HH Electronics MZ Series User manual

INSTALLATION
V0.1 DESIGNED AND ENGINEERED IN THE UK BY HH ELECTRONICS LTD. © 2023 HH ELECTRONICS LTD
* 130W AT 100-120V~ MAINS INPUT VOLTAGE
Absolute maximum loading for MZ-140D per zone is shown in the table below. Best practice states a roughly 10% de-rating margin
should be applied to these figures to allow for cable loses etc.
MZ-140D MAXIMUM LOADING
M ax Loading Per Zone
M ode 4 O HM 8 O HM HiZ 7 0 V HiZ 1 0 0 V
Zones 2 2 2 2
Max Power Per Zone 95W 140W * 140W 120W
Minimum Impedance 4 OHMS 8 OHMS 8 OHMS 8 OHMS
SPEAKER M O D E TN i-W 4 TN i-W 6 TN i-W 8 TN i-C4 TN i-C6 TN i-C8 TN i-W 8 PRO TN i-
W 1 2 PRO
Lo-Z 8 Ohms 8 Ohms 8 Ohms 8 Ohms 8 Ohms 8 Ohms 8 Ohms 8 Ohms
Max QTY Per Zone 2 2 2 2 2 2 2 2
1 0 0 V Power M ax 30 W 40 W 40 W 30 W 40 W 40 W - -
Max QTY Per Zone 4 3 3 4 3 3 - -
Total Impedance 83 83 83 83 83 83 - -
Total Power 120 120 120 120 120 120 - -
1 0 0 V Power M id 1 15 W 20 W 20 W 15 W 20 W 20 W - -
Max QTY Per Zone 8 6 6 8 6 6 - -
Total Impedance 83 83 83 83 83 83 - -
Total Power 120 120 120 120 120 120 - -
1 0 0 V Power M id 2 6 W 10 W 10 W - - - - -
Max QTY Per Zone 20 12 12 - - - - -
Total Impedance 83 83 83 - - - - -
Total Power 120 120 120 - - - - -
1 0 0 V Power Low 3 W 5 W 5 W 6 W 10 W 10 W - -
Max QTY Per Zone 40 24 24 20 12 12 - -
Total Impedance 83 83 83 83 83 83 - -
Total Power 120 120 120 120 120 120 - -
7 0 V Power M ax 15 W 20 W 20 W 15 W 20 W 20 W - -
Max QTY Per Zone 9 7 7 9 7 7
Total Impedance 36 35 35 36 35 35
Total Power 135 140 140 135 140 140
7 0 V Power M id 1 7.5 W 10 W 10 W 7.5 W 10 W 10 W - -
Max QTY Per Zone 17 13 13 18 14 14
Total Impedance 38 38 38 36 35 35
Total Power 127.5 130 130 135 140 140
7 0 V Power M id 2 3 W 5 W 5 W - - - - -
Max QTY Per Zone 46 28 28 - - -
Total Impedance 36 35 35 - - -
Total Power 138 140 140 - - -
7 0 V Power Low 1.5 W 2.5 W 2.5 W 3 W 5 W 5 W - -
Max QTY Per Zone 92 56 56 46 28 28
Total Impedance 36 35 35 36 35 35
Total Power 138 140 140 138 140 140 -

INSTALLATION
V0.1 DESIGNED AND ENGINEERED IN THE UK BY HH ELECTRONICS LTD. © 2023 HH ELECTRONICS LTD
MZ-140Q MAXIMUM LOADING
Absolute maximum loading for MZ-140Q per zone is shown in the table below. Best practice states a roughly 10% de-rating margin
should be applied to these figures to allow for cable loses etc.
* 130W AT 100-120V~ MAINS INPUT VOLTAGE
Max Loading Per Zone
Mode 4 OHM 8 OHM HiZ 70V HiZ 100V
Zones 4 4 4 4
Max Power Per Zone 95W 140W * 140W 120W
Minimum Impedance 4 OHMS 8 OHMS 8 OHMS 8 OHMS
SPEAKER M ODE TNi-W4 TNi-W6 TNi-W8 TNi-C4 TNi-C6 TNi-C8 TNi-W8PRO TNi-W12PRO
Lo-Z 8 Ohms 8 Ohms 8 Ohms 8 Ohms 8 Ohms 8 Ohms 8 Ohms 8 Ohms
Max QTY Per Zone 2 2 2 2 2 2 2 2
100V Pow er Max 30 W 40 W 40 W 30 W 40 W 40 W - -
Max QTY Per Zone 4 3 3 4 3 3 - -
Total Impedance 83 83 83 83 83 83 - -
Total Power 120 120 120 120 120 120 - -
100V Pow er Mid 1 15 W 20 W 20 W 15 W 20 W 20 W - -
Max QTY Per Zone 8 6 6 8 6 6 - -
Total Impedance 83 83 83 83 83 83 - -
Total Power 120 120 120 120 120 120 - -
100V Pow er Mid 2 6 W 10 W 10 W - - - - -
Max QTY Per Zone 20 12 12 - - - - -
Total Impedance 83 83 83 - - - - -
Total Power 120 120 120 - - - - -
100V Pow er Low 3 W 5 W 5 W 6 W 10 W 10 W - -
Max QTY Per Zone 40 24 24 20 12 12 - -
Total Impedance 83 83 83 83 83 83 - -
Total Power 120 120 120 120 120 120 - -
70V Pow er M ax 15 W 20 W 20 W 15 W 20 W 20 W - -
Max QTY Per Zone 9 7 7 9 7 7
Total Impedance 36 35 35 36 35 35
Total Power 135 140 140 135 140 140
70V Power M id 1 7.5 W 10 W 10 W 7.5 W 10 W 10 W - -
Max QTY Per Zone 17 13 13 18 14 14
Total Impedance 38 38 38 36 35 35
Total Power 127.5 130 130 135 140 140
70V Power M id 2 3 W 5 W 5 W - - - - -
Max QTY Per Zone 46 28 28 - - -
Total Impedance 36 35 35 - - -
Total Power 138 140 140 - - -
70V Pow er Low 1.5 W 2.5 W 2.5 W 3 W 5 W 5 W - -
Max QTY Per Zone 92 56 56 46 28 28
Total Impedance 36 35 35 36 35 35
Total Power 138 140 140 138 140 140 -

INSTALLATION
V0.1 DESIGNED AND ENGINEERED IN THE UK BY HH ELECTRONICS LTD. © 2023 HH ELECTRONICS LTD
MZ-280Q MAXIMUM LOADING
REMOTE
CONTROL
4-16 OHM
70V/100V
DIRECT
DRIVE
ECO
DESIGN
ADVANCED
CORE
PROCESSOR ACP
* 250W AT 100-120V~ MAINS INPUT VOLTAGE
Max Loading Per Zone
Mode 4 OHM 8 OHM HiZ 70V HiZ 100V
Zones 4 4 4 4
Max Power Per Zone 280W * 245W 250W 240W
Minimum Impedance 4 OHMS 8 OHMS 8 OHMS 8 OHMS
SPEAKER MODE TNi-W4 TNi-W6 TNi-W8 TNi-C4 TNi-C6 TNi-C8 TNi-W8PRO TNi-W12PRO
Lo-Z 8 Ohms 8 Ohms 8 Ohms 8 Ohms 8 Ohms 8 Ohms 8 Ohms 8 Ohms
Max QTY Per Zone 2 2 2 2 2 2 2 2
100V Pow er Max 30 W 40 W 40 W 30 W 40 W 40 W - -
Max QTY Per Zone 8 6 6 8 6 6 - -
Total Impedance 42 42 42 42 42 42 - -
Total Power 240 240 240 240 240 240 - -
100V Pow er Mid 1 15 W 20 W 20 W 15 W 20 W 20 W - -
Max QTY Per Zone 16 12 12 16 12 12 - -
Total Impedance 42 42 42 42 42 42 - -
Total Power 240 240 240 240 240 240 - -
100V Pow er Mid 2 6 W 10 W 10 W - - - - -
Max QTY Per Zone 40 24 24 - - - - -
Total Impedance 42 42 42 - - - - -
Total Power 240 240 240 - - - - -
100V Pow er Low 3 W 5 W 5 W 6 W 10 W 10 W - -
Max QTY Per Zone 80 48 48 40 24 24 - -
Total Impedance 42 42 42 42 42 42 - -
Total Power 240 240 240 240 240 240 - -
70V Pow er M ax 15 W 20 W 20 W 15 W 20 W 20 W - -
Max QTY Per Zone 16 12 12 16 12 12
Total Impedance 20 20 20 20 20 20
Total Power 240 240 240 240 240 240
70V Power M id 1 7.5 W 10 W 10 W 7.5 W 10 W 10 W - -
Max QTY Per Zone 32 24 24 33 24 24
Total Impedance 20 20 20 20 20 20
Total Power 240 240 240 247.5 240 240
70V Power M id 2 3 W 5 W 5 W - - - - -
Max QTY Per Zone 80 50 50 - - -
Total Impedance 20 20 20 - - -
Total Power 240 250 250 - - -
70V Pow er Low 1.5 W 2.5 W 2.5 W 3 W 5 W 5 W - -
Max QTY Per Zone 166 100 100 83 50 50
Total Impedance 20 20 20 20 20 20
Total Power 249 250 250 249 250 250 -
Absolute maximum loading for MZ-280Q per zone is shown in the table below. Best practice states a roughly 10% de-rating margin
should be applied to these figures to allow for cable loses etc.

INSTALLATION
V0.1 DESIGNED AND ENGINEERED IN THE UK BY HH ELECTRONICS LTD. © 2023 HH ELECTRONICS LTD
CALCULATING MAXIMUM LOADING
For Lo-Z modes (4 or 8 ohm) you should never load the amplifier below its rated minimum load impedance per zone. For example,
in 4 ohm mode you may connect either one 4 ohm loudspeaker, or two 8 ohm loudspeakers connected in parallel
For Hi-Z modes (70V or 100V) you should never load the amplifier greater than its rated maximum power per zone. For example, MZ-
280Q is 240W in 100V mode so you may connect eleven TNi-C8 loudspeakers running in 100V/20W mode (20W * 11 = 220W)
Depending on the scenario, a 10% derating may be required
11 TNi-C8s running at 20W = 220W
A safe margin of 20W is allowed for cable losses
x x
CONNECTED TO ZONE 4
MZ-280Q RUNNING IN 100V MODE
USES PIN 1+3
CONNECTED TO ZONE 3
MZ-280Q RUNNING IN 4 OHM MODE
USES PIN 1+2
1
1
8
( (
+1
8
( (
= 4 OHMS
( (
1 2 3 4 5 6 7 8 9 10
# ON OFF
10 FRONT PANEL LOCK
4 Z2 HiZ 70V /4 OHM Z2 HiZ 100V /8 OHM
6 Z3 HiZ 70V /4 OHM Z3 HiZ 100V /8 OHM
7 Z4 HiZ MODE Z4 LoZ MODE
8 Z4 HiZ 70V /4 OHM Z4 HiZ 100V /8 OHM
5 Z3 HiZ MODE Z3 LoZ MODE
9 POWER SAVING MODE
2 Z1 HiZ 70V /4 OHM Z1 HiZ 100V /8 OHM
1 Z1 HiZ MODE Z1 LoZ MODE
3 Z2 HiZ MODE Z2 LoZ MODE
ON
OFF
x7
