Heatwagon 4200 Manual

Installation and Maintenance Manual
Please retain this manual for future reference.
342 N. Co. Rd. 400 East
Va paraiso, IN 46383
219-464-8818 • Fax [phone]
www.heatwagon.com
Revision 10-12
4200
Construction
Heater
For your safety: Do not use this heater in
a space where gaso ine or other iquids
having f ammab e vapors are stored.

IMP RTANT INF RMATI N! READ FIRST
The heater is designed for use as a construction heater under ANSI Z83.7a-1993. eater is not
intended for use in pest remediation. The primary purpose of construction heaters is to provide
temporary heating of buildings under construction, alteration, or repair and to provide emer-
gency heat. Properly used, the heater provides safe, economical heating. Products of combustion
are vented into the area being heated.
The heater IS N T designed as an Unvented Gas Fired Room eater under ANSI-Z21.11.2 and
SH ULD N T be used in the home.
ANSI A119.2(NFPA 501C)-1987 Recreational Vehicle Standard prohibits the installation or stor-
age of LP-gas containers even temporarily inside any recreational vehicle. The standard also pro-
hibits the use of Unvented eaters in such vehicles.
NFPA-58 1989 STANDARD F R THE ST RAGE AND
HANDLING F LIQUEFIED PETR LEUM GASES
Use of the heater must be in accordance with this Standard and in compliance with all governing
state and local codes. Storage and handling of propane gas and propane cylinders must be in
accordance with NFPA 58 and all local governing codes.
We cannot anticipate every use which may be made for our heaters. CHECK WITH Y UR
L CAL FIRE SAFETY AUTH RITY IF Y U HAVE QUESTI NS AB UT L CAL REGULATI NS.
Other standards govern the use of fuel gases and heat producing products in specific applica-
tions. Your local authority can advise you about these.
F R Y UR SAFETY
D N T USE THIS HEATER IN A SPACE WHERE GAS LINE R THER LIQ-
UIDS HAVING FLAMMABLE VAP RS ARE ST RED R USED.
C NSTRUCTI N HEATER GENERAL HAZARD WARNING:
Failure to comply with the precautions and instructions provided with this heater, can
result in death, serious bodily injury and property loss or damage from hazards of
fire, explosion, burn, asphyxiation, carbon monoxide poisoning, and/or electrical
shock.
nly persons who can understand and follow the instructions should use or service
this heater.
If you need assistance or heater information such as an instruction manual, labels,
etc., contact your local Heat Wagon dealer or the manufacturer.
W A R N I N G
Fire, burn, inhalation, and explosion hazard. Keep solid combustibles, such as build-
ing materials, paper or cardboard, a safe distance away from the heater as recom-
mended by the instructions. Never use the heater in spaces which do or may contain
volatile or airborne combustibles, or products such as gasoline, solvents, paint thin-
ner, dust particles or unknown chemicals.
Not for home or recreational vehicle use!

Table of Contents: Page
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Proper Set Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
ose Sizing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Cord Sizing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Sequence of Component Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Preventive Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Parts Breakdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12-13
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14-19
Installation and Maintenance Manual
Model 4200
Construction Heater
342 N. Co. Rd. 400 East • Val araiso, IN 46383
219-464-8818 • 888-432-8924 • Fax [phone]
www.heatwagon.com
WARRANTY
All new eat Wagon and Sure Flame heaters and fans are guaranteed against defective materials and work-
manship for one (1) year from invoice date.
Warranty repairs may be made only by an authorized, trained and certified eat Wagon dealer. Warranty
repairs by other entities will not be considered. Warranty claims must include model number and serial
number.
LIMITATI NS
Warrant claims for service parts (wear parts) such as spark plugs, igniters, flame rods will not be allowed.
Diagnostic parts such as voltage meters and pressure gauges are not warrantable.
Evidence of improper fuel usage, fuel pressures outside of manufacturer’s specification, poor fuel quality,
and improper electric power, misapplication or evidence of abuse may be cause for rejection of warranty
claims.
Travel time, mileage and shipping charges will not be allowed. Minor adjustments of heaters are dealers’
responsibility. Defective parts must be tagged and held for possible return to the factory for 60 days from
date of repair. The factory will provide a return goods authorization, (RGA) for defective parts to be
returned.
No warranty will be allowed for parts not purchased from eat Wagon.

SPECIFICATI NS
Model No. 4200
Designed to ANSI Z83.7-1990 Standard Construction eater
Gases: Natural or Propane
Capacity: 5,000,000/6,000,000/7,000,000 Btu/h maximum
Orifice Size: 19/64” - 21/64” - 3/8”, Nat
7/32” - 15/64” - 1/4”, LP
Blower: 27,500 CFM, 33,500 CFM, 40,000 CFM
Electrical Rating: 240V 60 amps, Single Phase (4210)
240V 40/50/60 amps, Three Phase
480V 25/30/40 amps, Three Phase
Minimum Temperature Rating: Minus 40 degrees F
Gas Supply: Inlet Pressure Manifold Pressure
Max PSI Min PSI PSI
Propane 250 lbs. 30 psi 15 psi
Natural Gas 250 lbs. 30 psi 15 psi
Inlet Connection:
Model 4200 (LP) 1/2” FNPT
Model 4200 (Nat/Vap) 1/2” FNPT
Maximum Duct Length, Straight:
400/500/600 Ft. @ 42” Diameter
Weight (approximate):
1200 lbs/ 1210 lbs/ 1420 lbs
4

INSTALLATI N
The eat Wagon Model 4200 Series is a direct fired gas heater intended to be used primarily for the
temporary heating of building under construction, alteration, or repair. Since all the products of
combustion are released into the area being heated, it is imperative that adequate ventilation is pro-
vided. The flow of supply air and combustion gases must not be obstructed in any way.
1. The heater is designed for indoor or outdoor installation in a horizontal position. Allow the
following clearances from any combustible material or fuel containers.
Front Outlet: 10 feet Sides: 2 feet
Intake: 1.5 feet Top: 4 feet
Also make sure that no flammable vapors are present in the space where the heaters is being used.
2. The heater should be inspected before each use, and at least annually by a qualified service
person.
3. The hose assembly must be inspected prior to each use of the heater. If it is evident that there is
excessive abrasion or wear, or the hose is cut, it must be replaced prior to the heater being put
into operation. The replacement hose assembly shall be that specified by the manufacturer. See
parts list.
4. When connecting the heater to a natural gas or propane supply line ensure that the pressure at
the heater inlet is within the specified range. Excessive pressure (over 250 psig) will damage the
controls and void the warranty.
5. Connect the hose assembly to the heater gas inlet elbow. The elbow has a 1/2” Female NPT
thread. The hose assembly is supplied with a swivel connector to avoid kinking or twisting the
hose. Use a minimum inside diameter of 1/2” on LP or 3/4” on natural gas installations. Ensure
that the hose assembly is protected from traffic, building materials, and contact with hot
surfaces.
6. After installation, check hose assembly for gas leaks by applying a soap and water solution to
each connection.
7. Connect the heater to an adequate electrical supply as specified on the rating plate. For
protection against shock hazard the supply cord should be connected directly into a properly
grounded fused disconnect.
8. Replacement parts are available from any eat Wagon distributor or by calling 1-888-432-8924
for parts information.
5

PR PER SET UP
(N TE: The 4200 Series must be specifically set up for the type of available fuel PRI R to
installation)
Model 4200 Series with built-in vaporizer. The heater
will use 55-77 gallon of L.P. per hour. Use at least two
1000 gal. Liquid withdrawal tank. This will insure 20
hours of continuous operation.
When running unit on Liquid Propane, the heater must be set up onside of the building,
forcing the heat through a building opening.
• ose size for Liquid Propane
–up to 50’ 1/2” ID
Keep hose length as short as possible.
Model 4200 Series, if setup for Vapor Propane
withdraws 5,000,000 to 7,000,000 BTU’s per hour. Proper Tank sizing is essential. A propane tank
can only make X amount of Vapor per hour. With drawing the vapor at a faster rate will frost the
tank and eventually the burner will run out of fuel.
Hose sizing Vapor Propane
•Up to 50’, use 3/4” or larger hose
For Natural Gas applications you must know the available line pressure and pipe inside diameter.
Call the factory for the proper size of orifice, gas manifold and hose.
Vapor Propane and Natural Gas Units can be used inside the building or outside.
•Wire heater directly into fused disconnect
Power Supply line sizing:
4210 - 240V - under 75’ 8 ga. 3 conductor
75 ft to 100 ft 6 ga. 3 conductor
4200 - 480V - under 75’ 10 ga. 4 conductor
75 ft to 150 ft 8 ga. 4 conductor
Position heater properly before use.
Install heater in a horizontal position. Clearances required for combustibles and containers.
Front utlet 12 ft
Intake 2 ft
Sides 2 ft
Top 4 ft
LARGE PR PANE ST RAGE TANK VAP RIZATI N RATE
TANK SIZE: MAXIMUM WITHDRAWAL RATE (BTUH):
40” 30” 20” 0”
500 gallon 480,000 420,000 360,000 300,000
1000 gallon 850,000 740,000 640,000 530,000
6

For your safety do not use this heater in a space where gasoline or other liquids, having flammable
vapors, are stored or used.
It is best to provide outside clean air to heater inlet and adequate ventilation to heated areas. The
hose assembly shall be protected from traffic, damage, building materials and contact with hot sur-
faces.
Check all connections for leaks.
Turn off fuel supply and burn out leftover fuel in hose when heater is not in use.
eater can be ducted up to 400 ft of straight 27” duct. For every 90˚ bend cut the total length in
half.
If the heater is ducted it may be necessary to adjust the air flow switch (located inside control box)
by turning adjusting screw CCW until the light on the control box turns on.
If the heater is equipped with a i/Lo Fire Thermostat, place the thermostat inside the area to be
heated, then set desired temperature. eater will cycle from high to low fire.
INSTALLATI N USING A PR PANE SUPPLY TANK(S)
1) The propane supply system must be set up for vapor withdrawal from the operating tank(s).
Liquid propane can cause the heater to overfire and will damage valve train components, unless
unit is supplied with a built in vaporizer.
2) The heater must be at least 6 ft. from any LP-Gas container, and not directed toward any LP-Gas
container with in 20 ft.
3) Minimum Tank Size Outdoor Temperature
500 Gal. Above +25˚F
1000 Gal. +25˚F to + 10˚ F
2 x 1000 Gal. Below +10˚F
4) The installation must conform with local codes, or in the absence of local codes, with the
Standard for Storage and andling of Liquefied Petroleum Gasses ANSI/NFPA 58.
5) Turn off the propane supply valve at the tank(s) when the heater is not in use.
6) When the heater is to be stored indoors the propane tank(s) must be disconnected from the
heater and the tank(s) stored in accordance with Chapter 5 of the above National Standard.
7

C MM N INSTALLATI N AND PERATI NAL PR BLEMS
1) LOW VOLTAGE AT T E EATER
This is one of the most common problems and is usually the result of the supply cord having
too small a wire gauge for its length, or low voltage at the power source. Low voltage results in
the motor overheating, burnt relay contacts, or a relay that will not make contact. Check
voltmeter on heater before start-up.
2) SUPPLY LINE TOO SMALL
Minimum Size: 1/2” for LP, 3/4” for Natural Gas.
3) INSUFFICIENT VAPORIZATION AT SUPPLY
Normally caused by undersized supply tank.
4) IMPROPER GAS SUPPLY PRESSURE
Usually a result of propane supply pressure being too high because of improper or lack of
regulation or too low of natural gas pressure at meter.
5) DIRTY GAS SUPPLY
Dirty gas can cause strainers to plug or form a build-up in the burner orifice.
6) LACK OF PREVENTIVE MAINTENANCE
eaters must be cleaned as required, especially when used in a dirty environment.
7) IMPROPER SUPPLY OF FRES AIR
It is strongly recommended that the intake air of the heater be taken from outside the enclosed
area. This provides a slight pressurization and prevents any problems associated with
recirculation of products of combustion.
8
PERATING INSTRUCTI NS
Model 4200 Series
ON
1. Turn on fuel supply
2. Turn on the manual shut off valve
3. Turn on the fan switches
4. Turn on the burner switch.
OFF
1. Turn off fuel supply
2. Turn off the burner switch
3. Turn off the fan switch

9
M DEL 4200 SERIES
SEQUENCE F C MP NENT PERATI N
1) P WER SUPPLY
240/480 Volt wire directly into the fused disconnect.
2) FUSE DISC NNECT SWITCH
Turned on, it sends power to motor relay and to control voltage transformer.
3) C NTR L V LTAGE TRANSF RMER
Sends power to the 3 amp circuit breaker.
4) 3 AMP CIRCUIT BREAKER
Sends power to the fan switch.
5) FAN SWITCH
Sends power to the motor relay holding coil.
6) M T R RELAY
Closes, the fan motor starts, there is power at the burner switch.
7) BURNER SWITCH
In the ON position it sends power to the air flow switch.
8) AIR FL W SWITCH
It was blown closed by the fan turning, sends power to the ignition control board.
9) IGNITI N C NTR L B ARD
Creates a spark at the igniter and sends power to the high limit switch.
10) HIGH LIMIT SWITCH
Sends power to the gas solenoid valve.
11) GAS S LEN ID VALVE
Opens, sending fuel to the burner (where there is spark).
12) BURNER
It ignites.
13) IGNITER SENS R
Sends a flame sensing signal to the ignition control board. The unit is operating.

10
TR UBLE SH TING
N TE: MUST CHECK C MP NENTS IN SEQUENCE LISTED
DIRECTI NS: Find the specific symptom. Refer to Sequence of component peration Guide.
Check the components listed with a voltmeter for proper operation as described. Replace any com-
ponents not operating correctly.
Fan will not start when fan switch and thermostat are N.
• Check sequences 1 through 5 (Page )
• Push reset button on Motor Overload Relay
Fan runs, no spark for ignition.
• Check sequences 6 through 9 (Page )
• Check continuity of igniter leads. Replace if shorted or broken.
• Check igniter for carbon buildup, gap spacing (1/8”), secure mounting
• Replace igniter if porcelain is cracked or if electrodes are rubbery
Have spark but no flame.
• Check sequences 9 through 11 (Page )
• Check for gas pressure on the manifold gauge, if gas is present, clean the burner port holes
Flame occurs but burner locks out after a few seconds.
• Check burner ground wire (Bad connections)
• Check sensor wire (Burned wire or bad connection)
• Check igniter/sensor (Replace if probe is rubbery)
• Clean port holes in burner around igniter/sensor
• Replace ignition control board
Flame occurs but trips pressure reset button after 30 to 40 seconds.
• Pressure regulator is set too high.
• Limit switch shuts burner off.
• Adjust pressure regulator to proper setting. (1”W.C. LP Max, 2.5” W.C. Nat. Max)
• Indicator light will glow when proper setting is obtained.
Flame established, but too small.
A: Check for proper pressure at manifold gauge — (if yes)
1. Clean port holes in burner
B: Not enough pressure at manifold gauge.
1. Check fuel supply
2. Check liquid strainer — Filter at the “Y” fitting. (Liquid Propane model only) for restriction
from dirt, oil, etc.
3. Check high pressure regulator for similar restriction.
4. Check gas solenoid valve for similar restrictions.

11
PREVENTATIVE MAINTENANCE
1) Check - Fused disconnect
A) Continuity through fuses.
2) Check - All wiring for tight and correct connections
3) Check - Motor Relay
A) If it buzzes, clean contacts or replace.
B) Check for voltage drop through L1 & T1 contacts. If it’s more than 2 volt replace.
4) Check - Air Flow Switch
A) Clean inlet and negative pressure tubes (Blow out with air)
B) Adjust the switch, turn adjusting screw CCW until the light on the control panel stays on.
5) Clean the burner
A) Clean port holes (gas outlet)
B) Clean air mixture holes (Main burner section)
6) Clean and inspect solenoid valves
A) Remove tops of solenoid valves, clean dirt and propane oil out
B) Inspect diaphragm (Not hard or cracked)
7) Check/Replace the igniter/sensor
A) Move senor probe with fingers. If “rubbery” replace it.
B) If probe solidly rigid, clean igniter and check gap @ 1/8”
8) Check for gas leaks
A) eater operating, check for leaks at all pipe joints with leak detector or soapy water. Remake
joints where bubbles occur.
9) Tighten all bolts
A) Motor mounts
B) Fan blade
C) Burner mount
D)Pipe train (manifold) mounts

12
Model 4200 Series
ITEM PART# DESCRIPTION
1 WP C1069B LID FOR CONTROL BOX
2 WP C1069A CONTROL BOX LID
3 N/S COPPER TUB/AIR SWITC
4 WP P1048 FAN BLADE (SPECIFY P)
5 WP G1051 FAN GUARD
6 WP M1078 MOTOR 7.5 P 1 P
* WP M1079 MOTOR 7.5 P 3 P
* WP M1067 MOTOR 10 P 1 P
* WP M1068 MOTOR 10 P 3 P
* WP M1071 MOTOR 15 P 3 P
* WP M1080 MOTOR 20 P 3 P
7 WP C1009 I LIMIT SWITC
8 WP B4200 BODY
9 WP B1070 BURNER
10 WP TT-3 TRAILER
11 WP D1055B DISCONNECT 60 AMP 1P
* WP D1057B DISCONNECT 60 AMP 3P
* WP D1057 DISCONNECT 30 AMP 3P
12 WP V1067 VAPORIZER RING
* Items not shown on breakdown
ITEM PART# DESCRIPTION
1 WP S1046 MOTOR RELAY (3P )
* WP S1045 MOTOR RELAY (1P )
2 WP S1046B OVERLOAD RELAY (3P )
* WP S1045B OVERLOAD RELAY (1P )
3 WP C1017 CONTROL TRANSFORMER
4 WP C1004B IGNITER (FENWALL)
5 WP C1001C D.S.I. CONTROL BOARD
6 WP C1010 AIR FLOW SWITC
7 SFP 2453 I-LO T ERMOSTAT
8 WP C1072 TIME DELAY BREAKER
9 WP C1019B 3 AMP BREAKER
10 SFP 5989 VOLT METER (150 VOLT)
ITEM PART# DESCRIPTION
11 WP C1011 BURNER SWITC
12 WP C1011 FAN SWITC
13 SFP 2505 LIG T
14 WP 099125-03 NEUTRAL BLOCK
15 WP C1077 DELAY BREAK TIMER
* WP S1046BM BRACKET MOUNTING KIT
* WP S1046C OVERLOAD RELAY PRIOR TO 1991
* WP 2453A T ERMOSTAT SUB. ASSEMBLY W/15’
16/3 CORD
* Items not shown on breakdown
Model 4200 Series Control Box

13
4200 Series L.P.Pipe Train ITEM PART# DESCRIPTION
1 WP V1042B OSE ASSEMBLY
2 WP V1037 1/2” LIQUID PROPANE SOLENOID VALVE
3 WP V1023 MANUAL S UT-OFF VALVE
4 WP V1054 200 PSI GAUGE
5 WP V1029 1/2” LIQUID STRAINER
6 WP V1023 1/2” MANUAL S UT-OFF VALVE
7 WP R1053 REGULATOR
8 WP V1025 1/2” SOLENOID VALVE
9 WP V1076 1/2” I-LO VALVE (DRILLED AT 1/4”)
10 WP V1075 GAS PRESSURE LIMIT SWITC
11 WP V1027 30 PSI VAPOR PRESSURE GAUGE
* WP 1038 115V REPLACEMENT COIL FAN FOR V1037
ITEM PART# DESCRIPTION
1 WP V1023 BALL VALVE
2 WP R1053 REGULATOR
3 WP V1025 1/2” SOLENOID VALVE
4 WP V1076 1/2” I-LO VALVE (DRILLED AT 3/8”)
5 WP V1075 GAS PRESSURE LIMIT SWITC
6 WP V1027 30 PSI VAPOR PRESSURE GAUGE
4200 Series Natural Gas Pipe Train

14
480 Volt 3 PH

15
240 Volt 3 PH

16
240 Volt 1 PH

17
240 Volt 3 PH

18
480 Volt 3 PH

240 Volt 1 PH
19

20
PROPANE FACTS
LBS Per Gallon 4.24
BTU Per Gallon 91,960
BTU Per LB 21,591
BTU Per Cu Ft 2,516
Cubic feet of air
Required to burn 1 Cu Ft propane 23.5
NATURAL GAS FACTS
BTU Per Cu Ft 1040
100,000 BTU = T ERM
1 T ERM = 100 Cubic Foot
Cu Ft of air required to burn 1 Cu Ft of Natural Gas 10.5
MISCELLANEOUS
BTU .25 CALORIES
CALORIES 4 BTU’S
PSI 27.7 INC ES
1 P 2550 BTU
OPEN FLAME APPROX. 3500˚F
KW 3411 BTU’S
DISC ARGE TEMPERATURE
OF PORTABLE OIL EATERS 225˚ ABOVE AMBIENT
DISC ARGE TEMPERATURE
OF PORTABLE GAS EATERS 240˚ ABOVE AMBIENT
AMOUNT OF MOISTURE
ADDED TO AIR BY 7 LBS OF WATER
PORTABLE GAS EATER PER 100,000 BTU
