6 7058-206C 05/06/2015
HEATILATOR ECO CHOICE
Model ECO-ADV-PS35, ECO-ADV-PS50
and ECO-CAB50
Laboratory Intertek
Report No. 3198406
Type Solid Fuel Room Heater/Pellet Fuel
Burning Type
Standard ASTM E1509-04 and ULC S627-00,
ULC/ORD-C1482-M1990 Room Heater
Pellet Fuel Burning type and (UM) 84-
HUD, Mobile Home Approved.
FCC Complies with Part 15 of FCC Rules.
Operation is subject to the following
two conditions: (1) this device may not
cause harmful interference, and (2) this
device must accept any interference
received, including interference that may
cause undesired operation.
B. BTU & Efficiency Specifications
1 Listing and Code Approvals
A. Appliance Certification
NOTICE: This installation must conform with local codes. In
the absence of local codes you must comply with the ASTM
E1509-04, ULC S627-00, (UM) 84-HUD and ULC/ORD-
C-1482.
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
For assistance or additional information, consult a qualified
installer, service agency or your dealer.
• Installation and use of any damaged appliance.
• Modification of the appliance.
• Installation other than as instructed by Hearth & Home
Technologies.
• Installation and/or use of any component part not approved by
Hearth & Home Technologies.
• Operating appliance without fully assembling all components.
• Operatingappliancewithout legsattached (ifsuppliedwith unit).
• Do NOT Overfire - If appliance or chimney connector glows,
you are overfiring.
Any such action that may cause a fire hazard.
WARNING
Fire Risk.
Hearth & Home Technologies disclaims any
responsibility for, and the warranty will be voided by,
the following actions:
C. Glass Specifications
This stove is equipped with 5mm ceramic glass. Replace
glass only with 5mm ceramic glass. Please contact your
dealer for replacement glass.
D. Electrical Rating (on high)
Model PS35: 115 VAC, 60 Hz, Start 3.8 Amps, Run 1.3 Amps
Model PS50: 115 VAC, 60 Hz, Start 5.1 Amps, Run 3.0 Amps
Model CAB50: 115 VAC, 60 Hz, Start 5.1 Amps, Run 3.0 Amps
E. Mobile Home Approved
• This appliance is approved for mobile home installa-
tions when not installed in a sleeping room and when
an outside combustion air inlet is provided.
• The structural integrity of the mobile home floor, ceil-
ing, and walls must be maintained.
• The appliance must be properly grounded to the frame
of the mobile home and use only Listed pellet vent
Class “L” or “PL” connector pipe.
• Outside Air Kit, part OAK-ACC must be installed in a
mobile home installation.
• Unit must be secured to mobile home structure.
Note: The appliance is also approved for installation
into a shop
PS35 PS50
CAB50
EPA Certification #: 937-14 938-14
EPA Certified Emissions: 2.1 1.7 grams/hour
*LHV Tested Efficiency: N/A N/A %
**HHV Tested Efficiency: N/A N/A %
***EPA BTU Output: 9,300 to
24,400 11,900 to
31,400 per hr.
****BTU Input: 12,900 to
34,400 16,300 to
43,000 per hr.
Vent Size: 3 or 4 inches, “L” or “PL”
Hopper Capacity: 45 83/120 lbs.
Fuel Wood Pellets
* Weighted average LHV efficiency using data collected during
EPA emissions test.
**Weighted average HHV efficiency using data collected during
EPA emissions test.
***Arange of BTU outputs based on EPADefault Efficiency and
the burn rates from the low and high EPA tests.
****Based on the maximum feed rate per hour multiplied by
approximately 8600 BTU’s which is the average BTU’s from a
pound of pellets.
The Heatilator ECO Choice Pellet Heater meets the U.S. Environ-
mental Protection Agency’s emission limits for pellet heaters sold
after May 15, 2015.
This pellet heater needs periodic inspection and repair for proper
operation.Itisagainstfederalregulationstooperatethis pelletheater
in a manner inconsistent with operating instructions in this manual.
