodforslow,evenheatand
longerburntime.
2. Moisture content
The majority of the problems replace owners expe-
rienceare caused by trying to burn wet, unseasoned
wood.Freshlycutwoodcanbeasmuchwaterasitis
wood,havingamoisturecontentofaround50%.Imag-
ineawoodenbucketthatweighsabout8pounds.Fillit
withagallonofwater,putitinthereboxandtrytoburn
it.This sounds ridiculous butthatisexactly what you
are doing if you burn unseasoned wood. Dead wood
lyingontheforestoorshouldbeconsideredwet,and
requiresfullseasoningtime.Standingdeadwoodcan
beconsideredtobeabouttwo-thirdsseasoned,ifcutat
thedrytimeoftheyear.
Burningwet,unseasonedwoodwillproducelessheat
outputbecause it requiresenergyin theformof heat
toevaporatethe watertrappedinside.Thisiswasted
energythatshouldbeusedforheatingyourhome.This
moisture evaporates in the form of steam which has
a cooling effect in your rebox and chimney system.
Whencombinedwithtarandotherorganicvaporsfrom
burningwooditwillformcreosotewhichcondensesin
therelativelycoolreboxandchimney.
Even dry wood contains at least 15% moisture by
weight,andshouldbeburnedhotenoughtokeepthe
chimneyhotforaslongasittakestodrythewoodout
-aboutonehour.Totellifwoodisdryenoughtoburn,
checktheendsofthelogs.Iftherearecracksradiating
inalldirectionsfromthecenter,itisdry.Ifyourwood
sizzlesinthere,eventhoughthesurfaceisdry,itmay
notbefullycured.
WARNING! For use with solid wood fuel only.
Otherfuelsmayoverreandgeneratepoisonousgases(i.e.
carbon monoxide).
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15

12
5. Burning Process
Firerequiresfuel,airandheat.Ifheatisrobbedfrom
thereplace duringthe dryingstage, thenew loadof
woodhasreducedthechancesforagoodcleanburn.
Alwaysburndry,seasonedrewood.
6. Creosote Formation
Whenwoodisburnedslowly,itproducestarandother
organicvaporswhichcombinewithexpelledmoisture
to form creosote. The creosote vapors condense in
the relatively cool chimney ue of a newly-started or
a slow-burning re.As a result, creosote residue ac-
cumulatesontheuelining.
When ignited, creosote creates an extremely hot re
which may damage the chimney or even destroy the
house.
Thechimneyshallbe inspected atleastannually be-
forelighting,oronceeverytwomonthsduringheating
season.
Whencreosotehasaccumulateditshallberemovedto
reducetheriskofachimneyre.
7. Processed Solid Fuel Firelogs
Manufacturedrelogsmaybeusedwiththisreplace.
Hearth&HomeTechnologiesrecommendstheuseof
ULClassiedprocessedfuelrelogs.Followthemanu-
facturer’slightingandsafetyinstructions.
Usingrelogsmayrequire more frequent chimney in-
spectionsandcleaning.
Donotpokeorstirthelogswhiletheyareburning.Use
only relogs that have been evaluated for the appli-
cation in manufactured replaces and refer to relog
warningsand cautionmarkings onpackaging priorto
use.
3. Seasoning
Seasonedrewoodisnothingmorethanwoodthatis
cuttosize,splitandairdriedtoamoisturecontentof
around20%.Thetimeittakestoseasonwoodvaries
fromaroundninemonthsforsoftwoodstoaslongas
eighteenmonthsforhardwoods.Thekeytoseasoning
woodistobesureithasbeensplit,exposingthewet
interiorandincreasingthesurfaceareaofeachpiece.
A tree that was cut down a year ago and not split is
likelytohavealmostashighamoisturecontentnowas
itdidwhenitwascut.
Toseasonwood:
• Cutlogstosize
• Splitto6in.(152mm)orless
• Airdrytoamoisturecontentofaround20%
 - Softwood-aboutninemonths
 - Hardwood-abouteighteenmonths
NOTICE: Seasoningtimemayvarydependingondrying
conditions.
4. Storing Wood
Splittingwoodbefore it isstoredreduces drying time.
Thefollowingguidelinewill ensure properly seasoned
wood:
• Stackthewoodtoallowairtocirculatefreelyaround
andthroughthewoodpile.
• Elevate the woodpile off the ground to allow air
circulationunderneath.
• Thesmallerthepieces,thefasterthedryingprocess.
Anypieceover6in.(152mm)indiametershouldbe
split.
• Woodshouldbestackedsothatbothendsofeach
pieceareexposedtoair,sincemoredryingoccurs
throughthecutendsthanthesides.Thisistrueeven
withwoodthathasbeensplit.
• Storewoodundercover,suchasinashed,orcovered
withatarp,plastic,tarpaper,sheetsofscrapplywood,
etc.,asuncoveredwoodcanabsorbwaterfromrain
or snow, delaying the seasoning process.Avoid
covering the sides and ends completely. Doing so
maytrapmoisturefromthegroundandimpedeair
circulation.
D. First Fire
Beforelightingyourrstreinthereplace,makecertain
that:
• refractoryisinplace
• alllabelshavebeenremovedfromglassandtrim.
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15

13
WARNING! Risk of Fire! Keep combustible materials,
gasolineandotherammablevaporsandliquidsclearof
thereplace.
DO NOT:
• storeammablematerialsclosetothereplace
• use gasoline, lantern fuel, kerosene, charcoal lighter
uidorsimilarliquidstostartor“freshenup”areinthis
replace.
E. Lighting Instructions
NOTICE: Youmustestablishagooddrafttopreventsmoke
spillageintotheroom.
Therstthreeorfourresshouldbeofmoderatesizeto
allowtheoilsandbinderstobeburnedfromthereplace
andtherefractoryandpainttocure.Youmaynoticeanin-
dustrialodortherstfewres.Thisisconsiderednormal.
Usewell-seasonedwood.
• Opentheuedampertoafullyopenposition.
• Place crumpled or twisted paper under the replace
grate.
• Looselyarrangekindlingorsmallpiecesofwoodtoform
a‘tent’onthereplacegrate.
• Pre-warm the ue to establish a draft to help reduce
smokespillageduringstart-up.Holdarolleduppiece
ofburningnewspaperundertheuedamperforafew
moments.
• Lightthecrumpledpapertoignitethekindling.
• Addsmallpiecesofwooduntilahotbedofembershas
beenestablished.
• Add a minimum of three average size pieces of split
rewood, placed to allow combustion air and ames
betweenthem.
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15

14
Figure 4.1 Chimney & Termination Cap Cleaning
4 Maintenance and Service
WARNING! Hot Surfaces!
GlassandothersurfacesarehotduringoperationANDcool
down. DO NOTcleanreplaceuntilitiscooled.
Installationandrepairshouldbedonebyaqualied
servicetechnicianonly.Thereplaceshouldbeinspected
beforeuseandatleastannuallybyaprofessionalservice
person.
Thefollowingtasksmaybeperformedannuallybythe
homeowner.Ifyouareuncomfortableperforminganyof
thelistedtasks,please contact your dealer for a ser-
vice appointment.
A. Chimney Inspection
Frequency: Asnecessary;atleastannuallybefore
lightingreplace,oronceeverytwomonthsduring
heatingseason.
By: Homeowner/ChimneySweep
• Confirm that termination cap remains clear and
unobstructed.
• Inspectforblockagessuchasbirdnests,leaves,etc.
• Inspectforcorrosionorseparation.
• Inspectforcreosoteandremoveasneeded,atleast
everytwomonthsduringtheheatingseason.
• Inspectthesystematthereplaceconnectionand
atthechimneytop.
Inthe event of a chimneyre, Hearth & HomeTech-
nologiesrecommendsreplacementofthechimneyand
inspectionoftheadjacentstructuretotheprovisionsof
NFPALevelIIIinspectioncriteria.
WARNING! Risk of Asphyxiation and Fire! Annual
inspectionbyqualiedtechnicianrecommended.
 Check:
 • conditionofdoors,surroundsandfronts
 • conditionofglassandglassassembly
 • obstructionsofcombustionandventilationair
 • obstructionsofterminationcap
 Clean:
 • glass
 • airpassageways,grilles
WARNING! Risk of Fire! Ignitedcreosoteisextremely
HOT. Prevent creosote buildup.
B. Creosote (Chimney) Cleaning
Frequency: Asneeded;atleastannuallybeforelight-
ing,oronceeverytwomonthsduringheatingseason.
Whencreosotehasaccumulateditshallberemoved
toreducetheriskofachimneyre.
By: ChimneySweep
Tools Needed:Brush,Phillipsscrewdriver
• When wood is burned slowly, it produces tar and
otherorganicvapors,whichcombinewithexpelled
moisture to form creosote. The creosote vapors
condense in the relatively cool chimney ue of a
slow-burning fire.As a result, creosote residue
accumulates on the ue lining. When ignited, this
creosotemakesanextremelyhotre.
• Removeallashfromthereboxandextinguishall
hot embers before disposal.Allow the replace to
coolcompletely.
• Closethedoortightly.
• Removethetopoftheterminationcapasshownin
Figure4.1tocleanthecapandchimney.
• Thecreosoteorsootshouldberemovedfromthe
chimneywitha brush specically designedforthe
sizeofchimneyinuse.
• Reinstallterminationcap.
• Cleanoutfallendebrisfromtherebox.
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15
Chimney
Cap
Remove screws,
lift top cover.
Top Cover
TR344
Round
Termination Cap

15
F. Refractory
Frequency: Aftereachashremoval
By: Homeowner
• Inspect condition of refractory. Replace if crumbly
orotherwisedeteriorated,orifcracksexceed1/4in.
(6mm).
C. Grate
Frequency: Aftereachashremoval
By: Homeowner
Inspectgratefor:
• Warpingorsagging1-1/2in.(38mm)ormore
• Brokenwelds
• Burn-throughofgratebars
 Forsafeoperation,replaceonlywiththeapprovedgrate
fromHearth&HomesTechnologies.
E. Ash Removal
Frequency: Asnecessary
By: Homeowner
Tools Needed:Coveredmetalcontainer,metal
shovel,replacebroom
WARNING! Risk of Fire! DO NOT remove ashes until
thereisoutandthereplaceiscold.
• Ashesshouldbeplacedinmetalcontainerwithtight
ttinglid.
• The closed container of ashes should be placed
on a noncombustible oor or on the ground, well
awayfromallcombustiblematerials,pendingnal
disposal.
• If the ashes are disposed of by burial in soil or
otherwiselocallydispersed,theyshouldberetained
in the closed container until all cinders have
thoroughlycooled.
D. Glass Cleaning
Frequency: Asnecessary
By: Homeowner
Tools Needed:Vinegarorglasscleaner,softtowel
• Cleanglasswithanon-abrasiveglasscleaner.Usea
dampclothdippedinwoodashesoracommercially
availableovencleaner.Removeanyoven cleaner
residuewithaglasscleanerorsoapandwater.
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15

16
5 Troubleshooting
Start Fire Problems Possible Cause Solution
Can’tgetrestarted
Excessivesmokeorspillage
Burnstooslowly
Smolders,sizzles
Notenoughkindling/paperorno
kindling/paper
Usedrykindling,morepaper.Arrangekindling&woodfor
airmovement.
Damperclosed/notfullyopen Opendamper.
Notenoughairforretoignite Checkforrestrictedcap/shroud.
Openairkit(ifinstalled).
Checkforueblockage.
Pre-warmuebeforestartingre(refertostartingre
section).
Checkforadequateventheight(refertochimney
assemblysection).
Openwindowbelowthereplacetowardsthewind.
Woodconditionistoowet,toolarge Usedry,seasonedwood(refertowoodfuelsection).
Bedofcoalsnotestablishedbefore
addingwood
Startwithpaper&kindlingtoestablishbedofcoals(refer
tostartingresection).
Flueblockagesuchasbirds’nests
orleavesinterminationcap
Havechimneyinspectedforcreosoteandcleanedbya
certiedchimneysweep.
Downdraftornegativepressure
Competitionwithexhaustdevices
Donotuseexhaustfansduringstart-up(refertonegative
pressuresection).
Openwindowbelowthereplacetowardsthewind.
Fireburnstoofast Extremelydryorsoftwood Mixinhardwood.
Mixinlessseasonedwoodafterreisestablished(refer
towoodfuelsection).
Noglassdoors Addglassdoorstoslowdownairow.
Overdrafting Checkforcorrectventheight;toomuchverticalheight
createsoverdrafting.
Checklocationofventtermination(refertochimney
assemblysection).
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15

17
Another appliance in
home also exhausting
air (furnace, fan,
dryer, etc.)?
Air register from
furnace near
fireplace?
Doors opening
and closing?
Window closed
for start-up?
Outside air
closed?
Overhead fan
operating?
Overhanging
tree?
Bird's nest
or leaves in
termination
cap?
Structural
changes in
chimney area?
Creosote buildup
in flue?
S
t
r
o
n
g
w
i
n
d
s
a
r
o
u
n
d
c
h
i
m
n
e
y
t
e
r
m
i
n
a
t
i
o
n
?
Unsealed
can lights?
Combustion
air control
Figure 5.1 Factory-built Fireplaces: Troubleshooting
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15

18
A. FAQs
Ifsmokespillageoccursfromareplaceopeningwhen
thedoorisopen,thereiseitheraleakageintheue,a
blockageintheue,orsomeconditionisaffectingdraft
Understandinganddifferentiatingtheconditionswhich
cancauseeachofthesekindsofspillageproblemsis
essentialtotheirsolution.
• FlueLeakage
 Check for improperly connected flue joints or a
damaged ue joint in the chimney system. Such
leakagewouldreducedraft(airwouldbedrawnin
throughtheleaksratherthanthroughthereplace).
The result might be difficult start-up and smoky
resthatmightspillifotheradversedraftconditions
accompanythisproblem.
• FlueBlockage
 Thedampershouldbeopen.
 Check for objects that may have fallen down the
chimney.
eratinginstructions,“StartingaFire”.Besureyourue
systemisinstalledcorrectlyandthatitistheproperdi-
ameterandheight.Checkforthefollowing:
• Allchimneysectionsareproperlyinstalled.
• Thechimney iscleanandfreeofcreosoteor soot
buildup.
• Makesureoverhangingtreesandbranchesarecut
backwithintenfeetofthetopofthechimneyandthe
chimneyisfreeofdebrisfromanimals.
• Ensure the chimney cap is clean and free of any
buildupofsootorcreosoteifcapisequippedwitha
sparkarrestorscreen.
• Thewoodbeingusedindryandwellseasoned.
Ifyoustillsuspectyouhavealowdraftproblemitmay
be necessary to increase the volume of air in your
uesystem.Sincethediameterofyouruesystemis
matchedwiththesizeoftheuecollarandshouldnot
bechanged,thentheheightofthesystemmustbein-
creased.Addchimneysectionsoneatatimeuntilthe
draftimproves.
Insomecases,regardlessofwhatyoudo,itcanstillbe
difculttoestablishtheproperuedraft.Thisisespe-
ciallyevidentwhenusinganexteriorfactory-builtchim-
neyorexteriormasonrychimney.Tryholdingaburning
rolledupnewspaperasclosetotheueoutletaspos-
sibleforafewminutes,thenlightthepaperunderthe
kindling.Theheatgeneratedfromtheburningrolledup
newspapershouldhelpgetthedraftestablished.
Stillotherfactorscanaffecthowwellyouruesystem
performs.Neighboringstructures,highwinds,talltrees,
evenhillsidescanaffectaircurrentsaroundthechim-
ney.Welldesignedchimneycapsareavailablethatcan
help. Your replace dealer is the local expert in your
area. He can usually make suggestions or discover
problems that can be easily corrected allowing your
replacetooperatecorrectlyasithasbeendesigned,
providingsafeandeconomicalheatforyourhome.
Flue draft is measured as negative pressure in the
chimney.Theamountofnegativepressuredetermines
howstrongthedraftis.Thedraftisimportantbecause
itdrawsthecombustionairintothereplaceandpulls
thesmokeoutofthechimney.
Therearethreebasiccriteriaessentialinestablishing
andmaintaininguedraft:
• availabilityofcombustionair
• heatgeneratedfromthere
• diameterandheightoftheuesystem
Thesethreefactorsworktogetherasasystemtocreate
theuedraft.Increasingordecreasinganyoneofthem
willaffecttheothertwoandthuschangetheamountof
draftintheentiresystem.
Ifthereishardtostartandsmokespillsoutofthere-
place,oryounditdifculttoestablishandmaintaina
moderatelyhighburnrate,thentheuedraftistoolow
andcorrectivemeasuresmustbetaken.
Besureyouhaveairavailableforcombustionandthat
yourrewoodisdryandwellseasoned.Buildyourres
properlyandaccordingtotheinstructionsgiveninop-
Hearth&HomeTechnologiesassumesnoresponsibil-
ity for the improper performance of the replace sys-
temcaused byinadequatedraftduetoenvironmental
conditions, down drafts, tight sealing construction of
thestructure,ormechanicalexhaustingdeviceswhich
willcreateanegativeairpressurewithinthestructure
wherethereplaceislocated.
Contact your dealer for additional informa-
tion regarding operation and troubleshoot-
ing. Visit www.heatilator.com to nd a
dealer.
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15

19
6 Reference Materials
A. Service Parts
Service Parts
Beginning manufacturing Date: Nov 2009
Ending Manufacturing Date: May 2014
Reactivated Manufacturing Date: Oct 2014
MEL36-B, MEL36-BK
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor.
Hearth and Home Technologies does not sell directly to consumers. Provide model
number and serial number when requesting service parts from your dealer or distributor.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
1 Starter Section Assembly 22069B Y
2 Damper Kit 4044-029 Y
3 Damper Weight 19785A
4 Damper Rod 28900
5 Damper Blade Assembly 4044-030
6 Damper Control 4044-152
7 Top Standoff Qty 4 req 4044-111
8 Door Track (used for upper) 15425
9 Extended Smoke Shield Kit 4044-179
10 Refractory Retainer Qty 3 req 11847
11 Side Refractory Qty 2 req 4044-114
12 Back Refractory 4044-130
13 Hearth Refractory 4044-129
14 Hearth Retainer 4044-128
15 Grate Retainer Qty 2 req 4044-170
16 Grate GR41 Y
17 Firescreen Assembly Qty 2 req 4044-028 Y
18 Firescreen Rod 4044-175 Y
19 Firescreen Handle 10002
Additonal service parts on following page 8/15
36” Woodburning Fireplace
9
15
18
17
14
16
13
3
1
4
5
6
7
2
8
12
19
(Air Handle)
10
11
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15
►

20
Service Parts
Beginning manufacturing Date: Nov 2009
Ending Manufacturing Date: May 2014
Reactivated Manufacturing Date: Oct 2014
MEL36-B, MEL36-BK
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor.
Hearth and Home Technologies does not sell directly to consumers. Provide model
number and serial number when requesting service parts from your dealer or distributor.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
Door Pivot Clip Qty 2 req 31527
Door Replacement, Black DM1036
Left Door Assembly 23216
Right Door Assembly 23203
Fastener Pack 12010B
Smoke Shield Kit Installation Instructions 4044-165
Hair Pin Clip Pkg of 24 101025/24 Y
Nailing Flange Qty 4 req 4044-161
Outside Air Plate 4044-182
Outside Air Tube Assembly 31494
Smoke Bafe Qty 2 req 4044-116
Strip Protector Qty 2 req 18320
Component Pack Assembly:
(Includes OA Assembly, Fastener Pack, UD6 Duct, 2
Cable Ties, Installation Manual, and Owner’s Manual)
SRV4044-057
OA Assembly 4044-051
OA Plate 4044-182
OA Ring 4044-183
Fastener Pack 4025-023
UD6 Duct 4021-632
Installation Manual 4044-212
Owner’s Manual 4044-211
Heatilator • MEL36, MEL42 Owners Manual • 4044-211 • Rev D • 08/10/15
