Heta INSPIRE 40-40H User manual

1
OPERATING AND INSTALLATION
INSTRUCTIONS
DANISH DESIGN . DANISH QUALITY . DANISH PRODUCTION
www.heta.dk
EN
INSPIRE 40-40H / 45-45H / 55-55H STOVE
is exempt for use in smoke control areas when burning dry wood
ECODESIGN READY

2
Declaration of Performance EN
__________________________________________________________________________________________________________________________________
Regulation No. 305/2011
DOP-Inspire 40-40H 1858-2016
1. Unique identification code of product-type Stove
2. Product name Inspire 40-40H
3. Intended use or uses of the construction product, in
accordance with the applicable technical specification
Room heater burning solid fuel without hot water supply
4. Name and contact address of the manufacturer Heta A/S, Jupitervej 22, DK-7620 Lemvig. [e-mail]
5. Where applicable, name and contact address of
authorized representative. E-mail.
Factory Manager Martin Bach, E-mail: [e-mail]
6. System of assessment and verification of constancy of
performance of the construction product
System 3
7. Notified body relevant to the assessment and
verification of constancy of performance
Teknologisk Institut, DK-8000 Aarhus. Notified body No.
1235. Rapport nr. 300-ELAB-1858-EN-Rev. 1.
8. Declared Performance
Harmonized technical specification EN 13240:2001/A2:2004
Emission CO 0,09% / 1103 mg/Nm3
Nox 92 mg/Nm3
Dust 27 mg/Nm3
Dust (NS3058/3059) 2,86 g/kg
OGC (CEN/TS 15883) 123 mgC/Nm3ved 13% O2
Fire safety
Reaction to fire A1
Test of fire safety in connection with the burning of wood Approved
Distance to combustible materials
Rear
Sides distance to combustible materials
Distance to floor from lower edge of the door
Furniture distance
Minimum distances in mm
120/190
340/400
170
900
Safety
Mechanical resistance (to carry a chimney / flue) Not tested (NPD)
Electrical safety NA
Surface temperature Approved
Cleanability No specification
Thermal output
Nominal heat output 4,5 kW
Room heat output 4,5 kW
Energy efficiency Ƞ81%
Fluegas temperature at nominal heat output T 262oC
Water heating output NA
Maximum water operating pressure NA
9.
The performance of the product identified in points1 and 2 is in conformity with the declared performance in point 8. This
declaration of performance is issued under the sole responsibility of the manufacturer.
Signed on behalf the manufacturer of 18.08.2016
____________________________________________________________________________________________________________________
In case of any change of the above-mentioned production type this Declaration of Performance becomes invalid.
Heta A/S, Jupitervej 22, DK-7620 Lemvig, Tlf. [phone], www.heta.dk
Page 1 of 1
Certifikat no. 1858

Declaration of Performance EN
__________________________________________________________________________________________________________________________________
Regulation No. 305/2011
DOP-Inspire 45-45H 1987-2016
1. Unique identification code of product-type Stove
2. Product name Inspire 45-45H
3. Intended use or uses of the construction product, in
accordance with the applicable technical specification
Room heater burning solid fuel without hot water supply
4. Name and contact address of the manufacturer Heta A/S, Jupitervej 22, DK-7620 Lemvig. [e-mail]
5. Where applicable, name and contact address of
authorized representative. E-mail.
Factory Manager Martin Bach, E-mail: [e-mail]
6. System of assessment and verification of constancy of
performance of the construction product
System 3
7. Notified body relevant to the assessment and
verification of constancy of performance
Teknologisk Institut, DK-8000 Aarhus. Notified body No.
1235. Rapport nr. 300-ELAB-1987-EN-Rev. 1.
8. Declared Performance
Harmonized technical specification EN 13240:2001/A2:2004
Emission CO 0,08% / 1052 mg/Nm3
Nox 115 mg/Nm3
Dust 8 mg/Nm3
Dust (NS3058/3059) 1,89 g/kg
OGC (CEN/TS 15883) 74 mgC/Nm3ved 13% O2
Fire safety
Reaction to fire A1
Test of fire safety in connection with the burning of wood Approved
Distance to combustible materials
Rear
Sides distance to combustible materials
Distance to floor from lower edge of the door
Furniture distance
Minimum distances in mm
150/195
300
120
860
Safety
Mechanical resistance (to carry a chimney / flue) Not tested (NPD)
Electrical safety NA
Surface temperature Approved
Cleanability No specification
Thermal output
Nominal heat output 4,5 kW
Room heat output 4,5 kW
Energy efficiency Ƞ84%
Fluegas temperature at nominal heat output T 221oC
Water heating output NA
Maximum water operating pressure NA
9.
The performance of the product identified in points1 and 2 is in conformity with the declared performance in point 8. This
declaration of performance is issued under the sole responsibility of the manufacturer.
Signed on behalf the manufacturer of 19.09.2016
____________________________________________________________________________________________________________________
In case of any change of the above-mentioned production type this Declaration of Performance becomes invalid.
Heta A/S, Jupitervej 22, DK-7620 Lemvig, Tlf. [phone], www.heta.dk
Page 1 of 1
Certifikat no. 1987
3

4
Declaration of Performance EN
__________________________________________________________________________________________________________________________________
Regulation No. 305/2011
DOP-Inspire 55-55H 3900-2016
1. Unique identification code of product-type Stove
2. Product name Inspire 55-55H
3. Intended use or uses of the construction product, in
accordance with the applicable technical specification
Room heater burning solid fuel without hot water supply
4. Name and contact address of the manufacturer Heta A/S, Jupitervej 22, DK-7620 Lemvig. [e-mail]
5. Where applicable, name and contact address of
authorized representative. E-mail.
Factory Manager Martin Bach, E-mail: [e-mail]
6. System of assessment and verification of constancy of
performance of the construction product
System 3
7. Notified body relevant to the assessment and
verification of constancy of performance
RRF Rhein-Ruhr feuerstätten Prüfstelle GmbH.
46047 Oberhausen, Deutschland
Notified body No. NB 1625 Rapport nr. RRF 40 14 3900
8. Declared Performance
Harmonized technical specification EN 13240:2001/A2:2004
Emission CO 0,1% / 1250 mg/Nm3
Nox 130 mg/Nm3
Dust 28 mg/Nm3
Dust (NS3058/3059) 1,97 g/kg
OGC (CEN/TS 15883) 100 mgC/Nm3ved 13% O2
Fire safety
Reaction to fire A1
Test of fire safety in connection with the burning of wood Approved
Distance to combustible materials
Rear
Sides distance to combustible materials
Distance to floor from lower edge of the door
Furniture distance
Minimum distances in mm
150/220
420
430
1200
Safety
Mechanical resistance (to carry a chimney / flue) Not tested (NPD)
Electrical safety NA
Surface temperature Approved
Cleanability No specification
Thermal output
Nominal heat output 6,3 kW
Room heat output 6,3 kW
Energy efficiency Ƞ80%
Fluegas temperature at nominal heat output T 263oC
Water heating output NA
Maximum water operating pressure NA
9.
The performance of the product identified in points1 and 2 is in conformity with the declared performance in point 8. This
declaration of performance is issued under the sole responsibility of the manufacturer.
Signed on behalf the manufacturer of 18.08.2016
____________________________________________________________________________________________________________________
In case of any change of the above-mentioned production type this Declaration of Performance becomes invalid.
Heta A/S, Jupitervej 22, DK-7620 Lemvig, Tlf. [phone], www.heta.dk
Page 1 of 1
Certifikat no. 3900

5
Congratulations on your new wood stove, we are confident that you will be more than
satisfied with your new Heta stove. Especially if you follow the following advice and
instructions.
Inspire 40-40H, 45-45H and 55-55H wood stoves are approved according to EN
13240, NS 3058 and 3059. These approvals, means that the wood stove meets a
variety of specifications and requirements, ensuring it is made of quality materials,
minimum environmental impact and that it has an optimum fuel economy.
Operating Instructions
Contents
Declaration of Performance ............................................................ 2-4
Before installation........................................................................... 6-7
1. Operating instructions........................................................................ 8
1.1 Before using ....................................................................................... 8
1.2 First firing ........................................................................................... 8
1.3 Regulating the airflow ........................................................................ 8
1.4 Lighting the stove............................................................................... 8
1.5 Refueling ............................................................................................ 8
1.6 Emptying the ash ............................................................................... 9
1.7 Reduced burning................................................................................ 9
1.8 Risk of explosion................................................................................ 9
1.9 Draft conditions in the chimney ....................................................... 10
1.10 Fuel................................................................................................... 10
1.11 Operating problems ......................................................................... 11
1.12 Chimney fires ................................................................................... 12
1.13 Troubleshooting ............................................................................... 13
1.14 Maintenance..................................................................................... 13
1.15 Cleaning the glass............................................................................ 13
1.16 Maintenance schedule ..................................................................... 13
1.17 Cleaning/Replacing bicks after chimney sweeping ......................... 14
1.18 Parts Inspire 40-40H ........................................................................ 15
1.19 Parts Inspire 45-45H ........................................................................ 16
1.20 Parts Inspire 55-55H ........................................................................ 17
1.21 Stove data table EN 13240 .............................................................. 18
1.22 Garantee........................................................................................... 18
2. Installation Instructions .................................................................... 19
Heta A/S
Jupitervej 22,
DK-7620 Lemvig
Phone: [phone]
E-mail: [email protected]
Copyright © 2014
Heta is a registered
trademark of Heta A/S
13.10.2020
0037-1395 Version 3,3
Printed in Denmark
Subject to printing errors
and changes.
