Hirschmann EAGLE30-0402 series User manual

Installation EAGLE20/30
Release 05 10/2013
Technical support
https://hirschmann-support.belden.eu.com
User Manual
Installation
Industrial Security Router
EAGLE20/30
EAGLE20-0400...EAGLE30-0402...

The naming of copyrighted trademarks in this manual, even when not specially indicated, should
not be taken to mean that these names may be considered as free in the sense of the trademark
and tradename protection law and hence that they may be freely used by anyone.
© 2013 Hirschmann Automation and Control GmbH
Manuals and software are protected by copyright. All rights reserved. The copying, reproduction,
translation, conversion into any electronic medium or machine scannable form is not permitted,
either in whole or in part. An exception is the preparation of a backup copy of the software for
your own use. For devices with embedded software, the end-user license agreement on the
enclosed CD/DVD applies.
The performance features described here are binding only if they have been expressly agreed
when the contract was made. This document was produced by Hirschmann Automation and
Control GmbH according to the best of the company's knowledge. Hirschmann reserves the right
to change the contents of this document without prior notice. Hirschmann can give no guarantee
in respect of the correctness or accuracy of the information in this document.
Hirschmann can accept no responsibility for damages, resulting from the use of the network
components or the associated operating software. In addition, we refer to the conditions of use
specified in the license contract.
You can get the latest version of this manual on the Internet at the Hirschmann product site
(www.hirschmann.com).
Printed in Germany
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Germany
Tel.: [phone]
EAGLE20/30 039 793-001-05-1013 - 21.10.13

Installation EAGLE20/30
Release 05 10/2013 3
Contents
Safety instructions 5
About this manual 11
Key 11
1 Description 12
1.1 General device description 12
1.2 Device name and product code 13
1.3 Combination options 16
1.4 Device views 17
1.4.1 Front view 17
1.4.2 Rear view 18
1.5 Power supply 18
1.5.1 Operating voltage characteristic value K 18
1.5.2 Operating voltage characteristic value C 18
1.6 Ethernet ports 19
1.6.1 10/100 Mbit/s twisted pair port 19
1.6.2 100/1000 Mbit/s F/O port 19
1.7 Display elements 19
1.7.1 Device state 20
1.7.2 Additional status information 21
1.7.3 Input 21
1.7.4 Port state 21
1.8 Management interfaces 21
1.8.1 V.24 interface (external management) 21
1.8.2 SD card interface 22
1.8.3 USB interface 22
1.9 Input/output interfaces 23
1.9.1 Signal contact 23
1.9.2 Input 23
2 Installation 24
2.1 Unpacking the package and checking the content 24
2.2 Installing the SD card (optional) 24
2.3 Installing and grounding the device 25
2.3.1 Installing the device onto the DIN rail 25
2.3.2 Grounding the device 26

4Installation EAGLE20/30
Release 05 10/2013
2.4 Installing an SFP transceiver (optional) 26
2.5 Connecting the terminal blocks 27
2.5.1 Operating voltage characteristic value K 27
2.5.2 Operating voltage characteristic value C 28
2.5.3 Signal contact 29
2.6 Installing terminal blocks, switching on the supply voltage 30
2.7 Connecting network cables 30
2.7.1 10/100 Mbit/s twisted pair port 30
2.7.2 100/1000 Mbit/s F/O port 30
2.8 Insert data in label area 30
3 Basic set-up 31
4 Maintenance and service 32
5Disassembly 33
5.1 Removing the device 33
5.2 Removing the SFP transceivers 33
6 Technical data 35
A Further Support 47

Installation EAGLE20/30
Release 05 10/2013 5
Safety instructions
Certified usage
Only use the device for application cases that are described in the
Hirschmann product information, including this manual. Only operate the
device according to the technical specifications.
Supply voltage
Note:The supply voltage is only connected with the chassis via protective
elements.
Solely for device variants with operating voltage characteristic value K:
For every supply voltage to be connected, make sure the following
requirements are met:
The supply voltage complies with the description on the data plate
of your device.
The power supply conforms to overvoltage category I or II.
The voltage supply has an easily accessible disconnecting device
(e.g. a switch or a plug). This disconnecting device is clearly
identified so that in the case of an emergency, it is clear which
disconnecting device belongs to which line.
Disconnect device for equipment supplied from IT supply system,
shall disconnect both poles of mains supply.1
The lines to be connected are voltage-free.
Supply with DC voltage:
A fuse suitable for DC voltage is located in the plus conductor of the
power supply. A fuse is also located in the minus conductor, if this
is not grounded.
Regarding the properties of this fuse: See “General technical data”
on page 35.
Supply with AC voltage:
A fuse is located in the outer conductor of the power supply. A fuse
is also located in the neutral conductor, if this is not grounded.
Regarding the properties of this fuse: See “General technical data”
on page 35.
Supply with DC voltage:
The wire diameter for the input supply line is at least 1 mm² (North
America: AWG16).
AC voltage Supply: the wire diameter for the input supply line is at
least 0.75 mm² (North America: AWG18).
1. IT supply system according to the technical standard UL 60950-1

6Installation EAGLE20/30
Release 05 10/2013
The cross-section of the protective conductor cable is the same
size as or bigger than the cross-section of the voltage supply
cables.
The connection cables used are permitted for the specified
temperature range.
Relevant for North America:
The supply voltage lines are made of copper wire, which is suitable
for ambient temperatures of up to at least 167 °F (75 °C).
For device variants with operating voltage characteristic value C
exclusively.
For every supply voltage to be connected, make sure the following
requirements are met:
Relevant for North America:
The power supply is Class 2 compliant.
The power supply conforms to overvoltage category I or II.
The voltage supply has an easily accessible disconnecting device
(e.g. a switch or a plug). This disconnecting device is clearly
identified so that in the case of an emergency, it is clear which
disconnecting device belongs to which line.
The lines to be connected are voltage-free.
A fuse suitable for DC voltage is located in the plus conductor of the
power supply. A fuse is also located in the minus conductor, if this
is not grounded.
Regarding the properties of this fuse: See “General technical data”
on page 35.
The wire diameter for the input supply line is at least 1 mm² (North
America: AWG16).
The wire diameter for the input supply line is at least 1 mm² (North
America: AWG16).
The connection cables used are permitted for the specified
temperature range.
Relevant for North America:
The supply voltage lines are made of copper wire, which is suitable
for ambient temperatures of up to at least 167 °F (75 °C).
Use undamaged parts.
The device does not contain any service components. Internal fuses
are only triggered if there is a fault in the device. If the device is not
functioning correctly, or if it is damaged, switch off the voltage supply
and return the device to the plant for inspection.
Only switch on the supply voltage for the device when the following
prerequisites are fulfilled:
The housing is closed
The terminal blocks are wired correctly
The terminal blocks for the voltage supply are connected

Installation EAGLE20/30
Release 05 10/2013 7
Connect the protective conductor with the ground screw before you
set up the other connections. When removing the connections, you
remove the protective conductor last.
For supply voltages with protective conductor connections: first
connect the protective conductor before connecting the lines for the
supply voltages.
Shielded ground
The shielded ground wire of the twisted pairs lines is connected to the
front panel as a conductor.
Beware of possible short circuits when connecting a cable section with
conductive shield braiding.
Housing
Only technicians authorized by the manufacturer are permitted to open
the housing.
Never insert pointed objects (narrow screwdrivers, wires, etc.) into the
device or into the connection terminals for the supply voltage.
Make sure there is at least 3.94 inches (10 cm) of space in front of the
ventilation slits of the housing.
Install the device in the vertical position.
Grounding the device
The device is grounded by the separate ground screw on the front panel.
Environment
Install the device in a fire protected enclosure according to EN 60950-
1.
Solely for device variants with operating voltage characteristic value K:
Only install this device in a switch cabinet or in an operating site with
limited access, to which only maintenance staff have access.
Only operate the device at the specified ambient temperature
(temperature of the surrounding air at a distance of up to 5 cm from the
device) and at the specified relative humidity.
When you are selecting the installation location, make sure you
observe the climatic threshold values specified in the technical data.
Use the device in an environment with a maximum pollution degree
that complies with the specifications in the technical data.

8Installation EAGLE20/30
Release 05 10/2013
Qualification requirements for personnel
Qualified personnel as understood in this manual and the warning signs,
are persons who are familiar with the setup, assembly, startup, and
operation of this product and are appropriately qualified for their job. This
includes, for example, those persons who have been:
trained or directed or authorized to switch on and off, to ground and to
label power circuits and devices or systems in accordance with current
safety engineering standards;
trained or directed in the care and use of appropriate safety equipment
in accordance with the current standards of safety engineering;
trained in providing first aid.
General safety instructions
This device is operated by electricity. You must follow precisely the
prescribed safety requirements for the voltage connections in this
document.
Siehe „Supply voltage“ auf Seite 5.
Non-observance of these safety instructions can cause material damage
and/or injuries.
Only appropriately qualified personnel should work on this device or in
its vicinity. The personnel must be thoroughly familiar with all the
warnings and maintenance procedures outlined in this operating
manual.
The proper and safe operation of this device depends on proper
handling during transportation, proper storage and assembly, and
conscientious operation and maintenance procedures.
Never start operation with damaged components.
Only use the devices in accordance with this manual. In particular,
observe all warnings and safety-related information.
Any work that may be required on the electrical installation may only
be carried out by personnel trained for this purpose.
Note: LED or LASER components in compliance with IEC 60825-1
(2007):
CLASS 1 LASER PRODUCT
CLASS 1 LED PRODUCT
National and international safety regulations
Make sure that the electrical installation meets local or nationally
applicable safety regulations.
CE marking
The labeled devices comply with the regulations contained in the following
European directive(s):

Installation EAGLE20/30
Release 05 10/2013 9
In accordance with the above-named EU directive(s), the EU conformity
declaration will be at the disposal of the relevant authorities at the
following address:
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Germany
Tel.: [phone]
The product can be used in the industrial sector.
Interference immunity: EN 61000-6-2
Emitted interference: EN 55022
Solely for device variants with operating voltage characteristic value K:
Reliability: EN 60950-1
Warning! This is a class A device. This device can cause interference in
living areas, and in this case the operator may be required to take
appropriate measures.
Note: The assembly guidelines provided in these instructions must be
strictly adhered to in order to observe the EMC threshold values.
FCC note
This device complies with part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference; (2) this device must accept any interference received,
including interference that may cause undesired operation.
Device variant Directive
All variants 2011/65/EU (RoHS)
Directive of the European Parliament and of the Council on the
restriction of the use of certain hazardous substances in
electrical and electronic equipment.
All variants 2004/108/EC (EMC)
Directive of the European Parliament and the council for
standardizing the regulations of member states with regard to
electromagnetic compatibility.
Solely for device variants with
operating voltage characteristic
value K:
2006/95/EC
Directive of the European Parliament and the council for
standardizing the regulations of member states with regard to
electrical equipment to be used within specific voltage ranges.

10 Installation EAGLE20/30
Release 05 10/2013
Appropriate testing has established that this device fulfills the
requirements of a class A digital device in line with part 15 of the FCC
regulations.
These requirements are designed to provide sufficient protection against
interference when the device is being used in a business environment.
The device creates and uses high frequencies and can also radiate high
frequencies, and if it is not installed and used in accordance with this
operating manual, it can cause radio transmission interference. The use
of this device in a living area can also cause interference, and in this case
the user is obliged to cover the costs of removing the interference.
Recycling note
After usage, this device must be disposed of properly as electronic waste,
in accordance with the current disposal regulations of your county, state,
and country.

Installation EAGLE20/30
Release 05 10/2013 11
About this manual
The “Installation” user manual contains a device description, safety
instructions, a description of the display, and the other information that you
need to install the device.
The following manuals are available as PDF files on the CD/DVD supplied:
Installation user manual
Basic Configuration user manual
Reference manual for the graphical user interface
Command Line Interface user manual
The Industrial HiVision Network Management Software provides you with
additional options for smooth configuration and monitoring:
Simultaneous configuration of multiple devices
Graphical user interface with network layout
Auto-topology discovery
Event log
Event handling
Client/server structure
Browser interface
ActiveX control for SCADA integration
SNMP/OPC gateway.
Key
The symbols used in this manual have the following meanings:
Listing
Work step
Subheading

12 Installation EAGLE20/30
Release 05 10/2013
1 Description
1.1 General device description
You can choose from between a wide range of variants. You have the option
to set up your device individually based on different criteria:
Number of ports
Transmission speed
Types of connectors
Temperature range
Voltage range
Certifications
The EAGLE20/30 devices are designed for the special requirements of
industrial automation. They meet the relevant industry standards, provide
very high operational reliability, even under extreme conditions, and also
long-term reliability and flexibility.
The devices allow you to set up switched and routed industrial Ethernet
networks that conform to the IEEE 802.3 standard.
The devices work without a fan.
The devices are mounted very quickly by snapping them onto the DIN rail.
You have the option of choosing various media to connect to the terminal
devices and other network components:
twisted pair cable
multimode F/O
singlemode F/O
There are convenient options for managing the device. Administer your
devices via:
a Web browser
SSH
HiDiscovery (Software for putting the device into operation)
management software (such as Industrial HiVision)
a V.24 interface (locally on the device)
The devices provide you with a large range of functions, which the manuals
for the operating software inform you about. You will find these manuals as
PDF files on the enclosed CD/DVD, or you can download them from the
Internet on the Hirschmann product pages (www.hirschmann.com).
The Hirschmann network components help you ensure continuous
communication across all levels of the company.

Installation EAGLE20/30
Release 05 10/2013 13
1.2 Device name and product code
The device name corresponds to the product code. The product code is
made up of characteristics with defined positions. The characteristic values
stand for specific product properties.
Item Product
characteristic Character istic value Value for the characteristic
1 ... 7 Product EAGLE20 Router without gigabit ports
EAGLE30 Router with gigabit ports
8 (hyphen) –
9 ... 10 Number:
10/100 Mbit/s ports
04 4 × 10/100 Mbit/s ports
11 ... 12 Number:
100/1000 Mbit/s ports
00 0 × 100/1000 Mbit/s ports
02 2 × 100/1000 Mbit/s ports
13 ... 15 Configuration of the
uplink ports
2O6 2 × SFP slot for 100/1000 Mbit/s F/O port
999 Not present
16 ... 17 Configuration of the
other ports
TT All the other ports are RJ45 sockets for twisted
pairs
18 Cellular phone
interface
9 Not present
19 ... 20 WAN port 99 Not present
21 Temperature range S Standard 0 °C ... +60 °C (+32 °F ...
+140 °F)
T Extended −40 °F ... +158 °F (−40 °C
... +70 °C)
E Extended with
conformal coating
−40 °F ... +158 °F (−40 °C
... +70 °C)
22 Operating voltage C Voltage input
Rated voltage range DC
24 V ... 48 V
K Voltage input
Rated voltage range AC
110 V ... 230 V, 50 Hz ... 60 Hz
Rated voltage range DC
60 V ... 250 V
23 Operating voltage C Voltage input
Rated voltage range DC
24 V ... 48 V
9 Not present
Table 1: Device name and product code

14 Installation EAGLE20/30
Release 05 10/2013
24 ... 25 ApprovalsaZ9 CE, FCC, EN 61131-2, EN 60950-1
Y9 “Z9” + cUL 508, (UL 60950-1)
X9 “Z9” + cUL 508, (UL 60950-1), ISA 12.12 Class 1
Div. 2
V9 “Z9” + IEC 61850-3,
IEEE 1613
Substation applications
VY “V9” + cUL 508,
(UL 60950-1)
Substation applications
VU “V9” + cUL 508,
(UL 60950-1), GL,
(ABS, BV, DNS, LR)
Substation and navy
applications
VT “V9” + cUL 508,
(UL 60950-1),
EN 50121-4
Sub-station and railway
applications (trackside)
U9 “Z9” + GL, (ABS, BV,
DNS, LR)
Navy applications
UY “U9” + cUL 508,
(UL 60950-1)
Navy applications
UX “U9” + cUL 508,
(UL 60950-1),
ISA 12.12 Class 1
Div. 2
Navy applications
UT “U9” + cUL 508,
(UL 60950-1),
EN 50121-4
Navy and rail applications
(trackside)
T9 “Z9” + EN 50121-4 Railway applications
(trackside)
TY “T9” + cUL 508,
(UL 60950-1)
Railway applications
(trackside)
a. For approvals which appear in brackets, the following restrictions apply:
The EN60950-1 and UL60950-1 certifications apply to device variants with an operating
voltage characteristic value K exclusively (see device names in position 22).
The ABS, BV, DNS and LR certifications are available on request.
Item Product
characteristic Character istic value Value for the characteristic
Table 1: Device name and product code

Installation EAGLE20/30
Release 05 10/2013 15
Figure 1: Example of a device name:
EAGLE20-0400999TT999SCCZ9
3RVLWLRQ
3URGXFWQDPH
($*/(URXWHU
'HVFULSWLRQ
'DWDUDWHRI(WKHUQHWSRUWV
0ELWVRQO\
+DUGZDUHW\SH
6WDQGDUG
²
1XPEHURI0ELWVSRUWV

1XPEHURI0ELWVSRUWV

&RQILJXUDWLRQRIXSOLQNSRUWV
QRQH
&RQILJXUDWLRQRIDOORWKHUSRUWV
5-VRFNHWVIRU7ZLVWHG3DLU
&HOOXODUSRUW
QRWDYDLODEOH
:$1SRUWV
QRWDYDLODEOH
7HPSHUDWXUHUDQJH
6WDQGDUG
2SHUDWLQJYROWDJH
9ROWDJHLQSXW99'&
$SSURYDOV
&()&&(1

($*/( ±  
77


6
=














&&
2SHUDWLQJYROWDJH
9ROWDJHLQSXW99'&

16 Installation EAGLE20/30
Release
05
10/2013
1.3 Combination options
Item 1 ... 5 6 ... 7 89 ... 10 11 ... 12 13 ... 15 16 ... 17 18 19 ... 20 21 22 ... 23 24 ... 25
Charac-
teristic Product Name
Data rate
and
hardware
type
-
(hyphen)
Number
of 10/100
Mbit/s
ports
Number of
100/1000
Mbit/s
ports
Configur
ation of
uplink
ports
Configur
ation of
other
ports
Cellular
phone
interface
WAN port Temperatur
e range
Operating
voltage
Certifications
Descrip-
tion EAGLE 20 — 04 00 999 TT 9 99 S; T; E CC; K9 Z9; Y9; X9; V9; VY; VU; VT; U9; UY; UX;
UT; T9; TY; SY
EAGLE 30 — 04 02 2O6 TT 9 99 S; T; E CC; K9 Z9; Y9; X9; V9; VY;
VU; VT; U9; UY; UX;
UT; T9; TY; SY
Table 2: Combination options for the device variants of the EAGLE20/30

Installation EAGLE20/30
Release 05 10/2013 17
1.4 Device views
1.4.1 Front view
1 LED display elements for device status
2 V.24 interface
3 USB interface
4 Optional:
2× SFP slot for 100/1000 Mbit/s F/O port
5 4 × 10/100 Mbit/s twisted pair ports
6 Grounding screw
7 Power supply connection
alternatively,
depending on
device variant
2 × Operating voltage
characteristic value:
C
Rated voltage range DC
24 V ... 48 V
2-pin terminal block
1 × Operating voltage
characteristic value:
K
Rated voltage range AC
110 V ... 230 V, 50 Hz ... 60 Hz
Rated voltage range DC
60 V ... 250 V
3-pin terminal block
8 Connection for the signal contact
9 Connection for input
(no function in the existing device version)
10 LED display element for input
(no function in the existing device version)
11 Save/Load/Reset button
(no function in the existing device version)
12 LED display elements for additional status information
Table 3: Front view (example EAGLE30-04022O6TT999SCC...)
6
7
8
9
10
11
12 1
2
3
4
5

18 Installation EAGLE20/30
Release 05 10/2013
1.4.2 Rear view
1.5 Power supply
1.5.1 Operating voltage characteristic value K
A 3-pin terminal block is available to supply the device.
You will find further information under “Operating voltage characteristic
value K” on page 27.
1.5.2 Operating voltage characteristic value C
For the redundant supply of the device, two 2-pin terminal blocks are
available.
You will find further information under “Operating voltage characteristic
value C” on page 28.
1 Slot for the SD card
2 Knurled screw
1
2

Installation EAGLE20/30
Release 05 10/2013 19
1.6 Ethernet ports
You can connect terminal devices and other segments on the ports of the
device via twisted pair cables or F/O cables.
1.6.1 10/100 Mbit/s twisted pair port
This port is an RJ45 socket.
The 10/100 Mbit/s twisted pair port offers you the ability to connect network
components according to the IEEE 802.3 10BASE-T/100BASE-TX standard.
This port supports:
Autonegotiation
Autopolarity
Autocrossing (if autonegotiation is activated)
100 Mbit/s half-duplex mode, 100 Mbit/s full duplex mode
10 Mbit/s half-duplex mode, 10 Mbit/s full duplex mode
Delivery state: autonegotiation activated
The socket housing is electrically connected with the front panel.
1.6.2 100/1000 Mbit/s F/O port
This port is an SFP slot.
The 100/1000 Mbit/s F/O port offers you the ability to connect network
components according to the IEEE 802.3 100BASE-FX/1000BASE-
SX/1000BASE-LX standard.
This port supports:
Full duplex mode
1.7 Display elements
After the operating voltage is set up, the software starts and initializes itself.
Afterwards, the device performs a self-test. During this process, various
LEDs light up.
Pin Function
1 RD+ Receive path
2RD−Receive path
3 TD+ Transmission path
6TD−Transmission path
4,5,7,8 —
Table 4: Pin assignment of the 10/100 Mbit/s twisted pair port, RJ45 socket, MDI-X
mode
1
2
3
4
5
6
7
8

20 Installation EAGLE20/30
Release 05 10/2013
1.7.1 Device state
These LEDs provide information about conditions which affect the operation
of the whole device.
LED Display Color Activity Meaning
Power Power supply — None The supply voltage is too low.
Yellow Lights up Device variants with redundant voltage
supply:
The supply voltages 1 or 2 are on.
flashes 4 times
a period
Software update is running. Maintain the
voltage supply.
Green Lights up Device variants with redundant voltage
supply:
The supply voltages 1 and 2 are on.
Device variants with simple voltage supply:
The supply voltage is on.
Status Device Status — None Device starts
Device is not ready for operation
Green Lights up Device is ready for operation.
Characteristics can be configured.
Red Lights up The device reports a detected error.
See “Reference Manual GUI Graphical
User Interface”, Chapter “Device Status”.
Flashes 1 time
a period
The boot parameters used when the device
has been started differ from the boot
parameters saved.
Start the device again.
RM Redundancy
Manager
— None (no function in the existing device version)
ACA Storage medium
ACA31
ACA21
— None No ACA connected
Green Lights up The storage medium ACA is inserted.
Flashes 3
times a period
The device writes to/reads from the storage
medium.
Yellow Lights up The storage medium ACA is out of order.
Check the file system format See “SD card
interface” on page 22.
Deactivate the write protection on the
ACA31 by pushing the lock towards the
contacts.
Status
RM
ACA
Power
