Herculano T2ET Series User manual

0
USER MANUAL
T2ET
REV.02
09/01/2018
THREE-WAY TIPPERS
SEMI
-
TRAILERS / TRAILERS
G2ET / G3ET
MODELS
T2ET – 10000 / 12000 / 14000 / 16000 / 18000
G2ET – 10000 / 12000 / 14000 / 16000
G3ET
-
18000

0

HERCULANO – ALFAIAS AGRÍCOLAS, S.A
.
APARTADO 1 – 3720-051 Loureiro OAZ – Oliveira de Azeméis – Portugal
Tel.: [phone] Fax: [phone] e-mail: [e-mail] Internet: www.herculano.pt
1
CONTENTS
1 - INTRODUCTION...............................................................................................................................................................3
2 - “CE” DECLARATION OF CONFORMITY......................................................................................................................... 3
3 - GENERAL IDENTIFICATION OF THE EQUIPMENT
3.1 – SEMI-TRAILERS T2ET........................................................................................................................................... 4
3.2 – TRAILERS G2ET/G3ET.......................................................................................................................................... 4
4 – GENERAL SAFETY RULES..........................................................................................................................................5/6
5 – SELF-ADHESIVE SAFETY / WARNING LABELS........................................................................................................ 7/8
6 – SIGNALIZATION SIGNS AND LIGHTS...................................................................................................................... 9/10
6.1 – CONNECTION TO THE TRACTOR’S ELECTRICAL SYSTEM – PLUG ................................................... 11
7 – TRACTOR - TRAILER/SEMI-TRAILER COUPLING
7.1 – TRACTOR WITH HOLE COUPLER ............................................................................................... 12
7.2 – TRACTOR WITH QUICK COUPLER .............................................................................................. 13
7.3 – CONNECTION BETWEEN THE HYDRAULIC TIPPING SYSTEM AND THE TRACTOR ............................. 13
7.4 – HYDRAULIC BRAKING SYSTEM CONNECTION .............................................................................. 14
7.5 – PNEUMATIC BRAKING SYSTEM CONNECTION (*OPTIONAL) .......................................................... 14
7.6 – CONNECTION OF THE DRAWBAR’S HYDRAULIC JACK - SEMI-TRAILERS (T2ET) ............................... 15
7.7 – COUPLER FOR 2ND TRAILER ..................................................................................................... 15
8 - PRECAUTIONS PRIOR TO STARTING TRANSPORT AND TIPPING
8.1 – TYRE DIMENSIONS AND PRESSURES AND WHEEL TIGHTENING .................................................... 16
8.2 – ENSURE THAT ......................................................................................................................... 17
8.3 – CHECK THE HYDRAULIC / PNEUMATIC CIRCUITS ......................................................................... 17
8.4 – TIPPING – POSITIONING OF PEGS
8.4.1 – TIPPING TOWARDS THE REAR ......................................................................................... 17
8.4.2 – TIPPING TO THE LEFT ..................................................................................................... 17
8.4.3 – TIPPING TO THE RIGHT ................................................................................................... 17
9 – PRECAUTIONS DURING TRANSPORT AND WORK ................................................................................ 18
10 – TECHNICAL CHARACTERISTICS (1) – MODELS AND VERSIONS
10.1 – THREE-WAY TIPPING SEMI-TRAILERS - T2ET ............................................................................. 19
10.2 – THREE-WAY TIPPING SEMI-TRAILERS - G2ET / G3ET
................................................................... 20

HERCULANO – ALFAIAS AGRÍCOLAS, S.A
.
APARTADO 1 – 3720-051 Loureiro OAZ – Oliveira de Azeméis – Portugal
Tel.: [phone] Fax: [phone] e-mail: [e-mail] Internet: www.herculano.pt
2
11 – OPTIONAL EQUIPMENT: T2ET; G2ET/G3ET
11.1 – OPTIONAL DRAWBARS – SEMI-TRAILERS T2ET .......................................................................... 21
11.2 – SUPPLEMENTARY LATERAL SIDES ........................................................................................... 21
11.3 – FRONT PLATFORM ................................................................................................................. 21
11.4 – 2ND TRAILER COUPLER .......................................................................................................... 21
11.5 – ROLLING CANOPY .................................................................................................................. 22
11.6 – HYDRAULIC REAR DOOR ........................................................................................................ 22
11.7 – CEREAL EXIT DOOR ............................................................................................................... 22
11.8 - TOMATO EXIT DOOR ............................................................................................................... 22
11.9 – CEREAL UNLOADING TUBE ..................................................................................................... 22
11.10 – WHEEL CHOCKS .................................................................................................................. 22
11.11 – WATER TANK ....................................................................................................................... 23
11.12 – ROTATING LIGHT KIT ............................................................................................................ 23
11.13 – LED LIGHTING ...................................................................................................................... 23
11.14 – LONG VEHICLE KIT ............................................................................................................... 23
11.15 – HIDRO-PNEUMATIC DRAWBAR - *OPTIONAL SEMI-TRAILERS T2ET .............................................. 24
11.16 – PNEUMATIC BRAKING SYSTEM – With / Without ALB ................................................................... 25
11.17 – SELF-STEERING BOGIE ......................................................................................................... 25
11.18 – FORCED STEERING BOGIE .................................................................................................... 25
11.18.1 – FORCED DIRECTIONAL AXLES ...................................................................................... 26
12 – MAINTENANCE ............................................................................................................................. 27
12.1 – DAILY ................................................................................................................................... 27
12.2 – PERIODICALLY ...................................................................................................................... 27
12.3 – WHEN STOPPED FOR LONG PERIODS .................................................................................. 28-29
13 – FAULTS ....................................................................................................................................... 30
14 – WARRANTY CONDITIONS ............................................................................................................... 31
15 – HOW TO ORDER PARTS ................................................................................................................. 32

HERCULANO – ALFAIAS AGRÍCOLAS, S.A
.
APARTADO 1 – 3720-051 Loureiro OAZ – Oliveira de Azeméis – Portugal
Tel.: [phone] Fax: [phone] e-mail: [e-mail] Internet: www.herculano.pt
3
1. INTRODUCTION
Congratulations on your purchase. You have just acquired equipment that is constructed using state of the
art technology to the strictest quality standards.
We put every effort into researching, developing and perfecting this machine so you can take advantage of
its quality and high performance operations in safety.
This manual has been written to assist you and warn you of safety, maintenance, trust and performance
issues while using your equipment. Please start by reading it carefully to ensure that you are familiar with
all of the material, as well as with the most important aspects of its use, and other useful information.
Take note of all issues related to safety, and the suggestions contained in this Manual.
Keep the manual in a safe and accessible place, so that you can consult it whenever necessary.
This equipment must be inspected periodically, maintained and fitted with suitable replacement parts.
HERCULANO will provide you with any support that you might need with solving problems or clarifying any
doubts that may arise when using the equipment.
2. “CE” DECLARATION OF CONFORMITY
This piece of equipment complies with the requirements of European Parliament and
Council Directive 2006/42/EC, of 17 May 2006, transposed into Portuguese law by
Decree-Law no. 103/2008 of 24 June 2008.
The CE Declaration of Conformity is attached to the User Manual.

HERCULANO – ALFAIAS AGRÍCOLAS, S.A
.
APARTADO 1 – 3720-051 Loureiro OAZ – Oliveira de Azeméis – Portugal
Tel.: [phone] Fax: [phone] e-mail: [e-mail] Internet: www.herculano.pt
4
3. GENERAL IDENTIFICATION OF THE EQUIPMENT
3.1. THREE-WAY SEMI-TRAILERS - T2ET
41526300 - T2ET 10000
SEMI-TRAILER - 2 REAR AXLES, TANDEM, THREE-WAY TIPPING BOX, USEFUL LOAD (*) = 10,000 kg.
41526320 - T2ET 12000
SEMI-TRAILER - 2 REAR AXLES, TANDEM, THREE-WAY TIPPING BOX, USEFUL LOAD (*) = 12,000 kg.
41526340 - T2ET 14000
SEMI-TRAILER - 2 REAR AXLES, TANDEM, THREE-WAY TIPPING BOX, USEFUL LOAD (*) = 14,000 kg.
41526360 - T2ET 16000
SEMI-TRAILER - 2 REAR AXLES, TANDEM, THREE-WAY TIPPING BOX, USEFUL LOAD (*) = 16,000 kg.
41526380 - T2ET 18000
SEMI-TRAILER - 2 REAR AXLES, TANDEM, THREE-WAY TIPPING BOX, USEFUL LOAD (*) = 18,000 kg.
(*) Pay attention to points 4.6 and 4.7 of the “User Manual” and the characteristics of your equipment.
3.2. THREE-WAY TRAILERS - G2ET / G3ET
41526310 - G2ET 10000
TRAILER - 1 REAR AXLE + 1 TURNING FRONT AXLE, THREE-WAY TIPPING BOX, USEFUL LOAD (*) = 10,000 kg.
41526330 G2ET 12000
TRAILER - 1 REAR AXLE + 1 TURNING FRONT AXLE, THREE-WAY TIPPING BOX, USEFUL LOAD (*) = 12,000 kg.
41526350 G2ET 14000
TRAILER - 1 REAR AXLE + 1 TURNING FRONT AXLE, THREE-WAY TIPPING BOX, USEFUL LOAD (*) = 14,000 kg.
41526370 G2ET 16000
TRAILER - 1 REAR AXLE + 1 TURNING FRONT AXLE, THREE-WAY TIPPING BOX, USEFUL LOAD (*) = 16,000 kg.
41526390 G3ET 18000
TRAILER - 2 REAR AXLES + 1 TURNING FRONT AXLE, THREE-WAY TIPPING BOX, USEFUL LOAD (*) = 18,000 kg.
(*) Pay attention to points 4.6 and 4.7 of the “User Manual” and the characteristics of your equipment.

HERCULANO – ALFAIAS AGRÍCOLAS, S.A
.
APARTADO 1 – 3720-051 Loureiro OAZ – Oliveira de Azeméis – Portugal
Tel.: [phone] Fax: [phone] e-mail: [e-mail] Internet: www.herculano.pt
5
4. GENERAL SAFETY RULES
Before performing any maintenance or repair operations on the equipment that require tipping, ensure that
the vehicle is properly supported. Switch off the engine and ensure that the tractor’s brakes are properly on
before conducting any operation that could affect the safety of the operator or third parties.
Serious fatal errors could occur if due precautions are not taken and all safety measures are not respected.
Equipment must only be repaired, and damaged components only replaced, by people approved or qualified
for this purpose.
Always use the most appropriate tools and protection equipment during maintenance operations and repairs
to vehicle faults.
Ensure that all replacement parts or components are compatible with the equipment and that they do not
affect the vehicle’s safety, your safety or that of the operator or third parties
It is recommended that the manufacturer’s original spare / replacement parts are always used, to guarantee
that they fit properly and that they do not affect the vehicle’s structural capacity or safety.
Ensure that your equipment undergoes all inspections and services at specific time intervals.
Alterations to the Trailer / Semi-Trailer:
The chassis structure, wheels, braking system, hydraulic system and electrical system must not be modified
or converted, as they are important safety elements and they could affect the equipment’s safety if altered.

HERCULANO – ALFAIAS AGRÍCOLAS, S.A
.
APARTADO 1 – 3720-051 Loureiro OAZ – Oliveira de Azeméis – Portugal
Tel.: [phone] Fax: [phone] e-mail: [e-mail] Internet: www.herculano.pt
6
4.1. Whenever carrying out coupling or decoupling operations of the semi-trailer / trailer, it is strictly
forbidden to stand between the tractor and trailer unless they are properly immobilised with the parking
brake on and chocks on the wheels.
4.2. When it is necessary to couple the trailer/semi-trailer to the tractor, always stand off to one side of the
tractor and ensure that the safety pin is correctly fitted.
4.3. Always use suitable clothes and shoes and avoid the use of long or loose clothing.
4.4. Never perform maintenance work when the box is lifted without first placing the safety prop between
the upper chassis and the lower chassis.
4.5. Do not allow people to stand or ride on the agricultural trailer/semi-trailer.
4. . Always check the pressure and general condition of the trailer’s tyres prior to each use.
4.7. Legal equipment load limits must not be exceeded.
4.8. Always comply with your tractor’s towing load limits.
4.9. Check hydraulic / pneumatic hoses on a regular basis and replace them if they are damaged or old.
The replacement hoses should comply with the technical requirements of the manufacturer.
4.10. Check oil levels, and always keep the lubrication points lubricated.
4.11. Before starting transport, check that the braking system works properly.
4.12. Following all rules in force when driving on public roads. Always check that the lighting devices fitted
to the rear, side and front of the vehicle operate correctly.

HERCULANO – ALFAIAS AGRÍCOLAS, S.A
.
APARTADO 1 – 3720-051 Loureiro OAZ – Oliveira de Azeméis – Portugal
Tel.: [phone] Fax: [phone] e-mail: [e-mail] Internet: www.herculano.pt
7
5. SELF-ADHESIVE SAFETY / WARNING LABELS
Warning stickers form part of the User Manual. Respect all operations, ensure that stickers remain legible
and immediately replace any lost labels.
- ALWAYS READ THE USER MANUAL
- DANGER! ARTICULATED MACHINERY.
- DANGER OF CRUSHING! ALWAYS FIT THE SAFETY PROP.
- DANGER OF CRUSHING! BOX WITH TIPPING.
- DANGER OF CRUSHING! DO NOT TIP ON INCLINED GROUND.
- DANGER OF CRUSHING! TIPPING HYDRAULIC REAR DOOR
- DANGER OF CRUSHING! TIPPING HYDRAULIC REAR DOOR

HERCULANO – ALFAIAS AGRÍCOLAS, S.A
.
APARTADO 1 – 3720-051 Loureiro OAZ – Oliveira de Azeméis – Portugal
Tel.: [phone] Fax: [phone] e-mail: [e-mail] Internet: www.herculano.pt
8
-
DANGER! KEEP THE BOX/CHASSIS BALANCE IN MIND. ENSURE THAT
IT IS BALANCED BEFORE FULLY OPENING THE TIPPING CYLINDER.
- LUBRICATION POINT.
- TYRE PRESSURE.
NOTE: Read the label affixed to your TRAILER / SEMI-TRAILER!
Inflation pressure varies depending on the tyre that is fitted!
- INDICATION OF WHEEL TIGHTENING FREQUENCY
ATTENTION !
BEFORE INICIATE LATERAL TIPPING, DON’T
FORGET TO DISCONECT THE HYDRAULIC
HOSES FROM REAR HYDRAULIC DOOR
* OPTIONAL – HYDRAULIC REAR DOOR
- ATTENTION ! BEFORE INICIATE LATERAL TIPPING, DON’T
FORGET TO DISCONECT THE HYDRAULIC HOSES FROM REAR
HYDRAULIC DOOR

HERCULANO – ALFAIAS AGRÍCOLAS, S.A
.
APARTADO 1 – 3720-051 Loureiro OAZ – Oliveira de Azeméis – Portugal
Tel.: [phone] Fax: [phone] e-mail: [e-mail] Internet: www.herculano.pt
9
. SIGNALIZATION SIGNS AND LIGHTS
All TRAILER / SEMI-TRAILER models are equipped with signalization signs and light devices, as per
current legislation in each country.
The following images show some of these devices, which vary from country to country.
SIDE REFLECTORS / LIGHTING
DELIMITATION LIGHTS
LONG VEHICLE PLATE
REAR LIGHTS
SPEED LIMIT SIGNS
REGISTRATION NUMBER
LIGHTING
ROTATING LIGHT

HERCULANO – ALFAIAS AGRÍCOLAS, S.A
.
APARTADO 1 – 3720-051 Loureiro OAZ – Oliveira de Azeméis – Portugal
Tel.: [phone] Fax: [phone] e-mail: [e-mail] Internet: www.herculano.pt
10
LIGHT + FRONT REFLECTOR
LIGHT + FRONT REFLECTOR
LIGHT + FRONT REFLECTOR
LIGHT + FRONT REFLECTOR
T2ET
G2ET
G3ET
TRAILER
SEMI-TRAILER

HERCULANO – ALFAIAS AGRÍCOLAS, S.A
.
APARTADO 1 – 3720-051 Loureiro OAZ – Oliveira de Azeméis – Portugal
Tel.: [phone] Fax: [phone] e-mail: [e-mail] Internet: www.herculano.pt
11
.1. CONNECTION TO THE TRACTOR’S ELECTRICAL SYSTEM – PLUG
Follow the inspection procedure set out below for good performance and durability of the trailer’s
lighting and wiring system:
•Clear all reflective components and all other lighting devices thoroughly.
•Check that all bulbs are working correctly, and replace all blown or damaged bulbs, as well as
reflective elements in poor condition.
•When replacing, always use bulbs with the same power, as well as the most appropriate
reflective components.
•Inspect all cables and verify if they are damaged. Cables must be properly supported and
protected, and their connection plugs must be tight.
•Any damaged cables must be replaced with new cables of the same dimensions, in order to
guarantee the connection of elements that they run to.
NOTE:
If you need to test bulbs, use a 12V DC power supply. Never use battery chargers or transformers.
PIN COLOUR CIRCUIT
1 BLUE / (GREEN*)
RIGHT INDICATOR LIGHT
•OPTIONAL LED (GREEN)
2 WHITE (x2) MASS
3 “FREE” / (BLUE*) •OPTIONAL LED
4 YELLOW LEFT INDICATOR LIGHT
5 RED BRAKE
BROWN (x2) POSITION LIGHT
7 BLACK POSITION LIGHT
PLUG
(Cod: 20303001)
- Lighting system diagrams are shown on the exploded diagrams document: “Spare Parts List”,
which is sent with the User Manual.
WARNING!
Failure to take notice of this warning could lead
to damage to property, serious injury or death !

HERCULANO – ALFAIAS AGRÍCOLAS, S.A
.
APARTADO 1 – 3720-051 Loureiro OAZ – Oliveira de Azeméis – Portugal
Tel.: [phone] Fax: [phone] e-mail: [e-mail] Internet: www.herculano.pt
12
7. TRACTOR - TRAILER / SEMI-TRAILER COUPLINGS
There should be nobody present in the danger zone
between the tractor and trailer when it is necessary
to couple / decouple the trailer from the tractor!
NOTE: Before starting the coupling operation, ensure
that the semi-trailer / trailer is on flat ground, and that the
hand brake / parking brake are properly on. If it has
chocks, always ensure that the trailer’s wheels are
chocked prior to starting the following procedures.
7.1. TRACTOR WITH HOLE COUPLER
1º Align and move the tractor’s coupler towards the
trailer’s drawbar;
2º Connect the drawbar’s traction/safety chains to
the tractor;
3º Connect the trailer’s hydraulic system hoses to
the tractor’s respective hydraulic sockets - (the
tractor must be off);
See Connection of the Tipping Hydraulic
System - page 12
4º Connect the plug of the trailer’s electrical
system to the tractor’s socket;
5º SEMI-TRAILERS (T2ET) - Operate the drawbar’s hydraulic cylinder to level the coupling eye with
the tractor’s coupler;
TRAILERS (G2ET / G3ET) - Manually adjust the height of the drawbar with the help of the spring,
fixing it with the chain links; such that this is fixed at an adequate height for the coupling eye to
receive the tractor’s coupling;
6º Slowly reverse the tractor until the tractor’s coupler hole is aligned with the hole of the semi-trailer
/ trailer’s coupling eye. When these are properly aligned, put the tractor’s brake on and place the
fixing bolt in the coupler, together with the bolt’s specific safety system;
7º SEMI-TRAILERS (T2ET) - Retract the drawbar’s hydraulic cylinder to its working position;
8º Remove the chocks from the wheels (if fitted) and release the hand/parking brake.
WARNING!
PEOPLE LOCATED IN THE HAZARD
AREA BETWEEN THE TRACTOR AND
THE SEMI-TRAILER / TRAILER
MAY BE CRUSHED OR RUN OVER!
 ENSURE ALL PEOPLE ARE KEPT OUT OF
THE HAZARD AREA WHEN COUPLING /
UNCOUPLING THE TRAILER;
 NO PERSON IS AUTHORISED TO REMAIN
ALONGSIDE THE AXLES OF THE SEMI-
TRAILER / TRACTOR WHEN THEY ARE
BEING COUPLED;
 THE TRACTOR’S DRIVER MUST ALWAYS
STAY WELL CLEAR OF VEHICLE WHEELS

HERCULANO – ALFAIAS AGRÍCOLAS, S.A
.
APARTADO 1 – 3720-051 Loureiro OAZ – Oliveira de Azeméis – Portugal
Tel.: [phone] Fax: [phone] e-mail: [e-mail] Internet: www.herculano.pt
13
7.2. TRACTOR WITH QUICK COUPLER
1º Align and move the tractor’s coupler towards the semi-trailer / trailer’s drawbar;
2º Connect the drawbar’s traction (safety) chains to the tractor;
3º Connect the trailer’s hydraulic system hoses to the tractor’s respective hydraulic circuits (the tractor
must be off);
4º Connect the plug of the trailer’s electrical system to the tractor’s socket;
5º SEMI-TRAILERS (T2ET) - With the tractor’s coupler fully lowered, operate the drawbar’s hydraulic
cylinder to position the coupling eye slightly above the level of the tractor’s quick coupler;
TRAILERS (G2ET / G3ET) - With the tractor’s coupler fully lowered, manually adjust the height of
the drawbar with the help of the spring, fixing it with the chain links, such that this is fixed in place
and the coupling eye is slightly above the level of the tractor’s quick coupler.
6º With the tractor’s coupler in its fully lowered position, slowly reverse the tractor until it reaches a
position where the trailer’s coupling eye can be coupled to the tractor’s coupler. Once this position
has been guaranteed, apply the tractor’s brake;
7º Raise the tractor’s quick coupler using the levelling control command (see the tractor’s instruction
manual). Ensure that the coupling operation has been carried out correctly, and that the safety
system operates properly. Next, apply the tractor’s brake;
8º SEMI-TRAILERS (T2ET) - Retract the drawbar’s hydraulic cylinder to its operating position;
9º Remove the chocks from the wheels and release the hand/parking brake.
7.3. CONNECTION BETWEEN THE HYDRAULIC TIPPING SYSTEM AND THE TRACTOR
Note: For safety reasons, never connect/disconnect the tractor’s hydraulic hoses while the
box is tipped! When connecting the hoses, ensure that the quick connect valves are not
dirty!
1º Ensure that the box is not tipped;
2º Lower the tractor’s linkage to gain access to the tractor’s hydraulic sockets zone;
3º Switch off the tractor’s engine;
4º Connect the trailer’s hydraulic hoses system to the tractor’s respective hydraulic sockets; “When
connecting the hydraulic hoses, ensure that the quick connect valves are not dirty! “
5º Turn on the tractor’s engine and re-position the linkage in its elevated position to prevent collision
with the drawbar during transport.

HERCULANO – ALFAIAS AGRÍCOLAS, S.A
.
APARTADO 1 – 3720-051 Loureiro OAZ – Oliveira de Azeméis – Portugal
Tel.: [phone] Fax: [phone] e-mail: [e-mail] Internet: www.herculano.pt
14
7.4. HYDRAULIC BRAKING SYSTEM CONNECTION
1º Switch off the tractor’s engine;
2º Connect the trailer’s hydraulic hoses to the tractor’s corresponding brake socket;
“When connecting the hoses, ensure that the quick connect valves are not dirty! “
3º Turn on the tractor’s engine and test the braking system to ensure that it is operating correctly.
Note: Do not drive on public roads if the braking system is not operating correctly, or if any anomaly
is detected that could affect the safety of the vehicle or people!
7.5. PNEUMATIC BRAKING SYSTEM CONNECTION (*OPTIONAL)
1º Switch off the tractor’s engine;
2º Connect the trailer/semi-trailer’s pneumatic braking hoses to the tractor’s sockets;
3º Turn on the tractor’s engine and test the braking system to ensure that it is operating correctly.
Note: Do not drive on public roads if the braking system is not operating correctly, or if any anomaly
is detected that could affect the safety of the vehicle or people!
