Hilti TE 30-A36 User manual

TE 30A36
English 1
Français 16
Español 34
Português 51

1

2
3
4
5

6
7
8
9

TE 30A36
en Original operating instructions . . . . . . . . . . . . . . . . . . . . . . . . . . 1
fr Moded'emploioriginal ............................... 16
es Manual de instrucciones original . . . . . . . . . . . . . . . . . . . . . . . 34
pt Manual de instruções original . . . . . . . . . . . . . . . . . . . . . . . . . . 51

*2173713* 2173713 English 1
Original operating instructions
1 Information about the operating instructions
1.1 About these operating instructions
• Read these operating instructions before the product is used or operated
for the first time. This is a prerequisite for safe, trouble-free handling and
use of the product.
• Observe the safety instructions and warnings in these operating instruc-
tions and on the product.
• Always keep the operating instructions with the product and make sure
that the product is accompanied by these operating instructions only,
when the product is given to other persons.
1.2 Explanation of symbols
1.2.1 Warnings
Warnings alert persons to hazards that occur when handling or using the
product. The following signal words are used:
DANGER
DANGER !
▶Draws attention to imminent danger that will lead to serious personal
injury or fatality.
WARNING
WARNING !
▶Draws attention to a potential threat of danger that can lead to serious
injury or fatality.
CAUTION
CAUTION !
▶Draws attention to a potentially dangerous situation that could lead to
personal injury or damage to the equipment or other property.
1.2.2 Symbols in the operating instructions
The following symbols are used in these operating instructions:
Comply with the operating instructions
Instructions for use and other useful information
Dealing with recyclable materials
Do not dispose of electric equipment and batteries as household
waste
Hilti Liion battery

2 English 2173713 *2173713*
Hilti charger
1.2.3 Symbols in illustrations
The following symbols are used in illustrations:
These numbers refer to the illustrations at the beginning of these
operating instructions.
The numbers in illustrations refer to important work steps or to com-
ponents important for the work steps. In the text, the corresponding
numbers draw attention to these work steps or components, e.g. (3).
Item reference numbers are used in the overview illustration and
refer to the numbers used in the key in the product overview sec-
tion.
This symbol is intended to draw your special attention to certain
points for handling the product.
1.3 Product-dependent symbols
1.3.1 Symbols on the product
The following symbols are used on the product:
Drilling without hammer action
Drilling with hammer action (hammer drilling)
Chiseling
Chisel positioning
Forward / reverse
Diameter
Rated speed under no load
Revolutions per minute
The product supports wireless data transmission compatible with
iOS and Android platforms.
Hilti Li-ion battery type series used. Observe the information given in
the section headed Intended use.
Li-ion battery
Never use the battery as a striking tool.
Do not drop the battery. Never use a battery that has suffered an
impact or is damaged in any other way.
1.4 Product information
products are designed for professional users and only trained,
authorized personnel are permitted to operate, service and maintain the

*2173713* 2173713 English 3
products. This personnel must be specifically informed about the possible
hazards. The product and its ancillary equipment can present hazards if
used incorrectly by untrained personnel or if used not in accordance with
the intended use.
The type designation and serial number are printed on the rating plate.
▶Write down the serial number in the table below. You will be required to
state the product details when contacting Hilti Service or your local Hilti
organization to inquire about the product.
Product information
Combihammer TE 30A36
Generation 03
Serial no.
1.5 Declaration of conformity
We declare, on our sole responsibility, that the product described here
complies with the applicable directives and standards. A copy of the
declaration issued by the certification department can be found at the end
of this documentation.
The technical documentation is filed here:
Hilti Entwicklungsgesellschaft mbH | Tool Certification | Hiltistrasse 6 | 86916
Kaufering, Germany
2 Safety
2.1 General power tool safety warnings
WARNING Read all safety warnings, instructions, illustrations and
specifications provided with this power tool. Failure to follow all instruc-
tions listed below may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) power tool.
Work area safety
▶Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
▶Do not operate power tools in explosive atmospheres, such as in
the presence of flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
▶Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
Electrical safety
▶Power tool plugs must match the outlet. Never modify the plug in
any way. Do not use any adapter plugs with earthed (grounded)

4 English 2173713 *2173713*
power tools. Unmodified plugs and matching outlets will reduce risk of
electric shock.
▶Avoid body contact with earthed or grounded surfaces, such as
pipes, radiators, ranges and refrigerators. There is an increased risk
of electric shock if your body is earthed or grounded.
▶Do not expose power tools to rain or wet conditions. Water entering
a power tool will increase the risk of electric shock.
▶Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk
of electric shock.
▶When operating a power tool outdoors, use an extension cord
suitable for outdoor use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
▶If operating a power tool in a damp location is unavoidable, use
a residual current device (RCD) protected supply. Use of an RCD
reduces the risk of electric shock.
Personal safety
▶Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in serious personal
injury.
▶Use personal protective equipment. Always wear eye protection.
Protective equipment such as a dust mask, non-skid safety shoes, hard
hat or hearing protection used for appropriate conditions will reduce
personal injuries.
▶Prevent unintentional starting. Ensure the switch is in the off-
position before connecting to power source and/or battery pack,
picking up or carrying the tool. Carrying power tools with your finger
on the switch or energising power tools that have the switch on invites
accidents.
▶Remove any adjusting key or wrench before turning the power tool
on. A wrench or a key left attached to a rotating part of the power tool
may result in personal injury.
▶Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
▶Dress properly. Do not wear loose clothing or jewellery. Keep your
hair and clothing away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
▶If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used.
Use of dust collection can reduce dust-related hazards.

*2173713* 2173713 English 5
▶Do not let familiarity gained from frequent use of tools allow you
to become complacent and ignore tool safety principles. A careless
action can cause severe injury within a fraction of a second.
Power tool use and care
▶Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at
the rate for which it was designed.
▶Do not use the power tool if the switch does not turn it on and off.
Any power tool that cannot be controlled with the switch is dangerous
and must be repaired.
▶Disconnect the plug from the power source and/or remove the
battery pack, if detachable, from the power tool before making any
adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool
accidentally.
▶Store idle power tools out of the reach of children and do not
allow persons unfamiliar with the power tool or these instructions
to operate the power tool. Power tools are dangerous in the hands of
untrained users.
▶Maintain power tools and accessories. Check for misalignment or
binding of moving parts, breakage of parts and any other condition
that may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by poorly
maintained power tools.
▶Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
▶Use the power tool, accessories and tool bits etc. in accordance
with these instructions, taking into account the working conditions
and the work to be performed. Use of the power tool for operations
different from those intended could result in a hazardous situation.
▶Keep handles and grasping surfaces dry, clean and free from oil and
grease. Slippery handles and grasping surfaces do not allow for safe
handling and control of the tool in unexpected situations.
Battery tool use and care
▶Recharge only with the charger specified by the manufacturer. A
charger that is suitable for one type of battery pack may create a risk of
fire when used with another battery pack.
▶Use power tools only with specifically designated battery packs. Use
of any other battery packs may create a risk of injury and fire.
▶When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other small
metal objects, that can make a connection from one terminal to
another. Shorting the battery terminals together may cause burns or a
fire.

6 English 2173713 *2173713*
▶Under abusive conditions, liquid may be ejected from the battery;
avoid contact. If contact accidentally occurs, flush with water. If
liquid contacts eyes, additionally seek medical help. Liquid ejected
from the battery may cause irritation or burns.
▶Do not use a battery pack or tool that is damaged or modified.
Damaged or modified batteries may exhibit unpredictable behaviour
resulting in fire, explosion or risk of injury.
▶Do not expose a battery pack or tool to fire or excessive temperature.
Exposure to fire or temperature above 130° C (265 °F) may cause
explosion.
▶Follow all charging instructions and do not charge the battery pack
or tool outside the temperature range specified in the instructions.
Charging improperly or at temperatures outside the specified range may
damage the battery and increase the risk of fire.
Service
▶Have your power tool serviced by a qualified repair person using
only identical replacement parts. This will ensure that the safety of the
power tool is maintained.
▶Never service damaged battery packs. Service of battery packs should
only be performed by the manufacturer or authorized service providers.
2.2 Hammer safety warnings
Safety instructions for all operations
▶Wear ear protectors. Exposure to noise can cause hearing loss.
▶Use auxiliary handle(s), if supplied with the tool. Loss of control can
cause personal injury.
▶Hold the power tool by insulated gripping surfaces, when performing
an operation where the cutting accessory may contact hidden wiring.
Cutting accessory contacting a "live" wire may make exposed metal parts
of the power tool "live" and could give the operator an electric shock.
Safety instructions when using long drill bits with rotary hammers
▶Always start drilling at low speed and with the bit tip in contact with
the workpiece. At higher speeds, the bit is likely to bend if allowed
to rotate freely without contacting the workpiece, resulting in personal
injury.
▶Apply pressure only in direct line with the bit and do not apply
excessive pressure. Bits can bend causing breakage or loss of control,
resulting in personal injury.
2.3 Additional safety instructions for breakers
Personal safety
▶Use the product and accessories only when they are in perfect working
order.

*2173713* 2173713 English 7
▶Never tamper with or modify the product or accessories in any way.
▶When chiseling into ceilings, walls and floors, always make sure that you
have a safe and firm stance. A sudden break-through can affect your
balance!
▶Apply appropriate safety measures at the opposite side of the workpiece
in work that involves breaking through. Parts breaking away could fall
out and / or fall down causing injury to other persons.
▶You and the other persons in the vicinity must wear suitable eye
protection, a hard hat, ear protection, protective gloves and light
respiratory protection while the product is in use.
▶Wear protective gloves when changing the accessory tool. Touching the
accessory tool can result in cuts and burns.
▶Wear eye protection. Flying fragments can injure the body and eyes.
▶Dust produced by grinding, sanding, cutting and drilling can contain
dangerous chemicals. Some examples are: lead or lead-based paints;
brick, concrete and other masonry products, natural stone and other
products containing silicates; certain types of wood, such as oak,
beech and chemically treated wood; asbestos or materials that contain
asbestos. Determine the exposure of the operator and bystanders
by means of the hazard classification of the materials to be worked.
Implement the necessary measures to restrict exposure to a safe level,
for example by the use of a dust collection system or by the wearing
of suitable respiratory protection. The general measures for reducing
exposure include:
▶working in an area that is well ventilated,
▶avoidance of prolonged contact with dust,
▶directing dust away from the face and body,
▶wearing protective clothing and washing exposed areas of the skin
with water and soap.
▶Take frequent breaks and do physical exercises to improve the blood
circulation in your fingers. High vibration during long periods of work can
lead to disorders of the blood vessels and nervous system in the fingers,
hands and wrists.
Electrical safety
▶Before beginning work, check the working area for concealed electric
cables or gas and water pipes. External metal parts of the product could
give you an electric shock or cause an explosion if you accidentally
damage an electric cable or a gas or water pipe.
Power tool use and care
▶Wait until the product has come to a complete stop before you lay it
down.

8 English 2173713 *2173713*
3 Description
3.1 Product overview 1
@Chuck
;Depth gauge release button
=Depth gauge
%Function selector switch
&Forward / reverse switch
(Control switch
)Battery state of charge / fault
display
+Release buttons / battery state
of charge display
§Battery
/Side handle
3.2 Intended use
The product described is a cordless (battery-powered) combihammer with
pneumatic hammering mechanism. It is designed for drilling in concrete,
masonry, wood and metal. The product can also be used for light to medium-
duty chiseling on masonry and surface finishing work on concrete.
▶Use only Hilti Li-ion batteries from the B 36 series with this product.
▶Use only the Hilti battery chargers from the C4/36 series for these
batteries.
3.3 Possible misuse
• This product is not suitable for working on hazardous materials.
• This product is not suitable for working in a damp environment.
3.4 ATC
The product is equipped with the ATC (Active Torque Control) quick-acting
electronic cut-out.
If the accessory tool sticks or stalls, the product will suddenly pivot about
its own axis in the opposite direction. ATC detects this sudden pivoting
movement of the product and switches the product off immediately.
For ATC to function correctly, the product must be free to pivot.
After an ATC cut-out, switch the product off and then on again.
3.5 Motor protection system
The tool is equipped with a motor protection system. The system monitors
current input and motor temperature and thus prevents the tool from
overheating.
If the motor is overloaded through application of excessive working pressure,
the power tool’s performance drops noticeably or it may stall completely.
If the power tool stalls or slows significantly due to overloading, release the
pressure applied to the tool and then allow it to run under no load for approx.
30 seconds.

*2173713* 2173713 English 9
3.6 Lithiumion battery status display
The Li-ion battery state of charge and malfunctions of the power tool are
indicated by the display on the Liion battery. The Liion battery state of
charge is displayed after pressing one of the two battery release buttons.
Status Meaning
4 LEDs light. State of charge: 75 % to 100 %
3 LEDs light. State of charge: 50 % to 75 %
2 LEDs light. State of charge: 25 % to 50 %
1 LED lights. State of charge: 10 % to 25 %
1 LED blinks. State of charge: < 10 %
1 LED blinks, the power tool is not
ready for use.
The battery has overheated or is
completely discharged.
4 LEDs blink, the power tool is not
ready for use.
The power tool is overloaded or has
overheated.
Battery state of charge cannot be displayed while the control switch is
pressed and for up to 5 seconds after releasing the control switch.
If the battery display LEDs blink, please observe the instructions given
in the Troubleshooting section.
3.7 Items supplied
Combihammer, side handle with depth gauge, operating instructions.
To help ensure safe and reliable operation, use only genuine Hilti spare
parts and consumables. Spare parts, consumables and accessories
approved by Hilti for use with the product can be found at your local
Hilti Center or online at: www.hilti.com
4 Technical data
TE 30A36
Rated voltage 36 V
Weight 5.1 kg
5 Operation
5.1 Preparations at the workplace
WARNING
Risk of injury by inadvertent starting!
▶Before inserting the battery, make sure that the product is switched off.
▶Remove the battery before making any adjustments to the power tool or
before changing accessories.

10 English 2173713 *2173713*
Observe the safety instructions and warnings in this documentation and on
the product.
5.1.1 Inserting the battery 2
1. Push the battery into the battery holder until it engages with an audible
click.
2. Check that the battery is seated securely.
5.1.2 Removing the battery 3
1. Press the release buttons on the battery.
2. Pull the battery out toward the rear.
5.1.3 Charging the battery
Make sure that the outer surfaces of the battery are clean and dry before
inserting the battery in the approved battery charger.
Read the operating instructions for the charger for further information
about the charging process.
▶Use an approved charger to charge the battery.
5.1.4 Fitting the side handle 4
CAUTION
Risk of injury! Loss of control over the product.
▶Check that the side handle is fitted correctly and tightened securely.
Check that the clamping band is engaged in the groove in the product.
1. Release the side handle clamping band by turning the handle grip.
2. Slide the side handle clamping band over the tool holder from the front
and into the recess provided.
3. Set the side handle to the desired position.
4. Tighten the side handle clamping band by turning the handle grip.
5.1.5 Adjusting the depth gauge (optional) 5
1. Press the release button on the side handle.
2. Adjust the depth gauge to the desired drilling depth.
3. Release the release button.
4. Check that the side handle is securely attached.
5.1.6 Removing the chuck 6
CAUTION
Risk of injury. The depth gauge, if fitted but not used, might hinder the
operator.
▶Remove the depth gauge from the product.

*2173713* 2173713 English 11
Set the function selector switch to the “Chiseling” position for
changing the chuck.
1. Remove the battery from the tool.
2. Grip the chuck as shown in the illustration and pull the three chuck
release rings upwards.
3. Lift the chuck upwards away from the tool.
5.1.7 Fitting the chuck 6
CAUTION
Risk of injury. The depth gauge, if fitted but not used, might hinder the
operator.
▶Remove the depth gauge from the product.
When changing the chuck, set the function selector switch to this
position: .
1. Remove the battery from the tool.
2. Grip the chuck as shown in the illustration and pull the three chuck
release rings upwards.
3. Fit the chuck onto the chuck mount.
4. Rotate the chuck until it engages in position.
5.1.8 Inserting the tool 7
1. Lightly grease the connection end of the accessory tool.
▶Use only genuine Hilti grease. Using the wrong grease can result in
damage to the tool.
2. Push the accessory tool into the chuck as far as it will go (until it engages).
3. After fitting the accessory tool, grip it and pull it in order to check that it
is securely engaged.
▶The product is ready for use.
5.1.9 Removing the accessory tool 7
CAUTION
Risk of injury by the accessory tool! The accessory tool might be hot or
have sharp edges.
▶Wear protective gloves when changing the accessory tool.
▶Pull the tool lock back as far as it will go and remove the accessory tool.

12 English 2173713 *2173713*
5.2 Types of work
CAUTION
Risk of damage by incorrect handling!
▶Do not operate the switches for direction of rotation and/or function
selection during operation.
Observe the safety instructions and warnings in this documentation and on
the product.
5.2.1 Function selector switch 8
▶Set the function selector switch to the desired working position.
▶Do not operate the function selector switch while the motor is running.
Risk of damage!
5.2.2 Drilling without hammering
▶Set the function selector switch to this symbol: .
5.2.3 Drilling with hammering action (hammer drilling)
▶Set the function selector switch to this symbol: .
5.2.4 Chisel positioning
▶Set the function selector switch to this symbol: .
▶The chisel can be adjusted to 12 different positions (in 30° incre-
ments). This ensures that flat chisels and shaped chisels can always
be set to the optimum working position.
5.2.5 Chiseling
▶Set the function selector switch to this symbol: .
5.2.6 Forward / reverse 9
▶Set the forward / reverse switch to the desired direction of rotation.
6 Care and maintenance
WARNING
Risk of injury with battery inserted !
▶Always remove the battery before carrying out care and maintenance
tasks!
Care of the product
• Carefully remove stubborn dirt.
• Carefully clean the air vents, if present, with a dry, soft brush.
• Use only a slightly damp cloth to clean the housing. Do not use cleaning
agents containing silicone as these can attack the plastic parts.
• Use a dry, clean cloth to clean the contacts of the product.

*2173713* 2173713 English 13
Care of the Liion batteries
• Never use a battery with clogged air vents. Clean the air vents carefully
using a dry, soft brush.
• Avoid unnecessary exposure of the battery to dust and dirt. Never
expose the battery to high levels of moisture (e.g. by being dipped in
water or left in the rain).
If a battery has been soaked by moisture, treat it as a damaged battery.
Isolate it in a non-flammable container and consult Hilti Service.
• Keep the battery free of extraneous oil and grease. Do not permit dust
or dirt to accumulate unnecessarily on the battery. Clean the battery
with a dry, soft brush or a clean, dry cloth. Do not use cleaning agents
containing silicone as these can attack the plastic parts.
Do not touch the contacts of the battery and do not remove the factory-
applied grease from the contacts.
• Use only a slightly damp cloth to clean the housing. Do not use cleaning
agents containing silicone as these can attack the plastic parts.
Maintenance
• Check all visible parts and controls for signs of damage at regular
intervals and make sure that they all function correctly.
• Do not use the product if signs of damage are found or if parts
malfunction. Immediately have the product repaired by Hilti Service.
• After cleaning and maintenance, install all guards and protective devices
and check that they are in full working order.
To help ensure safe and reliable operation, use only genuine Hilti spare
parts and consumables. Spare parts, consumables and accessories
approved by Hilti for use with your product can be found at your
Hilti Store or online at: www.hilti.group
7 Transport and storage of cordless tools and batteries
Transport
CAUTION
Accidental starting during transport !
▶Always transport your products with the batteries removed!
▶Remove the battery/batteries.
▶Never transport batteries loose and unprotected. During transport,
batteries should be protected from excessive shock and vibration and
isolated from any conductive materials or other batteries that may come
in contact with the terminals and cause a short circuit. Comply with the
locally applicable regulations for transporting batteries.
▶Do not send batteries through the mail. Consult your shipper for
instructions on how to ship undamaged batteries.

14 English 2173713 *2173713*
▶Prior to each use and before and after prolonged transport, check the
product and the batteries for damage.
Storage
WARNING
Accidental damage caused by defective or leaking batteries !
▶Always store your products with the batteries removed!
▶Store the product and the batteries in a cool and dry place. Comply with
the temperature limits stated in the technical data.
▶Do not store batteries on the charger. Always remove the battery from
the charger when the charging operation has completed.
▶Never leave batteries in direct sunlight, on sources of heat, or behind
glass.
▶Store the product and batteries where they cannot be accessed by
children or unauthorized persons.
▶Prior to each use and before and after prolonged storage, check the
product and the batteries for damage.
8 Troubleshooting
If the trouble you are experiencing is not listed in this table or you are unable
to remedy the problem by yourself, please contact Hilti Service.
8.1 The combihammer is in working order.
Trouble or fault Possible cause Action to be taken
The battery runs
down more quickly
than usual.
Battery condition is not
optimal.
▶Replace the battery.
The battery doesn’t
engage with an audi-
ble click.
The retaining lugs on the
battery are dirty.
▶Clean the retaining
lugs and refit the
battery.
The control switch
can’t be pressed, i.e.
the switch is locked.
The forward / reverse
switch is in the middle
position.
▶Push the forward /
reverse switch to the
right or left.
The drive spindle
doesn’t rotate.
The permissible operat-
ing temperature of the
combihammer’s elec-
tronics has been ex-
ceeded.
▶Allow the combiham-
mer to cool down.
Battery is discharged. ▶Change the battery
and charge the empty
battery.
