Quick Start Guide
About this Manual
This Manual is applicable to IPC-T1XX-I Network Turret Camera.
The Manual includes instructions for using and managing the
product. Pictures, charts, images and all other information
hereinafter are for description and explanation only. The
information contained in the Manual is subject to change, without
notice, due to firmware updates or other reasons. Please find the
latest version in the company website
Please use this user manual under the guidance of professionals.
Legal Disclaimer
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF
PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. OUR COMPANY
SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER
ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET
SECURITY RISKS; HOWEVER, OUR COMPANY WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL
RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS
PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE
APPLICABLE LAW. OUR COMPANY SHALL NOT BE LIABLE IN THE
EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.
Regulatory Information

Network Turret Camera·Quick Start Guide
2
2
FCC Information
Please take attention that changes or modification not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.

Network Turret Camera·Quick Start Guide
3
3
2. This device must accept any interference received, including
interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized European
standards listed under the EMC Directive 2014/30/EU, the RoHS
Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific battery
information. The battery is marked with this symbol,
which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your
supplier or to a designated collection point. For more information
see: www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards
requirements.

Network Turret Camera·Quick Start Guide
4
4
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
Warnings
●Proper configuration of all passwords and other security
settings is the responsibility of the installer and/or end-user.
●In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region. Please
refer to technical specifications for detailed information.
●Input voltage should meet both the SELV (Safety Extra Low
Voltage) and the Limited Power Source with 12 VDC according
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these
precautions to prevent
potential injury or material
damage.

Network Turret Camera·Quick Start Guide
5
5
to the IEC60950-1 standard. Please refer to technical
specifications for detailed information.
●Do not connect several devices to one power adapter as
adapter overload may cause over-heating or a fire hazard.
●Please make sure that the plug is firmly connected to the power
socket. When the product is mounted on wall or ceiling, the
device shall be firmly fixed.
●If smoke, odor or noise rise from the device, turn off the power
at once and unplug the power cable, and then please contact
the service center.
Cautions
●Make sure the power supply voltage is correct before using the
camera.
●Do not drop the camera or subject it to physical shock.
●Do not touch sensor modules with fingers. If cleaning is
necessary, use clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period,
please replace the lens cap to protect the sensor from dirt.
●Do not aim the camera at the sun or extra bright places.
Blooming or smearing may occur otherwise (which is not a
malfunction), and affect the endurance of sensor at the same
time.
●The sensor may be burned out by a laser beam, so when any
laser equipment is in using, make sure that the surface of
sensor will not be exposed to the laser beam.

Network Turret Camera·Quick Start Guide
6
6
●Do not place the camera in extremely hot, cold (the operating
temperature shall be -10°C to 40°C), dusty or damp locations,
and do not expose it to high electromagnetic radiation.
●To avoid heat accumulation, good ventilation is required for
operating environment.
●Keep the camera away from liquid while in use.
●While in delivery, the camera shall be packed in its original
packing, or packing of the same texture.
●Regular part replacement: a few parts (e.g. electrolytic
capacitor) of the equipment shall be replaced regularly
according to their average enduring time. The average time
varies because of differences between operating environment
and using history, so regular checking is recommended for all
the users. Please contact with your dealer for more details.
●Improper use or replacement of the battery may result in
hazard of explosion. Replace with the same or equivalent type
only. Dispose of used batteries according to the instructions
provided by the battery manufacturer.
●If the product does not work properly, please contact your
dealer or the nearest service center. Never attempt to
disassemble the camera yourself. (We shall not assume any
responsibility for problems caused by unauthorized repair or
maintenance.)

Network Turret Camera·Quick Start Guide
7
7
Table of Contents
1 Appearance Description ................................................................. 8
2 Installation...................................................................................... 9
2.1 Ceiling Mounting............................................................. 9
2.2 Mounting with Junction Box.......................................... 13
2.3 Mounting with Inclined Base......................................... 15
2.4 Wall Mounting .............................................................. 17
3 Setting the Network Camera over the LAN .................................. 19
3.1 Wiring ........................................................................... 19
3.2 Activating the Camera................................................... 20
Activation via Web Browser ..................................... 203.2.1
Activation via SADP Software................................... 213.2.2
3.3 Modifying the IP Address .............................................. 23
4 Accessing via Web Browser .......................................................... 26
5 Operating via CCTV Guard App..................................................... 28
5.1 Enable Guarding Vision Service on Camera ................... 28
Enable Guarding Vision Service via SADP Software.. 285.1.1
Enable Guarding Vision Service via Web Browser .... 295.1.2
5.2 CCTV Guard Setup ......................................................... 31
5.3 Adding Camera to CCTV Guard...................................... 31
5.4 Initializing the Memory Card ......................................... 33

Network Turret Camera·Quick Start Guide
8
8
1Appearance Description
1
2
3
4
5
Figure 1-1 Turret Camera Overview
Type DescriptionTable 1-1
No.
Description
1
Enclosure
2
Camera Body
3
Mounting Base
4
Power Cord
5
Network Cable
Note:
For cameras support power over Ethernet (PoE), the power is passed
along with data on Ethernet cabling. And a switch supports PoE
function is required.

Network Turret Camera·Quick Start Guide
9
9
2Installation
Before you start:
●Make sure the device in the package is in good condition and all
the assembly parts are included.
●The standard power supply is 12 V DC, make sure your power
supply matches with your camera.
●Make sure all the related equipment is power-off during the
installation.
●Check the specification of the products for the installation
environment.
●Make sure that the wall is strong enough to withstand four
times the weight of the camera and the bracket.
●Make sure that there is no reflective surface too close to the
camera lens. The IR light from the camera may reflect back into
the lens causing reflection.
Ceiling Mounting2.1
Before you start:
Both wall mounting and ceiling mounting are suitable for the turret
camera. Ceiling mounting will be taken as an example in this section.
And you can take steps of ceiling mounting as a reference for wall
mounting.
Steps:
1. Paste the drill template (supplied) to the desired mounting
position on the ceiling.

Network Turret Camera·Quick Start Guide
10
10
2. Drill the screw holes and the cable hole in the ceiling according to
the drill template.
Note:
Drill the cable hole, when adopting ceiling outlet to route the cable.
Φ85 mm (3.35")
Φ110 mm
(4.33")
3-Φ4.2 mm
(0.17")
Φ20 mm
(0.79")
Screw
Hole
Cable
Hole
Figure 2-1 The Drill Template
3. Disassemble the camera.
1). Rotate the camera to align the notch to one of the marks.
2). Pry the mounting base to remove the mounting base with the
camera body with a flat object, e.g., a coin.

Network Turret Camera·Quick Start Guide
11
11
Mark
Notch
Figure 2-2 Disassemble the Camera
4. Fix the mounting base to the ceiling with supplied screws.
Notes:
In the supplied screw package, both self-tapping screws, and
expansion bolts are contained.
If the ceiling is cement, expansion bolts are required to fix the
camera. If the ceiling is wooden, self-tapping screws are
required.
Figure 2-3 Fix the Mounting Base

Network Turret Camera·Quick Start Guide
12
12
5. Route the cables through the cable hole or the side opening.
6. Install the camera body back to the mounting base.
Figure 2-4 Install the Camera Body
7. Connect the power cord and network cable.
8. Power on the camera, and set the network configuration (for
details, refer to 3 Setting the Network Camera over the LAN and 4
Accessing via Web Browser) to check whether the image is gotten
from the optimum angle. If not, adjust the surveillance angle.
0°to 360°
0°to 360°
0°to 75°
Figure 2-5 Adjust Surveillance Angle

Network Turret Camera·Quick Start Guide
13
13
1). Hold the camera body and rotate the enclosure to adjust the
pan angle [0°to 360°].
2). Move the camera body up and down to adjust the tilt angle [0°
to 75°].
3). Rotate the camera body to adjust the rotation angle [0°to
360°].
Mounting with Junction Box2.2
Before you start:
●You need to purchase a junction box separately if you adopt the
mounting with a junction box.
●Both wall mounting and ceiling mounting are suitable for the
turret camera. Wall mounting will be taken as an example in
this section. And you can take steps of wall mounting as a
reference for the ceiling mounting.
Steps:
1. Paste the drill template (supplied) to the desired mounting
position on the wall.
2. Drill the screw holes and the cable hole in the wall according to
the drill template.
Note:
Drill the cable hole, if adopting ceiling outlet to route the cable.

Network Turret Camera·Quick Start Guide
14
14
Screw
Hole
Cable
Hole
Figure 2-6 Drill Template
3. Take apart the junction box, and fix the camera’s mounting base
with three MP4 screws on the junction box’s cover.
Junction Box
Cover
Mounting
Base
Figure 2-7 Fix screws on the junction box’s Cover
4. Secure the junction box’s body on the wall with four PA4 × 25
screws.

Network Turret Camera·Quick Start Guide
15
15
Figure 2-8 Secure the Junction Box’s Body on the Ceiling/Wall
5. Combine the junction box’s cover with its body with supplied
screws.
6. Repeat steps 5 to 8 of 2.1 Ceiling Mounting to complete the
installation.
Mounting with Inclined Base2.3
Before you start:
●You need to purchase an inclined base separately if you adopt
the mounting with an inclined base.
●Both wall mounting and ceiling mounting are suitable for the
turret camera. Wall mounting will be taken as an example in
this section. And you can take steps of wall mounting as a
reference for the ceiling mounting.
Steps:
1. Paste the drill template to the wall.

Network Turret Camera·Quick Start Guide
16
16
2. Drill screw holes and the cable hole (optional) on the wall
according to the supplied drill template.
Note:
Drill the cable hole, if adopting ceiling outlet to route the cable
Screw
Hole
Cable
Hole
Figure 2-9 Drill Template
3. Disassemble the inclined base by the screw driver.
4. Install the turret camera’s mounting base on the inclined base
cover with three PM4 screws.
Inclined Base
Cover
Mounting
Base
Figure 2-10 Fix Camera’s Mounting Base
5. Install the inclined base’s body on the ceiling/wall with four
PA4×25 screws.

Network Turret Camera·Quick Start Guide
17
17
Inclined
Base Body
Figure 2-11 Fix the Inclined Base’s boy on Ceiling/Wall
6. Combine inclined base’s cover with its body with supplied screws.
7. Repeat steps 5 to 8 of 2.1 Ceiling Mounting to complete the
installation.
Wall Mounting2.4
Note:
You need to purchase a wall mounting bracket separately.
Steps:
1. Drill four screw holes in the wall according to the holes of the
bracket.
2. Install the bracket to the wall by aligning the four screw holes of
the bracket with expansion screws on the wall.
3. Secure the bracket with four hex nuts and washers.

Network Turret Camera·Quick Start Guide
18
18
Figure 2-12 Install the Wall Mounting Bracket
4. Install the mounting base of the turret camera to the wall
mounting bracket and secure them with supplied screws.
Figure 2-13 Install the Mounting Base on the Wall Mounting Bracket
5. Repeat steps 5 to 8 of 2.1 Ceiling Mounting to complete the
installation.

Network Turret Camera·Quick Start Guide
19
19
3Setting the Network Camera over the
LAN
Note:
You shall acknowledge that the use of the product with Internet
access might be under network security risks. For avoidance of any
network attacks and information leakage, please strengthen your
own protection.
If the product does not work properly, contact your dealer or the
nearest service center for help.
Wiring3.1
Connect the camera to network according to the following figures.
半球
Network Cable
or
Network Camera
Computer
Connecting DirectlyFigure 3-1
网络交换机
半球
Network Cable
Network Cable
or
or
Network Camera Computer
Connecting via a Switch or a RouterFigure 3-2
