Heston Blumenthal everdure HBPK Quick guide

ASSEMBLY & MAINTENANCE
INSTRUCTIONS
for everdure by heston blumenthal Prep Kitchen
Model Number:
HBPK

CLEANING:
Using a soft cloth thoroughly wipe down all surfaces with a mild detergent and warm water
DO NOT use scourers or harsh detergents
DO NOT put cutting boards or wooden lids in the dishwasher
DO NOT put seasoning boxes in a microwave or oven to reheat food
STORAGE:
When the prep kitchen is not in use, it can be stored outdoors, but MUST be under cover and covered (preferably with
a purpose made cover HBPKCOVERL) out of the weather ensuring the cutting surfaces are clean before storing away.
NOTE: These instructions are also available at www.everdurebyheston.com/international
PACKAGING:
Remove all external packaging and remove the Prep Kitchen from the packaging before use
Removal all internal cartons and packaging from within the Prep Kitchen assembly
Prep Kitchen
HBKP
LENGTH
(in)
WIDTH
(in)
HEIGHT
(in)
40.2
21.7
35
MAINTENANCE
Recycle as per local government laws

NOTE: 2 people required for assembly
Main Parts
(P1) Body ×1
(P2) Handle ×2
(P3) Leg ×4
(P4) Cutting Board LU×1pc
(P5) Cutting Board LB×1
(P6) Cover×1
(P7) Top Pan el×1
(P8) Lid ×2
(P9) Storage Tray×3
(P10) Seasoning Box ×4
(P11) Divider ×1
(P12) Waste Bin ×1
Hardware
(H1)/ Hex Bolt M8*20mm ×
4
(H2)/ Washer φ8mm×4
(H3/) Spring Washer φ
8mm×4
(H5)/ Hex Bolt M6*12mm
×16
(H6)/ Washer φ6mm×16
(H7)/ Spring Washer φ
6mm×16pcs
(H8)/Self-tapping screw ×
3pcs
(H9)/ Bolt M6 ×3pcs
(H10)/ Nut M6 ×3pcs
ASSEMBLY
(P13)/ knife holder×1pc

/Rotate (P1) upside-down onto a clean and flat surface, ensuring the body is protected using a sheet or
cardboard. Assemble (P3 x 4) to the bottom plate using (H5 x 16, H6 x 16, H7 x 16)
Ensure the legs are angled outwards (see final image for reference) and rotate the body to the upright
position.
/Fix and fully tighten (P2 x 2) onto main body and the side door using (H1 x 4, H2 x 4, H3 x 4).
Step 01
Step 02
ASSEMBLY

/Slide (P11 x 1) into (P12 x 1)
/ Assemble (P13 x 1) to the bottom of the Cutting Board LU (P4 x 1) using (H8 x 3).
*Note, please remove the plastic protection from all wooden boards before assembly.
There are 3 reserved small holes at the bottom of the Cutting Board LU, corresponding to the installation
screws
Step 04
Step 03
ASSEMBLY

/Fix and fully tighten (H9 x 3) onto both sides at the top of main body (H10 x 3).
/Place (P4 x 1, P5 x 1, P6 x 1, P7 x 1, P8 x 2, P9 x 3, P10 x 4) into positon. See final image for reference
*Note, ignore this section if product arrived with parts pre-assembled
Step 06
Step 05
ASSEMBLY
