Hill EC3000 User manual

EC-3000 PORTABLE
AIR COMPRESSOR
QUICK START
GUIDE
Full instruction manual available at:
www.airriflepump.com
IMPORTANT
THIS PRODUCT IS DESIGNED TO FILL
PRE-CHARGED PCP AIR GUNS AND
PAINTBALL GUNS DIRECTLY. IT CAN
ALSO BE USED TO TOP UP SMALL
TANKS, BUDDY BOTTLES, AND
CYLINDERS UP TO 7 LITRES. LARGE
CYLINDERS AND TANKS ABOVE 4
LITRES SHOULD ONLY BE FILLED BY
COMPETENT OR QUALIFIED PEOPLE
NOT FOLLOWING THE INSTRUCTIONS
OR MISUSE OF THE COMPRESSOR
WILL VOID YOUR WARRANTY AND
MAY RESULT IN DEATH OR INJURY
DANGER OF EXPLOSION
FROM OVERFILLING OF
COMPRESSED AIR BOTTLES
DO NOT EXCEED MAXIMUM FILL
PRESSURE OF YOUR CYLINDER AT
ROOM TEMPERATURE ONLY FILL
CYLINDERS THAT ARE IN GOOD
CONDITION AND ARE IN DATE OF
INSPECTION
IMPORTANT
READ ALL INSTRUCTIONS BEFORE
USE TO PROTECT YOUR EYES. YOU
SHOULD ALWAYS WEAR SAFETY
GLASSES WHEN OPERATING THIS
COMPRESSOR AND HEARING
PROTECTION WHEN BLEEDING
WARNING
THIS COMPRESSOR PRODUCES
CLEAN AIR SUITABLE FOR FILLING
PCP AIRGUNS IT DOES NOT
COMPRESS AIR SUITABLE OR
CERTIFIED FOR BREATHING
APPARATUS. DO NOT USE IT TO FILL
SCUBA TANKS THAT MAY LATER BE
USED FOR BREATHING
DANGER OF ELECTRIC SHOCK
DO NOT OPERATE IN THE RAIN
OR WITH WET HANDS OR CLOTHES
DANGER
PARTS OF THIS COMPRESSOR GET
VERY HOT
WARNING
DO NOT TOUCH MOVING PARTS FOR
EXAMPLE THE COOLING FAN.KEEP
FINGERS AND LOOSE CLOTHING
AWAY FROM MOVING PARTS
OPERATING TEMPERATURE
+5℃ to 75℃ (41℉ to 167℉)
THERMAL PROTECTION WILL NOT
ALLOW COMPRESSOR TO START
OUTSIDE THIS RANGE

SET UP - OIL
1. Fill crank with 50ml of crank oil
(entire bottle) and allow 5 mins
to settle.
2. Fill silicone oil up to the max
limit indicated on the reservoir
by the blue line.
3. Keep silicone oil always
topped up to blue line
4. Change crank oil every 50
running hours or once
yearly (whichever comes
first).
DO NOT MIX OILS
OPERATING INSTRUCTIONS
For full operating manual and images go to:
www.airriflepump.com
1. Connect filling probe to
bottle or gun
2. Ensure bleed screw is
closed finger tight
3. Insert power cable into
pump
4. Switch compressor on
5. Press rotary control knob
to confirm lubricant levels
are checked and are
correct
6. To set the pressure press
control knob to set required
pressure. Rotate clockwise
to increase fill pressure.
When you reach the
desired pressure press
control knob to confirm.
DO NOT SET THE
COMPRESOR ABOVE
THE MANUFACTURERS
RECOMMEND
PRESSURE FOR THE
BOTTLE YOU ARE
FILLING
7. Rotate control knob to
reach the start display
screen. Press the control
knob and the compressor
will start.
You can pause filling at any
time by pressing the control
knob.
8. The compressor may
automatically pause and
restart. This is the normal
cooling cycle.
9. When the target pressure is
reached the compressor
will stop.
10. Depressurise by
unscrewing bleed screw.
This will expel any trapped
moisture or silicone.
11. Store the compressor
upright with the bleed screw
undone not connected to
any bottle
DO NOT LEAVE THE
COMPRESSOR
UNATTENDED WHEN IN
USE
