Read the manual carefully and ensure you have fully understood
its contents before operating this device for the first time.

English
Read the manual carefully and ensure you have fully understood
its contents before operating this device for the first time.

A
Important Safety Instructions
Paragraphs beginning with the symbol indicate important instructions, tips or
conditions for the following settings.
For your own safety and the optimal performance of your TV, ensure to
read the safety instructions before performing any installation.
It is not guarantee operation and performance of peripheral devices made by other
manufacturers. We disclaim any liability or damage that may arise from operation and/
or performance from usage of such other maker’s peripheral devices.
The recording and playback of content on this or any other device may require
permission from the owner of the copyright or other such rights in that content. It is
your responsibility to ensure that your use of this or any other device complies with
applicable copyright legislation in your country. Please refer to that legislation for more
information on the relevant laws and regulations involved or contact the owner of the
rights of the content you wish to record or playback.
The Index/Glossary explains certain terms used in this user manual and in the TV menu.
Read these instructions
Follow all instructions
Heed all warnings
Keep these instructions
All rights reserved.
▐ Important Notice
▌Safety Instructions
The lightning flash with arrowhead
symbol, within an equilateral triangle is
intended to alert the user to the presence
of uninsulated dangerous voltage within
the product's enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock.
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
Class II product : This symbol indicates that it does not require a safety connection of
protective earthing (ground).
AC voltage: This symbol indicates that the rated voltage marked with the
symbol is AC voltage.
To ensure safe and correct use of this product, always comply with the following
precautions to avoid dangerous situations and damage to your unit:

B
Important Safety Instructions
The intended use and ambient conditions for this TV
This TV is intended for the rendering of video and audio signals, on a table-top or wall-
mounted, in a home or ofce environment. It must not be used in rooms with a high
level of humidity or dust concentration. The warranty is only valid if used as intended
by the manufacturer.
WARNING
High humidity and dust concentration may lead to current leaks in the device. To
reduce the risk of re or electrical shock:
- Do not expose this unit to rain, moisture, dripping or splashing water, and do
not place objects lled with liquids, such as vases, cups, etc. on or over the
unit.
- Do not touch the TV with wet hands.
- Do not expose to direct air-conditioning and keep candles or other naked
ames away from the TV at all times.
If the TV is moved from a cold environment to a hot environment, leave it switched off
for at least an hour to avoid condensation. If used outside, make sure it is protected
from moisture.
If you notice anything unusual, immediately remove the power plug.
In case of re, use preferably a CO2 gas or powder re extinguisher. If such extinguishers
are not accessible, try to isolate the electrical supply before using a water re extinguisher.
WARNING
Never place a television set in an unstable location. A television set may fall,
causing serious personal injury or death. Many injuries, particularly to children, can
be avoided by taking simple precautions such as:
- Using cabinets or stands recommended by the manufacturer of the television
set.
- Only using furniture that can safely support the television set.
- Ensuring the television set is not overhanging the edge of the supporting
furniture.
- Not placing the television set on tall furniture (for example, cupboards or
bookcases) without anchoring both the furniture and television set to a suitable
support.
- Not placing the television set on cloth or other materials that may be located
between the television set and supporting furniture.
- Educating children about the dangers of climbing on furniture to reach the
television set or its controls.
If your existing television set is being retained and relocated, the same
considerations as above should be applied.

C
Important Safety Instructions
Moving/Transportation
Before moving this TV, disconnect all
cables and move in the vertical position
only. Grasp the device on the upper and
lower edges of the frame.
- Do not press or put stress on the front
panel of the TV. It may take two or
more people to carry larger TVs.
If you have to briey lay down the TV,
place the unit with its entire front surface
lying at on soft material.
The LED screen is made of glass and can
break if is not handled properly. Always
wear rubber gloves to carry the unit. If
the LED screen is damaged, liquid crystal
might leak out. In case of skin contact,
immediately rinse thoroughly with water.
Power Supply
Incorrect voltages can damage the TV.
Only connect this unit to a power supply
with the correct voltage and frequency
noted on the type plate, using the
supplied power cable.
The power plug must be easily accessible
so that the device can be disconnected at
all time. The unit is live, even if in standby
mode, as long as the unit is connected to
a power outlet.
It is recommended that this unit is placed
on a dedicated circuit.
- Do not overload the power outlets by
connect too many appliances to the
same outlet. Overloaded wall outlets,
extension cords, etc. are dangerous
and can result in electric shock and
re.
After power off, don't turn it on again in
5 seconds. Frequent switching power
supply in a short period of time can cause
abnormal TV.
Power plug and power cable
- Do not touch the power plug with wet
hands.
- Do not place heavy objects on the
power cable. Route the cable so that it
is not kinked or laid over sharp edges,
walked on or exposed to chemicals. A
power cable with damaged insulation
can cause electric shock and re.
- Pull the power plug, NOT on the cable
when disconnecting. The cable can
become damaged and cause a short
circuit if pulled on.
- Do not place the power cable near a
high temperature object.
- Do not move the TV with the power
cable plugged into a socket.
- Do not use a damaged or loose power
cable, or a damaged socket outlet.
- Do not use any power cords other
than the one supplied with this unit.
Set-up
Check that the location is suitable to bear
the load of the TV. Place on a level, sturdy
and horizontal base. Ensure that the unit
does not hang over the edge of the base
when placed in or on furniture. If placed
on a cart, use caution when moving to
avoid the unit from tipping over.
- Place the unit in a normal upright
horizontal position. It must never
be operated vertically, lying at or
hanging overhead from the ceiling.
- Place the unit where it is not exposed to
direct sunlight or other sources of heat.
When mounting the TV on a wall, follow
the instructions supplied with the wall-
mount, make sure not to install the TV by
hanging the power and signal cables on
the back of the TV.

D
Air ventilation and high
temperatures
Install your TV only where there is proper
ventilation, and ensure that there is at least
10 cm free space on the sides and 20 cm
above the unit for air circulation. Excessive
heat and obstruction of ventilation could
lead to re or early failure of some electric
components.
- Do not block any ventilation openings
with newspapers, tablecloths, curtains,
etc.
- Do not dry clothing etc. on top of the unit.
- Take care not to touch the ventilation
openings since they may become hot.
- Do not insert foreign objects into the TV
through the vents.
The Stand
- Do not use any stand other than the one
supplied with this unit.
- Do not modify or use the stand if it
becomes warped of physically damaged.
- During setup, make sure that all the
screws are securely tightened.
- Ensure that the TV does not suffer any
impact during the attachment of the
stand.
- Ensure that children do not climb onto
the stand.
- Attach or remove the stand with at least
two people.
20cm
10cm
10cm
10cm
Important Safety Instructions
Prevent small items from getting into the
interior of the device through the ventilation
slots. Such objects may cause short circuits,
which may cause re.
If something should get inside the unit,
immediately unplug the power plug of the
device and contact service support.
The LED screen
Despite thorough care when manufacturing
this display, it cannot be 100% guaranteed
that no sub-pixel defects will occur due
to technical reasons. These cannot be
considered as a device defect in terms
of the guarantee. They will not affect the
performance and reliability of the TV.
To prevent “image burn”, avoid displaying
still images for long periods of time, there
is a possibility that a copy of the image
may remain. If the aspect ratio is set to 4:3
for a long period of time, image burn may
occur on the black areas. Image burn is not
covered by the warranty.
- Do not apply strong force or impact on
the display panel.
Avoid touching the LED screen or touching
it for long periods of time. Doing so may
produce some temporary distortion effects
on the screen.
Radio waves
- Do not use the TV in any medical
institutions or locations with medical
equipment. Radio waves may interfere
with medical equipment and cause
malfunction.
- Do not use the TV near any automatic
control equipment such as automatic
doors or re alarms. Radio waves
may interfere with automatic control
equipment and cause malfunction.

E
Important Safety Instructions
If you have a cardiac pacemaker, keep a
distance of at least 22 cm from the TV. Radio
waves may interfere with the operation of a
pacemaker.
Built-in wireless LAN
- Do not connect to wireless networks
that you do not have the usage rights
for. Data transmitted and received over
radio waves may be intercepted and
monitored.
The built-in wireless LAN uses 2.4 GHz
and 5 GHz frequency bands. To avoid
malfunctions or slow response caused by
radio wave interference, keep the TV away
from devices such as other wireless LAN
devices, microwaves, mobile phones, and
other devices that use 2.4 GHz and 5 GHz
signals.
Warning about off-gassing
New furniture, carpet, paint, building
materials and electronics can release
chemicals into the air through evaporation.
After you set your TV up and turn it on for
the rst time, you may notice a slight smell
within a couple of hours. This is because
some components of TV are heating up
for the rst time. The materials that we use
fully meet the environmental requirements
and regulations. Your TV is working just
ne and the fumes from the off-gassing
will diminish eventually.
Supervision
- Do not let children play unsupervised
close to the TV. It could tip over, be
pushed off or pulled down from the
stand surface and injure someone.
- Do not allow a switched-on TV to run
unattended.
Volume
Loud music and noises can lead to
irreversible damage to your ears. Avoid
extreme volume, especially over long
periods and when using headphones.
If you hear a drumming noise in your ears,
turn down the volume or temporarily stop
using headphones.
Thunder Storms
Pull out the power plug and all connected
antenna cables from the TV during a
thunderstorm. Overvoltage caused by
lightning strikes can damage the TV via
the antenna system, as well as the wall
socket.
Long periods of absence
As long as the power plug is connected to
a live socket outlet, the TV will consume
power even in standby mode. The power
plug and all connected antenna cables
should be disconnected out during long
periods of absence.

F
Cleaning and care
CAUTION:
Unplug the power cord prior to cleaning
the TV.
Clean the TV, the screen, and the remote
control with a soft, moist, clean and
color-natural cloth only. Do not use any
chemicals.
- Do not subject the surfaces to insect
repellent, solvent, thinner or other
volatile substances. This may degrade
the surface quality.
- Do not spray water or other liquids
directly on the TV. Liquid inside the TV
could lead to product failure.
- The surface of the display panel is
treated and may be easily damaged.
Take care not to scratch it with
ngernails or other hard objects.
- Also wipe the power plug with a dry
cloth at regular intervals.
Service/Repair
Never remove the cover/back of the TV;
there are no user serviceable parts inside.
Refer all service to qualied service
personnel.
Packaging
Keep the anti-moisture materials and
plastic bags out of reach of children.
Plastic bags can cause suffocation and
the anti-moisture material is harmful if
swallowed. If swallowed by mistake, force
the patient to vomit and visit the nearest
hospital.
Modication
Do not attempt to modify this product
in any way. Unauthorized modication
could void the warranty of this unit, cause
electric shock and res.
Remote Control batteries
- Incorrect installation may cause battery
leakage, corrosion and explosion.
- Replace only with the same or
equivalent type.
- Do not mix old and new batteries.
- Do not mix different battery types.
- Do no use rechargeable batteries.
- Do not burn or break up batteries.
- Be sure to dispose of batteries
correctly.
- Do not expose batteries to excessive
heat such as sunshine, re or the like.
Outdoor Antenna Grounding
If an outdoor antenna used, be sure the
antenna system is protected against
voltage surges and built-up static charges.
Disposal
Refer to the recycling section of this manual.
Important Safety Instructions

1
Contents
Contents
Accessories List
The following accessories are included with TV:
Product image is only for reference, actual product may vary in appearance.
Parts of the software function changes with the system upgrade.
Accessories List..............................................................................................................1
Installing the Stand or Wall mount bracket .....................................................................2
TV Front..........................................................................................................................5
TV Rear ..........................................................................................................................6
Making Connections.......................................................................................................7
Remote Control ............................................................................................................10
Turning the TV on for the First Time.............................................................................13
Specifications ...............................................................................................................14
Other Information..........................................................................................................18
User Manual × 1 European Guarantee × 1 Base Stand × 1
Remote Control × 1 AAA Battery × 2 Screw × 9
Power Cord × 1 Column Base × 1

2
Installing the Stand or Wall mount bracket
Installing the Stand
CAUTION
Be sure to disconnect the A/C power cord before installing a stand or Wall-Mount
brackets.
The LED display is very fragile, and must be protected at all times when installing
the base stand. Be sure that no hard or sharp object, or anything that could scratch
or damage the LED display, comes into contact with it. DO NOT exert pressure on
the front of the TV at any time because the screen could crack.
Follow the illustrations and textual instructions below to complete the installa-
tion steps:
Product images are only for reference, actual product may vary in appearance.
NOTE
1. Carefully place your TV face-down on a soft, flat surface to prevent damage to the
TV or scratching to the screen.
2. Open Base Cover by using the bulge on it and take it away. Base Cover is on the
back cover and at the place that used to fix the base.
3. Using the 5 screws in the accessory bag, secure the Column Base to the Base
Stand tightly.
Column Base
Base Stand
Screws:
M5×10 (50"/55")
M5×12 (65")
Base Cover

3
Installing the Stand or Wall mount bracket
Base Cover
5. Install the Base Cover downward at the place shown in the illustration.
4. Secure the base assembly to the TV with the 4 screws in accessory tightly.
base assembly
Screws:
M5×10 (50"/55")
M5×12 (65")
1. Remove the Top Cap and Side Cap from the base column.
Installing the Cable Clamp
Top Cap
Side Cap

4
Installing the Stand or Wall mount bracket
2. The three Cable Clamps in the Column Base will help you to arrange the power
cable.
3. After nish arranging the power cable, install the Top Cap and Side Cap back to the
Column Base.
9.5 -11.5 mm
Wall mount bracket
(not provided)
Screw (not provided)
Spacer (not provided)
Rear cover of the TV
Wall mount hole pattern VESA (mm) 400 × 200
Wall mount screw size (mm) M6
The diameter and length of the screws differ depending on the wall mount bracket model.
Follow instructions provided with the Wall mount bracket.
NOTE
Installing the wall mount bracket (not included)
Cable Clamp

5
TV Front
TV Front
NOTES
Powering on the TV requires several seconds to load programs. Do not rapidly
turn the TV off as it may cause the TV work abnormally.
Single button (Remote sensor / Power indicator / Standby)
Item Description
Remote sensor
Receive remote signals from the remote control.
Do not put anything near the sensor, as its function may be
affected.
Power indicator The light is red in standby mode.
Standby / Source
Press the single button when in standby mode, TV will be turned
on. Press the single button to call up the menu, when the focus
is on "Power Off", long press the single button to turn the TV into
standby mode.
/ Press the single button to call up the menu and then select
among the different input signal sources.

6
TV Rear
TV Rear
NOTES
ANT2 Jack supports power supply for satellite antenna
(13/18V, 0.5A max.)
Check the jacks for position and type before making any
connections. Loose connections can result in image or
color problems. Make sure that all connections are tight and
secure.
Not all A/V devices have the ability to connect to a TV, please
refer to the user’s manual of your A/V device for compatibility
and connections procedure.
Before connecting external equipment, remove the mains
plug from the wall socket. Otherwise, it may cause electric
shock.
ANT 1
DVB-T/T2/C
ANT 2
DVB-S/S2
DC 5V 0.5A(MAX)
USB 1
DC 5V 1A(MAX)
USB 2 HDMI 3(4K@30Hz) HDMI 2(4K@60Hz) HDMI 1(4K@60Hz)
ARC
HDMI 4(4K@30Hz)
HDMI 4(4K@30Hz)
Power input
VIDEO
VIDEO
L
L
R
R
AV IN
AV IN
COMMON INTERFACE
DIGITAL
AUDIO OUT
SERVICE
LAN
LAN
50"
55"/65"
Note: There's one screw at
the place of arrow and it is
usually covered by an AC
INPUT label.

7
Making Connections
LAN (Wired setup)
Connect your TV to your network by connecting the LAN port on the back of your
TV to an external modem or router using a LAN (Ethernet/Cat 5) cable. See the
illustration below.
Wireless setup
Connect your TV to your network wirelessly, you need a wireless router or modem.
See the illustration below.
Wireless router with DHCP
LAN Cable
Wireless LAN Adapter
built-in TV set
TV JACK
Modem CableLAN CableLAN Cable
External Modem
(ADSL / VDSL / Cable TV)
IP Sharer (Router)
(with DHCP server)
LAN
NOTES
You must use the built-in Wireless LAN Adapter to use a wireless network because
the set doesn’t support external USB network adapter.
If the wireless router supports DHCP, your TV can connect more easily to the wireless
network.
If you apply a security system other than the systems listed below, it will not work with
the TV.
security system:WPA,WEP,WPA2.
In order to guarantee smooth network, the distance between router and TV should be
less than 10 meters.

8
Making Connections
Outdoor
Antenna
Antenna Cable (75Ω)
or ANT OUT
Cable
VHF/UHF Antenna
Satellite antenna
ANT 1
DVB-T/T2/C
ANT 2
DVB-S/S2
DIGITAL AUDIO cable (not included)
Audio Amplier/Speaker
ANT
AV
DIGITAL
AUDIO OUT
HDMI
HDMI
(ARC)
HDMI
HDMI cable (not included)
HDMI cable (not included)
(Cables are not included)
(Cables are not included)
HDMI
Audio Amplier/Speaker
HDMI
ARC
HDMI
DVD/Blu-Ray/AV receiver/
Set-top Box
HDMI
White(L)
White(L)
Red(R)
Red(R)
Yellow(Video)
Yellow(Video)
VCR/DVD Player/
Recorder/Set-top box/
Satellite Receiver/
Video Camera
VCR/DVD Player/
Recorder/Set-top box/
Satellite Receiver/
Video Camera
Video L
A/V OUT
R
Video L
A/V OUT
R
(not included)
VIDEO VIDEO
L L
R R
AV IN
AV IN
DIGITAL
AUDIO OUT
55"/65"
50"

9
Making Connections
NOTES
When connecting a hard disk or a USB hub, always connect
the mains adapter of the connected device to the power
supply. Exceeding a total current consumption may result in
damage. The USB1.1 and USB2.0 devices maximum current
consumption are 500mA. The USB3.0 device maximum current
consumption is 1A.
For individual non-standard high-capacity mobile hard disk, if
its impulse current is greater than or equal 1A, it may cause
TV-rebooting or self-locking. So the TV does not support it.
The USB port supports a voltage of 5V.
SMART CARD
CAM CARD
12
NOTES
Before you insert/remove the CI+ module, ensure that the TV
is switched off. Then insert the CI card into the CI+ module in
accordance with the Service Provider’s instructions.
Do not repeatedly insert or remove the Common Access
Module as this may damage the interface and cause a
malfunction.
You must obtain a CI+ module and card from the service
provider of the channels you want to watch.
Insert the CI+ module with the SmartCard in the direction
marked on the module and SmartCard.
CI+ is not supported in some countries and regions; check with
your authorized dealer.
COMMON
INTERFACE
USB
USB 1
DC 5V 0.5A(MAX)DC 5V 1A(MAX)
USB 2

10
Remote Control
1POWER: Switch the TV on or into standby
mode
2INPUT: Select input sources
3P.Mode: Picture Mode button
4S.Mode: Sound Mode button
5Sport: Enter Sports of Picture Mode and
Sound Mode
6SLEEP: Set the sleep timer
7Channel Number: Direct channel selection or
numbers input
8GUIDE: Display the Electronic Program Guide
(DTV mode)
9INFO: Display the present program information
10 CH.List: Display the Channel List on the
screen
11 MUTE: Mute or restore the TV sound
12 VOL / : Adjust the volume
13 CH / : Switch channel
14 HOME: Enter the Smart
15 SETTING: Display the Settings menu
16 Display the Quick setup menu
17 / / < / >: Allows you to navigate the OSD
menus and adjust the system settings to your
preference
18 OK: Confirm the selection in the OSD menus
19 BACK: Return to previous menu
20 EXIT: Exit the menu
21 Colour keys for direct selection of options
22 Playback keys
23 PVR: Record the current program
(DTV mode)
24 Subtitle: Activate or deactivate the subtitle
mode
25 TXT: Turn on/off the teletext function
26 Language: Select the audio languages (only
applicable when the TV program has this
feature)
1
5
3
8
12
10
15
18
17
21
20
23
25
22
2
6
9
4
7
13
14
16
19
11
26
24

11
Remote Control
27
27 NOTE: The information here will vary
depending on the remote control model.
App: Quick access to the app
Media: Enter the media mode

12
1. Slide the back cover to open the battery compartment
of the remote control.
2. Insert two AAA size batteries. Make sure to match
the (+) and ( - ) ends of the batteries with the (+)
and ( - ) ends indicated in the battery compartment.
3. Close the battery compartment with the cover.
Installing Batteries in the Remote Control
Remote Control
Remote Control Operation Range
NOTES
Product image is only for reference, actual product may vary in appearance.
Handling the Batteries
Incorrect use of batteries may cause corrosion or battery leakage, which could
cause fire, personal injury or damage to property.
Only use the battery type indicated in this manual
Do not mix old and new batteries or different types of batteries .
Do not dispose of used batteries as domestic waste. Dispose of them in
accordance with local regulations.
