Hidrotermal Mini Series Manual

HT Mini Lights Series
INSTALLATION AND MAINTENANCE MANUAL
Please read this operation manual carefully and keep it for future reference.

1.Technical Parameters
Model Description Power Option Color Option
Mini-LSS62 Mini Stainless Steel AISI-316 Light 6W 9W Single RGB
Mini-LPC62 Mini Plastic Light 3W 5W Single RGB
Mini-LPC94 Mini Plastic Light 6W Single RGB
Mini-LSS95 Mini Stainless Steel AISI-316 Light 6W Single RGB
Mini-LPC95 Mini Plastic Light 6W Single RGB
Mini-LSS105 Mini Stainless Steel AISI-304 Light 9W 12W Single RGB
Mini-LSS105 Mini Stainless Steel AISI-316 Light 9W 12W Single RGB
Mini-LPC125 Mini Plastic Light 9W Single RGB
Mini-LSS150 Mini Stainless Steel AISI-316 Light 6W 9W Single RGB
Mini-LPC150 Mini Plastic Light 6W 9W Single RGB
2. Before Installation
1) Please turn off the power before installation to avoid electric shock caused by improper operation. Non-
professional and technical personnel are not allowed to repair or modify this product;
2) Please pay attention to checking whether the voltage marked on the underwater light is consistent with the
input voltage to be connected before installation, so as not to damage the LED underwater light;
3) This lamp is designed with waterproof and moisture-proof functions, and its waterproof level can reach
IP68. The lamp is able to work in an environment of 100cm deep under the water;
4) The working environment temperature for the lamp should be between -20℃~+45℃ to ensure the service
life of the lamp;
5) If the lamp is damaged or there is a problem with the insulation of the wire, please do not use it!
6) Corrosive or soluble chemicals will destroy the protection of the lamp housing;
7) The manufacturer is not responsible for the consequences caused by using the power supply not provided
by the manufacturer;
8) If the lamps do not work, please put the lamps together in one place, and then send them back to the
manufacturer for inspection and repair.
It is forbidden to turn on the underwater light outside the water, otherwise it may shorten
its service life and even cause burning of integrated components of LED chips.
In order to connect underwater light, a switching power supply must be used to adapt to the
load power.
For user safety, DR circuit breaker must be installed in the system, and the specifications
are chosen according to the load power.

3. Installation
3.1 Suggestions of Installation Height for Underwater Light
1) The circuit system of the underwater light needs to be equipped with GFCI (Ground Fault Circuit
Interrupter) and a suitable rated current circuit breaker;
2) The length of the cable connecting the underwater light and the transformer should not exceed 30m,
otherwise it may affect the normal operation of the underwater light;
3) The underwater light must be installed on a vertical pool wall, and it is prohibited to install it on an irregular
wall (concave wall, wall with an arc radius greater than 3m);
4) Reserve a spare cable with a length of at least 1500mm at the back of the underwater light for use as a
connection line for future replacement and maintenance;
5) To achieve synchronization of underwater lights, all underwater lights must be correctly connected to the
same switch.(See Figure 1)
3.2 Instructions for Installation in Concrete Pool (PVC Pipe Ø20mm)
1) Before installation, ensure that there is enough space on the wall of the concrete pool (B) so that the
underwater light can be directly inserted into the Ø20mm pipe;
2) After fixing and sealing it and inserting it, operate it through the ring (A) to push the underwater light and
keep it close to the wall of the concrete pool (B).
Key No. Product Description
A O-ring for fixing underwater light
B Concrete Pool Wall
Figure 1
Figure 2
Figure 3

3.3 Instructions for Installation in Concrete Pool (PVC Pipe Ø25mm)
1) First, the ring (A) must be inserted into the underwater light, and then the underwater light is inserted into
the pipe (B) by pressure to fix it;
2) After inserting the casing (B), the ring on the back of the casing (B) will be fixed on the Ø25mm pipe by
pressure. In order to obtain the best installation effect, please follow the following sequence to push the
underwater light up so that it is flush with the wall of the concrete pool (C).
Key No. Product Description
A O-ring for fixing underwater light
B Casing for 25mm Pipe
CConcrete Pool Wall
4. Trouble shooting
1) Underwater light cannot be lit for more than 10 minutes without being immersed in water;
2) When the underwater light is installed in the swimming pool, the swimming pool should be filled with water
as soon as possible. The underwater light should not be exposed to the sun for a long time;
3) Before installing the underwater light and lighting, please check whether the underwater light is completely
immersed in the water and whether the electric box and circuit are working normally;
4) This product does not require any maintenance. If it does not work normally, please contact us.
Possible problem Solution
Lamp Dimming
Check the control box;
If controller is connected, please check whether controller is
connected. If it is connected, check whether it is turned on.
After power on, the light
doesn't light up.
Check the connection position of the cable;
Check the fuse on the switchboard;
Replace the lamp;
Contact a qualified electrician for testing.
After power on, the light can
turn on, but it turn off after a
few seconds.
Check the control box;
Contact a qualified electrician for testing.
Figure 4
Figure 5
