HighPoint SRD7204DC User manual

1
SRD7204DC
PCIe 3.0 DC SRD Series NVMe AIC Drives
Quick Installation Guide

2
V1.00
System Requirements
Windows Compatibility
•Compatible with a free PCIe 4.0/3.0 x16 slot
•Windows 10, Windows Server 2016 or later, Microsoft Hyper-V
Linux Compatibility
•Compatible with a free PCIe 4.0/3.0 x16 slot
•Linux Kernel v3.10 or later
macOS Compatibility
•Compatible with a free PCIe 4.0/3.0 x16 slot
•macOS 10.13 or later
For information about motherboard compatibility, please visit the link
below:
https://highpoint-tech.com/PDF/Compatibility_List/FnL/SRD/DC/FnL_
SRD7204DC_Compatibility_List_v1.00_21_9_6.pdf

3
SRD7204DC Kit Content
•Pre-Configured SRD7204DC AIC Drives
•Quick Installation Guide
SRD7204DC Hardware
Front View
Full-Height form factor
Anodized aluminum heatsink
PCIe 3.0 x8 Host Interface

4
SRD7204DC Hardware Installation
Step 1. Carefully remove the SRD7204DC from the box.
Step 2. Power off the motherboard and locate the PCIe slot (x8 or x16).
Figure 1 - PCIe x16 slot diagram
Note: Please consult your computer/motherboard manual for more
information about the system’s PCIe configuration.
Step 3. Align the Host Interface of the SRD7204DC with the PCIe slot
and gently press it in.
Note: Please make sure the AIC Drives is securely installed before
powering on the system. A loose connection will prevent the AIC
Drives from functioning properly.

5
Resources
We recommend visiting the SRD7204DC Product Pages for the latest
documentation. (Installation guide, compatibility list, etc.)
Document Downloads:
https://www.fnlnvme.com/srd7204dc-overview
If you want to know more about similar products (BRD/SRD/CRD
Series), please visit the FnL website at:
https://www.fnlnvme.com/
FnL Monitor
FnL Monitor is an intuitive, web-based monitoring utility that is
available for all major operating system platforms. FnL Monitor’s
enables customers to check and track the health of their AIC drives in
real time.
For more information, please refer to the links below:
https://www.fnlnvme.com/srd7204dc-overview

6
Customer Support
If you encounter any problems while utilizing the SRD7204DC AIC
Drives, or have any questions about this or any other HighPoint
Technologies, Inc. product, feel free to contact our Customer Support
Department.
Web Support:
https://www.highpoint-tech.com/websupport/main.php
FnL Product websites:
https://www.fnlnvme.com/
HighPoint Technologies, Inc. websites:
https://www.highpoint-tech.com
© Copyright 2021 HighPoint Technologies, Inc. All rights reserved.
