Heroproof BFGun X100 User manual

OWNERS MANUAL
HyperDrive Percussive Massager

Preface
With the engineering of BFGun HyperDrive Percussive Massager, the breakthrough technology enables the
powerful massager to increase training efficiency, accelerate muscle mass gain, boost athletic
performance, and relief common injuries & conditions.
Numerous independent clinical trials and studies have confirmed the efficacy of HyperDrive Percussive
Therapy/Massage. Percussive massage accelerates the growth and repair of tissues by providing
concentrated, rapid, short-duration pulses deep into the tissues of the body. This heavily increases blood
flow to the area causing pain relief and an increasing range of motion and function. Percussive massage
also provides a gentle stretch to the muscles and connective tissues improving responsiveness and
performance. In addition, BFGun is a perfect companion for athletes and fitness professionals to achieve
optimal pre-work warm-ups and balanced post-workout warm-downs releases.
Heroproof helps bring out the hero that is in each and everyone of us with unwavering pursuit of
innovation in performance enhancing and sports recovery technologies.

BFGun X100 Overview
Angle A d j u s t m e n t
A c t uat o r
Cooling Vent
(do not block)
P ow e r Tr i gger
B a e r y Re l e a s e
Speed Con t r o l
D i a l
Massage Aa c hme n t
1
B a e r y
Aa c h m e n t A r m

OPERATING
01
Once the battery is properly attached,
push the trigger once to turn on the
massager gun. (Hold the BFGun with
one hand, and do not hold the
massager by the attachment when
operating to prevent injury)
0 2
Press the trigger again to turn off
the massager. 2
USAGE:
Clinical studies have shown that optimal results may be
achieved by targeting each area or muscle group between 2 and
3 minutes. If you are experiencing extra soreness, you may
target the area for additional 30~60 seconds throughout the day.
Unlike traditional general-use “vibrating” massager, BFGun
utilizes HyperDrive Percussive Technology so user do not need
to press the massager into your body. Simply hold the BFGun
close to the target area, and allow the BFGun to deliver the
deep-muscle percussive massage.

ROTATING THE
ATTACHMENT ARM
01
Push and hold the Angle Actuator.
0 2
While holding the Actuator, rotate
the arm to the 90 degree, 45
degree or straight position.
0 3
Once the Attachment Arm locks in
place, you may release the
Actuator.
3

MASSAGE
ATTACHMENTS
Large Dampening Ball *1
For large muscle groups (quads, glutes, calves…etc)
Small Dampening Ball * 1
For more targeted area massage.
Small DeepDrive Ball * 1
For more targeted area massage.
Cone * 1
For trigger points and small muscle areas (feet, wrist, etc.)
4
*Dampening Balls are made of high-density EVAfoam that withstands
repeated use while maintaining shape and integrity.
*DeepDrive Balls are made from polyurethane compound that are more
rigid, while providing an elastic characteristic to enable deeper
percussive delivery.
USAGE:
To switch between attachments, simply unscrew the attachment
and replaced it with desired attachment.

RECHARGEABLE BATTERY
01
To release the battery, squeeze the grips
on both sides of thebattery to disengage,
then pulloutward to remove.
0 2
Insert the battery with the triangle pointed
towards the massage gun. The battery
will click once it is engaged and secured.
5

CHARGING
01
Remove the battery. If the battery
feels warm, allow it to cool before use.
When the battery is fully
charged, the red LED turns off
When the battery is charging,
the red LED will turn red.
0 2
Plug in the charger. The green LED
will be on.
0 3
Insert the battery into the charger until
the LED turns red. Once the LED turn
off the battery is fully charged.
6
LED

7
•
•
•
AC Charger
Rated input: 100-120V~50/60Hz, 22W
13.6V, 1000mA
12V DC
Li-ion
2000mAh
20-60min
90min
0-2500/min max
60W max
1st gear 15Hz,2nd gear 20Hz,3rd gear 25Hz
4th gear 30Hz,5th gear 35Hz,6th gear 40Hz
22mm
1.21kg/1.44kg (including charger and box)
18*14*6cm
74dB(A)
85dB(A)
Rated output:
Battery
Rated voltahe:
Type:
Capacity:
Working hour:
Charging time:
Massager
•Massager
No-load speed:
Power:
Frequency:
Stroke length:
Weight:
Dimension:
Acoustic pressure level LpA:
Acoustic power level LwA:

MAINTENANCE
The batteries in packs are not designated for exchange or removal by the users. If problems with the
power supply should occur, please contact the servicecenter.
If the device malfunctions, please do not try to repair or to fix it by taking the device apart yourself. This
leads to the automatic expiration of warranty.
WARNINGS AND CAUTION
Before connecting the device to the power supply, please ensure that the supply voltage stated onthe
rating plate is compatible with the unit.
Please charge the new batteries before first use.
The device should only be used with the provided, certified,charger.
Do not adjust the speed/frequency or pull out the battery while the massager gun is ON.
Do not put the device in water or in other liquids.
Do not use the device for more than 30 minutes at a time. Wait 5 minutes prior to using the device
again following a 30-min session with the device.
Do not apply the massager gun on your head or near yourgenitals.
Do not use the device to supplement or replace any medical treatment. Please ask your doctor before
using the device if you have any unexplained pain, if you are receiving medical treatment, or using
medical equipment.
DISCLAIMER
PLEASE CONTACT YOUR DOCTOR BEFORE USING THE MASSAGER GUN IF YOU HAVE ANY PHYSICAL HEALTH
CONCERNS OR IF YOU HAVE ANY OF THE FOLLOWING CONDITIONS:
Pregnancy, complications with diabetes, recent surgery, epilepsy or migraines, herniated disks, spondylolisthesis, spondylolysis, or
spondylosis, recent joint replacements or IUD’s, and metal pinsor plates.
8

1-YEAR WARRANTY
If within one year from the date of purchase, this product fails due to a defect in material or work-
manship, Heroproof will repair or replace the product or necessary components.
THIS WARRANTY EXCLUDES:
(a) damage caused by accident, abuse, mishandling, ortransport;
(b) unit subjected to unauthorized repair;
(c) unit not used in accordance with BFGun care instructions;
(d) damage exceeding the cost of the product;
(e) deterioration of the delivered product resulting from abnormal storage and/or safeguarding
conditions on the client’s premises.
(f) failure to provide the dated proof of purchase.
CONTACT
14978 Ramona Blvd. Baldwin Park, California 91706
suppor[email protected]
www.heroproof.com
9
