Helion conquest 10MT XLR User manual

QUICK-START GUIDE
Full manual available to download from: www.Helion-RC.comFull manual available to download from: www.Helion-RC.com
Quick-Start
Guide
Product specications are subject to change without notice.
Due to ongoing development, the actual product may vary from
images shown.
This product contains chemicals known to the State of California
to cause cancer, birth defects and other reproductive harm.
This product is not a toy! (14+) Recommended for ages 14 and
up. Adult supervision required for ages under 18 years old.
Contains small parts, keep out of reach of children 3 years of
age and younger.
To download the full Owner’s Manual & Technical
Information Guide, please visit:
www.Helion-RC.com
or scan the QR code with your smart phone.
Distributed in the
UK by:
J Perkins Distribution Ltd,
Lenham,
Kent, UK
ME17 2DL.
www.jperkins.com
Distributed in Australia by:
Model Engines (Aust.) Pty. Ltd.,
P.O. BOX 828
NOBLE PARK 3174
Australia
www.modelengines.com.au
Ph [phone]
[email protected]
Distributed in the US by:
Firelands Customer Service/Product Support
1133 Libra Drive, Lincoln, NE 68512
www.relandsgroup.com
1-800-205-6773
customerservice@relandsgroup.com
HLNA0767 Conquest 10MT XLR (US)
HLNA0777 Conquest 10MT XLR (UK-EU)
HLNA0787 Conquest 10MT XLR (AU)
MADE IN CHINA

QUICK-START GUIDE
Full manual available to download from: www.Helion-RC.comFull manual available to download from: www.Helion-RC.com
2Remove the four body clips from
the car and lift the body clear.
3Remove the two body clips that
secure the dust cover and lift the
cover clear.
1Remove the components from
the box and ensure the contents
are correct:
• 1 x Conquest 2WD Monster
Truck
• 1 x 2000mAh 6-cell NiMH
battery pack
• 1 x IKONNIK ET3 2.4GHz
3-channel transmitter
• 1 x 6-cell wall charger
• 1 x Quick-Start Guide
4Locate the battery cradle in the
center of the car, release the
hook and loop tape and withdraw
the battery pack.

QUICK-START GUIDE
Full manual available to download from: www.Helion-RC.comFull manual available to download from: www.Helion-RC.com
5Plug the charger into a wall
socket, connect the battery to the
charger and place the battery on
a non-ammable surface. Switch
the wall socket ON noting that a
fully discharged battery will be
charged in approximately 3 hours.
Periodically monitor the temperature
of the battery when charging and
disconnect if it exceeds 120°F (49°C). Unplug the battery when charged.
6Re-insert the fully charged battery
pack into the cradle and tightly
secure it with the hook and loop
straps.
7Remove the battery cover from the
underside of the ET3 transmitter
and insert four AA alkaline cells.
Take care to ensure that the
correct polarity is observed.
8Ensure the radio switch is in the
OFF position, then connect the
battery to the ESC.
9Replace the dust cover and
secure it with the two body clips.

QUICK-START GUIDE
Full manual available to download from: www.Helion-RC.comFull manual available to download from: www.Helion-RC.com
11 Switch ON your IKONNIK ET3
transmitter and ensure the LED is
lit solid red and that no alarms are
audible. Ensure that the CH2 EPA
dials are turned fully clockwise
and that the D/R (steering rate)
dial is centered. Ensure, also, that
the CH1 and CH2 (trim) dials are
centered at zero.
12 Slide your nger under te dust
cover, locate the switch and
turn ON your Conquest. In the
unlikely event that the car does
not operate, see the PAIRING /
BINDING instructions at the back
of this guide.
13 Check the operation of the throttle
and steering. Pulling the throttle
trigger back will drive the car
forward, pushing the trigger forward
once will apply the brakes while
pushing the trigger forward twice
will drive the car in reverse. Turning
the wheel to the right will cause the
car to turn right and vice versa.
14 Use the throttle and steering trim
dials to ne-tune the controls of
your car. In doing so, ensure that
your Conquest tracks in a straight
line. Also that it doesn’t creep
forwards or backwards at zero
throttle.
Replace the body and secure it
with the four body clips.
10
LED
CH2 EPA D/R
CH1 &
CH 2
Trim

QUICK-START GUIDE
Full manual available to download from: www.Helion-RC.comFull manual available to download from: www.Helion-RC.com
1Remove the body and locate the
ET3 Krypton receiver.
2Place your Conquest and ET3
transmitter in close proximity but
not less than 12” (300mm) apart.
Having followed steps 1 to 12, in the unlikely event that your car does not operate please
follow the 5 stage pairing process detailed here.
Pairing / Binding The Transmitter
3Press and hold the PAIR / BIND
button on the receiver then switch
the receiver on. The receiver’s
LED will ash to indicate that it is
in PAIR / BIND mode.
5When the LED on the receiver
lights solid red your ET3
transmitter and Conquest will
be bound. You will now have full
control of throttle and steering.
Return to Step 13 of this guide to
complete the set-up of your car.
4Press and hold the PAIR / BIND
button on the transmitter then
switch the transmitter on. Release
the PAIR / BIND button only when
the transmitter’s LED begins
ashing.
300mm

REPLACEMENT PARTS
Full manual available to download from: www.Helion-RC.comFull manual available to download from: www.Helion-RC.com
Replacement Parts
HLNA0970 .........Rear Chassis Plate, B, ST, MT
HLNA0971 .........R-Clip, B, ST, MT
HLNA0972 .........Nuts(M4)
HLNA0973 .........M3*8 Column Head Hex Screw
HLNA0974..........Wheel Hex
HLNA0975 .........Nuts(M3)
HLNA0976 ......... Radio Tray Mount
HLNA0978 .........Back Shock
HLNA0979 .........Shock Ball Head C
HLNA0980 .........Pin 2*10
HLNA0981 .........Diff Planetary Gear
HLNA0982 .........Diff Shaft
HLNA0983 .........Differential Outdrive
HLNA0984 .........Diff O-Ring
HLNA0985 .........Flat Head Hex Machine Screw M3*14
HLNA0986 .........Flat Head Hex Machine Screw M3*12
HLNA0987 .........Flat Head Hex Machine Screw 3*8
HLNA0988 .........Flat Head Hex Machine Screw 2*10
HLNA0990 .........Sus. Arm E-Clips 0.6mm
HLNA0991 .........Flat Head Hex Mechnical Screw 3*10
HLNA0992 .........Cap Head Hex. Mechnical Screw (3*10)
HLNA0993 .........Cap Head Hex. Mechnical Screw (3*12)
HLNA0994 .........Cap Head Hex. Mechnical Screw (3*5)
HLNA0996 .........Front Bumper, MT
HLNA0997 .........Motor Guard, MT
HLNA0998 .........Wheelie Wheel, MT
HLNA0999 .........Motor Guard With Wheelie Wheel, ST, MT
HLNA1000 .........Slide Wheel Axle, MT
HLNA1001 .........Washer 6*4*0.5, MT
HLNA1002 .........Chassis Dustproof Cover(PVC), MT
HLNA1003 .........Battery Strap
HLNA1004 .........Chassis, B, ST, MT
HLNA1005 .........Front Lower Suspension Arm B, ST, MT
HLNA1006 .........Rear Lower Suspension Arm B, ST, MT
HLNA1007 ......... Front Chassis Plate B, ST, MT
HLNA1008 .........Front Shock Tower B, ST, MT

REPLACEMENT PARTS
Full manual available to download from: www.Helion-RC.comFull manual available to download from: www.Helion-RC.com
HLNA1009 .........Rear Shock Tower B, ST, MT
HLNA1010 ......... Steering Hub Carrier (L/R)
HLNA1011 ......... Front Hub Carrier (L/R)
HLNA1012 .........Rear Upright
HLNA1013 .........Front Bulk Head Brace
HLNA1014 ......... Front Shock Mount
HLNA1015 .........Front Upper Link 58.5mm
HLNA1016 ......... Steering Link 55mm
HLNA1017 ......... Rear Upper Link 73mm
HLNA1018 .........Servo Link 30.5mm
HLNA1019 .........Gear Box
HLNA1021 .........Main Gear Cover
HLNA1022 .........Differential Case(48P)
HLNA1023 .........Gear (34T-48P)
HLNA1024 .........Gear (81T-48P)
HLNA1026 .........Front Shock Absorber
HLNA1027 .........Rear Arm Bulkhead
HLNA1028 .........Front Arm Bulkhead
HLNA1031 .........Steering Sway Arm Assembly
HLNA1032 .........Gear (20T-48P)
HLNA1033 .........Slipper Shaft
HLNA1034 .........Slipper Pad
HLNA1035 .........Slipper Hub
HLNA1036 .........Slipper Tensioner Spring
HLNA1037 .........Motor Mount
HLNA1039 .........Rear Wheel Axle
HLNA1040 .........Dogbone
HLNA1041 ......... Front/Rear Suspension Pin
HLNA1042 .........Servo Saver Assembly
HLNA1043 .........Ball Head Scews 5.8mm
HLNA1044 .........Front Wheel Axle
HLNA1045 .........Steering Shaft Bush
HLNA1053 .........Gear (23T)48P
HLNA1054 .........Front Lower Suspension Arm Screws 3*25mm
HLNA1055 .........Rear Lower Suspension Arm Screws 3*29mm
HLNA1056 .........Pin 3*26
HLNA1057 .........Pin 5*18

REPLACEMENT PARTS
Full manual available to download from: www.Helion-RC.comFull manual available to download from: www.Helion-RC.com
NOTE: If you experience any problems,
please consult online troubleshooting guide.
HLNA1058 .........Motor Rc550(8514) MT
HLNA1059 .........Powder Steel Gear(20T-48P)
HLNA1061 .........Rear Shock Absorber
HLNA1062 .........Body Post, ST, MT
HLNA1063 .........Post Mount, ST, MT
HLNA1070 ......... Cap Head Hex. Mechnical Screw 3*14
HLNA1071 ..........Cap Head Hex. Mechnical Screw 3*16
HLNA1072 ......... M3*3 Grub Hex Screws
HLNA1073 ......... Wheels, MT
HLNA1074 ..........Tires + Sponge, MT
HLNA1075 ......... Wheel Complete, MT
HLNA1076 .........Washer 8*3*0.5, MT
HLNA1081B ....... Replacement Body, MT Blue
HLNA1081R ....... Replacement Body, MT Red
HLNA1081Y ....... Replacement Body, MT Yellow
HLNA1081G .......Replacement Body, MT Green
HLNA1082 .........Clear Body, MT
HLNA1086 .........Conquest Battery 2000 mAh
HLNA1088 .........Front Steering Turnbuckle (55mm)
HLNA1089 .........Front Arm Turnbuckle
HLNA1090 .........Front Steering Turnbuckle (74mm)
HLNA1091 .........Machine Serrated Axle Nuts
HLNA1092 .........Aluminum Axle Drive Hexes
HLNA1093 .........Front Aluminum Pivot
HLNA1094 .........Rear Aluminum Pivot Block
HLNA1095 .........Front Aluminum Chassis Brace
HLNA1096 .........Front Aluminum Pivot Plate
HLNA1097 ......... Rear Aluminum Pivot Plate
HLNA1098 .........Front and Rear Shock
RDNA0052 ........ Reaktor Brushless Combo, NS 50A-3000kV 4P
KNNS0024 ........ET3 3-Channel 2.4GHz (Krypton) - Transmitter and All Weather Receiver
KNNS0025 ........ ET3 3-Channel 2.4GHz (Krypton) - Transmitter Only
