Data Sheet
Travelstar™Z7K320
2.5-Inch Mobile 7200 RPM
7mm Hard Disk Drives
Highlights
• New 7mm z-height for greater
design flexibility
• 7200 RPM high-performance HDD
• Up to 320GB1of capacity
• Best-of-breed acoustics
• Low power consumption
• Halogen-free for eco-friendly footprint
• Self-encrypting models for data security
• Enhanced-availability (EA) models for
applications needing around-the-clock
access in lower-transaction environments
Applications/Environments
• Notebook and ultra-portable PCs
• Compact desktop PCs
• External storage
• Gaming PCs
• Compact video devices
• Blade servers (EA)
• Network routers (EA)
• Video surveillance (EA)
• Compact RAID systems (EA)
High-Performance, Quiet HDD Solution For Mobile Applications
Travelstar™Z7K320istheindustry’srst7200RPM,7mm,2.5-inchharddrivewithcapacities
rangingfrom160GBto320GB.The320GBperplatterone-diskmodelsaredesignedasa
directreplacementforstandard9.5mmHDDs,foruseinnotebookPCs,externalstorage
andcompactsystems.TheZ7K320oersdesignexibilitytoaccommodatenewthinner
andmorerobustdevices/systemsanddeliversupto18%betterapplicationperformance
than5400RPMmodelsofthesamecapacity.Alongwithcontinuedfocusonsuperiorshock
protectionandlowpowerconsumption,HGSTdeliversbest-of-breedacoustics.HGSToers
optionalhard-drive-levelencryptionforincreaseddatasecurityandmodelswithenhanced
availabilitytodeliverhigh-performancestoragefornon-stopenvironments.Travelstar
Z7K320providestherightbalanceofperformanceandcapacitytomeetthemulti-tasking
needsofcommercialandconsumerusersonthego.
Data Security Option
TravelstarZ7K320isthefourthgenerationtofeatureoptionalBulkDataEncryption(BDE)
forhard-drive-leveldatasecurity.WithBDE,thedataisscrambledusingakeyasitiswritten
tothedisk,thendescrambledwiththekeyasitisretrieved,givingusersthehighestlevel
ofdataprotectionavailable.Italsospeedsandsimpliesthedrivere-deploymentprocess.
Bydeletingtheencryptionkey,thedataonthedriveisrenderedunreadable,thereby
eliminatingtheneedfortime-consumingdata-overwrite.Forinformationabouttheself-
encryptingdrivesdesignedtotheTrustedComputingGroup(TCG)OpalStorageSecurity
specication,pleasecontactyourHGSTrepresentative.
Enhanced Availability (EA)—for 24x7 Access to Data
HGSTprovidesenhanced-availabilitymodelsoftheTravelstarZ7K320thatdeliver24x7
accesstoinformationfordata-intensiveapplicationsrequiringround-the-clockoperation.
Thenew,slimmerproleprovidesforadditionalcooling,especiallyimportantindenseblade
serverdesigns.TheZ7K320provideshighcapacity,performanceanddurabilityonaproven
platformforqualityandreliability.EAmodelssupportthestringentdemandsof“always-on”
applicationsinlower-transactionenvironments.
Features and Benefits
Feature / Function Benefits
Capacity Up to 320GB storage Up to 80 hours of high-definition video, 320 hours of standard video, 114 movies,
80,000 4-min songs or 160 games *
Performance Up to 1334Mb/s media transfer rate Faster downloads and up to 18% better application performance than 5400 RPM models at same capacity**
Power 1.8W read/write power
0.8W low power idle
Low energy use and long battery life for more “unplugged” notebook time
Reliability 400G operating shock
1000G non-operating shock
Robust design to help protect against bumps and rough handling
TrueTrack™ technology Prevents slow performance or errors in high shock or vibration environments
Acoustics Improved acoustics Quieter for a richer audio-listening experience for music, movies and games.
Interface SATA 3Gb/s Fast data throughput
Security
Option
Bulk Data Encryption Helps guard against data theft
320GB, 250GB and 160GB
7200 RPM | SATA 3Gb/s
* Actual storage may vary depending on the compression rate applied. Capacities may not be combined.
**In PCMark® Vantage testing

© 2012 HGST, a Western Digital company, 3403 Yerba Buena Road, San Jose, CA 95135 USA. Produced in the United States 5/10, rev. 11/10, 3/11, 9/12. All rights reserved.
Travelstar and Truetrack are trademarks of HGST, a Western Digital company.
The EcoTrac symbol identifies HGST hard drives that deliver on the principles of lower operating costs, safer product disposal and a more sustainable environment.
HGST trademarks are intended and authorized for use only in countries and jurisdictions in which HGST has obtained the rights to use, market and advertise the brand. The Travelstar trademark is
authorized for use in the Americas, EMEA, and the following Asia-Pacific countries and jurisdictions: Australia, Hong Kong, Japan, New Zealand, South Korea and Taiwan. Contact HGST for
additional information. HGST shall not be liable to third parties for unauthorized use of this document or unauthorized use of its trademarks.
References in this publication to HGST’s products, programs, or services do not imply that HGST intends to make these available in all countries in which it operates.
Product specifications provided are sample specifications and do not constitute a warranty. Information is true as of the date of publication and is subject to change. Actual specifications for
unique part numbers may vary.
Please visit the Support section of our website, www.hgst.com/support, for additional information on product specifications. Photographs may show design models.
DSTZ723210EN-04
HGST Quality and Service
HGST’smobileharddrivesaredesignedto
thehighestqualitystandardsandcontain
eld-provencomponents.HGSTprovides
worldwidetechnicalsupportandintegration
servicestoenableglobalcustomerstobring
theirproductstomarketquickly.
How to read the Travelstar model number
HTS543232A7A364 = 320GB, SATA 3Gb/s
H = HGST
T = Travelstar
S = Standard (vs E for Enhanced Availability)
72 = 7200 RPM
32 = Full capacity — 320GB
32 = Capacity this model, 32 = 320GB
(25 = 250GB, 16 = 160GB)
A = Generation code
7 = 7mm z-height
A3 = SATA 3Gb/s
16 = 16MB cache
4 = No encryption (1 = Bulk data encryption,
5 = TCG Opal Encryption)
Information and Technical Support
www.hgst.com (Main Web site)
www.hgst.com/partners (Partner Web site)
North America
[email protected]
Toll free: 1 888 426-5214, Direct: 1 408 717-8087
Asia Pacific
[email protected] / 65 6840 9595
EMEA and UK
[email protected] / 44 20 7133 0032
Germany
[email protected] / 49 6929 993601
Program Support
Partners First Program
[email protected]
Specifications
Models HTS723232A7A364
HTS723232A7A361
HTS723232A7A365
HTS723225A7A364
HTS723225A7A361
HTS723225A7A365
HTS723216A7A364
HTS723216A7A361
HTS723216A7A365
HTE723232A7A364
HTE723225A7A364
Configuration
Interface SATA 3Gb/s f
Capacity (GB)1320 / 250 / 160 320 / 250
Sector size (bytes) 512 f
Recording zones 24 f
Aerial density (Gbit/sq.in, max) 477 f
Performance
Data buffer (MB)216 f
Rotational speed (RPM) 7200 f
Latency average (ms) 4.2 f
Media transfer rate (Mbits/s, max) 1334 f
Interface transfer rate (MB/s) 300 f
Seek time
Average (typical) ms (read)313 f
Track to track (typical) ms (read) 1 f
Full stroke (typical) ms (read) 25 f
Reliability
Load/Unload cycle 600,000 f
Power on hours (POH) per month N/A 730
Availability4N/A 24x7
Power
Requirement +5VDC (+-5%) f
Dissipation (typical)
Startup (W, peak, max) 5.5
f
Seek (W, average) 2.1 f
Read/Write (W, average) 1.8 f
Performance idle (W, average) 1.7 f Idle (Avg.)
Active idle (W, average) 1.0 N/A
Low power idle (W, average) 0.8 N/A
Standby (W, average) 0.2 f
Sleep 0.1 f
Physical size
Height (mm, max) 7 f
Dimensions (width x depth, mm) 70 x 100 f
Weight (g, max) 95 f
Environmental (operating)
Shock (half-sine wave) 400G/2ms, 225G/1ms f
Ambient temperature 0° to 60° C f
Environmental (non-operating)
Shock (half-sine wave) 1000G/1 ms f
Ambient temperature -40° to 65° C f
Acoustics (A-weighted sound power)
Idle (Bels, typical) 2.3 f
Seek (Bels, typical) 2.4 f
Travelstar™Z7K320
Standard Models EA Models
1One GB is equal to one billion bytes when referring to hard drive
capacity. Accessible capacity will vary depending on the operat-
ing environment and formatting.
2Portion of buffer used for firmware
3Excludes command overhead
4Designed for low duty cycle, non mission-critical applications
in PC, nearline and consumer electronics environments, which
vary application to application
