HIK VISION DS-K1A802A Series User manual

Appearance
1
Installation
2
©2020 Hangzhou Hikvision Digital Technology Co., Ltd.
It includes instrucons on how to use the Product. The soware embodied in the Product is
governed by the user license agreement covering that Product.
About this Manual
This Manual is subject to domesc and internaonal copyright protecon. Hangzhou Hikvision
Digital Technology Co., Ltd. (“Hikvision”) reserves all rights to this manual. This manual cannot be
reproduced, changed, translated, or distributed, parally or wholly, by any means, without the
prior wrien permission of Hikvision.
Trademarks
and other Hikvision marks are the property of Hikvision and are registered
trademarks or the subject of applicaons for the same by Hikvision and/or its affiliates. Other
trademarks menoned in this manual are the properes of their respecve owners. No right of
license is given to use such trademarks without express permission.
Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH ITS
HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND ERRORS,
AND HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT
LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE,
AND NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL HIKVISION, ITS DIRECTORS,
OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL,
INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN
CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY
AT YOUR OWN RISKS. HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL
OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER
ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL
PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR
JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS
THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS
USED WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS.
Data Protecon
During the use of device, personal data will be collected, stored and processed. To protect data,
the development of Hikvision devices incorporates privacy by design principles. For example, for
device with facial recognion features, biometrics data is stored in your device with encrypon
method; for fingerprint device, only fingerprint template will be saved, which is impossible to
reconstruct a fingerprint image.
As data controller, you are advised to collect, store, process and transfer data in accordance with
the applicable data protecon laws and regulaons, including without limitaon, conducng
security controls to safeguard personal data, such as, implemenng reasonable administrave and
physical security controls, conduct periodic reviews and assessments of the effecveness of your
security controls.
DS-K1A802A Series
Fingerprint Time Aendance Terminal
Quick Start Guide
UD15388B-B
Screen
Keypad Card Presenng Area USB Interface Debugging
Port
Power
Interface Network Interface
Fingerprint
Recognion Area
Keypad Descripons
ESCOK
12
ABC
3
DEF
4
GHI
6
MNO
7
PQRS
8
TUV
9
WXYZ
5
JKL
Exing Key
Direcon
Keys
Numeric Keys/
Leer Keys
OK Key
Eding Key
Deleng
Key
0
OK Key: Press the key and confirm operaons. Hold the key
for 2 s to enter the login interface.
Deleting Key: Press the key to delete the entered leer or
number.
If the device supports connecng lithium baery, long press
the key to power off the device.
Numeric Keys/Letter Keys: Press the key to enter numbers
or leers.
Key 0 can also represent a space key except you are using the
number input method.
Exiting Key: Press the key to exit the menu.
Direction Keys: Press , , and to move the cursor
on the screen. Or on the text entering page, press up or down
buon to change the input method.
Editing Key: Press the key to enter the eding status.
You can shi among numbers/lowercases, numbers/uppercases
and symbols.
Notes:
1. The pictures here are for reference only. Some models do not support
card presenng funcon. For details, refer to the actual products.
2. If the aendance mode is Manual, the OK key, the direcon
key, and the exing key can be the shortcut key of the aendance status.
140 mm
155 mm 28 mm
Front View Side View Back View Keypad
Method 1:
Wall Mounting
without
Mounting Plate
Method 2:
Wall Mounting
with
Mounting Plate
2. Insert the screw sockets of the setscrews in the drilled
holes.
3. Fix and fasten the screws in the sockets on the wall or
other places. (You should reserve 5.2 mm to 5.5 mm for
the hanging the device when fix and fasten the screws.)
4. Align the 4 holes on the device plate with
the fixed screws and hang the device on the
wall.
1. Drill 4 holes on the wall or other places
according to the mounng template. (Supplied)
Note: The length and width will be 2 to 3 mm
smaller than the actual device’s.
152 mm
127 mm
Steps:
1. Install the gang box on the wall.
Note:
• Make sure the gang box screw holes match the mounng plate’s.
• The gang box here is for reference only. Select an appropriate gang box to
install.
• The gang box is not supplied.
2. Fix the mounng plate on the gang box with 2 supplied screws
(SC-PM4X10-IMP).
3. Route the device cable through the cable hole of the mounng plate and
insert the cables in the gang box.
4. Align the terminal with the mounng plate, and secure the terminal on
the mounng plate with two supplied socket hexagon screws
(SC-KM3X10_3-SUS).
44
Device Mounting Plate Gang Box Wall
1
2
3
120 mm
130.6 mm
25.15 mm
66.6 mm
53.2 mm
36.5 mm
83.65 mm
68.1 mm

Basic Operation
3
Activation
Parameters Configuration
Activating via SADP
Activating via Client Software
1
2
1. Download SADP Soware
Get the SADP soware from the supplied disk.Install and run
the soware.
2. Acvate Device
Check the inacve device from the device list. Create a
password in the right side of the interface and confirm the
password.
3. Edit Device IP Address
Check the device and manually edit the device IP address, Port
No., Subnet Mask, Gateway, etc.
1. Get the client soware from the official website. Install and run the client soware.
2. Enter the Device Management page.
3. Click Device tab on the top of the right panel.
4. Click Online Device to show the online device area at the boom of the page.
The searched online devices are displayed in the list.
5. Check the device status (shown on Security Level column) and select an inacve device.
6. Click Acvate to open the Acvaon dialog.
7. Create a password in the password field, and confirm the password.
8. Click OK to acvate the device.
9. Select an acvated device in Online Device area, click on the Operaon column to open the Modify
Network Parameter window. Change the device IP address to the same subnet with your computer if you need
to add the device to the client.
Add User: Edit the ID No. and the user name. Press the OK key to confirm. Enter the card No., register the fingerprint, set the password, select the department, select the user role and select the authencaon mode. Save the parameters to confirm adding. The employee ID should be unique, should be
between 1 and 99999999, and should not start with 0.
Edit Department: Select the department in the department list and select “Edit”. Edit the department name, the shi type and the shi name. Save the parameters to confirm eding.
Shift Management:
Normal Shi：Enter the Normal (Normal Shi) interface under the Shi Management menu. Configure the shi rule and the normal shi. Save the parameters to confirm eding.
Man-Hour Shi: Enter the Man-Hour (Man-Hour Shi) interface under the Shi Management menu. Configure the man-hour parameters and save the parameters.
Add Holiday: Enter the New （Add New Holiday） interface under the Holiday menu. Enter the holiday No., the holiday name, the holiday start date and the holiday end date. Save the parameters to confirm configuraon.
Shift Schedule Management:
Schedule Shi by Department: Select a department to configure in the By Dept. (Schedule by Department) interface. Configure the shi, the start date, the end date and the holiday. Save the parameters to confirm configuraon.
Schedule Shi by Individual: Select New Individual Shi in the By Indiv. (Schedule by Individual) interface. Select a person to schedule in the New Individual Shi interface. Configure the shi, the schedule start date and the end date. Save the parameters to confirm eding.
The device will automacally check the USB flash drive memory. If there is no enough space for exporng, a prompt will be displayed. You are able to configure the record over threshold prompt and record delete funcon in the System interface.
Record over Threshold Pop up Prompt (%): If the aendance record memory reaches the configured value, the system will pop up a prompt to remind you. If configure the threshold to 99%, the system will pop up a prompt to remind you to delete the aendance data when the capacity reaches
the threshold. The available value: 1 to 99.
Record Delete: When the funcon is enabled, the terminal will delete the first 3000 aendance records when the memory is full, in order to save the new aendance records. By default, the funcon is enabled. See Secon 5.2 Aendance Record Delete Rule in the User Manual of Fingerprint Time
Aendance Terminal.
Activating via Device
Power on and wire the network cable aer installaon.
You should acvate the device before the first login.
Aer powering on, the interface will be displayed as follows.
You can create the device password and confirm the
password to acvate.
The default values of the terminal are as follows:
• The default IP address: 192.0.0.64
• The default port No.: 8000
• The default user name: admin
Configure the shi schedule by department or by individual.
Schedule Shift by Department Flow: Add User (Select department when adding new user.) - Department Management - Shi Management - Add Holiday - Shi Schedule Management (Schedule Shi by Department)
Schedule Shift by Individual Flow: Add User - Shi Management - Add Holiday - Shi Schedule Management (Schedule Shi by Individual)
Attendance Report: Plug the USB flash drive in the device. In the Report interface, select a table type to export. Press the OK key to export the aendance report to the USB flash drive. The available USB flash drive format is FAT32.
View License: You can view the device License via the website: hp://opensource.hikvision.com/Home/List?id=46
[Number]
OK Next Input Method
Device Acvaon
Acvaon Password (8 to 16 Characters)
Attendance Status: Set aendance status as check in, check out, break out, break in, overme in, or overme out.
STRONG PASSWORD RECOMMENDED
We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case
leers, lower case leers, numbers, and special characters) in order to increase the security of your product. And we recommend you
reset your password regularly, especially in the high security system, reseng the password monthly or weekly can beer protect your
Regulatory Information
FCC Information
Please take aenon that changes or modificaon not expressly approved by
the party responsible for compliance could void the user’s authority to operate
the equipment.
FCC compliance: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protecon against harmful
interference in a residenal installaon. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance
with the instrucons, may cause harmful interference to radio communicaons.
However, there is no guarantee that interference will not occur in a parcular
installaon. If this equipment does cause harmful interference to radio or
television recepon, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
This product and - if applicable - the supplied accessories too are marked
with "CE" and comply therefore with the applicable harmonized European
standards listed under the RE Direcve 2014/53/EU, the EMC Direcve
2014/30/EU, the RoHS Direcve 2011/65/EU.
2012/19/EU (WEEE direcve): Products marked with this symbol cannot
be disposed of as unsorted municipal waste in the European Union. For
proper recycling, return this product to your local supplier upon the
purchase of equivalent new equipment, or dispose of it at designated
collecon points. For more informaon see: www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that
cannot be disposed of as unsorted municipal waste in the
European Union. See the product documentaon for specific
baery informaon. The baery is marked with this symbol, which
may include leering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the baery to your
supplier or to a designated collecon point. For more informaon
see: www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
This device complies with Industry Canada licence-exempt RSS standard(s). Operaon is subject to the following two
condions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radioexempts de licence. L'exploita-
on est autorisée aux deux condions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est suscepble d'en
compromere le fonconnement.
Under Industry Canada regulaons, this radio transmier may only operate using an antenna of a type and maximum (or
lesser) gain approved for the transmier by Industry Canada. To reduce potenal radio interference to other users, the
antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that
necessary for successful communicaon.
Conformément à la réglementaon d'Industrie Canada, le présent émeeur radio peut
fonconner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émeeur par Industrie Canada.
Dans le but de réduire les risques de brouillage radioélectrique à l'intenon des autres ulisateurs, il faut choisir le type
FCC Conditions
This device complies with part 15 of the FCC Rules. Operaon is subject to
the following two condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference
that may cause undesired operaon.
EU Conformity Statement
Scan the QR code to get the user
manual for detailed informaon.
Note that mobile data charges
may apply if Wi-Fi is unavailable.
Use only power supplies listed in the user instrucons:
Model Manufacturer Standard
DSA-12PFT-12FUK 120100
DSA-12PFT-12FAU 120100
DSA-12PFT-12FIN 120100
DSA-12PFT-12FUS 120100
DSA-12PFT-12 FBZ 120100
Dee Van Enterprise Co., Ltd. BS
Dee Van Enterprise Co., Ltd.
Dee Van Enterprise Co., Ltd.
Dee Van Enterprise Co., Ltd.
Dee Van Enterprise Co., Ltd.
AS
NBR
IEC
IS
