BCP SKY5452 User manual

SKY5452
Ver. 1
INSTRUCTION
MANUAL
Horizontal Slow Juicer

As shoppers, we’re always trying
to find the perfect balance between
quality & value. At BCP, we believe
we’ve achieved that. Our diverse
catalog of everyday essentials is
tailored especially to our customers
& guaranteed to hit that sweet
spot of high quality & low price.
Always.

• Do not allow children to operate this appliance. Keep appliance out of reach of children.
• Place appliance on a stable and level surface.
• This item is intended for indoor, household use only.
• Switch o and unplug appliance if it is left unattended and before assembly, disassembly, or cleaning.
• Ensure that your voltage is consistent with specifications.
• Do not plug appliance into the same circuit as other appliances.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
• If any parts are missing, broken, damaged, or worn, stop using this product until repairs are made
and/or factory replacement parts are installed.
• Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void the
product warranty.
• Routinely check if the appliance or power cable is damaged.
• Before operating, make sure appliance is correctly assembled and all parts are properly mounted in
place.
• Before plugging appliance into wall outlet, make sure the power switch is o. Switch o appliance
before unplugging.
• Keep appliance away from direct sunlight and other sources of heat (stove, heater, etc.).
• Do not run power cord over sharp edges/corners or a hot surface.
• Do not submerge the motor unit in water or any other liquid.
• Do not spill water on the electrical components or connectors.
• Do not operate appliance with wet hands.
• Do not insert your hand or objects (other than the pusher) into the appliance during operation.
• Do not move appliance or touch any of its components while it is in motion.
• Always wait until parts come to a complete stop before disassembly.
• Using an extension cord is not recommended as it may overheat and cause a risk of fire.
• Do not use if the plug or any components are damaged.
• Do not unplug the appliance by pulling on the power cord. Always grasp the plug firmly and pull
straight out from the outlet.
• Do not use any accessory or fitting other than original accessories and fittings.
• Do not use this appliance with an external switching device or timer.
• Switch o and unplug appliance after each use and before changing accessories or handling parts.
WARNING
NOTICE
SPECIFICATIONS
Voltage
Power
120V, 60Hz
150 Watts
RPM 80 to 115
| 3

DIAGRAM
MOTOR UNIT
LOCK RELEASE
Press to release
feeding chute
FEEDING CHUTE
JUICE SPOUT
AUGER
FILTER
END CAP
PULP SPOUT
HOPPER
PUSHER
JUICE PITCHER
FOAM SEPARATOR
Separates foam from juice
PULP PITCHER
FORWARD/OFF/REVERSE
Use reverse function to
dislodge jammed food
BEFORE FIRST USE
1. Remove all packaging and accessories.
2. Wash parts with warm water, mild detergent, and a soft cloth.
3. Wipe down motor unit with warm water and a soft cloth.
4. Thoroughly dry all parts.
5. Place appliance on a stable and level surface. Make sure power switch is in OFF position.
4|

1 PC
MOTOR UNIT
1 PC
FEEDING CHUTE
1 PC
1 PC
HOPPER
D
1 PC
FILTER
PARTS
AB
F
E
1 PC
END CAP
1 PC
PULP PITCHER
G
1 PC
PUSHER I
H
1 PC
JUICE PITCHER
J
1 PC
FOAM SEPARATOR K
1 PC
BRUSH
AUGER
C
| 5

6 |
PRODUCT ASSEMBLY
1Insert the part B feeding chute into the part A motor unit. Turn the feeding chute
counterclockwise until it locks in place.
2Slide the part C auger into the feeding chute opening and press it into the motor unit.
NOTE: Press the lock release button to remove the feeding chute.
AB
C
LOCK RELEASE

| 7
PRODUCT ASSEMBLY
3Align the notches on the part D filter with the feeding chute, then insert the filter.
4Align the part E end cap with the feeding chute opening and turn it
counterclockwise until it locks in place.
D
E

8|
PRODUCT ASSEMBLY
5Slide the part J foam separator into the part H juice pitcher. Place the juice pitcher and
part I pulp pitcher under the juice and pulp spouts.
6Insert the part F hopper.
F
J

•Do not use the appliance empty or unloaded.
•Remove seeds, pits, and shells from fruits and vegetables before juicing.
•If using frozen fruit, always add juice or milk.
•Never push food with hands or other utensils; always use the provided pusher.
•The proper amount of force should be used to push food. Do not push with excessive force, rather push
just enough for food to meet the auger.
•Be aware that parts may become discolored during operation; this is normal and has no eect
on health or safety.
•This appliance is equipped with overheating protection. If the motor runs for more than 20 minutes,
becomes jammed/overloaded, or overheats, the unit will automatically stop.
•If motor overheats, stop operation for 20 to 30 minutes. Do not operate the appliance until it has cooled.
•Do not sterilize parts or accessories in temperatures higher than 176°F as it may cause
damage or deformation.
•Switch o, unplug, and clean after every use.
•Unplug the appliance before cleaning or storage.
•Wash parts and accessories with warm water, mild detergent, and a soft cloth.
•Wipe down motor unit with warm water and a soft cloth.
•Do not submerge the motor unit in water or any other liquid.
•Do not clean with steel wool or abrasive detergents.
•Place the parts in a well-ventilated place to dry. Allow parts to thoroughly dry before
reassembling the appliance.
1. Cut food into pieces small enough to fit into the opening of the feeding chute. Load the feeding
chute and hopper with food pieces.
2. Plug appliance into a wall outlet and press the FORWARD button to begin juicing.
3. Use the pusher to push food through the feeding chute. The juice and pulp are separated automatically.
NOTE: The proper amount of force should be used to push food. Do not push with excessive force,
rather push just enough for food to meet the auger.
4. To dislodge jammed food and/or maximize the amount of juice you get, press and hold the REVERSE
button for 3 seconds to run the motor in reverse.
5. When finished, switch to the OFF position to turn the juicer o.
USAGE TIPS
OPERATING INSTRUCTIONS
CLEANING
| 9
