Heston Blumenthal Sage Nutri Juicer BJE410UK User manual

Registered in England & Wales No. 8223512. Due to continued product improvement, the products illustrated or
photographed in this document may vary slightly from the actual product.
Copyright BRG Appliances 2013.
BJE410UK Issue - B13
Phone: [phone]
www.sageappliances.co.uk
[e-mail]
Register your product and
get more from your purchase
Product registration takes only a few
minutes and ensures both a record
of your purchase and your warranty.
Registration also makes it easier to get
support and advice on any questions or
issues that you might have in the future.
If you wish, we can also send you free
recipes and additional hints and tips on
making the best of your appliance.
Go to www.sageappliances.co.uk
and click on ‘Product Registration’.
What’s on your mind?
Our constant aim is to improve the
quality and features of our appliances.
We welcome your comments and ideas
in assisting our ongoing development.
Go to www.sageappliances.co.uk
and click on ‘Support’.
Sage™by Heston Blumenthal‰
Customer Service Centre

BJE410UK
the Nutri Juicer™
Instruction Booklet

2
PAge heAder.....CONTENTS
5We recommend safety first
9Getting to know your
new appliance
10 Assembling your new appliance
13 Operating your new appliance
15 Disassembling your
new appliance
17 Care & cleaning
19 Troubleshooting
21 Tips on juicing
23 Fruit & vegetable facts

3
PAge heAder.....WE RECOMMEND SAFETY FIRST
READ ALL INSTRUCTIONS
BEFORE USE AND SAVE
FOR FUTURE REFERENCE
• Before using for the first
time please ensure that
your electricity supply is the
same as shown on the rating
label on the underside of the
appliance. If you have any
concerns please contact your
local electricity company.
• Your Sage™by Heston
Blumenthal‰appliance
includes a BS 13 amp
moulded mains plug on the
supply cord.
• Should you need to change
this plug, please complete
the rewiring as follows
(after safe disposal of the
moulded plug).
• Please note that a cut off plug
inserted into a socket is a
serious danger risk.
• Wires are coloured as follows:
−Blue = Neutral
−Brown = Live
• As the colours of the wire
may not correspond with the
coloured markings which
identify the terminals in
your plug, please refer to the
following:
−The Blue wire must be
connected to the terminal
which is marked ‘N’.
−The Brown wire must be
connected to the terminal
which is marked with the
letter ‘L’.
• Please note that if a 13 amp
plug is used, a 13 amp fuse
should be used.
IMPORTANT SAFEGUARDS
At Sage™by Heston Blumenthal‰we are very safety conscious.
We design and manufacture consumer products with the safety
of you, our valued customer, foremost in mind. In addition we
ask that you exercise a degree of care when using any electrical
appliance and adhere to the following precautions.

4
PAge heAder.....WE RECOMMEND SAFETY FIRST
• Remove and safely discard
any packaging material or
promotional labels before
using the Juicer for the
first time.
• To eliminate a choking
hazard for young children,
remove and safely discard the
protective cover fitted to the
power plug of this appliance.
• Do not place the juicer near
the edge of a bench or table
during operation. Ensure
that the surface is level, clean
and free of water, flour, etc.
Vibration during operation
may cause the appliance
to move.
• Any significant spillage
onto the surface under or
around the appliance, or
onto the appliance itself,
should be cleaned and
dried before continuing
to use the appliance.
• Do not place the juicer on
or near a hot gas or electric
burner, or where it could
touch a heated oven.
• Always ensure the Juicer
is properly assembled
before use. The appliance
will not operate unless
properly assembled.
• Do not use the Juicer on a
sink drain board.
• Do not leave the juicer
unattended when in use.
• Always ensure the juicer
is turned off by pressing
the ON/OFF switch on the
control panel to OFF. Then
switch the appliance off at the
power outlet and unplug the
cord. Make sure the stainless
steel filter basket has stopped
rotating and the motor has
completely stopped before
releasing the safety locking
arm and/or attempting to
move the appliance, when the
juicer is not in use, and before
Disassembling, cleaning
and storing.
• Do not operate the appliance
continuously with heavy
loads for more than 10
seconds. Allow the motor to
rest for 1 minute between
each use.

5
WE RECOMMEND SAFETY FIRST
• Recipes in this instruction
book are not considered a
heavy load. However, hard
fruits and vegetables will put
excess strain onto the motor
if a low speed is selected.
Please refer to the juicing
guide to determine the
correct speed for the fruits
and vegetables selected
for juicing.
• Keep hands, fingers, hair,
clothing as well as spatulas
and other utensils away
from the appliance
during operation.
• Do not push food into the
feed chute with your fingers
or other utensils. Always use
the food pusher provided.
Do not place hand or fingers
into the food chute when it
is attached to the appliance.
• Be careful when handling the
stainless steel filter basket as
the small cutting blades at
the base of the filter basket
are very sharp. Mishandling
may cause injury.
• Do not use the juicer for
anything other than food
and/or beverage preparation.
• Keep the appliance clean.
Refer to care and cleaning.
• Remove rind from all citrus
fruit before juicing.
IMPORTANT SAFEGUARDS
FOR ALL ELECTRICAL
APPLIANCES
• Fully unwind the power cord
before use.
• Do not use the appliance if
the filter basket is damaged.
• Do not let the power cord
hang over the edge of a
bench or table, touch hot
surfaces or become knotted.
• To protect against electric
shock do not immerse the
power cord, power plug or
appliance in water or any
other liquid.
• Children should be
supervised to ensure
that they do not play with
the appliance.

6
WE RECOMMEND SAFETY FIRST
• Regularly inspect the
supply cord, plug and actual
appliance for any damage. If
found damaged in anyway
or maintenance other
than cleaning is required,
immediately cease use of the
appliance and contact Sage
Customer Service on
0844 334 5110.
• CAUTION In order to avoid
a hazard due to inadvertent
resetting of the thermal cut
out, this appliance must
not be supplied through an
external switching device
such as a timer or connected
to a circuit that it regularly
switched on and off by the
utility.
• This appliance can be used
by persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way
and understand the
hazards involved.
• Keep the appliance and
its cord out of the reach of
children aged less than
8 years.
• Always disconnect the
appliance from the supply if it
is left unattended and before
assembling, disassembling
and cleaning.
• Do not use the appliance if
the filter basket is damaged.
• Misuse may cause injury
• Do not use the appliance if
power cord, power plug or
appliance becomes damaged
in any way. If damaged or
maintenance other than
cleaning is required, please
contact Sage™by Heston
Blumenthal‰Customer
Service on 0844 334 5110 or
go to sageappliances.co.uk.

7
WE RECOMMEND SAFETY FIRST
• This appliance is for
household use only.
Do not use this appliance
for anything other than its
intended use. Do not use in
moving vehicles or boats.
Do not use outdoors.
Misuse may cause injury.
• The installation of a residual
current device (safety switch
is recommended to provide
additional safety protection
when using electrical
appliances. It is advisable that
a safety switch with a rated
residual operating current not
exceeding 30mA be installed
in the electrical circuit
supplying the appliance.
See your electrician for
professional advice.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way
and understand the hazards
involved. Children shall
not play with the appliance.
Cleaning and user
maintenance shall not
be made by children
without supervision.

8
WE RECOMMEND SAFETY FIRST
The symbol shown
indicates that this
appliance should not be
disposed of in normal
household waste. It
should be taken to a
local authority waste
collection centre
designated for this
purpose or to a dealer
providing this service.
For more information,
please contact your local
council office.
SAVE THESE
INSTRUCTIONS

9
GETTING TO KNOW YOUR NEW APPLIANCE
A. Food pusher
For pushing whole fruit and vegetables
down the feed chute.
B. Unique Direct Central Feed System
Ensures maximum juice extraction.
C. Extra wide 84mm feed chute fits larger
fruit and vegetables whole.
D. Large capacity pulp container
(dishwasher safe).
E. Stainless steel titanium reinforced
micro mesh filter basket
F. Heavy duty 1200 watt motor
With 5 year motor warranty.
G. Cord storage
Cord wraps around feet and clips into
position under base.
B
A
C
D
E
F
G
H. Interlocking safety arm
Stops juicer operating without cover
locked into place.
I. Juicer cover
(not dishwasher safe).
J. Filter bowl surround
Dishwasher safe.
K. 1 litre juice jug and lid
With built in froth separator
(dishwasher safe).
L. 2 speed electronic control
ON/OFF switch
H
I
J
K
L

10
PAge heAder.....
ASSEMBLING YOUR NEW APPLIANCE
BEFORE FIRST USE
Before using your juicer for the first time,
remove and safely discard any packaging
materials and promotional stickers
and labels.
Ensure the appliance is switched off at the
power outlet and the power cord is unplugged.
Wash the filter bowl surround, filter basket,
juicer cover, food pusher, pulp container and
juice jug and lid in warm, soapy water with
a soft cloth. Rinse and dry thoroughly. The
motor base can be wiped with a damp cloth.
Dry thoroughly.
1. Place motor base on a flat, dry
surface such as a bench top. Ensure
that the motor base is switched OFF
at the control panel, then switch the
appliance off at the power outlet and
unplug the power cord.
2. Place filter bowl surround on top of
the motor base.
3. Align the arrows at the base of the
stainless steel filter basket with the
arrows on the motor drive coupling
and push down until it clicks into
place. Ensure the stainless steel filter
basket is fitted securely inside the
filter bowl surround and onto the
motor base.
4. Place the juicer cover over the filter
bowl surround, positioning the feed
chute over the stainless steel filter
basket and lower into position.

11
PAge heAder.....
ASSEMBLING YOUR NEW APPLIANCE
5. Raise the safety locking arm up and
locate into the two grooves on either
side of the juice cover.
The safety locking arm should now be in
a vertical position and locked into place
on top of the juice cover.
6. Slide the food pusher down the
food chute by aligning the groove
in the food pusher, with the small
protrusion on the inside of the top of
the feed tube.
FOOD
PUSHER
GROOVE
SMALL
PROTRUSION
INSIDE FEED
TUBE
Continue to slide the food pusher down
on the feed chute.

12
PAge heAder.....
ASSEMBLING YOUR NEW APPLIANCE
7. Place the pulp container into
position by tilting the motor base
slightly to the right. Insert the pulp
container under the juicer cover
on the left hand side ensuring it is
supported by the juicer cover and
motor base.
NOTE
To minimise cleaning, line the pulp
container with a plastic freezer bag to
collect the pulp. Pulp can be used in
other dishes, or as a compost for the
garden or discarded.
8. Place the juicer jug under the juice
spout on the right hand side of the
juicer. The juice jug lid can be used
to avoid any splatter.

13
OPERATING YOUR NEW APPLIANCE
1. Wash your selection of fruit and
vegetables to be juiced.
NOTE
Most fruit and vegetables such as
apples, carrots and cucumbers will not
need to be cut or trimmed to size as
these will fit whole into the feed cute.
Ensure vegetables such as beetroots,
carrots etc. have all soil removed, are
well washed and trimmed of leaves
before using.
2. Ensure the juicer is correctly
assembled. Refer to Assembling your
Sage™by Heston Blumenthal‰juicer.
Ensure the juicer jug is placed
under the juice spout and pulp
container is in position before
commencing juicing.
3. Plug the power cord into a 230V
power outlet. Turn the power ON at
the power outlet. Adjust the speed
to the desired setting. Push the two
speed switch either up for low speed
or down for high speed depending
on the type of fruit or vegetable
being juiced. Use the speed selector
as a guide for juicing different fruits
and vegetables.
SPEED SELECTOR TABLE
Apples High
Apricots (stone removed) Low
Beetroot (trimmed) High
Blueberries Low
Broccoli Low
Brussels sprouts (trimmed) High
Cabbage Low
Carrots High
SPEED SELECTOR TABLE
Cauliflower Low
Celery High
Cucumber (peeled) Low
Cucumber, soft skinned High
Fennel High
Grapes (seedless) Low
Kiwi Fruit (peeled) Low
Mangoes (peeled, stone
removed) Low
Melons (peeled) Low
Nectarines (stone removed) Low
Oranges (peeled) High or Low
Peaches (stone removed) Low
Pears (stalks removed) High for hard
or Low for soft
Pineapple (peeled) High
Plums (stone removed) Low
Raspberries Low
Tomatoes Low
Watermelon (peeled) Low
4. With the motor running, place food
into the feed chute and use the food
pusher to gently guide food down.
To extract the maximum amount of
juice, always push the food pusher
down slowly.

14
OPERATING YOUR NEW APPLIANCE
5. As fruit and vegetables are
processed, juice will flow into the
juice jug and the separated pulp will
accumulate in the pulp container.
NOTE
The pulp container can be emptied
during juicing by turning the juicer
OFF at the control panel and then
carefully removing the pulp container.
Replace empty pulp container before
continuing to juice.
Do not allow the pulp container
to overfill as this may affect the
operation of the appliance.
NOTE
To minimise cleaning, line the pulp
container with a plastic freezer bag to
collect the pulp. Pulp can then be used
for other dishes, or as compost for
gardens or discard.
NOTE
To include the froth with your juice,
simply remove the lid of the juice jug
when pouring juice into the glass.
NOTE
The juicer is fitted with a safety device
which safeguards against overheating
with excessive loads. If overheating
occurs, the juicer will automatically
activate the overload protection
device and the unit will switch itself
off. When the overload protection is
activated, unplug the Juicer from the
power outlet for at least 15 minutes to
allow the unit to cool. Then plug juicer
into the power outlet and use
as normal.
WARNING
Never use fingers to push food down
the feed chute or to clear the feed
chute. Always use the food pusher
provided.

15
DISASSEMBLING YOUR NEW APPLIANCE
1. Ensure the juicer is turned off by
pushing the speed switch up or
down to the OFF position.
Then switch the appliance off at
the power outlet and unplug the
power cord.
2. Remove the pulp container by
tilting the motor base slightly to
the right and unlatch it from under
the juicer cover.
3. Place both hands on either side of
the safety locking arm and pull back
and lift over the grooves on either
side of the juicing cover.
Lower the safety locking arm down out
of position.
4. Lift the juicer cover of the juicer.
5. To remove the filter bowl surround
with the stainless steel filter basket,
still in place, hold base of the juicer
and turn filter bowl surround by the
juice spout.

16
DISASSEMBLING YOUR NEW APPLIANCE
6. Lift off the filter bowl surround with
the stainless steel filter basket still
in place.
7. To remove the stainless steel filter
basket from the filter bowl surround,
insert fingers under the grooves
marked ‘lift basket’ and lift filter
basket up. For easy cleaning, it is
recommended to remove filter
basket over the sink.
FILTER BASKET
CAUTION:
SHARP BLADES
WARNING
The stainless steel filter basket
contains small sharp blades to cut and
process fruit and vegetables. Avoid
touching the blades when handling the
filter basket.

17
CARE & CLEANING
Ensure the juicer is turned off by switching
the ON/OFF button on the control panel to
OFF. Then switch the appliance off at the
power outlet and unplug the power cord.
Ensure the juicer is correctly disassembled.
Refer to Disassembling your new appliance.
FOR EASIER CLEANING:
• Clean as you go and avoid dried on juice
or pulp residue.
• Immediately after each use, rinse
removable parts in hot water to remove
wet pulp. Allow parts to air dry.
NOTE
To minimise cleaning, line the pulp
container with a plastic freezer bag to
collect the pulp. Pulp can then be used
for other dishes, or as compost for the
garden or discarded.
CLEANING THE MOTOR BASE
• Wipe the motor base with a soft, damp
cloth then dry thoroughly.
• Wipe any excess food particles from the
power cord.
NOTE
Do not use abrasive scouring pads or
cleaners when cleaning the parts or
motor base as they may scratch the
surface.
CLEANING THE FILTER BOWL
SURROUND, JUICER COVER, FOOD
PUSHER, PULP CONTAINER
Wash all parts in warm soapy water with
a soft cloth. Rinse and dry thoroughly.
NOTE
The filter bowl surround, juicing
jug and lid, food pusher and pulp
container, are dishwasher safe (top
shelf only). The juice cover is not
dishwasher safe.
CLEANING THE FILTER BASKET
• For consistent juicing results always
ensure that the stainless steel filter
basket is thoroughly cleaned using the
supplied cleaning brush.
• Soak the stainless steel filter basket
in hot soapy water for approximately
10 minutes immediately after juicing
is completed. If pulp is left to dry on
the filter it may clog the fine pores of
the filter mesh thereby lessening the
effectiveness of the juicer.
• Using the cleaning brush, hold the filter
basket under running water and brush
from the inside of the basket to the outer
rim. Avoid touching the small sharp
blades in the centre of the filter basket.
After cleaning the filter basket, hold it
up towards a light to ensure the fine
mesh holes are not blocked. If the holes
are blocked, soak the filter basket in hot
water with 10% lemon juice to loosen the
blocked holes. Alternatively, wash the
filter basket in the dishwasher.

18
CARE & CLEANING
Do not soak the stainless steel filter basket
in bleach or other abrasive cleansers.
Always treat the filter basket with care as it
can be easily damaged.
NOTE
The stainless steel filter basket is
dishwasher safe (top shelf only).
CLEANING THE JUICE JUG
• Rinse the juice jug and lid with froth
attachment under running water.
• Wash both parts in warm soapy
water with a soft cloth. Rinse and
dry thoroughly.
NOTE
The juice jug and lid are dishwasher
safe (top shelf only).
REMOVING STUBBORN OR STRONG
FOOD STAINS AND ODOURS
Discolouration of the plastic may occur with
strongly coloured fruit and vegetables. To
help prevent this, wash parts immediately
after use. If discolouration does occur, the
plastic parts can be soaked in water with
10% lemon juice or they can be cleaned with
a non abrasive cleaner.
The juicer is constructed with a heavy duty
1200 watt motor. So heavy duty, we have
given the motor a 5–year guarantee against
faulty materials or manufacture. This
warranty is an extension of the 12–month
replacement guarantee and covers the motor
only. The warranty does not cover damage
caused by accident, misuse, or being used in
a manner not stated in the instruction book.
WARNING
Do not immerse the motor base in
water or any other liquid. The centre
of the filter basket and feed chute
contains small sharp blades to process
fruit and vegetables during the juicing
function. Do not touch blades when
handling the filter basket or feed chute.

19
TROUBLESHOOTING
POSSIBLE PROBLEM EASY SOLUTION
Machine will not work
when switched ON
• The safety locking arm may not be correctly engaged in the
vertical operating position with the locking arm located into
the two grooves on either side of the juicer cover.
Motor appears to stall
when juicing
• Wet pulp can build up under the juicer cover if the juicing
action is too vigorous. Try slower juicing action by pushing
the food pusher down more slowly. Follow Disassembling
and Cleaning instructions and clean the filter bowl
surround, the stainless steel filter basket and the
juicer cover.
• The juicer will automatically stop operating if the motor
is stalled for more than 10 seconds. Either too much food
is being processed at one time or the pieces are not small
enough. Try trimming the food or cutting into smaller
pieces of even size and processing a smaller amount per
batch. To continue juicing, reset the juicer by pressing the
ON/OFF switch on the control panel back to OFF then turn
the appliance back on by pressing ON/OFF switch to ON.
• Hard fruit and vegetables will put excess strain onto the
motor if a low speed is selected. Please refer to the juicing
guide to determine the correct speed for the fruit and
vegetables selected for juicing.
Excess pulp building
up in the stainless
steel filter basket
• Stop the juicing process and follow Disassembling
instructions. Remove the juicer cover, scrape off pulp,
reassemble and begin juicing again. Try alternating (soft
and hard) vegetables and fruit varieties.
Pulp too wet and
reduced extracted juice
• Try a slower juicing action. Remove the stainless steel filter
basket and thoroughly clean mesh walls with a cleaning
brush. Rinse the filter basket under hot water. If the fine
mesh holes are blocked, soak the basket in a solution of hot
water with 10% lemon juice to unlock the holes or wash in
the dishwasher. This will remove excess fibre build up (from
fruit and vegetables) which could be inhibiting the flow.
