HH Electronics VECTOR VRE-12 User manual

VRE-12 VRE-15 VRE-215
USER MANUAL
FULL RANGE PASSIVE SYSTEMS

WWW.HHELECTRONICS.COM
2
SPECIFICATIONS
2 x Speakon compatible sockets
800W
595 x 388 x 308
1" exit compression driver
Unit 12.5Kg, Packed 13.5Kg
2 x Side Bar Handles
Heavy Custom Punched gauge steel
1 x 12" driver
200W
Moulded Passive Enclosure
8 Ohm
VRE-12
Moulded Passive Enclosure
VRE-15
8 Ohm
200W
800W
1 x 15" driver
692 x 450 x 348
Unit 15Kg, Packed 16.5Kg
2 x Side Bar Handles
1" exit compression driver
Heavy Custom Punched gauge steel
2 x Speakon compatible sockets
1100 x 450 x 348
Unit 19Kg, Packed 20.5Kg
2 x Speakon compatible sockets
Heavy Custom Punched gauge steel
Moulded Passive Enclosure
VRE-215
2 x Side Handles
1" exit compression driver
1600W
2 x 215" driver
8 Ohm
400W
Model
System type
Grille
Handles
Woofers
Dimensions (HxWxD)
Impedance
Power Peak
Tweeter
Power RMS
Connections
Weight
3) Comply with warnings: All warnings and instructions for these products should be adhered to.
4) Unpacking: Please retain the packing carton and liners in case the unit should need to be returned at any time.
Thank you for purchasing an HH Passive Full Range Inclosure.
5) Amplifier connection. In order to avoid damage, it is advisable to establish and follow a pattern for turning on and off your sound system.
The Vector series are professional specification cabinets designed to give exceptional dynamics, clarity and projection in all applications from
clubs to large venues.
In order to take full advantage of it and enjoy long and trouble-free performance, please read this owner's manual carefully, and keep it in a safe
place for future reference.
1) Read Instructions carefully before installing or operating this product.
2) Retain these instructions
With all system parts connected, turn on source equipment, tape decks, cd players, mixers, effects processors etc. BEFORE turning on your power
amplifier. Many products have large transient surges at turn on and off which can cause damage to your speakers.
7) Caution: These professional loudspeaker systems are capable of generating very high sound pressure levels. Use care with placement and
operation to avoid exposure to excessive levels that can cause permanent hearing damage.
6) Cables- never use shielded or microphone cable for any speaker connections as this will not be substantial enough to handle the amplifier load
and could cause damage to your complete system.
Wait until all system parts have stabilised usually a couple of seconds.
By turning on your power amplifier LAST and making sure its level control are set to minimum any transients from other equipment will not reach
your loudspeakers.
Similarly when turning off your system always turn down the level controls on your power amplifier and then turn off its power before turning off
other equipment.
9) Servicing: The user should not attempt to service these products. Refer all servicing to qualified service personnel.
VRE-12
VRE-15
VRE-215

12 REVISION 1.00
Model number:
Serial number:
Place of purchase:
Date of purchase:
