HPE FlexNetwork 5140 HI Switch Series
Installation Guide
Document version: 6W100-20220408

© Copyright 2022 Hewlett Packard Enterprise Development LP
The information contained herein is subject to change without notice. The only warranties for Hewlett Packard
Enterprise products and services are set forth in the express warranty statements accompanying such
products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett
Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
Confidential computer software. Valid license from Hewlett Packard Enterprise required for possession, use, or
copying. Consistent with FAR 12.211 and 12.212, Commercial Computer Software, Computer Software
Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government under vendor’s
standard commercial license.
Links to third-party websites take you outside the Hewlett Packard Enterprise website. Hewlett Packard
Enterprise has no control over and is not responsible for information outside the Hewlett Packard Enterprise
website.
Acknowledgments
Intel®, Itanium®, Pentium®, Intel Inside®, and the Intel Inside logo are trademarks of Intel Corporation in the
United States and other countries.
Microsoft® and Windows® are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
Adobe® and Acrobat® are trademarks of Adobe Systems Incorporated.
Java and Oracle are registered trademarks of Oracle and/or its affiliates.
UNIX® is a registered trademark of The Open Group.

i
Contents
Preparing for installation····································································1
Safety recommendations···············································································································2
Examining the installation site·········································································································2
Temperature/humidity ············································································································2
Cleanliness ··························································································································3
Corrosive gas limit·················································································································3
EMI ····································································································································4
Laser safety ·························································································································4
Installation tools···························································································································4
Installation accessories·················································································································5
Installing the switch ··········································································7
Installing the switch in a 19-inch rack·······························································································8
Installation methods···············································································································8
Installation accessories ··········································································································9
Rack-mounting the switch by using front mounting brackets ··························································9
Rack-mounting the switch by using front and rear mounting brackets············································11
Mounting the switch on a workbench ····························································································· 15
Grounding the switch·················································································································· 15
Grounding the switch with a grounding strip ············································································· 15
Grounding the switch with a grounding conductor buried in the earth ground ·································· 17
Installing/removing a power supply································································································ 18
Installing a PSR150-A1/PSR150-D1 power supply·····································································19
Removing a PSR150-A1/PSR150-D1 power supply··································································· 20
Installing a PSR720-56A/PSR1110-56A power supply································································20
Removing a PSR720-56A/PSR1110-56A power supply······························································22
Connecting the power cord ·········································································································· 23
Connecting the PSR150-A1 ·································································································· 23
Connecting the PSR150-D1 ·································································································· 24
Connecting the PSR720-56A/PSR1110-56A ············································································ 24
Installing/removing an expansion card···························································································· 25
Installing an expansion card ·································································································· 25
Removing an expansion card ································································································ 27
Verifying the installation ·············································································································· 27
Accessing the switch for the first time ·················································29
Connecting the switch to a configuration terminal············································································· 29
Connecting the serial console cable······························································································· 29
Connecting the micro USB console cable ······················································································· 30
Setting terminal parameters ········································································································· 32
Powering on the switch ··············································································································· 32
Setting up an IRF fabric···································································34
IRF fabric setup flowchart············································································································ 34
Planning IRF fabric setup ············································································································ 35
Planning IRF fabric size and the installation site········································································ 35
Identifying the master switch and planning IRF member IDs························································35
Planning IRF topology and connections··················································································· 35
Identifying physical IRF ports on the member switches······························································· 36
Planning the cabling scheme································································································· 37
Configuring basic IRF settings······································································································ 39
Connecting the physical IRF ports································································································· 39
Verifying the IRF fabric setup ······································································································· 40
Maintenance and troubleshooting ······················································41
Hot-swappable power supply failure ······························································································ 41
Hot-swappable fan tray failure ······································································································ 41

ii
Removing a fan tray············································································································· 42
Installing a fan tray ·············································································································· 42
Configuration terminal display problems ························································································· 43
No display·························································································································· 43
Garbled display··················································································································· 44
Appendix A Chassis views and technical specifications··························45
Chassis views ··························································································································· 45
HPE 5140 24G 4SFP+ 1-slot HI····························································································· 45
HPE 5140 24G PoE+ 4SFP+ 1-slot HI····················································································· 46
HPE 5140 48G 4SFP+ 1-slot HI····························································································· 47
HPE 5140 48G PoE+ 4SFP+ 1-slot HI····················································································· 48
Technical specifications ·············································································································· 49
Non-PoE switch models········································································································ 49
PoE switch models ·············································································································· 50
Appendix B FRUs and compatibility matrixes ·······································52
Hot-swappable power supplies ····································································································· 52
Expansion cards ························································································································ 53
Connecting cables to the copper ports on the interface cards ······················································ 54
Appendix C Ports and LEDs·····························································55
Ports········································································································································ 55
Console port······················································································································· 55
Management Ethernet port···································································································· 55
USB port···························································································································· 55
1/10BASE-T autosensing Ethernet port ··················································································· 56
10/100/1000BASE-T autosensing Ethernet port ········································································ 56
10G/5G/2.5G/1000/100BASE-T autosensing Ethernet port··························································56
SFP port···························································································································· 57
SFP+ port·························································································································· 59
Combo interface·················································································································· 61
LEDs ······································································································································· 61
System status LED·············································································································· 61
Power supply status LED······································································································ 61
MODE LED························································································································ 61
10/100/1000BASE-T autosensing Ethernet port LED ································································· 62
10G/5G/2.5G/1000/100BASE-T autosensing Ethernet port LED···················································63
SFP port LED····················································································································· 63
SFP+ port LED ··················································································································· 64
Management Ethernet port LED····························································································· 64
Expansion card status LED ··································································································· 65
Port status LED on the expansion card···················································································· 65
Input status LED and output status LED on the power supply ······················································65
Fan tray status LED on the fan tray························································································· 65
Appendix D Cooling system······························································66
Document conventions and icons ······················································67
Conventions······························································································································ 67
Network topology icons ··············································································································· 68
Support and other resources·····························································69
Accessing Hewlett Packard Enterprise Support················································································ 69
Accessing updates····················································································································· 69
Websites ··························································································································· 70
Customer self repair ············································································································ 70
Remote support ·················································································································· 70
Documentation feedback ······································································································ 70
Index···························································································72

1
Preparing for installation
Table 1 describes the HPE FlexNetwork 5140 HI switches, power supplies,and interface cards
available for the switches.
Table 1 HPE 5140 HI switch models and power supplies
Product code HPE description Alias
HPE 5140 HI switches
R9L61A HPE FlexNetwork 5140 24G 4SFP+ 1-slot
HI Switch HPE 5140 24G 4SFP+ 1-slot HI
R9L62A HPE FlexNetwork 5140 48G 4SFP+ 1-slot
HI Switch HPE 5140 48G 4SFP+ 1-slot HI
R9L63A HPE FlexNetwork 5140 24G PoE+ 4SFP+
1-slot HI Switch HPE 5140 24G PoE+ 4SFP+ 1-slot HI
R9L64A HPE FlexNetwork 5140 48G PoE+ 4SFP+
1-slot HI Switch HPE 5140 48G PoE+ 4SFP+ 1-slot HI
Power supplies
JD362B HPE X361 150W AC Power Supply PSR150-A1
JD366B HPE X361 150W DC Power Supply PSR150-D1
JG545A HPE X362 1110W AC PoE Power Supply PSR1110-56A
JG544A HPE X362 720W AC PoE Power Supply PSR720-56A
Interface cards
JH156A HPE 5130/5510 10GBASE-T 2-port Module LSWM2XGT2PM
JH157A HPE 5130/5510 10GbE SFP+ 2-port
Module LSWM2SP2PM
R9L65A HPE 5140/5520 10GBASE-T MACsec
2-port Module LSWM2XMGT2PM
For regulatory identification purposes, the HPE 5140 HI switches are assigned Regulatory Model
Number (RMN), which are listed in the following table. These regulatory numbers should not be
confused with the marketing name HPE 5140 HI, or the product codes.
Product code RMN HPE description
R9L61A BJNGA-AD0093 HPE FlexNetwork 5140 24G 4SFP+ 1-slot HI Switch
R9L62A BJNGA-AD0094 HPE FlexNetwork 5140 48G 4SFP+ 1-slot HI Switch
R9L63A BJNGA-AD0096 HPE FlexNetwork 5140 24G PoE+ 4SFP+ 1-slot HI Switch
R9L64A BJNGA-AD0097 HPE FlexNetwork 5140 48G PoE+ 4SFP+ 1-slot HI Switch

2
Safety recommendations
To avoid any equipment damage or bodily injury caused by improper use, read the following safety
recommendations before installation. Note that the recommendations do not cover every possible
hazardous condition.
•
Before cleaning the switch, remove all power cords from the switch. Do not clean the switch
with wet cloth or liquid.
•
Do not place the switch near water or in a damp environment. Prevent water or moisture from
entering the switch chassis.
•
Do not place the switch on an unstable case or desk. The switch might be severely damaged in
case of a fall.
•
Ensure good ventilation of the equipment room and keep the air inlet and outlet vents of the
switch free of obstruction.
•
Connect the yellow-green protection grounding cable before powering on the switch.
•
Make sure the operating voltage is in the required range.
•
To avoid electrical shocks, do not open the chassis while the switch is operating or when the
switch is just powered off.
•
When replacing field replaceable units (FRUs), including expansion cards, power supplies, and
fan trays, wear an ESD wrist strap to avoid damaging the units.
Examining the installation site
The switch must be used indoors. You can mount your switch in a rack or on a workbench, but make
sure:
•
Adequate clearance is reserved at the air inlet and outlet vents for ventilation.
•
The rack or workbench has a good ventilation system.
•
Identify the hot aisle and cold aisle at the installation site, and make sure ambient air flows into
the switch from the cold aisle and exhausts to the hot aisle.
•
Identify the airflow designs of neighboring devices, and prevent hot air flowing out of the
neighboring device from entering the device.
•
The rack is sturdy enough to support the switch and its accessories.
•
The rack or workbench is reliably grounded.
To ensure correct operation and long service life of your switch, install it in an environment that meets
the requirements described in the following subsections.
Temperature/humidity
For correct operation and long service life of your switch, maintain the temperature and humidity in
the equipment room at acceptable ranges.
•
Lasting high relative humidity can cause poor insulation, electricity leakage, mechanical
property change of materials, and metal corrosion.
•
Lasting low relative humidity can cause washer contraction and ESD and cause problems
including loose mounting screws and circuit failure.
•
High temperature can accelerate the aging of insulation materials and significantly lower the
reliability and lifespan of the switch.
For the temperature and humidity requirements of the switch, see technical specifications in
Hardware Information and Specifications.

3
Cleanliness
Dust buildup on the chassis might cause electrostatic adsorption and dust corrosion, resulting in
poor contact of metal connectors and contact points. This might shorten the device's lifetime and
even cause device failure in the worst case. Table 2 describes the dust concentration limits in the
equipment room.
Table 2 Dust concentration limits in the equipment room
Substance Particle diameter Concentration limit
Dust particles ≥ 0.5 µm ≤ 3.5 × 106particles/m3
Dust particles ≥ 5 µm ≤ 3 × 104particles/m3
Dust (suspension) ≤75 µm ≤0.2 mg/m3
Dust (sedimentation) 75 µm to 150 µm ≤1.5 mg/(m2h)
To maintain cleanliness in the equipment room, follow these guidelines:
•
Keep the equipment room away from pollution sources. Do not smoke, eat, or drink in the
equipment room.
•
Use double-layer glass in windows and seal doors and windows with dust-proof rubber strips.
Use screen doors and window screens for doors and windows open to the outside and make
sure the external windows are air tight.
•
Use dustproof materials for floors, walls, and ceilings and use wallpaper or matt paint that does
not produce powders.
•
Clean the equipment room regularly and clean the air filters of the rack each month.
•
Wear ESD clothing and shoe covers before entering the equipment room, keep the ESD
clothing and shoe covers clean, and change them frequently.
Corrosive gas limit
Corrosive gases can accelerate corrosion and aging of metal components. Make sure the corrosive
gases in the equipment room do not exceed the concentration limits as shown in Table 3.
Table 3 Corrosive gas concentration limits in the equipment room
Gas Average concentration (mg/m3) Maximum concentration (mg/m3)
SO20.3 1.0
H2S 0.1 0.5
Cl20.1 0.3
HCI 0.1 0.5
HF 0.01 0.03
NH31.0 3.0
O30.05 0.1
NOX0.5 1.0
CAUTION:
As a best practice, control the
corrosive gas concentrations in the equipment room at their
average
values
. Make sure the corrosive gas concentrations do not exceed 30 minutes per day at their
maximum values.

4
To control corrosive gases, use the following guidelines:
•
As a best practice, do not build the equipment room in a place with a high concentration of
corrosive gases.
•
Make sure the equipment room is not connected to sewer, vertical shaft, or septic tank pipelines
and keep it far away from these pipelines. The air inlet of the equipment room must be away
from such pollution sources.
•
Use environmentally friendly materials to decorate the equipment room. Avoid using organic
materials that contains harmful gases, such as sulfur or chlorine-containing insulation cottons,
rubber mats, sound-proof cottons, and avoid using plasterboards with high sulfur concentration.
•
Place fuel (diesel or gasoline) engines separately. Do not place them in the same equipment
room with the device. Make sure the exhausted air of the engines will not flow into the
equipment room or towards the air inlet of the air conditioners.
•
Place batteries separately. Do not place them in the same room with the device.
•
Employ a professional company to monitor and control corrosive gases in the equipment room
regularly.
EMI
All electromagnetic interference (EMI) sources, from outside or inside of the switch and application
system, adversely affect the switch in the following ways:
•
A conduction pattern of capacitance coupling.
•
Inductance coupling.
•
Electromagnetic wave radiation.
•
Common impedance (including the grounding system) coupling.
To prevent EMI, use the following guidelines:
•
If AC power is used, use a single-phase three-wire power receptacle with protection earth (PE)
to filter interference from the power grid.
•
Keep the switch far away from radio transmitting stations, radar stations, and high-frequency
devices.
•
Use electromagnetic shielding, for example, shielded interface cables, when necessary.
•
To prevent signal ports from getting damaged by overvoltage or overcurrent caused by lightning
strikes, route interface cables only indoors.
Laser safety
WARNING
!
The switch is Class 1 laser device.
Do not stare into any fiber port when the switch has power. The
laser light emitted from the optical fiber might hurt your eyes.
Installation tools
•
Flat-blade screwdriver
•
Phillips screwdriver
•
ESD wrist strap
All these installation tools are user supplied.

5
Installation accessories
Table 4 Installation accessories
Product code Description Quantity Applicable models
5066-0850
1 U four-hole mounting bracket kit
(including one pair of mounting brackets
and eight M4 countersunk screws)
1 kit All HPE 5140 HI switches
5190-0297
Rear mounting bracket kit (including one
pair of mounting brackets and two
load-bearing screws)
1 kit
•HPE 5140 24G PoE+
4SFP+ 1-slot HI
•HPE 5140 48G PoE+
4SFP+ 1-slot HI
N/A
M6 screw and floating nut (user
supplied)
As required All HPE 5140 HI switches
5185-9292
Grounding cable (tin-plated at one end
and with a ring terminal at the other end)
1
•HPE 5140 24G 4SFP+
1-slot HI
•HPE 5140 48G 4SFP+
1-slot HI
5185-9408
Grounding cable (with ring terminals at
both ends)
1
•HPE 5140 24G PoE+
4SFP+ 1-slot HI
•HPE 5140 48G PoE+
4SFP+ 1-slot HI
5185-8503
Power supply filler panel
1
•HPE 5140 24G 4SFP+
1-slot HI
•HPE 5140 48G 4SFP+
1-slot HI
5190-1774
Power supply filler panel
1
•HPE 5140 24G PoE+
4SFP+ 1-slot HI
•HPE 5140 48G PoE+
4SFP+ 1-slot HI
5190-0296
Interface card filler panel
1 All HPE 5140 HI switches
5060-0174 HPE X722 port to power fan tray
(already installed on the switch) 2 All HPE 5140 HI switches

6
Product code Description Quantity Applicable models
5060-0175
HPE X721 power to port fan tray (order
as required)
2 All HPE 5140 HI switches
5185-9443
5080-0120
DC power cord (supplied with the
PSR150-D1 (JD366B) DC power
supply)
The power cord colorcode scheme is for
illustration only. The cable delivered for
your country or region might use a
different color scheme.
1 PSR150-D1 (JD366B)
N/A
AC power cord
NOTE:
The AC power cord part number will
differ depending on the country or
region.
1
•PSR150-A1 (JD362B)
•PSR720-56A (JG544A)
•PSR1110-56A (JG545A)
5184-7298
Rubber feet
4 All HPE 5140 HI switches

7
Installing the switch
CAUTION:
Keep the tamper
-
proof seal on a mounting screw on the chassis cover intact, and if you want to open
the chassis, contact Hewlett Packard Enterprise for permission.
Otherwise, Hewlett Packard
Enterprise shall not be liable for any consequence.
Figure 1 Hardware installation flow
Ground the switch
Install the switch
Start
Connect power cords
Verify the installation
Power on the switch
Operating correctly? Power off the switch
Troubleshoot the switch
No
Yes
Install expansion cards?
Install expansion cards
Yes
Troubleshoot the switch
Yes
No
End
No
Operating correctly?
Connect interface cables
Select and install fan trays
Select and install power
supplies

8
Installing the switch in a 19-inch rack
Installation methods
Table 5 Installation methods for the HPE 5140 HI switches
Chassis Installation
methods Installation requirements Installation procedure
HPE 5140 24G
4SFP+ 1-slot HI
HPE 5140 48G
4SFP+ 1-slot HI
Using front
mounting
brackets
Install the front mounting
brackets at the port side or
power supply side.
See "Rack-mounting the
switch by using front
mounting brackets."
HPE 5140 24G PoE+
4SFP+ 1-slot HI
HPE 5140 48G PoE+
4SFP+ 1-slot HI
Using front and
rear mounting
brackets
•Install the front mounting
brackets at the port side or
power supply side.
•Install the rear mounting
brackets based on the rack
depth.
If the rack depth is in the
range of 429 to 595 mm
(16.89 to 23.43 in),
orient the bracket with
the wide flange inside
the rack.
If the rack depth is in the
range of 274 to 440 mm
(10.79 to 17.32 in) and
the distance from the
rear rack posts to the
inner surface of the
cabinet door is longer
than 153 mm (6.02 in),
orient the bracket with
the wide flange outside
the rack.
See "Rack-mounting the
switch by using front and
rear mounting brackets."
Figure 2 Procedure for rack-mounting the switch by using the front mounting brackets
Figure 3 Procedure for rack-mounting the switch by using the front and rear mounting
brackets
NOTE:
If a rack shelf is available, you can put the switch on the rack shelf, slide the switch to an appropriate
location, and attach the switch to the rack by using the mounting brackets.
Attach the front
mounting brackets to
the switch
Determine the front mounting
bracket installation position (port
side or power module side) Mount the switch
in the rack
Attach the front
mounting
brackets to the
switch
Attach the
shoulder
screws to the
switch
Attach the
rear mounting
brackets to
the rack
Determine the front
mounting bracket
installation position (port
side or power module side)
Mount the
switch in the
rack

9
Installation accessories
Table 6 Installation accessories for the HPE 5140 HI switches
Switch model Front mounting
brackets (Figure 4) Rear mounting brackets and shoulder screws (Figure 5)
HPE 5140 24G 4SFP+ 1-slot HI
HPE 5140 48G 4SFP+ 1-slot HI Provided N/A
HPE 5140 24G PoE+ 4SFP+ 1-slot HI
HPE 5140 48G PoE+ 4SFP+ 1-slot HI Provided Provided
Figure 4 Front mounting bracket
(1) Screw hole for attaching the bracket to the switch
(2) Screw hole for attaching the bracket to the rack
(3) M4 screw
Figure 5 Rear mounting bracket and shoulder screw
(1) Screw hole for attaching the bracket to the rack
(2) Shoulder screw
Rack-mounting the switch by using front mounting brackets
Attaching the front mounting brackets to the switch
The HPE 5140 24G 4SFP+ 1-slot HI and HPE 5140 48G 4SFP+ 1-slot HI switches provide two
installation positions on the side panels for the front mounting brackets. One is near the power
supply side and one is near the port side.
To attach the front mounting brackets to the switch:
1
2
3
12

10
1. Determine the mounting position for the front mounting brackets.
2. Align the round holes in the wide flange of one front mounting bracket with the screw holes in
the chassis. See Figure 6 and Figure 7.
3. Use M4 screws (provided with the switch) to attach the mounting bracket to the chassis.
4. Repeat the proceeding two steps to attach the other mounting bracket to the chassis.
Figure 6 Attaching the front mounting bracket to the port side
Figure 7 Attaching the front mounting bracket to the power supply side
Mounting the switch in the rack
1. Wear an ESD wrist strap and make sure it makes good skin contact and is reliably grounded.
2. Make sure the front mounting brackets have been attached securely to the two sides of the
switch.
3. Install cage nuts (user-supplied) in the mounting holes in the rack posts. Make sure the
corresponding cage nuts on the left and right front rack posts are at the same height.
4. One person holds the switch chassis and aligns the installation holes on the mounting brackets
with the cage nuts on the rack posts.
5. The other person attaches the mounting brackets with M6 screws (user-supplied) to the rack.

11
Figure 8 Mounting the switch in the rack (front mounting brackets at the port side)
Figure 9 Mounting the switch in the rack (front mounting brackets at the power supply
side)
Rack-mounting the switch by using front and rear mounting
brackets
Attaching the front mounting brackets and shoulder screws to the switch
To rack-mount the HPE 5140 24G PoE+ 4SFP+ 1-slot HI and HPE 5140 48G PoE+ 4SFP+ 1-slot HI
switches by using the front and rear mounting brackets, you can install the front mounting brackets at
the port-side or power supply-side mounting position. The following uses port-side mounting as an
example. The power-side mounting is similar.
To attach the front mounting brackets and shoulder screws to the switch:

12
1. Align the round holes in the wide flange of one front mounting bracket with the screw holes in
the port-side mounting position on one side of the chassis. See Figure 10.
2. Use M4 screws (supplied with the switch) to attach the mounting bracket to the chassis.
3. Repeat the proceeding two steps to attach the other mounting bracket to the chassis.
4. Unpack the shoulder screws. Attach the shoulder screw to one of the two installation positions
as red-marked in Figure 10.
Figure 10 Attaching the front mounting brackets and shoulder screws to the chassis
Attaching the rear mounting brackets to the rack
1. Determine the switch installation position in the rack.
2. Install cage nuts in the rack posts. Make sure the corresponding cage nuts on the left and right
rear rack posts are at the same height.
3. Orient the rear mounting brackets with the wide flange inside or outside the rack as required.
4. Use M6 screws to attach the rear mounting brackets to the rear posts, as shown in Figure 11.
Do not fully tighten the M6 screws before mounting the switch in the rack.

13
Figure 11 Attaching the rear mounting brackets to a rack with the wide flange inside the rack
Figure 12 Attaching the rear mounting brackets to a rack with the wide flange outside the
rack
Mounting the switch in the rack
1. Wear an ESD wrist strap and make sure it makes good skin contact and is reliably grounded.
2. Make sure the front mounting brackets and shoulder screws are securely attached to the two
sides of the switch.
3. Attach cage nuts to the front rack posts. Make sure the corresponding cage nuts on the left and
right front rack posts are at the same height.

14
4. One person supports the chassis bottom with one hand, holds the front part of the chassis with
the other hand, and pushes the chassis into the rack gently.
Make sure the shoulder screws make close contact with the upper edges of the rear mounting
brackets, as shown in Figure 13.
5. The other person attaches the front mounting brackets with M6 screws (user-supplied) to the
front rack posts.
Make sure the switch is installed securely in the rack.
Figure 13 Mounting the switch in the rack (with the wide flange of the rear mounting
brackets inside the rack)
Figure 14 Mounting the switch in the rack (with the wide flange of the rear mounting
brackets outside the rack)

15
Mounting the switch on a workbench
IMPORTANT:
•
Reserve a minimum of 10 cm (3.9 in) of clearance around the chassis for heat dissipation.
•Do not place heavy objects on the switch.
To mount the switch on a workbench:
1. Verify that the workbench is sturdy and reliably grounded.
2. Place the switch with bottom up, and clean the round holes in the chassis bottom with dry cloth.
3. Attach the rubber feet to the four round holes in the chassis bottom.
4. Place the switch with upside up on the workbench.
Grounding the switch
WARNING
!
Correctly connecting the grounding cable is crucial to lightning protection and EMI protection.
The power input end of the switch has a noise filter, whose central ground is directly connected to the
chassis to form the chassis ground (commonly known as PGND). You must securely connect this
chassis ground to the earth to minimize the potential for system damage, maximize the safety at the
site, and minimize EMI susceptibility of the system.
You can ground the switch in one of the following ways, depending on the grounding conditions
available at the installation site:
•
Grounding the switch with a grounding strip
•
Grounding the switch with a grounding conductor buried in the earth ground
NOTE:
The power and grounding terminals in this section are for illustration only.
Grounding the switch with a grounding strip
WARNING
!
•
Connect the grounding cable to the grounding strip
in the equipment room. Do not connect it to a
fire main or lightning rod.
•
To guarantee the grounding effect and avoid switch damage, use the grounding cable provided
with the switch to connect the switch to a grounding strip in the equipment room.
If a grounding strip is available at the installation site, connect the grounding cable to the grounding
strip.
Connecting the grounding cable to the chassis
1. Remove the grounding screw from the rear panel of the switch chassis.
2. Use the grounding screw to attach the ring terminal of the grounding cable to the grounding
screw hole. Fasten the screw.

16
IMPORTANT:
Orient the grounding cable as shown in
Figure 15 so you can easily install or remove the
expansion card.
Figure 15 Connecting the grounding cable to the chassis
(1) Grounding screw
(2) Ring terminal
(3) Grounding sign
(4) Grounding hole
(5) Grounding cable
Connecting the grounding cable to a grounding strip (1)
This method is applicable to the HPE 5140 24G PoE+ 4SFP+ 1-slot HI and HPE 5140 48G PoE+
4SFP+ 1-slot HI switches.
To connect the grounding cable to a grounding strip:
1. Remove the hex nut of a grounding post on the grounding strip.
2. Cut the grounding cable to a length required for connecting to the grounding strip.
3. Attach a ring terminal to the grounding cable:
a. Use a wire stripper to strip 5 mm (0.20 in) of insulation off the end of the grounding cable.
b. Slide the heat-shrink tubing onto the cable and insert the bare metal part into the end of the
ring terminal.
c. Use a crimper to secure the metal part of the cable to the ring terminal.
d. Slide the heat-shrink tubing down the cable until the tube covers the joint.
e. Use a heat gun to shrink the tubing around the cable.
Figure 16 Attaching a ring terminal to the grounding cable
4. Connect the ring terminal of the grounding cable to the grounding post of the grounding strip,
and fasten it with the removed hex nut.
5
123
4
(A)
