Chapter1. Introduction
1.1 Key Features
DS-D5019 Series:Support 1366×768 HD display;
DS-D5022/5024 Series:Supports 1920×1080 FHD dispiay;
User-friendly operation menu;
Three image modes to adapt different environment;
1 channel HDMI 1.3 input interface;
Support software spread-spectrum technology to reduce EMI radiation;
Standby Power Consumption is lower than 0.5W;
DS-D5019:Viewing Angle:Horizontal 90°, Vertical 65º ;
DS-D5022/24:Viewing Angle:Horizontal 170°, Vertical 160º ;
2Wx2 Speakers efficient output;
1.2 Power Supply Connection
Insert the 3-pin power device into well-grounded socket and turn the rocker switch on.
Figure 1.1 Power Input
Power in
p
ut s
p
ecification from 100VAC to 240VAC or
p
rovide automatic switchin
g
between
high line and low line input ranges.
Turn off the main
p
ower switch of the dis
p
la
y
unit, and
p
ull the
p
lu
g
from the
p
ower outlet if
the display unit will not be used for a long time.
Never connect the device to a DC power.

2
Chapter2. Device Interfaces
Chapter3. Panel Keys
Keys on lower right corner of the display unit panel are shown in the Figure 3.1 Keys on the Display
Unit.
Figure 3.1 Keys on the Display Unit
The functions of the keys on lower right corner of the display unit vary according to different situations.
Figure 2.1 Rear Panel of Device
POWER IN Power Input
HDMI IN
VGA IN VGA Analog Signal Input
AUDIO IN Audio Inpu
1
Power Input
VGA Analog Signal Input
23
HDMI Digital Signal Input
VGA Analog Signal Input
Power Input
Interfaces
Interfaces
Interfaces
1
2
3
Interfaces Interfaces Interfaces Interfaces
HDMI Digital Signal Input
t

3
Chapter4. Basic Operation
4.1 Input Source Selection(optional)
Turn on the display unit when the power supply is on
and input source is confirmed.
Press ◄ key of the remote controller to enter the menu
as shown on the right. DS-D5019/22 /24inch LCD
display unit includes 2 input sources as HDMI and
VGA signal. Press direction keys to select the input
source and press MENU to accomplish the input
source selection.
Figure 4.1 Input Source
4.2 Input Audio Volume Adjustment(optional)
Turn on the display unit when the power supply is on
and input source is confirmed.
Press ►key of the remote controller to enter the menu
as shown on the right.press ◄or ►to adjust the value
of volume. press MENU to accomplish the volume
adjustment.
Figure 4.2 Audio Volume
4.3 Auto Adjust
Turn on the display unit when the power supply is on
and input source is confirmed.
Press AUTO key of the remote controller to enter the
menu as shown on the right(In VGA Signal).
Figure 4.3 Input Source
Press key of the remote controller to enter the menu
as shown on the right. press ◄or ►to adjust the value
of contrast.
Press MENU to accomplish the contrast
adjustment.
Figure 4.1 Input Source
◄
4.1 Contrast
4.2
Figure 4.2 Brightness
Brightness ►
Press ► key of the remote controller to enter the menu
as shown on the right.press ◄ or ► to adjust the value of
Brightness. press MENU to accomplish the Brightness
adjustment.

4.4 Main Menu
4.4.1 Image Settings
Purpose:
You can adjust the picture parameters by switching image modes and adjust the values of contrast,
brightness, color temperature,auto adjust,color adjust.
Steps:
1. Press MENU key to enter the main menu interface as shown below.
2. Press MENU key to enter the setting you want.
3. Press ◄or ►to adjust the value. It applies for adjusting contrast, brightness, color temp and other
parameters.
Contrast, Brightness: Press ◄or ►to set the contrast, the range varies from 0-100.
Color temperature :Press ◄or ►to set the color temperature you need.
Gray indicates that under current mode or current inputsource condition it is not adjustable; Yellow
indicates that it is adjustable.
4.Press AUTO key to return to the main menu after accomplishing the adjustment.
Figure 4.4.1 Image Settings
4

4.4.2 Image Adjustment
Purpose:
When the input source is selected VGA, you can adjust the VGA parameters. It is for adjusting
VGA H position, V Position, clock and phase.
Steps:
1. Press Menukey to enter the main menu interface.
2. Press ◄key to enter the VGA parameter setting interface. (You can select Auto Adjust and press ◄
or ►to adjust the VGA parameters automatically or adjust it manually)
3. SelectH Position and press ◄or ►to adjust the H Position
4. SelectV Position and press ◄or ►to adjust the V position.
5. SelectClock and press ◄or ►to adjust the clock.
6. SelectPhase and press ◄or ►to adjust the phase.
The range of the adjustment varies between 0-100.
7. Press MENU key to return to the main menu after accomplishing the adjustment.
Figure 4.4.2 Image Adjustment
5

4.4.3 OSD Setting
Purpose:
You can set the language, blending and OSD duration of the menu.
Steps:
1. Press MENU key to enter the main menu interface.
2. Press ◄key twice and press MENU key to enter the【Language】interface, press ◄or ►to switch
the language you want.
3. SelectOSD H.Pos/OSD V.Pos to adjust the position of OSD with◄or ►.
4. SelectOSD Timer to adjust the OSD duration with◄or ►:5Sec~60Sec.
5. SelectTransparencyto adjust the OSD transparency value with◄or ►.
6. Press AUTO key to return to the main menu after accomplishing the adjustment.
Figure 4.4.3 OSD Setting
6

4.4.4 Other Settings
Purpose:
You can set Mode,Audio Volume,Signal Source,Aspect Ratio,DCR.
Steps:
1. Press MENU key to enter the main menu interface.
2. Press triple◄key and press MENU key to enter the Mode interface, press ◄or ►to switch the mode
between PC/GAME/MOVIE.
3. Press ◄or ►to adjust the Audio Volume from0~100(optional).
4. Press ◄or ►to change the Signal Source between VGA and HDMI(optional).
5. Press ◄or ►to switch the Aspect Ratio between 16:9/AUTO/4:3.
6. Press ◄or ►to switch the DCR On/Off.
7. Press MENU key to return to the main menu after accomplishing the adjustment.
Figure4.4.4 Other Settings
7

4.4.5 Reset Setting
Purpose:
You can reset settings to the factory defaults.
Steps:
1.Press MENU key to enter the main menu interface.
2.Press ◄key 4 times and press MENU key to reset settings to the factory defaults.
Figure 4.4.5 Reset Setting
8

9
Appendix: Specifications
Device Model DS-D5019
Display Type TFT-LED Backlight
Screen Size 18.5"
Dot Pitch 0.300×0.300 mm
Max Resolution 1366×768
Best Operation Resolution 1366×768@60Hz
Brightness 200cd/m²
Contrast 600:1
Color 16.7M
Viewable Area 409.8×230.4mm
Viewing Angle Horizontal 90°, Vertical 65º
Interfaces
VGA Input Port 1
AUDIO Input Port
AC Input Port 1
Power Supply AC 100-240V; 50/60Hz
Consumption ≤25W
Standby Power
Consumption ≤0.5W
Operation Temperature 0°C~40°C (32°F~104°F)
Operation Humidity 10%~85%
Storage Temperature: -20°C~55°C (-4°F~131°F)
Storage Humidity: 5%~95%
Bezel Material Plastic
Bezel Color Black
Wall-mounting Dot Site 75×75mm
Wall-mounting Thread M4
Device Dimensions 446×335×148mm
Package Dimensions 490×333×101mm
G.W. 3.5Kg
N.W. 2.8Kg
Standard Package
Display Unit 1
VGA Cord 1
User Manual 1
Power Cord 1
Audio Cord 1
(optional)
Series
1
1
1
1
HDMI Input Port
1
Interfaces 1 Interfaces 2 Interfaces 3
1
NA
NA NA
1

10
Structure Figure
18.10
44.60
1.95
411.20
231.80
445.58
274.99
84.63
200.13
147.62
41.97
17.89
75.00
75.00
70.50
40.50
180.29
130.6

11
Appendix: Specifications
Device Model DS-D5022 Series
Display Type TFT-LED Backlight
Screen Size 21.5"
Dot Pitch 0.248×0.248 mm
Max Resolution 1920×1080
Best Operation Resolution 1920×1080@60Hz
Brightness 250cd/m²
Contrast 1000:1
Color 16.7M
Viewable Area 477×268mm
Viewing Angle Horizontal 170°, Vertical 160º
Interfaces2
VGA Input Port 1
HDMI Input Port 1
AC Input Port 1
Power Supply AC 100-240V; 50/60Hz
Consumption ≤30W
Standby Power
Consumption ≤0.5W
Operation Temperature 0°C~40°C (32°F~104°F)
Operation Humidity 10%~85%
Storage Temperature: -20°C~55°C (-4°F~131°F)
Storage Humidity: 5%~95%
Bezel Material Plastic
Bezel Color Black
Wall-mounting Dot Site 100×100mm
Wall-mounting Thread M4
Device Dimensions 511×377×170mm
Package Dimensions 561×426×103mm
G.W. 4.5Kg
N.W. 3.3Kg
Standard Package
Display Unit 1
VGA Cord 1
User Manual 1
Power Cord 1
Interfaces 2Interfaces 3
AUDIO Input Port
1
1
1
NA 1

12
Structure Figure
511mm

13
Appendix: Specifications
Device Model DS-D5024
Display Type TFT-LED Backlight
Screen Size 23.6"
Dot Pitch 0.271×0.271mm
Max Resolution 1920×1080
Best Operation Resolution 1920×1080@60Hz
Brightness 250cd/m²
Contrast 1000:1
Color 16.7M
Viewable Area 521×293mm
Viewing Angle Horizontal 170°, Vertical 160º
Interfaces
VGA Input Port 1
AUDIO Input Port
AC Input Port
Power Supply AC 100-240V; 50/60Hz
Consumption ≤30W
Standby Power
Consumption ≤0.5W
Operation Temperature 0°C~40°C (32°F~104°F)
Operation Humidity 10%~85%
Storage Temperature: -20°C~55°C (-4°F~131°F)
Storage Humidity: 5%~95%
Bezel Material Plastic
Bezel Color Black
Wall-mounting Dot Site 100×100mm
Wall-mounting Thread M4
Device Dimensions 560×399×220mm
Package Dimensions 614×465×109mm
G.W. 5.4Kg
N.W. 4.5Kg
Standard Package
Display Unit 1
VGA Cord 1
User Manual 1
Power Cord 1
Audio Cord 1
(optional)
Series
HDMI Input Port
1
1
NA
Interfaces 2Interfaces 3
1
1
1
1

14
Structure Figure

13
