Helion IMPAKT User manual

1/12th SCALE 2WD ELECTRIC CAGED BUGGY
OWNER’S MANUAL AND EXPLODED VIEW
• Entire contents ©2014 Helion RC
• Before using your product, review all documenta-
tion and inspect the products carefully. If for some
reason you decide it is not what you wanted, then
do not continue with unpacking, setup or operation
of your product. Your local hobby dealer cannot
accept a product for return or exchange after par-
taking in actions that produce wear and tear.
• Read, understand and follow all instructions and
accompanying material carefully before operat-
ing or assembling your vehicle to prevent serious
damage to your vehicle. Failure to complete these
tasks properly or intentional aversion to the con-
tent will be considered abuse and/or neglect.
• Product specications are subject to change
without notice. Due to ongoing development, the
actual product may vary from images shown.
• This product contains chemicals known to the
State of California to cause cancer and birth de-
fects or other reproductive harm.
• This product is not a toy! (14+) Recommended
for ages 14 and up. Adult supervision required for
ages under 18 years old. Contains small parts,
keep out of reach of children 3 years of age and
younger.
Scan this QR
code with your
smart phone to
view the getting
started video for
this product.
LENGTH 344mm (13.54in)
WIDTH 213mm (8.39in)
HEIGHT 109mm (4.29in)
WHEELBASE 250mm (9.84in)
WHEEL SIZE F-O: 53mm (2.1in) x W: 23mm (0.9in)
R-O: 53mm (2.1in) x W: 28mm (1.1in)
TIRE DIAMETER F-O: 76mm (2.99in) x W: 29mm (1.14in)
R-O: 77mm (3.0in) x W: 36mm (1.42in)
WEIGHT* 770g (1lb-11.2oz)
BATTERY 1,500mAh 2S LIPO, 7.4V
MOTOR 380 SIZE, REVERSE ROTATION
RADIO 2.4GHz 2-CHANNEL
CHARGER AC 0.5A BALANCING
*APPROXIMATE OUT-OF-THE-BOX WEIGHT
EN-ENGLISH
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 1 2014-09-29 11:27:02

PACKAGE CONTENTS
NOTICE!!!
ITEMS NEEDED TO COMPLETE
RECOMMENDED TOOLS (NOT INCLUDED)
GETTING STARTED...
2
1. [1] Impakt 12B Buggy
2. [1] Battery
3. [1] Radio Transmitter
4. [1] Wall Charger with Power Supply
5. [1] Documentation Package
6. [1] Antenna Tube
7. [1] 4-Way Cross Wrench
8. [1] LiPo Safe Charging Bag
1. [4] 1.5V AA type alkaline batteries for transmitter
a. To help the environment, consider replacing the disposable batter-
ies for this transmitter and for other household electronic items with
rechargeable batteries. Visit your local hobby dealer for hobby grade
chargers and batteries
Please use caution and
follow the manufac-
turer’s recommended
operating instructions for
these items and always
wear eye protection.
Although your Helion RC product is adjusted and tested at the factory prior to nal packaging, some
issues may arise during shipping and handling that can be easily resolved at home. For other issues
it should be known that hobby grade radio controlled products such as those offered by Helion RC
differ from toy grade, in that they are intended to be user-servicable products where the user can
disassemble and maintain their own product using factory replacement parts. We try our best to
ensure the information you need to introduce you to this form of product maintenance is available
to you though this manual. Please see the trouble shooting guide at the back of this manual for as-
sistance in resolving issues, either as they are experienced out of the box or as found after regular
use. Assuming your product functions properly as intended out of the box, the best thing you can do
is pay close attention to how it feels, sounds and functions. This will help you identify problems later
since you will have a reference of how the product is supposed to perform. If you require further
information or assistance resolving a possible issue, please consult the warranty card included with
your product.
1. Carefully remove the box contents using side cutting pliers to cut the tie straps.
2. Remove body and the battery from LiPo Safe Charging sack to inspect it prior to charging.
a. Read charging instructions and understand all warnings and cautions before proceeding.
This product is not a toy and should not be charged by anyone except an adult.
b. Return to this guide in the presence of the charging battery, remembering never to leave
the battery unattended while charging.
3. Install antenna tube by sliding antenna into tube and inserting tube into mount on 2-in-1 module.
Be careful not to pinch the antenna during installation. NOTE: Do NOT fold end of antenna over
end of tube, this will reduce the range of the radio system and can cause interference when
operating your vehicle.
4. Install the [4] AA type alkaline batteries into the transmitter.
5. Remove the small body clip and battery door latch pin from the vehicle to open the battery
HOBBY KNIFEMETRIC HEX SCREWDRIVER SET SCREWDRIVERS CURVED HOBBY SCISSORS
SIDE CUTTING PLIERS NEEDLE NOSE PLIERS BODY REAMER CA GLUE
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 2 2014-09-29 11:27:03

1/12th SCALE 2WD ELECTRIC
CAGED BUGGY
...GETTING STARTED CONTINUED
CHARGING THE BATTERY
3
compartment.
6. Install the fully charged battery into the vehicle, be sure the On/Off switch is in the OFF position
rst, then ensure the motor is plugged into the ESC. Close and latch the battery door.
7. Ensure the switch is in the OFF position and connect the battery to the ESC.
8. Read and understand transmitter cautions and setting instructions before use.
a. Conrm settings for steering and throttle trim.
9. Turn your equipment ON (radio rst!) and enjoy!
• Always charge in a LiPo safe charging bag or container.
• Never use a non LiPo specic charger to charge the battery, doing so can cause catastrophic
failure which could lead to re.
• Never charge your LiPo batteries without utilizing the balance feature of your LiPo charger.
• Never leave the battery unattended while charging.
• Never operate the charger without adult supervision.
• Never charge a warm battery, always allow the battery to cool to room temperature before
charging.
• Never drop the charger or battery.
• Never attempt to charge a damaged battery.
• Inspect the battery and charger before use. Never charge a battery or charger if the wire or con-
nector has been damaged or if the battery has experienced a short.
• Incorrect use of the battery, connections, or charging equipment can cause personal injury or
property damage
• Never allow batteries or charger to come in contact with moisture at any time
• Stop charging immediately if the battery or charger becomes hot or changes form (swells) dur-
ing use
NOTE: Only use chargers designed for use with LiPo batteries for the RC industry, using the
supplied connector. Use of other (non-RC specic) chargers or connectors can permanently
damage the battery and/or connected equipment. Genuine replacement batteries are avail-
able at your local hobby dealer.
1. Plug the power supply into the charger and into a properly grounded standard AC wall plug.
2. Close the battery into the LiPo bag leaving only the charge leads exposed. Be sure to properly
secure the hook and loop closure material prior to connecting the battery to the charger.
3. Plug the battery into the charger and place the battery on/in a non-ammable surface/container
and away from any ammable objects.
4. A fully discharged battery should charge in approximately 3 hours, however your rst charge
should take around 1 hour
a. Caution: Periodically monitor the temperature of the battery while charging, if the
temperature exceeds 115°F (45°C), disconnect the battery from the charger and al-
low it to cool before reconnecting
5. Unplug the battery from the charger when the battery is fully charged, indicated by the red
charge light turning Off.
a. NOTE: Using a LiPo balance charger with a higher charge rate is recommended and will
provide you with a faster and better charging experience. We recommend the Radient RC
chargers which were developed specically with your product in mind.
b. Warning: Recommended charge current is 1.5A however, never charge the included
battery at a charge current exceeding 2A.
6. Remove charger from wall plug.
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 3 2014-09-29 11:27:03

THE HRSS-2 2.4GHz RADIO SYSTEM
4
Transmitter Features:
1. Steering wheel: controls left/right motion (designed to be operated
with right hand)
2. Throttle trigger: controls forward/reverse motion (designed to be
operated with left index nger)
3. Control panel cover: Covers control panel housing radio setting
controls
4. ON/OFF Switch: Turns the power ON/OFF for the transmitter
5. Indicator lights (G. LED): Multifunction Green LED
a. Solid Green: Adequate battery voltage for proper operation
b. Flashing Green: Low battery voltage warning, batteries should
be replaced/recharged before continued use
6. Steering Trim (ST. TRIM): Controls the “hands-off” left/right direction of the vehicle
7. Throttle Trim (TH. TRIM): Adjusts the motor speed to STOP when trigger is in “hands-off” (neu-
tral) position
Batteries:
• Remove the lower door from the transmitter to access the battery compartment.
• Install [4] AA type batteries into the compartment.
›Pay close attention to battery polarity (+/-) indicators during installation.
• Never mix brands or old/new batteries.
• Always remove dead batteries from the transmitter.
• If using rechargeable batteries, be sure to follow the manufacturer’s care and use instructions.
• Rechargeable batteries must be removed from transmitter before charging.
Transmitter Standard operation:
• Turning the transmitter wheel to the left from center makes the wheels on the vehicle turn LEFT
• Turning the transmitter wheel to the right from center makes the wheels on the vehicle turn
RIGHT
• Pulling the transmitter trigger back towards the handle will make the vehicle accelerate forward
• Pushing the transmitter trigger forward away from the handle will have the following affects
depending on the location of the trigger prior to pushing it forward
›From a stop at neutral: the vehicle will travel in reverse
›From pulled back: the vehicle will apply brakes to slow the speed
»A second push forward of the trigger will apply reverse throttle
»WARNING: Causing the vehicle to make quick transitions from forward/reverse
motion to the opposite direction using the throttle control can cause damage
to your vehicle and will void the warranty
Using the LVC function with LiPo Batteries:
The HRSS-2 modular 2-in-1 ESC is equipped with a Low Voltage Cut-Off (LVC) for use with LiPo
batteries. The LVC is used to prevent the over-discharge of LiPo batteries which can increase the
risk of re and damage the battery. This LVC mode cannot be disabled and therefore your vehicle
can only perform properly when used with LiPo batteries.
• When the LVC function of your ERS unit is active, the LED will ash slowly, indicating it is time
to stop and charge your battery. Always remember to allow your battery to cool before recharg-
ing. Also remember to allow the motor to cool down completely before running again.
›WARNING! THE MOTOR WILL BE HOT AFTER RUNNING, USE CAUTION WHEN
TESTING THE MOTOR TEMPERATURE. DO NOT TOUCH THE MOTOR DIRECTLY,
CAREFULLY TOUCH THE PLASTIC GUARD WHICH COVERS THE MOTOR TO
CHECK THE TEMPERATURE.
HRSS-2
HRSS-2
G. LED
TH. TRIMST. TRIM
+ +
- -
OFF ON
POWER
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 4 2014-09-29 11:27:03

1/12th SCALE 2WD ELECTRIC
CAGED BUGGY
USING YOUR HRSS-2 RADIO SYSTEM FOR THE FIRST TIME
5
Binding the Radio System:
The process of allowing communication to occur between a 2.4GHz transmitter and receiver is
called “binding” (sometimes referred to as “matching” or “pairing”). The radio system included
with your product has an auto-bind function that binds to the vehicle receiver every time the two
are powered on. When each are powered on they “search” for a match to bind with and begin the
binding procedure automatically. This usually works without issue, however if you are attempting to
operate multiple vehicles at the same time, be sure that you only turn one pair (transmitter/vehicle)
on at a time, waiting approximately 20 seconds before turning on another pair. This will ensure each
user’s vehicle is bound to their transmitter. If a mis-bind occurs, simply turn off all units and begin
the process again.
Setting the Trims:
1. Turn the transmitter ON and ensure the LED is lit SOLID indicating the batteries are supplying
adequate voltage for proper operation.
2. Ensure your vehicle battery is fully charged, installed and connected, then turn ON your vehicle.
3. Setting the throttle trim
a. If the wheels spin in a forward direction when the trigger is in the neutral position, turn
down the trim until the motor stops by pressing the (-) button.
b. If the wheels spin in a reverse direction when the trigger is in the neutral position, turn up
the trim until the motor stops by pressing the (+) button.
c. There will be a “dead band” area where the trim can be adjusted a slight amount in either
direction and the wheels will not begin to move. It is ideal to have the trim set in the middle
of this “dead band”.
d. The LED will ash when you have reached the center point of the trim setting range on the
transmitter.
4. Setting the steering trim
a. With your vehicle and transmitter turned on (and properly responding to transmitter
inputs), set the vehicle down on the ground and slowly accelerate in a direction directly
away from you. If the vehicle veers slightly either to the left or right, stop the vehicle and
adjust the Steering Trim in the opposite direction of the veer in small increments, one but-
ton press at a time.
i. Press the (-) button to increase LEFT trim.
ii. Press the (+) button to increase RIGHT trim.
iii. The LED will ash when you have reached the center point of the trim setting range
on the transmitter.
b. Reset the vehicle and re-test; adjust the trim as needed until the vehicle travels in a
straight line while the transmitter wheel remains at center location (“hands-off”).
Storage:
• Always store all equipment in a cool dry place when not in use.
• Always disconnect the batteries before storage.
• Never store the battery, vehicle or transmitter in direct sunlight for extended periods of time
• Never store the transmitter with batteries installed for extended periods of time. Doing so may
allow the batteries to leak and cause permanent damage to the transmitter.
Disposal:
Your product is equipped with LiPo batteries which are considered electronic waste and should
never be discarded in standard garbage containers. Please visit your local hobby dealer and use the
FREE battery disposal center for proper disposal/recycling.
STORAGE AND DISPOSAL
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 5 2014-09-29 11:27:03

6
Although great for rst time users, Helion RC products are indeed advanced radio controlled
vehicles with sensitive electronics and moving parts capable of causing injury if used improperly.
Always use caution and common sense as failure to operate your Helion RC product in a safe and
responsible manner can result in damage to the product or other properties. Therefore this product
is not intended for use or maintenance by children without direct adult supervision. Helion RC and
your hobby dealer shall not be liable for any loss or damages, whether direct, indirect, special,
incidental, or consequential, arising from the use, misuse, or abuse of this product or any product
required to operate or maintain it
• For your safety, do not operate your vehicle in rain, electrical, or thunder storms.
• The vehicle should never be turned ON without the transmitter being turned ON.
• Never operate your vehicle when with low transmitter batteries.
›Indicated by ashing LED on the transmitter
• Always check for proper radio system operation (steering and throttle) prior to letting go of the
vehicle. If the vehicle does not respond properly to transmitter input, turn the vehicle OFF and
inspect all connections and operating environment. Also see the Troubleshooting guide in this
manual.
• For the best experience and performance, operate in a dry (no puddles or mud), open environ-
ment away from trafc, and cars (never run into the street for any reason).
• Always turn off both transmitter and ESC and disconnect the battery from the ESC after use.
• Exercise extreme caution when touching the motor immediately after running your vehicle, it
may be HOT and may cause a burn.
• Always allow the motor in your vehicle to cool before using again
SAFETY TIPS
GENERAL CARE AND MAINTENANCE...
General Care:
• Always use clean, dry cloth or soft bristle brush to clean your equipment
• Never use chemical cleansers to avoid damage to the sensitive electronics and plastics
Maintenance:
We want you to enjoy your product to its fullest potential. For this to happen it is important to keep
your product clean and properly maintained. Lack of cleaning and maintenance can cause com-
ponent failure. For best and continued performance from your product it is recommended to briey
inspect your product for damage every few runs. Typically, a good time to do this is when changing
the battery or while it is charging. If a problem is discovered, stop use immediately and seek repairs.
Continued use of failed components can cause more unnecessary damage to your product. Always
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 6 2014-09-29 11:27:03

1/12th SCALE 2WD ELECTRIC
CAGED BUGGY
7
GENERAL CARE AND MAINTENANCE
remember to use genuine replacement parts from your local hobby dealer. Below is a list of items
for inspection. Inspection should not be limited to this list; if you notice any problem, listed or not, it
is recommended to give it proper attention
1. Electronics: The electronics included in your vehicle are not designed to power a submarine,
however they do perform well in all-weather conditions and light submersion for short periods of
time. This is typically found to happen when running through deep puddles where excess water
can ll the chassis area and submerge the electronics. Try to keep the electronics above water
whenever possible.
a. After using your vehicle in wet conditions, it is imperative that you clean and dry all con-
nectors to prevent corrosion. We recommend using electrical contact cleaner to displace
the water on the connectors.
b. Antenna: To achieve full operating range with your radio system, it is critical that the
receiver antenna be installed properly and undamaged
i. Ensure the antenna is installed in a vertical orientation, laying the antenna down will
reduce range and produce unexpected results during operation.
ii. Inspect any exposed antenna for cuts or abrasions
iii. Ensure there are no kinks in the antenna or antenna tube
iv. Never fold the end of the antenna over the tube, this will reduce the range and dam-
age the antenna
2. Gears: Periodically remove the gear box and disassemble the halves to expose the internal
gears. There should be no debris in the gear compartment, just grease.
a. Proper gear mesh setting is crucial for proper operation and life of gears in your product. It
is important to have the pinion gear (attached to motor) as close to the spur gear (attached
to drive shaft) as possible yet while providing a minimal amount of backlash. Backlash is
the rotation one gear has to make before contacting the other. Having the gear mesh set
too tight will cause excess load on the electrical components and may cause premature
failure. Having gear mesh set too loose will cause excess wear and possible skipping of
teeth during operation thus causing excess wear and premature failure
b. Fixed Gear Mesh Settings were designed into your vehicle to accommodate both a 12 and
14T pinion gear. These settings have the proper backlash pre-congured.
c. When gears become loud, this typically means it is time to replace them. The gear that
sees the most wear and tear is the top shaft compound gear.
3. Shocks: Periodically inspect the shocks for smooth/free motion, dirt residue build up around the
shaft and inside the shock body will cause the shocks to bind up and not operate properly.
a. Be sure to clean the shocks regularly with a clean and dry soft bristle brush and/or rag.
b. Adding a few drops of oil to the shock shaft can help keep the shocks operating smooth,
however this oil can also attract unwanted dirt so keep an eye on it and keep them clean
when possible.
4. Tires and wheels:
a. Inspect the tires to ensure they are properly glued to the wheels. The tires on your vehicle
come pre-glued from the factory; however after running your vehicle it is possible for the
glue to come loose in some areas.
i. To reattach the tire to the wheel, use hobby grade Cyanoacrylate (CA) glue and ap-
ply small amounts (one drop at a time) between the tire and wheel. Allow the glue to
fully dry before operating your vehicle.
Caution: Be sure to use extreme care when using hobby-grade CA glue. It is specially formu-
lated to cure quickly and create a strong bond. It will bond skin and can cause injury if used
improperly. Follow manufacturer’s warnings and directions when using CA glue. It is always
recommended to wear eye protection when maintaining your vehicle.
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 7 2014-09-29 11:27:03

Before contacting customer support, recall that this is a hobby grade product in-
tended to be user serviceable. Please take the time to fully inspect your product
for any obvious causes to the issues you are experiencing. Below are some of
the most common issues experienced. Scan the QR code to the right with your
smart phone for quick access to the product support page on our website.
1. Dead transmitter or vehicle batteries will cause the product to malfunction
and not work properly. As with TV remote controls in your home, if the bat-
teries are dead, they don’t work. Start power related troubleshooting with
fresh batteries in the transmitter and recharged batteries in the vehicle.
2. Connections between the Battery, ESC, and Motor are critical to the performance of the product.
Running in various debris may cause foreign objects to snag on wires, causing connections
to come loose. It is a good idea to unplug and reconnect motor and battery connections when
beginning troubleshooting.
3. Drivetrain issues can mask themselves as power related. Fully inspect the wheels, driveshafts,
and motor for foreign objects that may have become tangled or wrapped around the spinning
parts of the drivetrain. Small objects like shing line for example, can wrap around a drive shaft,
overheat and melt due to the friction and cause the entire drivetrain to lock up. Although a big
problem, it can be difcult to see when inspecting. Always remove the wheels from your vehicle
when starting drivetrain related issues.
4. When running in dirt and areas with a lot of debris, the motor can be exposed to foreign con-
taminants such as grass, twigs, or other objects which can get lodged in the cooling holes of
the motor, causing the motor to lock up and stop functioning. Inspect the holes of your motor for
foreign objects and remove them if present.
5. Healthy gears are crucial to a properly functioning vehicle. If you hear your vehicle making very
loud noises, you should immediately stop and check the gears for foreign debris. Even a small
pebble can get lodged into the teeth of the pinion gear, which would practically destroy the spur
gear in a very short period of time.
8
ii. When reinstalling tires, use caution when tightening the nuts that secure the wheels
to the vehicle. Ensure they rotate freely but don’t wobble excessively. Over tightening
the wheels will cause excess strain on the electrical and mechanical components of
your vehicle. Operating your vehicle under these conditions will void your warranty.
iii. Tire wear: Consequently running your vehicle will cause the tires to eventually wear
out. Be sure to obtain and use genuine replacement parts from your local hobby
dealer.
5. General wear and tear:
a. Use of your vehicle will cause general wear and tear which is not covered under warranty
yet may necessitate replacement of components. Continued operation of your product with
use of worn components may cause continued damage to other components
b. Be sure to regularly inspect your vehicle and accessories for excess wear and damaged
components. If any are found, replace them immediately.
GENERAL CARE AND MAINTENANCE
TROUBLESHOOTING PROBLEMS
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 8 2014-09-29 11:27:03

1/12th SCALE 2WD ELECTRIC
CAGED BUGGY
9
TROUBLESHOOTING GUIDE
Problem / Symptom Possible Cause Possible Solution
Vehicle will not turn on
Battery voltage too low Charge battery
Battery not connected Re/connect battery
Damaged battery Replace battery
Transmitter will not
turn on
Battery voltage too low Charge or change batteries
Battery/ies installed improp-
erly Correct installation
Short radio range (Ve-
hicle stops respond-
ing to transmitter at
short distances)
Damaged or improperly
installed receiver antenna
Check receiver antenna for damage. En-
sure antenna is properly installed in tube
and mount, extending perpendicular from
the ground
Transmitter battery voltage
too low Replace batteries
Spur gears stripping
Gear mesh too loose Tighten gear mesh for proper backlash
Bearings worn out and need
replacing
Check for loose fasteners on spur gear
cover and motor mount
Steering not respond-
ing as expected
Trim not set properly Adjust steering trim
Screws too tight on steering
components Adjust screws to allow for free motion
Vehicle not respond-
ing as expected to
transmitter
Trims not set properly Adjust throttle and/or steering trim
Radio system lost bind Re-bind radio system
Bad electrical connections Check motor and battery plugs to ensure
they are fully connected
Vehicle top speed and
acceleration is slow
Battery voltage too low Charge battery
Drivetrain has too much
friction Check and slightly loosen wheel nuts
Pinion gear is loose Check and tighten set screw on motor
pinion
Drive pin missing or stripped Check for missing wheel pins (behind
wheel hexes), or dogbone pins
Shocks sticking in up
position.
Dirt and dust has gotten into
shock body
Clean out shock bodies and clean off
shafts, apply small amount (1-2 drops to
each shaft)
Battery does not hold
charge
Battery has deteriorated and
needs replacement
Replace battery with compatible type or
upgrade
Vehicle only has
forward or reverse
throttle but not both
The TH trim is not centered Center the TH trim and power-cycle the
transmitter and vehicle.
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 9 2014-09-29 11:27:03

10
GEARBOX ASSEMBLY
HLNA0505
HLNA0504
HLNA0483
HLNA0535
HLNA0540
HLNA0513
HLNA0516
HLNA0514
HLNA0504
HLNA0516
HLNA0508
HLNA0507
HLNA0505
HLNA0515
HLNA0505HLNA0506
HLNA0508
HLNA0517
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 10 2014-09-29 11:27:04

1/12th SCALE 2WD ELECTRIC
CAGED BUGGY
11
REAR SUSPENSION ASSEMBLY HLNA0535
HLNA0510
HLNA0525
HLNA0512
HLNA0512
HLNA0522
HLNA0522
HLNA0518
HLNA0490
HLNA0490
HLNA0518
HLNA0493
HLNA0493
HLNA0535
HLNA0526
HLNA0521
HLNA0488
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 11 2014-09-29 11:27:05

12
REAR END ASSEMBLY
HLNA0536
HLNA0536
HLNA0535
HLNA0535
HLNA0536
HLNA0535
HLNA0535
HLNA0498
HLNA0498
HLNA0498
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 12 2014-09-29 11:27:05

1/12th SCALE 2WD ELECTRIC
CAGED BUGGY
13
REAR LINKS AND SHOCKS
HLNA0524
HLNA0524
HLNA0524
HLNA0524
HLNA0518
HLNA0509
HLNA0509
HLNA0518
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 13 2014-09-29 11:27:07

14
FRONT SUSPENSION ASSEMBLY
HLNA0519
HLNA0494
HLNA0495
HLNA0535
HLNA0536
HLNA0492
HLNA0492
HLNA0511
HLNA0491 HLNA0512
HLNA0512
HLNA0522
HLNA0491
HLNA0518
HLNA0518
HLNA0525
HLNA0518
HLNA0535
HLNA0535
HLNA0491
HLNA0525
HLNA0535
HLNA0491
HLNA0522
HLNA0518
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 14 2014-09-29 11:27:08

1/12th SCALE 2WD ELECTRIC
CAGED BUGGY
15
STEERING ASSEMBLY
HLNA0536
HLNA0496
HLNA0525
HLNA0535
HLNA0538
HLNA0535
HLNA0497
HLNA0538
HLNA0535
HLNA0523
HLNA0518
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 15 2014-09-29 11:27:10

16
ERS UNIT INSTALLATION
HLNA0482
HLNA0485
HLNA0535
HLNA0518
HLNA0535
HLNA0536
HLNA0518
HLNA0518
HLNA0518
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 16 2014-09-29 11:27:13

1/12th SCALE 2WD ELECTRIC
CAGED BUGGY
17
REAR END ASSEMBLY
HLNA0535
HLNA0532
HLNA0489
HLNA0525
HLNA0499
HLNA0520
HLNA0520
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 17 2014-09-29 11:27:15

18
WHEELS AND BODY
REPLACEMENT PARTS LIST...
HLNA0537
HLNA0487
HLNA0486
HLNA0527 (CLEAR)
HLNA0528 (GREEN-ORANGE)
HLNA0529 (BLUE-ORANGE)
HLNA0530 (BLUE-SILVER)
HLNA0531 (RED-SILVER)
HLNA0476.....Power Supply, 9V 500mAh, US...................................................................................
HLNA0480.....Balance Charger, 2s LiPo, 7.4V ..................................................................................
HLNA0481.....Battery, 2s LiPo, 1,500mAh, B-XH, HCT .....................................................................
HLNA0482.....Helion 2-1 Modular ERS, HCT (12KT) ........................................................................
HLNA0483.....Motor, Brushed, 380 Size, RR .....................................................................................
HLNA0484.....HRSS-2 2Ch 2.4GHz Transmitter................................................................................
HLNA0485.....Servo, 5-Wire, Modular ERS (12KT) ...........................................................................
HLNA0486.....Front Tires and Wheels (12B)......................................................................................
HLNA0487.....Rear Tires and Wheels (12B) ......................................................................................
HLNA0488.....Main Chassis (12B) .....................................................................................................
HLNA0489.....Battery Door and Pin (12KT) .......................................................................................
HLNA0490.....Rear Hub Carriers (12KT) ...........................................................................................
HLNA0491.....Spindles and Carriers (12KT)......................................................................................
HLNA0492.....Front Suspension Arms (12B) .....................................................................................
HLNA0493.....Rear Suspension Arms (12B)......................................................................................
HLNA0494.....Front Bulkhead (12KT) ................................................................................................
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 18 2014-09-29 11:27:17

1/12th SCALE 2WD ELECTRIC
CAGED BUGGY
19
REPLACEMENT PARTS LIST...
HLNA0495.....Front Shock Tower (12B).............................................................................................
HLNA0496.....Front Top Plate (12KT) ................................................................................................
HLNA0497.....Steering Set (12KT).....................................................................................................
HLNA0498.....Rear Shock Tower (12B) .............................................................................................
HLNA0499.....Roll Cage (12KT).........................................................................................................
HLNA0500.....Impakt 12B 2wd Caged Buggy (US)............................................................................
HLNA0504.....Transmission Case (12KT) ..........................................................................................
HLNA0505.....Differential Housing (12KT) .........................................................................................
HLNA0506.....Differential Outdrives (12KT) .......................................................................................
HLNA0507.....Differential Gears (12KT).............................................................................................
HLNA0508.....Differential Hardware (12KT).......................................................................................
HLNA0509.....Dogbones, Molded (12KT) ..........................................................................................
HLNA0510.....Rear Axle Cups (12KT)................................................................................................
HLNA0511 .....Front Axles (12KT).......................................................................................................
HLNA0512.....12mm Hex Adapters (12KT) ........................................................................................
HLNA0513.....Spur Gear (12B) ..........................................................................................................
HLNA0514.....Top Shaft (12KT) .........................................................................................................
HLNA0515.....Differential Bearings (12KT) ........................................................................................
HLNA0516.....Bearings, 3x6x2.5mm (12KT)......................................................................................
HLNA0517.....Motor Screw Kit (12KT) ...............................................................................................
HLNA0518.....Links, Pivot Balls and Screws (12KT)..........................................................................
HLNA0519.....Front Bumper (12B).....................................................................................................
HLNA0520.....Rear Wing (12B)..........................................................................................................
HLNA0521.....Rear Suspension D Brace (12KT)...............................................................................
HLNA0522.....Bushings, 5x10x4mm (12KT) ......................................................................................
HLNA0523.....Front Shock Set (12B).................................................................................................
HLNA0524.....Rear Shock Set (12B)..................................................................................................
HLNA0525.....Outer Hinge Pin Set (12KT).........................................................................................
HLNA0526.....Inner Hinge Pin Set (12KT) .........................................................................................
HLNA0527.....Body, Clear (12B) ........................................................................................................
HLNA0528.....Body, Green-Orange (12B)..........................................................................................
HLNA0529.....Body, Blue-Orange (12B) ............................................................................................
HLNA0530.....Body, Blue-Silver (12B) ...............................................................................................
HLNA0531.....Body, Red-Silver (12B) ................................................................................................
HLNA0532.....Driver (12KT) ...............................................................................................................
HLNA0533.....Clear Driver (12KT) .....................................................................................................
HLNA0534.....Decal Sheet (12B) .......................................................................................................
HLNA0535.....Button Head Philips Screw Set (12B)..........................................................................
HLNA0536.....Flat Head Philips Screw Set (12B) ..............................................................................
HLNA0537.....Flanged Locknuts, M4, Black ......................................................................................
HLNA0538.....Steering Hardware Kit (12KT) .....................................................................................
HLNA0539.....LiPo Charging Bag, 2s 1500mAh 10C.........................................................................
HLNA0040.....Pinion Gears, 2.3 x M0.6 12T, 14T (12KT) ..................................................................
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 19 2014-09-29 11:27:17

000426-001 (REV B)
000426-001 (REV B) Impakt 12B Owner's Manual and Exploded Views.indd 20 2014-09-29 11:27:17
