HIK VISION DS-2CE5512P(N) User manual

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
1
Color Camera
Technical Manual

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
2
Notices
The information in this documentation is subject to change without notice and does not represent any
commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data
that may appear in this documentation. The product(s) described in this documentation are furnished
subject to a license and may only be used in accordance with the terms and conditions of such license.
Copyright © 2006-2011 by HIKVISION. All rights reserved.
This documentation is issued in strict confidence and is to be used only for the purposes for
which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or
be used for any other purpose without prior written consent of HIKVISION and then only on the
condition that this notice is included in any such reproduction. No information as to the contents or
subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,
shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party
being an individual, firm, or company or any employee thereof without the prior written consent of
HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use
this product. HIKVISION reserves the right to make changes to its products as circumstances may
warrant, without notice.
This documentation is provided “as-is,” without warranty of any kind.
Please send any comments regarding the documentation to:
overseabusi[email protected]
Find out more about HIKVISION at www.hikvision.com

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
3
DS-2CE5512P(N)
Key Features
Compact design
DIS
Day/Night with auto switch
Auto white balance, auto gain control and electronic shutter control
Internal Synchronization
3-axis (pan/tilt/rotation) positioning allows adjustment for optimum Surveillance angles and position
Specification
Model
Parameter
DS-2CE5512P(N)
500 TVL DIS Dome Camera
Camera
Image Sensor
1/4” DIS
Signal System
PAL/NTSC
Effective Pixels
640 (H) × 480 (V)
Min. Illumination
0.1 Lux @ (F1.2, AGC ON)
0.28 Lux @ (F2.0, AGC ON)
Shutter Time
PAL: 1/25 s to 1/15,000 s
NTSC: 1/30 s to 1/15,000 s
Lens
2.8 mm @ F2.0
Angle of view: 66.2°(2.8 mm)
Lens Mount
M12
Angle Adjustment
Pan: 0 - 355°, Tilt: 0 - 90°, Rotation: 0 - 355°
Day & Night
Electronic
Horizontal
Resolution
500 TVL
Synchronization
Internal synchronization
Video Output
1Vp-p composite output (75 Ω/BNC)

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
4
S/N Ratio
More than 52 dB
General
Operating
Conditions
-40 °C - 60 °C (-40 °F - 140 °F)
Humidity 90% or less (non-condensing)
Power Supply
12 V DC ± 10%
Power
Consumption
Max.0.5 W
Dimension
Φ 97.8 x 64.4 mm (φ 3.85” x 2.54”)
Weight
300 g (0.66 lbs)
Order Models
DS-2CE5512P
DS-2CE5512N
Dimension
Unit: mm
