Hikmicro HM-TD1018-1/QR User manual

Thermal Presence Detector
User Manual

Thermal Presence Detector User Manual
i
Legal Information
© 2023 Hangzhou Microimage Software Co., Ltd. All rights reserved.
About this Manual
The Manual includes instructions for using and managing the Product. Pictures, charts, images and
all other information hereinafter are for description and explanation only. The information
contained in the Manual is subject to change, without notice, due to firmware updates or other
reasons. Please find the latest version of this Manual at the HIKMICRO website
(http://www.hikmicrotech.com).
Please use this Manual with the guidance and assistance of professionals trained in supporting the
Product.
Trademarks
and other HIKMICRO's trademarks and logos are the properties of
HIKMICRO in various jurisdictions.
Other trademarks and logos mentioned are the properties of their respective owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND
"WITH ALL FAULTS AND ERRORS". HIKMICRO MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR
A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT
WILL HIKMICRO BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT
DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT
LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKMICRO
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKMICRO SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKMICRO WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR

Thermal Presence Detector User Manual
ii
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE
LATTER PREVAILS.

Thermal Presence Detector User Manual
iii
Regulatory Information
These clauses apply only to the products bearing the corresponding mark or
information.
FCC Compliance Statement
Please take attention that changes or modification not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
Note: This product has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This product generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this product does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
EU/UK Compliance Statement
This product and - if applicable - the supplied accessories too are marked with
"CE" and comply therefore with the applicable harmonized European standards
listed under the Directive 2014/30/EU (EMCD), Directive 2014/35/EU (LVD),
Directive 2011/65/EU (RoHS), Directive 2014/53/EU.
For the device without a supplied power adapter, use the power adapter provided by a qualified
manufacturer. Refer to the product specification for detailed power requirements.

Thermal Presence Detector User Manual
iv
For the device without a supplied battery, use the battery provided by a qualified manufacturer.
Refer to the product specification for detailed battery requirements.
Directive 2012/19/EU (WEEE Directive): Products marked with this symbol cannot be
disposed of as unsorted municipal waste in the European Union. For proper recycling,
return this product to your local supplier upon the purchase of equivalent new
equipment, or dispose of it at designated collection points. For more information see:
www.recyclethis.info.
Directive 2006/66/EC and its amendment 2013/56/EU (Battery Directive): This
product contains a battery that cannot be disposed of as unsorted municipal waste
in the European Union. See the product documentation for specific battery
information. The battery is marked with this symbol, which may include lettering to
indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the
battery to your supplier or to a designated collection point. For more information see:
www.recyclethis.info.
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-003 (B)/NMB-003 (B) standards requirements.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to
the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Cet appareil répond aux exigences des normes CAN ICES-003 (B)/NMB-003 (B).
Cet appareil est conforme aux normes RSS exemptes de licence d’Industrie Canada. Son
fonctionnement est soumis aux deux conditions suivantes :
(1) cet appareil ne doit pas causer d’interférences, et
(2) cet appareil doit accepter toute interférence reçue, notamment les interférences susceptibles
d’occasionner un fonctionnement indésirable de l’appareil.
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
Cet appareil est conforme aux limites d’exposition au rayonnement IC RSS-102 établies pour un
environnement non contrôlé. Cet équipement doit être installé et utilisé à une distance minimale
de 20 cm entre la source du rayonnement et votre corps.
KC
B급기기: 이기기는 가정용(B급) 전자파적합기기로써 주로 가정에서 사용하는 것을
목적으로 하며, 모든 지역에서 사용할 수있습니다.

Thermal Presence Detector User Manual
v
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol
Description
Danger
Indicates a hazardous situation which, if not avoided, will or could
result in death or serious injury.
Caution
Indicates a potentially hazardous situation which, if not avoided,
could result in equipment damage, data loss, performance
degradation, or unexpected results.
Note
Provides additional information to emphasize or supplement
important points of the main text.

Thermal Presence Detector User Manual
vi
Safety Instruction
These instructions are intended to ensure that user can use the product correctly to avoid danger
or property loss.
Laws and Regulations
●In the use of the product, you must be in strict compliance with the electrical safety regulations
of the nation and region.
Transportation
●Keep the device in original or similar packaging while transporting it.
●Keep all wrappers after unpacking them for future use. In case of any failure occurred, you need
to return the device to the factory with the original wrapper. Transportation without the
original wrapper may result in damage on the device and the company shall not take any
responsibilities.
●DO NOT drop the product or subject it to physical shock. Keep the device away from magnetic
interference.
Power Supply
●Please purchase the charger by yourself. Input voltage should meet the Limited Power Source
(12 VDC) according to the IEC62368 standard. Please refer to technical specifications for
detailed information.
●Make sure the plug is properly connected to the power socket.
●The socket-outlet shall be installed near the equipment and shall be easily accessible.
●DO NOT connect multiple devices to one power adapter, to avoid over-heating or fire hazards
caused by overload.
●DO NOT touch the bare metal contacts of the inlets after the circuit breaker is turned off.
Electricity still exists.
●+ identifies the positive terminal(s) of equipment which is used with, or generates direct
current. - identifies the negative terminal(s) of equipment which is used with, or generates
direct current.
Battery
●Risk of explosion if the battery is replaced by an incorrect type. Dispose of used batteries
according to the instructions. Il y a risque d'explosion si la batterie est remplacée par une
batterie de type incorrect. Mettre au rebut les batteries usagées conformément aux
instructions.
●The built-in battery cannot be dismantled. Please contact the manufacture for repair if
necessary.
●For long-term storage of the battery, make sure it is fully charged every half year to ensure the
battery quality. Otherwise, damage may occur.
●This equipment is not suitable for use in locations where children are likely to be present.
●Improper replacement of the battery with an incorrect type may defeat a safeguard (for

Thermal Presence Detector User Manual
vii
example, in the case of some lithium battery types).
●DO NOT dispose of the battery into fire or a hot oven, or mechanically crush or cut the battery,
which may result in an explosion.
●DO NOT leave the battery in an extremely high temperature surrounding environment, which
may result in an explosion or the leakage of flammable liquid or gas.
●DO NOT subject the battery to extremely low air pressure, which may result in an explosion or
the leakage of flammable liquid or gas.
Installation
●Never place the equipment in an unstable location. The equipment may fall, causing serious
personal injury or death.
●This equipment is for use only with corresponding brackets. Use with other (carts, stands, or
carriers) may result in instability causing injury.
System Security
●You acknowledge that the nature of Internet provides for inherent security risks, and our
company shall not take any responsibilities for abnormal operation, privacy leakage or other
damages resulting from cyber attack, hacker attack, however, our company will provide timely
technical support if required.
●Please enforce the protection for the personal information and the data security as the device
may be confronted with the network security problems when it is connected to the Internet.
Please contact us when the device might exist network security risks.
●Please understand that you have the responsibility to configure all the passwords and other
security settings about the device, and keep your user name and password.
Maintenance
●If the product does not work properly, please contact your dealer or the nearest service center.
We shall not assume any responsibility for problems caused by unauthorized repair or
maintenance.
●A few device components (e.g., electrolytic capacitor) require regular replacement. The average
lifespan varies, so periodic checking is recommended. Contact your dealer for details.
●Wipe the device gently with a clean cloth and a small quantity of ethanol, if necessary.
●If the equipment is used in a manner not specified by the manufacturer, the protection
provided by the device may be impaired.
●To reduce the risk of fire, replace only with the same type and rating of fuse.
●The serial port of the equipment is used for debugging only.
Using Environment
●Make sure the running environment meets the requirement of the device. The operating
temperature shall be -20°C to 50°C (-4°F to 122°F), and the operating humidity shall be 95% or
less, no condensing.
●DO NOT expose the device to high electromagnetic radiation or dusty environments.
●DO NOT aim the lens at the sun or any other bright light.
●The equipment shall not be exposed to dripping or splashing and that no objects filled with

Thermal Presence Detector User Manual
viii
liquids, such as vases, shall be placed on the equipment.
●No naked flame sources, such as lighted candles, should be placed on the equipment.
●Provide a surge suppressor at the inlet opening of the equipment under special conditions such
as the mountain top, iron tower, and forest.
●Burned fingers when handling the parts with symbol . Wait one-half hour after switching off
before handling the parts.
Emergency
●If smoke, odor, or noise arises from the device, immediately turn off the power, unplug the
power cable, and contact the service center.
COMPLIANCE NOTICE: The thermal series products might be subject to export controls in various
countries or regions, including without limitation, the United States, European Union, United
Kingdom and/or other member countries of the Wassenaar Arrangement. Please consult your
professional legal or compliance expert or local government authorities for any necessary export
license requirements if you intend to transfer, export, re-export the thermal series products
between different countries.

Thermal Presence Detector User Manual
ix
Contents
Chapter 1 Overview....................................................................................................................1
1.1 Introduction...........................................................................................................................1
1.2 Application.............................................................................................................................1
Chapter 2 Device Activation and Accessing .................................................................................2
2.1 Activate the Device via SADP................................................................................................2
2.2 Activate the Device via Browser...........................................................................................2
2.3 Login.......................................................................................................................................3
2.3.1 Plug-in Installation .....................................................................................................3
2.3.2 Illegal Login Lock.........................................................................................................4
Chapter 3 Health Tracking ..........................................................................................................5
3.1 Set Exit Without Return Detection Rule...............................................................................5
3.2 Set Out of Bed Detection Rule..............................................................................................5
3.3 Set Out of Room Detection Rule...........................................................................................6
3.4 Set People Overstay Detection Rule.....................................................................................6
3.5 Set Fall Down Detection Rule ...............................................................................................7
Chapter 4 Event and Alarm.........................................................................................................8
4.1 Set Exception Alarm ..............................................................................................................8
4.2 Detect Audio Exception.........................................................................................................8
Chapter 5 Arming Schedule and Alarm Linkage.........................................................................10
5.1 Set Arming Schedule ...........................................................................................................10
5.2 Linkage Method Settings.....................................................................................................10
5.2.1 Trigger Alarm Output ...............................................................................................10
5.2.2 FTP/NAS/Memory Card Uploading .........................................................................11
5.2.3 Send Email ................................................................................................................12
5.2.4 Notify Surveillance Center .......................................................................................13
5.2.5 Trigger Recording .....................................................................................................13
Chapter 6 Live View..................................................................................................................14
6.1 Live View Parameters..........................................................................................................14
6.1.1 Start and Stop Live View..........................................................................................14

Thermal Presence Detector User Manual
x
6.1.2 Window Proportion .................................................................................................14
6.1.3 Live View Stream Type.............................................................................................14
6.1.4 Select the Third-Party Plug-in..................................................................................14
6.1.5 Start Digital Zoom ....................................................................................................14
6.2 Quick Set Live View .............................................................................................................15
6.3 Set Transmission Parameters .............................................................................................15
Chapter 7 Video and Audio.......................................................................................................17
7.1 Video Settings......................................................................................................................17
7.1.1 Stream Type..............................................................................................................17
7.1.2 Video Type................................................................................................................17
7.1.3 Resolution.................................................................................................................17
7.1.4 Bitrate Type and Max. Bitrate .................................................................................17
7.1.5 Video Quality............................................................................................................18
7.1.6 Frame Rate ...............................................................................................................18
7.1.7 Video Encoding.........................................................................................................18
7.1.8 Smoothing.................................................................................................................19
7.1.9 Display VCA Info.......................................................................................................19
7.2 Display Settings ...................................................................................................................20
7.2.1 Image Adjustment....................................................................................................20
7.2.2 Image Adjustment (Thermal Channel) ....................................................................20
7.2.3 DNR...........................................................................................................................20
7.2.4 Set Palette ................................................................................................................21
7.2.5 DDE............................................................................................................................21
7.2.6 Brightness Sudden Change.......................................................................................21
7.2.7 Mirror........................................................................................................................22
7.3 Set Privacy Mask..................................................................................................................22
7.4 OSD ......................................................................................................................................22
Chapter 8 Video Recording and Picture Capture........................................................................23
8.1 Storage Settings...................................................................................................................23
8.1.1 Set Memory Card......................................................................................................23
8.1.2 Set NAS .....................................................................................................................23

Thermal Presence Detector User Manual
xi
8.1.3 Set FTP ......................................................................................................................24
8.1.4 Set Cloud Storage .....................................................................................................24
8.2 Video Recording ..................................................................................................................25
8.2.1 Record Automatically...............................................................................................25
8.2.2 Record Manually ......................................................................................................27
8.2.3 Playback and Download Video ................................................................................27
8.3 Capture Configuration.........................................................................................................27
8.3.1 Capture Automatically .............................................................................................28
8.3.2 Capture Manually.....................................................................................................28
8.3.3 View and Download Picture ....................................................................................28
Chapter 9 Network Settings......................................................................................................30
9.1 TCP/IP ..................................................................................................................................30
9.1.1 Multicast Discovery..................................................................................................31
9.2 Port.......................................................................................................................................31
9.3 Port Mapping.......................................................................................................................32
9.3.1 Set Auto Port Mapping.............................................................................................32
9.3.2 Set Manual Port Mapping........................................................................................33
9.4 Multicast..............................................................................................................................33
9.5 SNMP ...................................................................................................................................33
9.6 Access to Device via Domain Name....................................................................................34
9.7 Access to Device via PPPoE Dial Up Connection ................................................................34
9.8 Enable Hik-Connect Service on Camera..............................................................................35
9.8.1 Enable Hik-Connect Service via Web Browser ........................................................35
9.8.2 Enable Hik-Connect Service via SADP Software......................................................36
9.8.3 Access Camera via Hik-Connect...............................................................................36
9.9 Set ISUP................................................................................................................................37
9.10 Set Alarm Server................................................................................................................37
9.11 Set Network Service..........................................................................................................38
9.12 Set SRTP .............................................................................................................................38
Chapter 10 System and Security ...............................................................................................39
10.1 View Device Information ..................................................................................................39

Thermal Presence Detector User Manual
xii
10.2 Search and Manage Log ....................................................................................................39
10.3 Import and Export Configuration File...............................................................................39
10.4 Export Diagnose Information............................................................................................40
10.5 Reboot ...............................................................................................................................40
10.6 Restore and Default ..........................................................................................................40
10.7 Upgrade .............................................................................................................................40
10.8 View Open Source Software License................................................................................41
10.9 Time and Date ...................................................................................................................41
10.9.1 Synchronize Time Manually...................................................................................41
10.9.2 Set NTP Server........................................................................................................41
10.9.3 Set DST....................................................................................................................42
10.10 Set RS-232........................................................................................................................42
10.11 Set RS-485........................................................................................................................42
10.12 Security ............................................................................................................................43
10.12.1 Authentication......................................................................................................43
10.12.2 Security Audit Log ................................................................................................43
10.12.3 Set IP Address Filter .............................................................................................44
10.12.4 Set SSH..................................................................................................................45
10.12.5 Set HTTPS..............................................................................................................45
10.12.6 Set QoS .................................................................................................................46
10.12.7 Set IEEE 802.1X.....................................................................................................46
10.13 User and Account ............................................................................................................47
10.13.1 Set User Account and Permission........................................................................47
Chapter 11 Appendix................................................................................................................49
11.1 Common Material Emissivity Reference ..........................................................................49
11.2 Device Command...............................................................................................................49
11.3 Device Communication Matrix .........................................................................................50
11.4 FAQ.....................................................................................................................................50

Thermal Presence Detector User Manual
1
Chapter 1 Overview
1.1 Introduction
Thermal Presence Detector is a detector based on thermal imaging technology.
Due to the advantages of thermal imaging, the detector is able to achieve the detection tasks
without the influence of changing light condition.
The detector can be used for health tracking such as out of room detection, out of bed detection,
exit without return detection, fall down detection, and people overstay detection in nursing
homes.
1.2 Application
The mobile client Hik-Connect or PC client iVMS-4200 and HikCentral Professional can be used to
configure the detector and to receive alarm information.
Table 1-1 Applications
Main Parts
Usage
Main Setting Procedure
●Thermal Presence Detector
●PC Client iVMS-4200 and
HikCentral Professional
Use PC client to configure and
manage the device, and
receive alarm notifications.
Activate and add the device to
PC client iVMS-4200 and
HikCentral Professional. See
User Manual of iVMS-4200
and User Manual of HikCentral
Professional for instructions.
●Thermal Presence Detector
●Mobile Client Hik-Connect
Use your mobile client to
configure and manage the
device, and receive alarm
notifications.
●Activate and configure the
device. See Device
Activation and Accessing.
●Add the device to your
mobile client. See Enable
Hik-Connect Service on
Camera.

Thermal Presence Detector User Manual
2
Chapter 2 Device Activation and Accessing
To protect the security and privacy of the user account and data, you should set a login password
to activate the device when access the device via network.
Note
Refer to the user manual of the software client for the detailed information about the client
software activation.
2.1 Activate the Device via SADP
Search and activate the online devices via SADP software.
Before You Start
Access https://www.hikmicrotech.com to get SADP software to install.
Steps
1. Connect your computer to the same Wi-Fi network that the device is in.
2. Run SADP software to search the online devices of the LAN.
3. Check Device Status from the device list, and select Inactive device.
4. Create and input the new password in the password field, and confirm the password.
Caution
We highly recommend you create a strong password of your own choosing (using a minimum of
8 characters, including upper case letters, lower case letters, numbers, and special characters)
in order to increase the security of your product. And we recommend you reset your password
regularly, especially in the high security system, resetting the password monthly or weekly can
better protect your product.
5. Click OK.
Device Status changes into Active.
6. Optional: Change the network parameters of the device in Modify Network Parameters.
2.2 Activate the Device via Browser
You can access and activate the device via the browser.
Steps
1. Connect the device to the PC using the network cables.
2. Change the IP address of the PC and device to the same segment.

Thermal Presence Detector User Manual
3
Note
The default IP address of the device is 192.168.1.64. You can set the IP address of the PC from
192.168.1.2 to 192.168.1.253 (except 192.168.1.64). For example, you can set the IP address of
the PC to 192.168.1.100.
3. Input 192.168.1.64 in the browser.
4. Set device activation password.
Caution
We highly recommend you create a strong password of your own choosing (using a minimum of
8 characters, including at least three of the following categories: upper case letters, lower case
letters, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
resetting the password monthly or weekly can better protect your product.
5. Click OK.
6. Input the activation password to log in to the device.
7. Optional: Go to Configuration → Network → Basic → TCP/IP to change the IP address of the
device to the same segment of your network.
2.3 Login
Log in to the device via Web browser.
2.3.1 Plug-in Installation
Certain operation systems and web browser may restrict the display and operation of the device
function. You should install plug-in or complete certain settings to ensure normal display and
operation. For detailed restricted function, refer to the actual device.
Operating System
Web Browser
Operation
Windows
Internet Explorer 10+
Follow pop-up prompts to
complete plug-in installation.
Google Chrome 57+
Mozilla Firefox 52+
Click to
download and install plug-in.
Go to Configuration →
Network → Advanced
Settings → Network Service
to enable WebSocket or
WebSockets for normal view if

Thermal Presence Detector User Manual
4
Operating System
Web Browser
Operation
plug-in installation is not
required. Display and
operation of certain functions
are restricted. For example,
Playback and Picture are not
available. For detailed
restricted function, refer to
the actual device.
Mac OS 10.13+
Mac Safari 12+
Plug-in installation is not
required.
Go to Configuration →
Network → Advanced
Settings → Network Service
to enable WebSocket or
WebSockets for normal view.
Display and operation of
certain functions are
restricted. For example,
Playback and Picture are not
available. For detailed
restricted function, refer to
the actual device.
Note
The device only supports Windows and Mac OS system and does not support Linux system.
2.3.2 Illegal Login Lock
It helps to improve the security when accessing the device via Internet.
Go to Configuration → System → Security → Security Service, and enable Enable Illegal Login
Lock. Illegal Login Attempts and Locking Duration are configurable.
Illegal Login Attempts
When your login attempts with the wrong password reach the set times, the device is locked.
Locking Duration
The device releases the lock after the setting duration.

Thermal Presence Detector User Manual
5
Chapter 3 Health Tracking
Health tracking is used to detect out of bed, out of room, fall down, people overstay, and exit
without return for specified groups, such as the elderly in nursing homes. The device triggers
alarms when there are exceptions, so as to prevent accidents.
3.1 Set Exit Without Return Detection Rule
Exit without return detection detects if the people stay in the toilet for over long time. Set the
detection rule for this function, and the device triggers alarms when the in-toilet duration exceeds
the set value.
Steps
1. Go to Configuration → Health Tracking → Rule.
2. Click to add a rule, and enter a name for the rule.
3. Select the rule type as Exit Without Return.
4. Click , and a yellow line will appear on the live view.
Note
Bis the toilet direction.
5. Optional: Left click the yellow line, hold the mouse to adjust its position, and drag the end of the
line with the mouse to adjust its length and angle.
6. Set the duration for the in-toilet time.
7. Check to enable this rule.
8. Click Save.
9. Refer to Set Arming Schedule for setting scheduled time. Refer to Linkage Method Settings for
setting linkage method.
3.2 Set Out of Bed Detection Rule
Set a rule for the out of bed detection. After enabling the rule, the device triggers alarms when the
people leave the bed.
Steps
1. Go to Configuration → Health Tracking → Rule.
2. Click to add a rule, and enter a name for the rule.
3. Select the rule type as Out of Bed.
4. Click , and click on the live image to draw a region.

Thermal Presence Detector User Manual
6
Note
●Only 1 out of bed rule can be configured.
●The rule area must be a convex quadrilateral.
5. Optional: Drag the frame to adjust the position of the drawn area.
6. Set the sensitivity for the rule.
7. Check to enable this rule.
8. Click Save.
9. Refer to Set Arming Schedule for setting scheduled time. Refer to Linkage Method Settings for
setting linkage method.
3.3 Set Out of Room Detection Rule
Set rules for the out of room detection. After enabling the rule, the device triggers alarms when
the people leave the room.
Steps
1. Go to Configuration → Health Tracking → Rule.
2. Click to add a rule, and enter a name for the rule.
3. Select the rule type as Out of Room.
4. Click , and a yellow line will appear on the live view.
5. Select the line crossing direction from the drop-down list.
6. Optional: Left click the yellow line, hold the mouse to adjust its position, and drag the end of the
line with the mouse to adjust its length and angle.
7. Set the sensitivity for the rule.
8. Check to enable this rule.
9. Click Save.
10. Refer to Set Arming Schedule for setting scheduled time. Refer to Linkage Method Settings for
setting linkage method.
3.4 Set People Overstay Detection Rule
People overstay detection detects if people stay in the drawn area for over long time. Set the
detection rule for this function, and the device triggers alarms when the overstay duration exceeds
the set value.
Steps
1. Go to Configuration → Health Tracking → Rule.
2. Click to add a rule, and enter a name for the rule.
3. Select the rule type as People Overstay.
4. Click , and click on the live image to draw an area.

Thermal Presence Detector User Manual
7
Note
The rule area must be a convex quadrilateral.
5. Optional: Drag the frame to adjust the position of the drawn area.
6. Set the overstay duration and overstay people number.
7. Check to enable this rule.
8. Click Save.
9. Refer to Set Arming Schedule for setting scheduled time. Refer to Linkage Method Settings for
setting linkage method.
Note
At most 5 people overstay rules can be configured. If you have configured a out of bed rule, only
4 people overstay rules can be configured.
3.5 Set Fall Down Detection Rule
Fall down detection detects if the people fall down and stay on the ground over long time. Set the
detection rule for this function, and the device triggers alarms when the falling down duration
exceeds the set value.
Steps
1. Go to Configuration →Health Tracking → Rule.
2. Select the rule type as Fall Down.
3. Set the duration for falling down.
4. Check to enable this rule.
5. Click Save.
6. Refer to Set Arming Schedule for setting scheduled time. Refer to Linkage Method Settings for
setting linkage method.
