ARPOOL XM PROJECTOR
INSTALLATION INSTRUCTIONS (FIXTURE)
All dimensions are given according to the SI system of units (mm, kg, °C), additional dimensions that are written in brackets,
are given according to the U.S. measurement system (in, lbs, °F)
UNDERWATER
5m MAX.
Ta I 40°C
22
IP68 AISI316L12 VDC
GENERAL REMARKS ON SAFETY
·READ ALL OF THESE INSTRUCTIONS BEFORE INSTALLING
FIXTURES.
·KEEP ALL OF THE INSTRUCTIONS FOR FUTURE
REFERENCE.
·INSTALLATION IS TO BE PERFORMED BY A QUALIFIED
ELECTRICIAN ONLY.
·ALL INSTALLATIONS ARE TO CONFORM TO THE
STANDARDS OF THE NATIONAL ELECTRICAL CODE AS
WELL AS ALL LOCAL JURISDICTIONAL CODES AND
REGULATIONS.
·PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH
THE APPLICABLE INSTALLATION CODE BY A PERSON
FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF
THE PRODUCT AND THE HAZARDS INVOLVED.
·TURN OFF POWER BEFORE INSTALLING FIXTURE.
·DO NOT OPEN THE LUMINAIRE AS IT WILL ANNUL THE IP
RATING OF LUMINAIRE AND VOID THE WARRANTY.
·THE SURFACE TEMPERATURE OF THE FIXTURE IS ≈40°C
(104°F) AND IMPOSES NO LIMITS ON INSTALLATION.
·CALCULATE THE MAXIMUM POWER CONSUMPTION AND
USE APPROPRIATELY SIZED DRIVERS/CONTROLLERS.
·FIXTURES' SURFACES EXPOSED TO THE EFFECTS OF
WATER (INCLUDING WATER CONTAINING CHLORINE) ARE
MADE OUT OF AISI316L STAINLESS STEEL. AISI316L IS
SUITABLE FOR THIS USE AND WILL PREVENT CORROSION
UP TO LEVEL OF 1000 PPM OF CHLORINE IN WATER AND
UP TO WATER pH LEVEL OF 7.
·THE EXTERNAL FLEXIBLE CABLE OR CORD OF THIS
LUMINAIRE CANNOT BE REPLACED; IF THE CORD IS
DAMAGED, THE LUMINAIRE WILL NO LONGER BE USABLE,
AND THE LUMINAIRE MUST BE REPLACED.
IK10
1/3
www.filixlighting.com
WARRANTY
ALL PRODUCTS ARE FACTORY TESTED AND ARE GUARANTEED FREE
FROM FACTORY DEFECT FOR A PERIOD OF 36 MONTHS UNDER
FOLLOWING TERMS:
·PRODUCT HAS NOT BEEN SUBJECT TO INCORRECT VOLTAGE OR
POLARITY CONNECTION.
·PRODUCT HAS NOT BEEN SUBJECT TO PHYSICAL OR
ATMOSPHERIC DAMAGE.
·PRODUCT HAS BEEN RETURNED AND FACTORY EVALUATED FOR
DEFECT OR MALFUNCTION.
·ALL DRIVERS AND CONTROLLERS ARE APPROVED FOR USE BY
FILIX.
·THE LUMINAIRE FACTORY SEAL ( IP RATING ) HAS NOT BEEN
COMPROMISED
THE MANUFACTURER ACCEPTS NO RESPONSIBILITY FOR DAMAGE TO
PERSONS OR PROPERTY ARISING THROUGH IMPROPER USE OR
INSTALLATION.
ANY MODIFICATION OF THE LUMINAIRE WILL VOID ANY AND ALL
WRITTEN OR IMPLIED WARRANTIES.
STANDARD REPLACEMENT AND NORMAL
SERVICING TERMS.
ALL ELECTRONIC AND OTHER CONSUMABLE COMPONENTS ARE
SUBJECT OF EXCHANGE AFTER 36 MONTHS OF OPERATIONS.
PRODUCT PERFORMANCE DEPENDS OF CRITICAL ELECTRONIC AND
OTHER COMPONENTS WHICH CAN BE SERVICED WITH OFFICIAL
DEALER OR DIRECTLY WITH THE MANUFACTURER.
MANUFACTURER HOLDS THE RIGHT TO REPAIR AND CHANGE
COMPONENTS AS PER CURRENT COMPONENT AVAILABILITY.
MANUFACTURER CANNOT BE HELD LIABLE FOR COMPONENTS AND
OTHER EXPENSES ( DE-INSTALLATION, INSTALLATION, SHIPPING,
ETC.) INCURRED DURING THE PROCESS OF PRODUCT IMPROVEMENT
AND SERVICING.
THE LIGHT SOURCE CONTAINED IN THIS LUMINAIRE SHALL ONLY BE
REPLACED BY THE MANUFACTURER OR HIS SERVICE AGENT OR A
SIMILAR QUALIFIED PERSON.
NO PRESSURE
WASH
