HIK VISION DS-2CD852MF-E Series User manual

Network Camera
Quick Guide
V3.0.0
Hikvision Digital Technology Co., Ltd.
http://www.hikvision.com

Quick Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
1
Thank you for purchasing our product. If there are any questions, or requests, please do not
hesitate to contact the dealer. This manual applies to
Box camera Ⅰ: DS-2CD852MF-E, DS-2CD862MF-E
Box camera Ⅱ: DS-2CD886BF-E, DS-2CD886MF-E, DS-2CD877BF, DS-2CD876BF, DS-2CD876MF
Box camera Ⅲ: DS-2CD883F-E(W), DS-2CD854F-E(W), DS-2CD853F-E(W), DS-2CD864FWD-E(W),
DS-2CD863PF(NF)-E(W), DS-2CD893PF(NF)-E (W), DS-2CD893PFWD(NFWD)-E(W),
DS-2CD833F-E(W)
Dome camera Ⅰ: DS-2CD752MF-E
Dome camera Ⅱ:DS-2CD752MF-FB(H),DS-2CD752MF-IFB(H), DS-2CD762MF-FB(H),
DS-2CD762MF-IFB(H)
Dome camera Ⅲ: DS-2CD783F-E(I), DS-2CD754F-E(I), DS-2CD764FWD-E(I), DS-2CD754FWD-E(I),
DS-2CD753F-E(I), DS-2CD763PF(NF)-E(I), DS-2CD793PF(NF)-E(I), DS-2CD793PFWD(NFWD)-E(I),
DS-2CD733F-E(I)
Bullet Camera: DS-2CD8264F-E(I), DS-2CD8264F-ES(I),DS-2CD8254F-E(I), DS-2CD8254F-ES(I),
DS-2CD8253F-E(I), DS-2CD8253F-ES(I)，DS-2CD8233F-E(I), DS-2CD8233F-ES(I)
Cube Camera: DS-2CD8153F-E(W)(I), DS-2CD8133F-E(W)(I)
Mini Dome Camera: DS-2CD7164-E,DS-2CD7153-E, DS-2CD7133-E
This manual may contain several technical incorrect places or printing errors, and the content is
subject to change without notice. The updates will be added to the new version of this manual. We
will readily improve or update the products or procedures described in the manual.
DISCLAIMER STATEMENT
“Underwriters Laboratories Inc. (“UL”) has not tested the performance or reliability of the security
or signaling aspects of this product. UL has only tested for fire, shock or casualty hazards as
outlined in UL’s Standard(s) for Safety, UL60950-1. UL Certification does not cover the
performance or reliability of the security or signaling aspects of this product. UL MAKES NO
REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE
PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS
PRODUCT.”

Quick Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
2
Table of Contents
Chapter 1 Interface Description.............................................................................................................1
1.1 Box Camera Interface Description......................................................................................................... 1
1.1.1 Box Camera Ⅰ................................................................................................................1
1.1.2 Box Camera Ⅱ................................................................................................................2
1.1.3 Box Camera Ⅲ................................................................................................................3
1.2 Dome Camera Interface Description .................................................................................................... 4
1.2.1 Dome Camera Ⅰ............................................................................................................4
1.2.2 Dome Camera Ⅱ............................................................................................................5
1.2.3 Dome Camera Ⅲ............................................................................................................6
1.3 Bullet Camera Interface Description..................................................................................................... 6
1.4 Cube Camera Interface Description ...................................................................................................... 7
1.5 Mini Dome Camera Interface Description........................................................................................... 8
Chapter 2 Search and Modify IP ............................................................................................................9
Chapter 3 Preview via WEB browser....................................................................................................12

Quick Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
1
Chapter 1 Interface Description
1.1 Box Camera Interface Description
1.1.1 Box Camera Ⅰ
Figure 1.1.1
Serial NO.
Description
1
CS Lens mount
2
Back Focus Ring
3
Auto iris interface
4
10M/100M self-adaptive Ethernet interface
5
AUDIO IN: Audio input interface
AUDIO OUT: Audio output interface
6
SD: SD card slot
7
VIDEO OUT: Video output interface
8
Power supply
9
PWR: Power LED indicator
10
D+, D-: RS-485 interface
11
Ground
12
1A, 1B: Alarm output interface
13
IN, G: Alarm input interface

Quick Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
2
1.1.2 Box Camera Ⅱ
Figure 1.1.2
Serial NO.
Description
1
CS Lens mount
2
Auto iris interface
3
Bracket mounting holes
4
F1+ F1-, F2+ F2- ,F3+ F3-: Alarm output interface
5
T1,T2,T3, T4,GND: Alarm input interface
6
D+, D-: RS-485 interface
7
10M/100M self-adaptive Ethernet interface
8
VIDEO OUT: Video output interface
9
RESET: Reset the camera
10
TXD, RXD, GND: RS-232 interface
11
Power supply
12
PWR: Power LED indicator
13
SD: SD card slot
14
AUDIO IN: Audio input interface
15
AUDIO OUT: Audio output interface
16
Ground

Quick Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
3
1.1.3 Box Camera Ⅲ
Figure 1.1.3
Serial NO.
Description
1
Lens mount
2
Back Focus Ring
3
SD: SD card slot
4
Auto iris interface
5
10M/100M self-adaptive Ethernet interface
6
VIDEO OUT: Video output interface
7
AUDIO OUT: Audio output interface
8
PWR: Power LED indicator
9
Power supply
10
MIC IN: Audio input interface
11
D+, D-: RS-485 interface
12
IN, G: Alarm input interface
13
1A, 1B: Alarm output interface
14
Ground
15
RESET: Reset the camera

Quick Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
4
1.2 Dome Camera Interface Description
1.2.1 Dome Camera Ⅰ
Figure 1.2.1
Serial NO.
Description
1
Video output interface
2
PWR: Power LED indicator
3
Dial switch
4
10M/100M self-adaptive Ethernet interface
5
D+, D-: RS-485 interface
6
Alarm IN: Alarm input interface
Alarm OUT: Alarm output interface
7
AIN: Audio input interface
AOUT: Audio output interface
8
Power supply

Quick Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
5
1.2.2 Dome Camera Ⅱ
Figure 1.2.2
Serial NO.
Description
1
10M/100M self-adaptive Ethernet interface
2
AUDIO IN: Audio input interface
3
AUDIO OUT: Audio output interface
4
D+, D-: RS-485 interface
5
ALARM
IN, G: Alarm input interface
1A, 1B: Alarm output interface
6
Power supply

Quick Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
6
1.2.3 Dome Camera Ⅲ
Figure 1.2.3
Serial NO.
Description
1
10M/100M self-adaptive Ethernet interface
2
INITIAL SET: Reset the camera
3
AUDIO OUT: Audio output interface
4
MIC IN: Audio input interface
5
D+, D-: RS-485 interface
6
1A, 1B, 2A, 2B: Alarm output interface
7
IN1, GND, IN2, GND: Alarm input interface
8
Power supply
1.3 Bullet Camera Interface Description
Figure 1.3.1

Quick Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
7
Serial NO.
Description
1
10M/100M self-adaptive Ethernet interface
2
Power supply
3
IN, G: Alarm input interface
1A, 1B: Alarm output interface
4
D+, D-: RS-485 interface
5
AUDIO IN, G: Audio input interface
AUDIO OUT, G: Audio output interface
1.4 Cube Camera Interface Description
Figure 1.4.1
Serial NO.
Description
1
Microphone hole
2
Micro SD card solt
3
LINK: Network status LED indicator.
When the network is connected, the LED flickers in green.
4
Power LED indicator, It turns solid red when power is applied to the unit
5
Lens
6
ETHERNET: 10M / 100M self-adaptive Ethernet interface
7
RESET: Reset all parameters to factory default settings
8
Speaker hole
9
Power supply
10
Bracket mounting holes, used to fix the camera to the bracket

Quick Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
8
1.5 Mini Dome Camera Interface Description
Figure 1.5.1
Serial NO.
Description
1
Back box
2
Lens
3
P: Power LED indicator, It turns solid red when power is applied to the unit.
4
Bottom board
5
Bottom board set screw hole
6
Lens set screw
7
S & L: Network status LED indicator.
When the network is connected, the “S”LED turns solid orange, while the “L”LED flickers in
green.
8
RESET: Reset all parameters to factory default settings.

Quick Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
9
Chapter 2 Search and Modify IP
SADP (Search Active Devices Protocol) software can automatically search the IP address of network
cameras in the same local area network (LAN) with connection diagram as following:
Figure 2.1
The operation of searching and modifying IP address is described as following:
Description of SADPV 2.0
SADP (Search Active Devices Protocol) is a kind of user-friendly and installation-free online device search tool. It
searches the active online devices within your subnet and displays the information of the devices. You can also
modify the basic network information of the devices using this software.
Search active devices online
Search online devices automatically
After launch the SADP software, it automatically searches the online devices every 15 seconds from the
subnet where your computer locates. It displays the total number and information of the searched devices
in the Online Devices interface. Device information including the device type, IP address, port number,
gateway, etc. will be displayed.

Quick Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
10
Figure 2.2 Searching Online Devices
Note: Device can be searched and displayed in the list in 15 seconds after it went online; it will be
removed from the list in 45 seconds after it went offline.
Search online devices manually
You can also click to refresh the online device list manually. The newly searched devices will
be added to the list.
Note: You can click or on each column heading to order the information; you can click to
expand the device table and hide the network parameter panel on the right side, or click to show
the network parameter panel.
Modify network parameters
Steps:
1. Select the device to be modified in the device list and the network parameters of the device will be displayed in
the Modify Network Parameters panel on the right side.
2. Edit the modifiable network parameters, e.g. IP address and port number.
3. Enter the password of the admin account of the device in the Password field and click to save the
changes.

Quick Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
11
Figure 2.3 Modify Network Parameters
Restore default password
Steps:
1. Contact our technical engineers to get the serial code.
Note: Serial code is a series of characters combined by the start time and the serial number of the device.
2. Input the code in the Serial code field and click to restore the default password.

Quick Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
12
Chapter 3 Preview via WEB browser
Note: The default IP of network cameras is ‘192.0.0.64’ with ‘admin’ as the administrator, ‘12345’ as
the password, and ‘8000’ as the default port.
For monitoring camera images, a computer running the Microsoft Windows Operating System and
Internet Explorer (Version 6.0 or later) are required. In this manual, we take Windows XP and IE 6.0
for example.
This chapter describes how to view the video from the camera via web browser, and operate as
following:
Figure 3.1
1. Open the IE browser, set the security level to [Medium] in
*Tools/InternetOptions/Security/Custom Level…+

Quick Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
13
Figure 3.2
2. Input the IP address of the camera and press [Enter], and
then click the dialog box that pops up.
Figure 3.3
3. Click [Run] to install the ActiveX control.

Quick Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
14
Figure 3.4
4. Input “Username” (Default: admin), “Password” (Default: 12345)
and “Port”(Default: 8000) of the camera, then click [Login]
Figure 3.5
5. View the image
Note: For detailed instructions of further configuration, please refer to the user manual of network
camera.

Quick Guide of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
15
First Choice for Security Professionals
