USER’S OPERATION MANUAL
Before operating this unit, please read this manual thoroughly,
and retain for future reference
WFQP6010EVM*
WFQP6012EVM*
WFQP7012EVM*
WFQP6010VM*
WFQP6012VM*
WFQP7012VM*

6$)(7<,1)250$7,21
*/45"--"5*0/(6*%&

The manufacturer reserves the right for any modifications
on the product which might be deemed necessary or
useful without informing about it in this IFU.
Before operating your new washing machine, please read
this instruction carefully, and keep it for future reference. If
you have lost it accidentally, ask customer service for e-
copy or hard copy.
Please make sure the socket is grounded securely, the
water source connection is reliable.
4. This appliance is not to be used by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
5. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
6. Children should be supervised to ensure that they do not
play with the appliance.
7. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
8. The new hose-sets supplied with the appliance are to be
used and that old hose-sets should not be reused.
SAFETY INFORMATION
1.
2.
3.
1
1

9. For appliances with ventilation openings in the base, that a
carpet must not obstruct the openings.
10. Children of less than 3 years should be kept away unless
continuously supervised.
11. The maximum permissible inlet water pressure, 1 MPa, for
appliances intended to be connected to the water mains.
The minimum permissible inlet water pressure, 0.1 MPa, if
this is necessary for the correct operation of the appliance.
2
12.
13.
14.
The maximum washing capacity is 6/7kg.
For private domestic use only.
2

3
ensure
Ensure
Single inlet -
Dual inlet - and cold
only
Ensure that the ventilation openings in the base of the washing machine
(if available on your model) are not obstructed by a carpet or other material.
3

that
the
ing
615 mm
855 mm
4

en the
from the mains supply,
,
the mains.
5
The symbol on the product, or on the documents accompanying the product
indicates that this appliance may not be treated as housedhold waste. instead it
shall be handed over to the applicable collection point for the recycling of electrical
and electronic equipment. Disposal must be carried out in accordance with local
environmental regulations for waste disposal. For more detailed information about
treatment, recovery and recycling of this product, please contact your local city
office, your household waste disposal service or the shop where you purchased
the product.
This appliance is marked according to the European directive on Was
te Electrical and Electronic Equipment (WEEE). By ensuring that this
product is disposed of correctly, you will help prevent potential negati
ve consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handl
ing of this product.

Control panel layout and
appearance will depend on the model.
6
Clean the outside of the washing machine with a damp cloth. Do not use abrasive
detergents.
Never open the door forcibly or use it as a step.
DESCRIPTION OF THE WASHINGMACHINE
6

7
1. Sort the laundry according to...
Type of fabric / care label symbol
Cottons, mixed fibres, easy care/synthetics, wool, handwash items.
2. Empty all pockets
Coins, safety pins etc. can damage your laundry as well as the appliance drum and
tub.
3. Fasteners
Close zips and fasten buttons or hooks; loose belts or ribbons should be tied
together.
Stain removal
Blood, milk, eggs etc. are generally removed by the automatic enzyme phase of the
programme.
To remove any residual water used during testing by the manufacturer, we
recommend that you carry out a short wash cycle without laundry.
1 Open the tap.
2 Close the door.
3 Pour a little detergent (about 30 ml) into the main wash chamber of the deter-
gent dispenser .
4 Select and start a short programme (see separate quick reference guide).
BEFORE THE FIRST WASH CYCLE
PREPARATION OF THE WASHING
7
Colour
Separate coloured and white items. Wash new coloured articles separately.
Loading
Wash items of different sizes in the same load to improve washing efficiency and
distribution in the drum.
Delicates
Wash small items (e.g. nylon stockings, belts etc.) and items with hooks (e.g. bras)
in a cloth bag or pillow case with zip. Always remove curtain rings or wash curtains
with the rings inside a cotton bag.

8
U
.
Open the door.
8

9
9
A
Fabric softener
Liquid starch
Pour additives only up to the “Max” mark.

10
unds
10

11
Press the release lever in the main wash compartment downward and
remove the drawer(fig.“A”).
Remove siphon cap from the fabric softener compartment (fig.“B”).
Refit the siphon in the detergent drawer and fit the drawer back inside its housing.
2 Insert removal tool like slotted screwdriver into the small opening of bottom
baffle, press the bottom baffle downward with much strength and open it.
1
if it fails to perform spin cycles.
Ensure that the water has
We recommend that you check and clean the filter regularly, at least two or three
times a year.
11
$%

12
3 Put a flat container under filter door and then drain with emergency drain pipe
(see [draining residual water] for specific operation methods). Then, loosen
filter anticlockwise and completely unscrew and remove the filter.
Check the supply hose regularly for brittleness and cracks and replace it if
necessary using a new hose of the same type(available from After-Sales Service
or specialist dealer).
4
5
6
7
12

13
D
13

14
solv
too
14

15
remove some
15

17
Fault Code List
Displayed on Display Window Fault Description
“F01” Water inflow fault
“F03” Drainage fault
Electronic module fault.
“F13” Door lock fault
“F14” Door unlock fault
“Unb” Unbalance alarm
Overflow or too much foam.
“F24”
else fault code, “F04-F98”
Ensure that
a. “F01” displayed on screen
The machine is not fed with water or insufficient water. Check:
Faucet is fully open and has enough water pressure.
Water inlet pipe is knotted or not.
Filtering net of water inlet pipe is blocked or not (refer to maintenance and
repair).
Water pipe is frozen or not.
Press “Start/Pause” key after fault is removed.
If fault occurs again, please contact with after-sale service (refer to after-sale
service.).
b. “F03” displayed on screen
The washer is not emptied. The washer stops the program being executed. Shut
down the machine and disconnect power supply. Check:
Drain pipe is knotted or not.
Filter in drain pump is blocked or not (refer to the cleaning of filter in drain pump)
Spin Start/Pause
16

18
nb” is shown
Unbalance alarm shall be solved by the following methods
1.Laundry winding
Turn the knob to “off” for 3 seconds for shutdown, open the door, shake the clothes and
put them back into the washing machine, then select the single dewatering program to
dry again.
2.Too light-weighted laundry
Turn the knob to “off” for 3 seconds for shutdown, open the door, put in one or two
towels, and then select the single dewatering program to dry again.
C.Fault code
The washer stops when the program is running. The display window shows
fault code “F13”, “F14”, “F24”, else fault codes from “F04” to “F98” or “Unb”.
,IIDXOWFRGHk)lLVVKRZQ
Door lock is abnormal. Start program for 20 sec and unlock the washer door
(PTC) to check whether the door is closed.
Open or close it again.
After fault is removed, press “Start/Pause” key. If fault occurs again, disconnect
power supply and contact with after-sale service.
,IIDXOWFRGHk)lLVVKRZQ
Door open fault.
Action: Press “Start/Pause” button. The washing machine will try to open the door.
The alarm will not be removed until the door is unlocked. Or, turn the nub to Off for 3
seconds to turn off the machine. Choose the desired programmme to start the
machine. The alarm will be removed.
,IIDXOWFRGHk)lLVVKRZQ
Water level reaches overflow level.
Remove it by pressing “Start/Pause” key and feed water.
Select and start required program. If fault occurs again, disconnect power supply
and contact with after-sale service.
If HOVHfault code “F04” to “F” LVshown
Electronic module fails.
Turn the nub to Off for 3 seconds to turn off the machine.
After fault is removed, press “Start/Pause” key. If fault occurs again, disconnect
power supply and contact with after-sale service.
