1Introduction
1.1 Product Features
This series of camera adopts high performance sensor and
advanced circuit board design technology. It features high
resolution, low distortion, and low noise, etc. It is suitable for the
surveillance system and image process system.
The main features of DS-2CC5181P (N)-VPIR (H), DS-2CC5191P
(N)-VPIR (H), and DS-2CC51A1P (N)-VPIR (H) are as follows:
High performance SONY CCD and high resolution bring
high-quality image
Low illumination, 0.001 Lux @ (F1.2, AGC ON), 0 Lux with IR
Support ICR filter auto switch
OSD menu, parameters are configurable.
Support auto white balance with high color rendition
High Signal No ise Ratio (SNR), which brings clear and
high-quality image
SMART IR
Auto iris
Up to 8 configurable privacy masks to ensure your privacy
Advanced 3-axis design meets different installation
requirements

High-definition Vandal-proof Dome Camera·User Manual
7
7
Impact Protection: IEC60068-2-75 test, Eh, 50J; EN50102, up
to IK10
Ingress protection: IP66
The main features of DS-2CC5195P (N)-VPIR (H), DS-2CC5197P
(N)-VPIR (H), DS-2CC51A5P (N)-VPIR (H), and DS-2CC51A7P
(N)-VPIR (H) are as follows:
High performance SONY CCD and high resolution bring
high-quality image
Low illumination, 0.001 Lux @ (F1.2, AGC ON), 0.0001 Lux @
(F1.2, AGC ON, sensitivity × 512), 0 Lux with IR
Support ICR filter auto switch
OSD menu, parameters are configurable
Wide Dynamic Range (supported by DS-2CC5197P (N)-VPIR(H)
and DS-2CC51A7P(N)-VPIR(H)) for backlighting surveillance
Back Light Compensation (BLC) with programmable BLC area
Support auto white balance with high color rendition
High Signal No ise Ratio (SNR) brings clear and high-quality
SMART IR
Electronic image stabilization (EIS) function to get steady and
clear image
Eclipse
Auto iris
Privacy mask with 8 optional co lors and 12 configurable areas

High-definition Vandal-proof Dome Camera·User Manual
8
8
Advanced 3-axis design meets different installation
requirements
Impact Protection: IEC60068-2-75 test, Eh, 50J; EN50102, up
to IK10
Ingress protection: IP66
1.2 Overview
2
13
4
6
5
Figure 1-1 Overview
Table 1-1 Description
No.
Description
1
Black Liner
2
Lower Dome
3
Lens Adjustable Screw

High-definition Vandal-proof Dome Camera·User Manual
9
9
No.
Description
4
Tilting Screw
5
Power Cable
6
Video Cable

High-definition Vandal-proof Dome Camera·User Manual
10
10
2Installation
Before you start:
Please make sure that the device in the package is in good
condition and all the assembly parts are included.
Make sure that all the related equipment is power-off during the
installation.
Check the specification of the products for the installation
environment.
Check whether the power supply is matched with your AC outlet
to avoid damage.
If the product does not function properly, please contact your
dealer or the nearest service center. Do not disassemble the
camera for repair or maintenance by yourself.
Please make sure the wall is strong enough to withstand three
times the weight of the camera and the mounting.
2.1 Ceiling Mounting
Steps:
1. Attach the drill template (supplied) to the place where you
want to fix the camera.
2. Drill the screw hole and the cable hole in the ceiling according
to the drill template.

High-definition Vandal-proof Dome Camera·User Manual
11
11
Figure 2-1 Drill Template
3. Loosen the three screws on the edge of the lower dome with
the supplied screwdriver.
4. Remove the lower dome and the black liner.
Figure 2-2 Remove the Lower Dome
Screws
Screws
Wall
Drill
Template

High-definition Vandal-proof Dome Camera·User Manual
12
12
5. Loosen the three set screws as shown in Figure 2-3 with the
supplied screwdriver.
6. Remove the camera from the back box.
Figure 2-3 Remove the Camera
7. Attach the back box to the ceiling by aligning the holes of the
back box with the holes on the drill template.
8. Secure the back box with the supplied screws.
Set Screws
Back Box

High-definition Vandal-proof Dome Camera·User Manual
13
13
Figure 2-4 Secure the Back box
9. Route the cables through the cable hole.
10. Align the camera with the back box.
11. Tighten the set screws to secure the camera with the back box.
12. Connect the video output connector to the monitor. Connect
the power connector to the power supply.
13. Adjust the image and focus. Please refer to the section 2.5 for
more details.
14. Fit the black liner back to the camera.
15. Tighten the screws to secure the lower dome with the back
box.
Cable Ho le

High-definition Vandal-proof Dome Camera·User Manual
14
14
Figure 2-5 Secure Lower Dome
2.2 In-ceiling Mounting
Steps:
1. Attach the drill template (supplied) to the place where you
want to fix the camera.
2. Drill the screws hole and the cable hole in the ceiling according
to the drill template.

High-definition Vandal-proof Dome Camera·User Manual
15
15
Figure 2-6 The Drill Template
3. Fold the toggle to get the toggle bolt go through the screw
holes of the in-ceiling mount.
4. Keep screwing the bolt till the toggle unfolds and props on the
ceiling.
In-ceiling
Mount
Bolt
Toggle
Figure 2-7 The In-ceiling Mount
Ceiling
Drill Template

High-definition Vandal-proof Dome Camera·User Manual
16
16
5. Route the cables through the hole in the center of the in-ceiling
mount.
6. Align the camera with the in-ceiling mount.
7. Tighten the set screws to secure the camera with the in-ceiling
mount.
8. Connect the video output connector to the monitor. Connect
the power connector to the power supply.
9. Adjust the image and focus. Please refer to the section 2.5 for
more detailed information.
Figure 2-8 Secure the Camera
10. Fit the black liner back to the camera.
11. Align the lower dome with the in-ceiling mount.
12. Tighten the screws to secure the lower dome with the in-ceiling
mount.

High-definition Vandal-proof Dome Camera·User Manual
17
17
Figure 2-9 Secure the Lower Dome
2.3 In-ceiling Mounting with gang box
Steps:
1. Secure the In-ceiling mount (supplied) to the gang box with
two screws.
Ceiling
In-ceiling
Mount
Gang
Box
Figure 2-10 In-ceiling Mount

High-definition Vandal-proof Dome Camera·User Manual
18
18
2. Route the cables through the hole in the center of the in-ceiling
mount.
3. Align the camera with the gang box.
4. Tighten the screws to secure the camera with the gang box.
5. Connect the video output connector to the monitor. Connect
the power connector to the power supply.
6. Adjust the image and focus. Please refer to the section 2.5 for
more details.
Ceiling
Gang
Box
Camera
Figure 2-11 Secure the Camera
7. Fit the black liner back to the camera.
8. Align the lower dome with the in-ceiling mount.
9. Tighten the screws to secure the lower dome with the in-ceiling
mount.
Ceiling

High-definition Vandal-proof Dome Camera·User Manual
19
19
Figure 2-12 Secure the Lower Dome
2.4 Indoor Wall Mounting
Steps:
1. Disassemble the lower dome, black liner and the camera as
you do in chapter 2.1.
2. Align the number 2 holes of the back box with the number 1
holes of the wall mount.
3. Secure the back box to the wall mount with four screws.
