HENKE TUBE TABLE PLOW
HENKE MODEL: 42RIS TT, 50RIS TT, EXP TT
For Medium to Heavy Duty Trucks
PARTS BOOK AND INSTALLATION MANUAL
SERIAL NUMBER ______________________ VERSION 3.2, NOVEMBER 2014
HENKE MANUFACTURING CORPORATION
MANUFACTURERS OF SNOW REMOVAL EQUIPMENT FOR 95 YEARS
3070 WILSON AVE. LEAVENWORTH, KS 66048 PHONE[phone] FAX[phone]
WEBSITE ADDRESS : WWW.HENKEMFG.COM EMAIL: [email protected]

TUBE_TABLE_PLOW_EFF_NOV09_TO_PRES_8400030_032.DOCX Page 2 of 32
<<THIS PAGE IS INTENTIONALLY LEFT BLANK>>

TUBE_TABLE_PLOW_EFF_NOV09_TO_PRES_8400030_032.DOCX Page 3 of 32
Introduction
Thank you for your purchase of a Henke “Tube Table” Reversible Snow Plow. Your new
Henke plow is designed with heavy-duty features for years of reliable use.
Product Features:
 10 gauge rolled plate steel moldboard with continuous welds standard.
 Heavy 4 x 4 x 3/4” bottom angle.
 Rubber shock absorbers to prevent over-stressing of springs.
 Adjustable moldboard layback: 10, 20, or 30°.
 Heavy 5 x 5 x 3/8” construction tube table reversing assembly.
 Heavy 4 x 12” dual-acting reversing cylinders with 2” nitride rods.
 “Steel Integral shield” prevents snow from blowing over top of moldboard.
 Water drainage ports in ribs to prevent water from pooling when plow is stored.
 Cushion relief valve and hydraulic quick couplers standard.
 Moldboards available in a variety of sizes, with and without discharge ears
(“mouse ears”)
 Multiple trip, hitch, and running gear options available.
 Wide variety of cutting edges, curb guards, and wear guards available.
 Many other options available, including rubber shields, rod markers, jack stands,
etc.
In addition to their field-proven standard units, Henke designs and manufactures many
plows and hitches to meet specific customer requirements.
Call Henke at 913-682-9000 if you need any replacement parts, or if we can provide you
with any other assistance.

TUBE_TABLE_PLOW_EFF_NOV09_TO_PRES_8400030_032.DOCX Page 4 of 32
TableofContents

Section1:
Introduction................................................................................................................................................................2
SafetySummary........................................................................................................................................................6
SetupandOperation...............................................................................................................................................7
Maintenance...............................................................................................................................................................8
Section2:
InstallationDiagrams&Partslists.................................................................................................................10
Hydraulics&InstallationInstructions..........................................................................................................12
Section3:
RunningGear............................................................................................................................................................16
Section4:
TripDevices..............................................................................................................................................................24
Section5:
SwivelPlates&PlowPortionHitches...........................................................................................................26
Section6:
CuttingEdges,CurbGuards,WearGuards..................................................................................................28
Section7:
WarrantyPolicy&Procedure...........................................................................................................................31


TUBE_TABLE_PLOW_EFF_NOV09_TO_PRES_8400030_032.DOCX Page 5 of 32
ListofFigures
FIGURE1‐1‐HenkeTubeTablePlow................................................................................................COVER
FIGURE2‐1‐HenkeTubeTablePlow..........................................................................................................10
FIGURE2‐2‐HydraulicinstallationInstructions.....................................................................................12
FIGURE2‐3‐CableLevelLiftAssembly.......................................................................................................14
FIGURE2‐4‐SlideLevelLiftAssemblyandInstallationInstructions............................................15
FIGURE3‐1‐SpringLoadedRunningGear.................................................................................................16
FIGURE3‐2‐Henke8”SteelWheelAssembly..........................................................................................18
FIGURE3‐3‐MushroomShoeAssembly.....................................................................................................19
FIGURE3‐4‐PneumaticRunningGear........................................................................................................20
FIGURE3‐5‐PneumaticWheelKit5‐LugHub..........................................................................................21
FIGURE3‐6‐OuterTube&YokeAssembly................................................................................................22
FIGURE4‐1‐ExtensionSpringTripAssembly,3‐Spring(EXT3&4)................................................24
FIGURE4‐2‐ExternalCompressionTripAssembly(ECT)..................................................................25
FIGURE5‐1‐UniversalQuickHitch(UQH).................................................................................................26
FIGURE5‐2‐SwivelPlates&PlowHitches................................................................................................27

ListofTables
TABLE2‐1‐HenkeTubeTablePlow,PartsList.......................................................................................11
TABLE2‐2‐HydraulicComponents(NotShowninFigure2‐1).......................................................13
TABLE2‐3‐CableLevelLiftAssembly.........................................................................................................14
TABLE3‐1‐SpringLoadedRunningGear,Partslist..............................................................................17
TABLE3‐2‐Henke8”SteelWheelAssembly,PartsList.......................................................................18
TABLE3‐3‐MushroomShoeAssembly,PartsList.................................................................................19
TABLE3‐4‐PneumaticRunningGear,PartsList.....................................................................................20
TABLE3‐5‐PneumaticWheelKit5‐LugHub,PartsList......................................................................21
TABLE3‐6‐OuterTube&YokeAssembly,PartsList............................................................................22
TABLE4‐1‐ExtensionSpringTripAssembly,3Spring(EXT3&4),PartsList............................24
TABLE4‐2‐ExternalCompressionTripAssembly(ECT),PartsList..............................................25
TABLE5‐1‐UniversalQuickHitch(UQH),PartsList.............................................................................26
TABLE6‐1‐CuttingEdges.................................................................................................................................28
TABLE6‐2‐CuttingEdgeHardware.............................................................................................................29
TABLE6‐3‐HenkeCurbGuards......................................................................................................................30
