Heatwagon P4000 Manual

P4000
Construction
Heater
Installation and Maintenance Manual
Please retain this manual for future reference.
342 N. Co. Rd. 400 East
Va paraiso, IN 46383
219-464-8818 • Fax [phone]
www.heatwagon.com
Revision 10-12
For your safety: Do not use this heater in
a space where gaso ine or other iquids
having f ammab e vapors are stored.

I PORTANT INFOR ATION! READ FIRST
The heater is designed for use as a construction heater under ANSI Z83.7a-1993. Heater is not
intended for use in pest remediation.The primary purpose of construction heaters is to provide
temporary heating of buildings under construction, alteration, or repair and to provide emer-
gency heat. Properly used, the heater provides safe, economical heating. Products of combustion
are vented into the area being heated.
The heater IS NOT designed as an Unvented Gas Fired Room Heater under ANSI-Z21.11.2 and
SHOULD NOT be used in the home.
ANSI A119.2(NFPA 501C)-1987 Recreational Vehicle Standard prohibits the installation or stor-
age of LP-gas containers even temporarily inside any recreational vehicle. The standard also pro-
hibits the use of Unvented Heaters in such vehicles.
NFPA-58 1989 STANDARD FOR THE STORAGE AND
HANDLING OF LIQUEFIED PETROLEU GASES
Use of the heater must be in accordance with this Standard and in compliance with all governing
state and local codes. Storage and handling of propane gas and propane cylinders must be in
accordance with NFPA 58 and all local governing codes.
We cannot anticipate every use which may be made for our heaters. CHECK WITH YOUR
LOCAL FIRE SAFETY AUTHORITY IF YOU HAVE QUESTIONS ABOUT LOCAL REGULATIONS.
Other standards govern the use of fuel gases and heat producing products in specific applica-
tions. Your local authority can advise you about these.
FOR YOUR SAFETY
DO NOT USE THIS HEATER IN A SPACE WHERE GASOLINE OR OTHER LIQ-
UIDS HAVING FLA ABLE VAPORS ARE STORED OR USED.
CONSTRUCTION HEATER GENERAL HAZARD WARNING:
Failure to comply with the precautions and instructions provided with this heater,
can result in death, serious bodily injury and property loss or damage from hazards
of fire, explosion, burn, asphyxiation, carbon monoxide poisoning, and/or electrical
shock.
Only persons who can understand and follow the instructions should use or service
this heater.
If you need assistance or heater information such as an instruction manual, labels,
etc. Contact your local Heat Wagon dealer or the manufacturer.
W A R N I N G
Fire, burn, inhalation, and explosion hazard. Keep solid combustibles, such as build-
ing materials, paper or cardboard, a safe distance away from the heater as recom-
mended by the instructions. Never use the heater in spaces which do or may contain
volatile or airborne combustibles, or products such as gasoline, solvents, paint thin-
ner, dust particles or unknown chemicals.
Not for home or recreational vehicle use!

Table of Contents: Page
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Principal of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Storage/ aintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Parts Breakdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Ladder Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Installation and Maintenance Manual
Model P4000
Construction Heater
342 N. Co. Rd. 400 East • Val araiso, IN 46383
219-464-8818 • 888-432-8924 • Fax [phone]
www.heatwagon.com
WARRANTY
All new Heat Wagon and Sure Flame heaters and fans are guaranteed against defective materials and work-
manship for one (1) year from invoice date.
Warranty repairs may be made only by an authorized, trained and certified Heat Wagon dealer. Warranty
repairs by other entities will not be considered. Warranty claims must include model number and serial
number.
LI ITATIONS
Warrant claims for service parts (wear parts) such as spark plugs, igniters, flame rods will not be allowed.
Diagnostic parts such as voltage meters and pressure gauges are not warrantable.
Evidence of improper fuel usage, fuel pressures outside of manufacturer’s specification, poor fuel quality,
and improper electric power, misapplication or evidence of abuse may be cause for rejection of warranty
claims.
Travel time, mileage and shipping charges will not be allowed. inor adjustments of heaters are dealers’
responsibility. Defective parts must be tagged and held for possible return to the factory for 60 days from
date of repair. The factory will provide a return goods authorization, (RGA) for defective parts to be
returned.
No warranty will be allowed for parts not purchased from Heat Wagon.

SPECIFICATIONS
odel No. P4000
Heat Output (Three stage selector) 51,200/102,400/136,500 BTU/Hr
Watts 16,000/32,000/40,000
Electrical Rating: 480V 60Hz 3Ø, Amp draw 50 Amps 3Ø
Ambient Thermostat Temp.Range 32 to 100˚F, 0-40˚C
Dimensions 46”L x 20”W x 25”H
Weight 130 lbs
STORAGE
Store heater in a dry, clean and safe place out of reach of children and unqualified persons.
AINTENANCE
WARNING
Ne er ser ice the heater while it is plugged in, running or hot. Se ere bodily
injury or electric shock may occur. Only qualified persons are allowed to open
heater for ser ice.
1. Keep heater clean. Use pressurized air to blow fan blades clean. NOTE: Use
moderate pressure to avoid damage to fan blades.
2. Inspect heater before and after each use.
3. The bearings of the fan motor must be lubricated according to instructions on the
motor.
4
Principal of Operation
STEEL
HANDLE
THER OSTAT +
SWITCHES
POWER SELECTOR
CONTACTORS
RUGGED GALVANIZED
STEEL HOUSING OVERHEAT SENSORS
FULLY SEALED, NON-
GLOWING STAINLESS
STEEL HEATING ELE-
ENT 15 PCS
SOLID PLASTIC
WHEELS
ALU INU
FAN BLADES
ELECTRIC
FAN
OTOR
A BIENT THER-
OSTAT SEN-
SOR TUBE
COOL
AIR
IN
WAR
AIR
OUT

OPERATION
REVIEW AND UNDERSTAND ALL WARNINGS IN THIS ANUAL. THEY ARE
ESSENTIAL FOR SAFE USE OF THE HEATER. FOLLOW ALL LOCAL CODES.
To start heating:
1. Place the heater on a stable and level surface. ake sure that no explosive or
combustible fumes or dust are present. See that the heater is not exposed to water
spray, rain, or dripping water.
inimum clearances from combustible materials:
Outlet 6 feet Sides 1 feet Top 2 feet Rear 2 feet
Floor: combustible
2. Connect power cord of heater into 480 volt 60 hertz three phase power source.
The power outlet has to be equipped with a circuit breaker!
See paragraph “Technical Specifications” in this manual for correct Amp rating.
3. Set the remote thermostat to a temperature above the ambient room temperature
by turning the knob. NOTE: The heater will start only if the thermostat “calls for
heat” meaning that it is set to higher than prevailing ambient temperature.
4. Select the power range by means of the switches marked S1....S3
S1 on = 16 kW = 51,200 BTUH (S2 & S3 off)
S1 & S2 on = 32 kW = 102,400 BTUH (S3 off)
S1 & S2 & S3 on = 40 kW = 136,500 BTUH
The heater will now operate automatically, controlled by the thermostat.
To stop heating
1. Turn all switches to off.
Allow fan to run until it stops automatically, controlled by the thermostat.
2. Unplug the power supply cable after the fan has stopped downcooling the heater.
NOTE: The heater is equipped with an overheat limit switch which may cause the
heater to stop. Check and remove the cause for overheating before re-starting.
5

6
Item Part No. Description
1 HWP 400001 HANDLE
2 HWP 400002 HOOD
3 HWP 400003 HEAT EXCHANGE CHA BER
4 HWP 400004 WHEEL ASSE BLY
5 HWP 400005 WHEEL SHAFT
6 HWP 400006 FRONT PANEL
7 HWP 400007 BOTTO FRA E
8 HWP 400008 HOSE DUCT ADAPTER
9 HWP 400009 BRACKET
10 HWP 400010 CONTACTOR OUNTING PLATE
11 HWP 400011 REAR LEG
12 HWP 400012 FAN BLADE
13 HWP 400019 FAN GUARD GRILL
14 HWP 400014 FAN OTOR
15 HWP 400015 REAR PANEL
Item Part No. Description
16 HWP 400016 STRAIN RELIEVER
17 HWP 400017 A BIENT THER OSTAT
18 HWP 400018 THER OSTAT KNOB
21 HWP 400021 SWITCHES
22 HWP 400022 CONTACTORS
26 HWP 400026 HEATING ELE ENT
See wiring diagram for electric parts

TR Transformer
F1 Fuse
1 Fan otor
TO Overheat Limit Switch
TA Ambient Thermostat
TE Outlet Air Thermostat
TC Unit Cooldown Thermostat
S1 Control Switch (For Output 16KW)
S2 Control Switch (For Output +16KW)
S3 Control Switch (For Output +8KW
C1 Contactor & Coil (For Output 16KW)
C2 Contactor & Coil (For Output +16KW)
C3 Contactor & Coil (For Output +8KW)
C4 Fan Contactor
C 1/4 Pole 4 of Contactor C1
R1...R15 Heating Elements 2.7 KW Each
480 Volt 60 Hz 3 PH
