DS-2CC11A1P(N)
Key Features
Compact design
SONY CCD
Digital Noise Reduction (DNR)
Digital Wide Dynamic Range
Day/Night with auto switch
Min. illumination: 0.001 Lux @ F1.2
OSD menu
Eclipse
Auto iris with DC drive
Auto white balance, auto gain control, electronic shutter control and backlight compensation
Internal Synchronization
Convenient back focus adjustment
Specification
Model
Parameter
DS-2CC11A1P(N)
700 TVL CCD Box Camera
Camera
Image Sensor
1/3” SONY CCD
Signal System
PAL/NTSC
Effective Pixels
PAL: 976 (H) × 582 (V)
NTSC: 976 (H) × 494 (V)
Min. Illumination
0.001 Lux @ (F1.2, AGC ON)
Shutter speed
PAL: 1/50 s to 1/10,000 s
NTSC: 1/60 s to 1/10,000 s
Lens Mount
C/CS mount
alarm shop

Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
4
Auto Iris
DC drive
Day & Night
Electronic
Horizontal Resolution
700TVL
Synchronization
Internal synchronization
Video Output
1Vp-p composite output (75 Ω/BNC)
S/N Ratio
More than 62 dB
Menu
Camera ID
On/Off (52 letters, position adjustable)
D/N Mode
Auto /Day /Night
White Balance
ATW/PUSH/USER1/USER2/ANTI CR/MANUAL/PUSH LOCK
Private Mask
On/Off, maximum 8 zones
Motion Detection
On/Off
Back Light
BLC/HLC/Off
Language
Chinese/ English/ Japanese/ German/ French/ Russian/
Portuguese/ Spanish
Function
ATR, HLC, DNR, Sharpness, Brightness, Contrast, Hue,
Gain, Mirror, Defect Pixel Correction
General
Working
Temperature/Humidity
-10 °C - 60 °C (14 °F - 140 °F)
Humidity 90% or less (non-condensing)
Power Supply
12 V DC ± 10%
Power Consumption
Max. 2 W
Dimensions
68.8 x 56 x 111 mm (2.71” × 2.20” × 4.37”)
Weight
400 g (0.88 lbs)
Order Models
DS-2CC11A1P
DS-2CC11A1N
alarm shop

Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
5
Dimensions
Unit: mm
Accessories
Indoor wall mount Indoor/outdoor wall mount
DS-1212ZJ DS-1213ZJ
