HERA POWER PACK 2500 Installation and operating instructions

www.heraled.com
Congratulations on choosing a HERA product!
We thank you for your custom.
Please note that this product, as all the others in the rich HERA range, has been designed and made with total quality to ensure excellent
performance and best meet your expectations and requirements. Carefully read this instruction manual in its entirety and keep it safe for
future reference. It is essential to know the information and comply with the instructions given in this manual to ensure the fitting is
installed, used and serviced correctly and safely. HERA disclaims all liability for damage to the fitting or to other property or persons
deriving from installation, use and maintenance that have not been carried out in conformity with this instruction manual, which must
always accompany the fitting. HERA reserves the right to modify the characteristics stated in this instruction manual at any time and
without prior notice.
POWER PACK 2500
R
User’s Manual & Installation Guide
Index V1.2
1
Technical Drawing
Block Diagram
6
7
Safety Information
Warranty
Marking
2
Explanation
Details
Ordering Information
3
4
Cover & Index
Back Cover
Connection Diagram
Connection Diagram
5
8
9
Products Table
Accessories

www.heraled.com
Safety Information
2
Warranty
Hera warrants the products for a period of three (3) years from date of purchase, provided that
the purchased items are used under the conditions stated in this user manual.
Marking
Caution – unplug the power supply from the main power before connecting any cables as this can damage the products.
Caution – avoid looking directly into the led light source at close range for your own safety.
Any people installing this product should comply with local standards and regulations and must be qualifed for the handling of
electrical equipment.
• Do not attempt to install or use the product until installation instructions and safety labels are fully understood.
This product is designed for indoor and outdoor usage.
• Ensure product operates within the specifed temperature range.
• Do not attempt to open the product.
• Do not use the product if the power cables are damaged.
• Only use product for specifed voltage.
• Always maintain connection to ensure waterproofing.
• If the product has been subjected to drastic temperature variances, for example, following transportation,
do not connect the fixture until it has reached room temperature, as moisture condensation may cause electric
shock and product damages.
• When installing the products and system power supplies, please ensure they will not be exposed to moisture and extreme heat
(and direct sunlight for outdoor products). Besides, keep a clean operating environment for the fixtures and system power supplies..
• Any non-compliance of the Installation Guide will void the Hera warranty.
Please study this Installation Guide thougly and check the lates Tecnical Specification Sheets available from the
our website www.heraled.com before setup.
20
POWER PACK 2500
R

Details
Hera Power Pack® 2500; consists of 8x320Watt power supply unit. DMX signal has been transformed into single connector with power
units and exits as 5 Pin Push-Lock. It has 90~264VAC 50/60Hz Universal operating voltage and 8x320 Watt power. It has active PFC. It has
standard 19inc 3U Rack type. It is manufactured at two different types as 24V and 48V. It has been shaped from plate, having aluminum
body. It is produced RAL9004 black as a standard
• Legendary solution in long distance DMX transmission
• DMX input and output with standard Neutrik® DMX connectors
• Ac Power input Neutrik® PowerCon® (NAC 3MPA)
• Power output with 5 Pin Push-Lock connectors
• It is cooled down with built in fan
• Safe use in interior spaces with IP20 protection
Explanation
Power Supply : Internal Power Supply 8x320 Watt With Active PFC
Input : 90~264VAC 50/60Hz Universal AC input / Full range
AC Input Connector Neutrik® PowerCon® (NAC 3MPA
Output : Output 5-Pin IP67 Waterproof Connector (Power + DMX)
DMX Signal Input and Output 3 Pin XLR
Housing : Aluminium Sheet Metal With Powder Finishing
Screw and Mounting Accessories : Black Iron
Temperature : Operating : -40°C - 50°C - (-40° - 122° F)
Storage : -40°C - 85°C - (-40°C - 185° F)
Dimensions (H x W x D): : 132x483x366 mm (5,19x19x14,4 in)
Weight : 0,12 kg (0,264 lb)
Certification : EU safety: EN 60950
EU EMC: EN 55103-1, EN 55103-2, EN 55022, EN 55024, EN 61000-3-2, EN 61000-3-3
US safety: ANSI/UL 60950-1
Ordering Information
Power Pack® 2500-48 8x320W Power Supply P08003
www.heraled.com 3
Power Pack® 2500-24 8x320W Power Supply P08011
POWER PACK 2500
R

Outdoor Zone
Indoor Zone
Block Diagram
www.heraled.com 4
POWER PACK 2500
R
POWERDMX OUTDMX INUSB
DMX Signal
8
Any device which supports Art-Net to DMX 512 or USB Interface
Please Check MADRIX Web Site
Minimum Computer System Requirements
Art-Net
White
DMX +
Blue
DMX -
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz

Connection DiagramConnection DiagramConnection Diagram
www.heraled.com 5
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
White
DMX (+)
Blue
DMX (-)
DMX 512
(+)48VDC
DMX(+) DMX(-)
GND
POWER PACK 2500
R
*Please check 6. page for numbers of product connection
Black
GND

www.heraled.com 6
POWER PACK 2500
R
Products Table
Sword® 25x1Series 30cm
32 pcs. PD®60S Dome Pixel Dot Series
32 pcs.
12 pcs.
Sword® 25x1Series 50cm
Sword® 25x1Series 100cm
Sword® 25x1Series 150cm
Sword® 50x1 Series 30cm
Sword® 50x1 Series 50cm
Sword® 50x1 Series 100cm
Sword® 50x1 Series 150cm
Sword® 100x1 Series 30cm
Sword® 101x1 Series 50cm
Sword® 101x1 Series 100cm
Sword® 101x1 Series 150cm
Sword® 100x4 Series 30cm
Sword® 101x4 Series 50cm
Sword® 101x4 Series 100cm
Sword® 101x4 Series 150cm
Vertical Tube® Series 50cm
Vertical Tube® Series 100cm
Vertical Tube® Series 150cm
Vertical Tube® Series 200cm
Pd®60 Dome Pixel Dot Series
PD®60S Pixel Dot Series
Pd®60 Pixel Dot Series
6 pcs.
4 pcs.
3 pcs.
14 pcs.
8 pcs.
4 pcs.
2 pcs.
32 pcs.
32 pcs.
17 pcs.
11 pcs.
32 pcs.
32 pcs.
17 pcs.
11 pcs.
28 pcs.
17 pcs.
8 pcs.
5 pcs.
8

www.heraled.com 7
POWER PACK 2500
R
Connection DiagramConnection Diagram
Connection Diagram
2Turn to left and pull for removing.
1
Push arrow direction
Accessories
A01014
NC3FXX 3 Pole Female XLR Connector
Optional
73mm / 2.8"
19.2mm
0,75"
A01020
5 Pole Female IP67 Push-lock Connector
Standard
A01019
NAC3FCA powerCON 20A Power In
Standard
75mm / 2.8"
17.5mm
0,68"

www.heraled.com 8
POWER PACK 2500
R
132,mm
482 mm / 19"
366mm
14.4"
5.19"
Technical Drawing
