HIEE HIVR 101 User manual
Manual
LCD video-goggle with 5,8 GHz diversity receiver
HIVR 101
EN
2- 2
48352_jh_V1
Index
Introduction....................................................................................3
Service Centre.................................................................................3
Intended use...................................................................................4
Package content............................................................................. 4
Symbols explication....................................................................... 5
Safety notes....................................................................................5
Charge the Lithium battery............................................................ 6
Control panel.................................................................................. 7
Commissioning............................................................................... 8
Technical Data.................................................................................8
Battery warranty............................................................................ 9
Declaration of conformity..............................................................9
Notes on environmental protection............................................10
Care and maintenance................................................................. 10
Warranty....................................................................................... 10
3- 12
48352_jh_V1
Introduction
Thank you very much for purchasing the Video-goggle. This Vid-
eo-goggle is extremely versatile. Read this manual carefully to
achieve the best results with your Video-goggle. If you experience
any trouble during operation, take the instructions to help or ask
your dealer or Graupner Service Centre.
Due to technical changes, the information may be changed in this
manual without prior notice. Keep updated by regularly checking
our own website, www.graupner.de to be always updated withthe
products and firmware.
This product complies with national and European legal require-
ments.
To maintain this condition and to ensure safe operation, you must
read and follow this user manual and the safety notes before using
the product!
NOTICE
This manual is part of that product. It contains important informa-
tion concerning operation and handling. Keep these instructions for
future reference and give it to third person in case you gave the prod-
uct.
Service Centre
Service Europe
Graupner/SJ-Zentralservice
Graupner/SJ GmbH
Henriettenstrasse 96
D-73230 Kirchheim / Teck
Servicehotline
(+49) (0)7021/722-130
Monday- Thursday
9:15 am- 4:00 pm
Friday
9:15 am- 1:00 pm
Graupner in Internet
For the service centers outside Germany please refer to our web site
www.graupner.de
4- 12
48352_jh_V1
Intended use
The Video-goggle is suitable to reproduce images from FPV cameras
signal or to playback videos or images from external sources. The
integrated 5,8 GHz receiver receives the video signal sent by the FPV
transmitters installed in the model. For any improper use no war-
ranty or liability is accepted.
Read through this entire manual before you attempt to install or use
the Video-goggle.
Graupner/SJ constantly works on the development of all products;
we reserve the right to change the item, its technology and equip-
ment.
Target group
The product is not a toy. It is not suitable for children under 14 years.
The operation of the Video-goggle must be performed by experi-
enced users. If you do not have sufficient knowledge about dealing
with FPV goggles, please contact an experienced users or adealer.
Package content
Diversity Video-goggle incl. Lithiumbattery
2x 5.8GHz receiver antennas
Lens set
2x AV out cable
5- 12
48352_jh_V1
Symbols explication
Always follow the information marked with the CAUTION or WARN-
ING symbol. The signal word WARNING indicates the potential for
serious injury, the signal word CAUTION indicates possibility of
lighter injuries.
The signal words NOTE and CAUTION indicate potential damages to
objects.
Safety notes
General
These safety instructions are intended not only to protect the prod-
uct, but also for your own and other people’s safety. Therefore please
read this section very carefully before using theproduct!
Persons, including children, with reduced physical, sensory or men-
tal capabilities, or lack of experience or knowledge, or not capable
to use safely the Video-goggle must not use the Video-goggle with-
out supervision or instruction by a responsible person.
Changes and modification on the Video-goggle are not allowed
because of safety and conformity (CE) reasons.
Makesurethatthe Video-goggle isnotexposed torough mechan-
ical stress and avoid the influence of extreme temperatures,
direct sunlight and intense vibration (e.g. invehicles).
Treat the Video-goggle at all times carefully. It can even be dam-
aged by vibration, pressure, blows or falls from a low height.
The Video-goggle must not come into contact with moisture,
(e.g. use when it rains). This can damage the Video-goggle and it
may lead to risk of short circuit, fire, injury (electric shock, burns).
Keep the Video-goggle out of the reach of children. It is not a toy.
Never leave the packing materials around! Plastic wrap or bags,
polystyrene parts, etc. can be a dangerous toy for children! Risk
of suffocation!
Repair work may only be carried out by Graupner Service Centre
or a specialized workshop.
For all questions that are not answered in this manual, please
contact our Customer Service.
!
6- 12
48352_jh_V1
Charge the Lithium battery
CAUTION
Allocation of the DC port
General notes on safety and handling Lithium (Li) batteries
• NEVER leave a Lithium battery unattended when in charge.
Charge the batteries only in rooms where a smoke detector is
installed.
• ALWAYS control the battery and the charger during the entire
charge process.
• ALWAYS charge the Lithium batteries on a non-flammable sur-
face.
• ALWAYS keep an extinguisher suitable for Lithium “Class type D”
when charging LiIo batteries.
• NEVER charge Lithium batteries at a higher rate than 1C ("C"
means the indicated capacity of the battery)
• NEVER charge the Lithium battery with a charger which does not
detect the full charge state of the battery.
• ALWAYS interrupt the charge or discharge process of a Lithium
battery if you detect smoke or if the battery slowly inflates. Let
the battery stay for at least 30 minutes in a fire-safe place. Do not
use the battery any more and disposeit as indicated.
Charge
• To charge the included 1800 mAh Lithium battery, you need a
suitable 12 V DC net adapter (not included in the package con-
tent).
• Plug the net adapter in a suitable net socket, then connect the
plug in the “12V DC IN” port of the battery.
• During the charge process the red LED lights on. When the charge
process has finished, the LED lights on blue.
1. Blue LED
2. Red LED
3. 7,4 V output
4. 12 V charge input
!
7- 12
48352_jh_V1
Control panel
1 Volume "+"
2 Scan
3 CH (channel)
4 FR (Frequency)
5 Volume "-"
6 Front camera (optional)
7 Brightness "-"
8 Select RF-2D,AV1-2D,
AV2-2D, HD-2D
9 Contrast "-"
10 Contrast "+"
11 Brightness "+"
12 Head-tracker (optional)
Bottom
1 AV input
2 AV output
3 Earphone socket
4 Shovel for pupils distance
5 Battery connection port
8- 12
48352_jh_V1
Commissioning
Technical Data
Screw the included 5,8GHz antennas on the two connectors placed
on the top of the Video-goggle.
The power is supplied by the included Lithium battery, pay attention
to charge the battery before use.
Fix the battery in the elastic band.
Connect the battery connection cable. The Video-goggle is in use
when the battery is connected.
Scan the available transmitters with the scan button.
When the battery is empty the Video-goggle emits a sound.
AV IN - AV OUT
Video in- and output
Earphone socket
Here you can connect your earphone
Format 16:9 or 4:3
WVGA 854 x 480 pixels
Contrast: 500:1
ISM 5.8 GHz, 40 channel diversity
Battery: 1800 mAh Lithium battery
Weight: ca. 198g
Power consumption 4,2W
Operational temperature: 0 °C ... +50° C
Frequency table
CH
FR
CH
CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH8
FR
FR1(A)
5865M
5845M
5825M
5805M
5785M
5765M
5745M
5725M
FR2(R)
5658M
5695M
5732M
5769M
5806M
5843M
5880M
5917M
FR3(E)
5705M
5685M
5665M
5645M
5885M
5905M
5925M
5945M
FR4(F)
5740M
5760M
5780M
5800M
5820M
5840M
5860M
5880M
FR5(B)
5733M
5752M
5771M
5790M
5809M
5828M
5847M
5866M
9- 12
48352_jh_V1
Battery warranty
The warranty on batteries is limited to 6 months
For this time we will only ensure that the battery fulfils its function,
only batteries which can not be more charged and discharged any
more can be replaced on warranty. This does not apply to batteries
in which the charge and discharge notes were not observed.
Declaration of conformity
HIVR 101 Video-goggle with 5,8 GHz receiver
Graupner/SJ declares that the product is conform to EU norms. EMV
1999/5/EC
EN 301 489-1 V1.9.2 (2011-09)
EN 301 489-17 V2.1.1 (2009-05)
EN 300 440-2 V1.4.1(2010-08)
10- 12
48352_jh_V1
Notes on environmental protection
Disposal notes
This symbol on the product, user manual or packaging indicates that
this product must not be disposed of with other household waste at
the end of its life. It must be handed over to the applicable collection
point for the recycling of electrical and electronic equipment.
The materials are recyclable as marked. By recycling, material reus-
ing or other forms of scrap usage you are making an important con-
tribution to environmental protection.
Batteries and accumulators must be removed from the device and
disposed of at an appropriate collection point. Please inquire if nec-
essary from the local authority for the appropriate disposalsite.
Care and maintenance
Warranty
Notes on care
The product does not need any maintenance, it works so as it is with-
out any special care. In your own interests protect it from dust, dirt
and moisture.
Clean the product only with a dry cloth (do not use detergent!) lightly
rub.
The Graupner, Henriettenstrassee 96, 73230 Kirchheim/Teck grants
from the date of purchase of this product for a period of 24 months.
The warranty applies only to the material or operational defects
already existing when you purchased the item. Damage due to wear,
overloading, incorrect accessories or improper handlingareexcluded
from the guarantee. The legal rights and claims are not affected by
this guarantee. Please check exactly defects before a claim or send
the product, because we have to ask you to pay shipping costs if the
item is free fromdefects.
The present construction or user manual is for informational pur-
poses only and may be changed without prior notice. The current
version can be found on the Internet at www.graupner.de on the
relevant product page. In addition, the company Graupner has no
responsibility or liability for any errors or inaccuracies that may
appear in construction or operation manuals.
No liability can be accepted for printing errors.
