Hifonics TPS-CMS65 Instruction Manual

The TPS-CMS65 clamping system is designed
for towers and support structures that utilize
ROUND tubing. Oval tubing and at structures
will not work with this clamp. The TPS-CMS65
clamp can be used with tube diameters from 1.5”
up to 2.75”. Included are separate bushing sets
for all tube sizes at 1/8” increments. Refer to the
table below to determine your conguration.
Choose a suitable
mounting location
Mounting Location
Dimensions
CAUTION
Always consider consulting a professional audio installer
before installing new speakers. Many manufacturers locate
speakers behind interior panels that require special tools to
remove. Be careful and take your time.
If you are using the speaker wire supplied with your new
speakers make sure that you run the speaker wires only
through safe areas. Do not let speaker wire make contact with
metal edges or hot engine components.
Congratulations on your choice of a Hifonics speaker.
This “Quick Start” Installation guide is meant to help
you complete a basic installation. For more detailed
information on system setting, speaker and subwoofer
conguration, and full specications by model, visit our
website at hifonics.com
It’s a good idea to conrm that you have purchased the
correct size speakers to t your application. If you have any
reservations about being able to complete the installation
yourself, we recommend contacting a professional.
Before you start
Carefully select a route for the audio signal
wires. If using existing speaker wires,
conrm that the wire is in good shape and
not shorted. Avoid routing wires through
dangerous areas. Attach the positive
illumination lead to either of the BLUE or the
RED termination point.
Route signal and
illumination wires
Wiring
Tube
Diameter
Tube
Circumference
Clamp Top
Bushing
Bottom
Bushing
1.5 4.71 A 1.50 1.50
1.625 5.10 A 1.63 1.63
1.75 5.50 A 1.75 1.75
1.875 5.89 A none 1.88
2 6.28 B 2.00 2.00
2.125 6.68 B 2.13 2.13
2.25 7.07 B 2.25 2.25
2.375 7.46 B 2.38 2.38
2.5 7.85 B 2.50 2.50
2.625 8.25 B 2.68 2.68
2.75 8.64 B none none
Black ...................................... Audio signal negative
Black w/white stripe ................ Audio signal positive

Hifonics products are designed and engineered in the USA by
www.maxxsonics.com
Quick Start
Installation Guide
WARRANTY
Maxxsonics USA Inc. warrants this product, to the original consumer purchaser, to be free from
defects in material and workmanship for a period of one (1) year from the date of purchase.
Maxxsonics USA Inc. will, at it’s discretion, repair or replace defective products during the warranty
period. Components that prove to be defective in materials and workmanship under proper installation
and use must be returned to the original authorized Maxxsonics USA Inc. retailer from where it was
purchased. A photocopy of the original receipt must accompany the product being returned. The
costs associated with removal, re-installation and freight are not the responsibility of Maxxsonics
USA Inc. This warranty is limited to defective parts and specically excludes any incidental or
consequential damages connected therewith. To view the full warranty, please visit the website.
TPS-CMS65
HF TPS-CMS65 QSG 01 - rev1
Your TPS-CMS65 speakers can be aligned to “hang
straight” on an angled tube by loosening, rotating and
re-mounting the speaker. Just behind the speaker
mounting holes is a series mounting holes that can
be used to align the speaker in the pod.
Adjust the speaker
alignment
Grill alignment
