HighPoint rDrive 6628AM User manual

1
rDrive 6628AM
Thunderbolt™ 3 8-Bay Hardware RAID Storage
Quick Installation Guide
V1.0.0

2
Applicable Products
rDrive 6628AM-32T
rDrive 6628AM-48T
rDrive 6628AM-64T
rDrive 6628AM-80T
rDrive 6628AM-96T
Kit Content
rDrive 6628AM RAID Storage Enclosure
Thunderbolt™ 3 40Gb/s Cable
UL Power Cord
Quick Installation Guide

3
Panel Layout-Front View
LED Indicators
Disk Present: Solid blue
Disk Active LED: Flashing blue
Disk Failure LED: Solid red
Disk rebuilding/identifying LED: Flashing red
Power LED: Solid blue
Panel Layout-Rear View

4
System Requirements
Mac system with a ThunderboltTM 3 (USB type-C) port
Mac system with a ThunderboltTM 2 port and ThunderboltTM 2 to
ThunderboltTM 3 adapter
Mac OS X 10.10 or later
Enclosure Setup
1. Connect the rDrive 6628AM to the host system with the
Thunderbolt™ cable
2. Connect the rDrive 6628AM to power and turn on the power
switch

5
Software Downloads
1. Download files from http://www.highpoint-
tech.com/USA_new/series-rd6628am-overview.htm
2. Run HighPointRDWebGUI.pkg and follow the onscreen
instructions
3. Your RAID array should be mounted as rDrive-01 on the desktop

6
Customer Support
If you encounter any problems with the rDrive 6628AM or have any
questions regarding this or any other HighPoint Technologies, Inc.
product, feel free to contact our Customer Support Department
Web Support:
http://www.highpoint-tech.com/websupport
HighPoint Technologies, Inc. Website:
http://www.highpoint-tech.com
© Copyright 2018 HighPoint Technologies, Inc. All rights reserved.
