POWER TOOLS
TECHNICAL DATA
AND
SERVICE MANUAL
METAL CUTTER
CD 7
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT
LIST No. 0788 Nov. 2000
C
MODEL
CD 7

--- 24 ---
METAL CUTTER
Model CD 7
2000•10•5
(E1)
LIST NO. 0788
ELECTRIC TOOL PARTS LIST

--- 25---
PARTS
CD 7
: ALTERNATIVE PARTS
ITEM
NO. CODE NO. DESCRIPTION NO. USED
REMARKS
1 307-290 DUST COVER (B) 1
2 CAUTION PLATE 1
3 993-604 GLASS PLATE 1
4 307-291 DUST COVER (C) 1
5 307-292 O-RING (4PC-5) 1
6 301-801 WING BOLT M6X27 1
7 305-095 TAPPING SCREW (W/FLANGE) D4X20 3
8 608-VVM BALL BEARING 608VVC2PS2L 1
9 307-285 SPINDLE AND GEAR SET 1
10 873-095 O-RING (P-16) 1
11 958-385 BEARING HOLDER 1
12 305-568 SEAL LOCK FLAT HD. SCREW M5X12 2
13 961-807 BUSHING 1
14 307-287 SAFETY COVER 1
15 957-062 RETURN SPRING 1
16 620-2DD BALL BEARING 6202DDCMPS2L 1
17 940-868 BEARING CAP 1
18 307-635 MACHINE SCREW (W/SP. WASHER) M4X10 3
19 961-366 DISTANCE PIECE 1
20 957-076 WASHER (A) ASS'Y 1 INCLUD.19
21 307-276 TCT SAW BLADE 185MM-D20 HOLE-NT38 1
22 957-064 WASHER (B) 1
23 957-749 BOLT (W/WASHER) M7X17.5 1
24 307-289 DUST COVER (A) 1
25 303-796
MACHINE SCREW (W/WASHERS) M5X40 (BLACK) 3
26 307-277 HOUSING ASS'Y 1 INCLUD.44,45
27 608-VVM BALL BEARING 608VVC2PS2L 1
28 956-387 DUST SEAL (A) 1
29 930-703 BRUSH TERMINAL 2
30 340-491D STATOR ASS'Y 110V 1 INCLUD.29
31 987-940 FAN GUIDE 1
32 360-546D ARMATURE 110V 1
33 987-981 LOCK LEVER 1
34 600-1VV BALL BEARING 6001VVCMPS2L 1
35 958-130 RUBBER RING 1
36 981-205 SIDE HANDLE FOR M10 1
37 307-634
MACHINE SCREW (W/WASHER) M4X10 (BLACK)
1
38 307-280 PROTECTOR (A) 1
39 307-281 PROTECTOR (B) 1
40 307-284 GEAR COVER 1
41 961-729 CUSHION 1
42 949-794 FLAT HD. SCREW M6X20 (10 PCS.) 1
43 303-331 WING BOLT M6X37 2
44 938-477 HEX. SOCKET SET SCREW M5X8 2
45 957-774 BRUSH HOLDER 2
46 999-043 CARBON BRUSH (1 PAIR) 2
47 935-829 BRUSH CAP 2
48 NAME PLATE 1
49 960-251 HEX. HD. TAPPING SCREW D5X65 2
50 301-713 HEX. BOLT M8X8.5 1
51 670-514 RETAINING RING (E-TYPE) FOR D10 SHAFT 1
*10 --- 00

--- 26 ---
PARTS
CD 7
ITEM
NO. CODE NO. DESCRIPTION NO.
USED
REMARKS
52 983-863 LEVER 1
53 949-426 WASHER M8 (10 PCS.) 1
54 307-294
MACHINE SCREW (W/WASHERS) M5X16 (BLACK) 4
55 307-028
TAPPING SCREW (W/FLANGE) D4X25 (BLACK) 2
56 307-278 HANDLE (A) 1
57 307-282 SUPPORT (B) 1
58 959-141 CONNECTOR 50092 (10 PCS.) 5
59 957-764 SWITCH (1P PILLAR TYPE) W/LOCK 1
60 307-279 HANDLE (B) 1
61 941-055 WING BOLT M6X15 1
62 941-056 SPRING 1
63 949-576 ROLL PIN D6X32 (10 PCS.) 1
64 307-286 BASE ASS'Y 1 INCLUD.61,62
65 938-051 CORD ARMOR D10.1 1
66 930-055 CORD 1
67 319-521 INTERNAL WIRE 1
68 319-351 NOISE SUPPRESSOR 1
69 984-750 TAPPING SCREW (W/FLANGE) D4X16 2
70 937-631 CORD CLIP 1
: ALTERNATIVE PARTS
*
10 --- 00

--- 27 ---
OPTIONAL ACCESSORIES
ITEM
NO. CODE NO. DESCRIPTION NO.
USED
REMARKS
601 307-580 TCT SAW BLADE 185MM-D20 HOLE-NT38 1
602 307-900 TCT SAW BLADE 185MM-D20 HOLE-NT48 1
603 307-847 TCT SAW BLADE 185MM-D20 HOLE-NT48 1
: ALTERNATIVE PARTS
*
STANDARD ACCESSORIES
CD 7
ITEM
NO. CODE NO. DESCRIPTION NO.
USED
REMARKS
501 940-543 BOX WRENCH 10MM 1
502 875-769 EYE PROTECTOR 1
503 316-106 GUIDE WITH WING BOLT AND SPRING 1 INCLUD.504,505
504 307-898 WING BOLT M6X18 1
505 941-056 SPRING 1
10 --- 00
