Hitachi EX 1200-6 User manual

EM18J-EN1-9EX1200-6 HYDRAULIC EXCAVATOR OPERATOR’S MANUAL
Serial No 1558 and up
Hydraulic Excavator
PRINTED IN JAPAN (E) 2019, 09
1200-6
This book is printed on recycled paper.
EM18J-EN1-9
PART NO.
Operator’s Manual
URL:http://www.hitachi-c-m.com

INTRODUCTION
Read this manual carefully to learn how to operate and
service your machine correctly. Failure to do so could
result in personal injury and/or machine damage.
This standard specification machine can be operated
under the following conditions without being modified.
Atmospheric Temperature: -20 °C to 50 °C (-4 °F to 122 °F)
Altitude: 0 m to 2000 m (0 ft to 6600 ft)
In case the machine is used under conditions other than
described above, consult your authorized dealer.
This manual should be considered a permanent part of
your machine and should remain with the machine when
you sell it.
This machine is of metric design. Measurements in this
manual are metric. Use only metric hardware and tools as
specified.
• SI Units (International System of Units) are used in
this manual.
For reference MKS system units and English units are
also indicated in parentheses after the SI units.
Example : 24.5 MPa (250 kgf/cm², 3550 psi)
Right-hand and left-hand sides are determined by
facing in the direction of forward travel.
Write product identification numbers in the Machine
Numbers section. Accurately record all the numbers
to help in tracing the machine should it be stolen.
Your dealer also needs these numbers when you order
parts. If this manual is kept on the machine, also file the
identification numbers in a secure place off the machine.
Use only diesel fuel with quality specified in JIS K-2204,
EN-590 or ASTM D-975 which contents 15 ppm or lower
sulfur.
Also use fuel that complies with solid contamination level
of class 18/16/13 of ISO4406-1999 (solid contamination
includes dust). If the fuel specified above is not used,
exhaust gas that exceeds the regulation values may be
discharged, causing serious problem on the engine.
Consult your authorized dealer.
Warranty is provided as a part of Hitachi’s support
program for customers who operate and maintain their
equipment as described in this manual. The warranty is
explained on the warranty certificate which you should
have received from your dealer.
All information, illustrations and specifications in this manual are based on the latest product information available at the
time of publication. The right is reserved to make changes at any time without notice.
©2019 Hitachi Construction Machinery Co., Ltd.
All rights reserved.
This warranty provides you the assurance that Hitachi will
back its products when defects occur within the warranty
period. In some circumstances, Hitachi also provides field
improvements, often without charge to the customer,
even if the product is out of warranty.
Should the equipment be abused or modified to
change its performance beyond the original factory
specifications, the warranty will become void and field
improvements may be denied.
Setting fuel delivery above specifications or otherwise
overpowering machines will result in such action.
Moreover, when replacement parts are required, be sure
to use genuine Hitachi parts. Failure to do so may result in
voiding the warranty and/or denial of field improvements.
The Yellow Pages in this operator’s manual contain
IMPORTANT SAFETY INFORMATION.
Read these pages thoroughly and familiarize yourself
with the safety standards and recommendations set
forth in these yellow pages of the manual.
Follow all safety instructions prior to and while
operating the excavator.
Only qualified, experienced operators officially licensed
(according to local law) should be allowed to operate the
machine.
Moreover, only officially licensed personnel should be
allowed to inspect and service the machine.
Prior to operating this machine, including satellite
communication system, in a country other than a
country of its intended use, it may be necessary to
make modifications to it so that it complies with
the local regulatory standards (including safety
standards) and legal requirements of that particular
country. Please do not export or operate this machine
outside of the country of its intended use until such
compliance has been confirmed.
Please contact Hitachi Construction Machinery Co.,
Ltd. or any of our authorized distributor or dealer if
you have any questions concerning compliance.
Find manuals at https://best-manuals.com

INDEX
MACHINE NUMBERS
SAFETY
VISIBILITY MAP
COMPONENTS NAME
GETTING ON/OFF MACHINE
HANDLING LADDER
OPERATOR’S STATION
BREAK-IN
OPERATING ENGINE
DRIVING MACHINE
OPERATING MACHINE
TRANSPORTING
MAINTENANCE
MAINTENANCE UNDER SPECIAL ENVIRONMENTAL CONDITIONS
STORAGE
TROUBLESHOOTING
SPECIFICATIONS
INDEX
SAFETY SIGNS
Find manuals at https://best-manuals.com

Find manuals at https://best-manuals.com

CONTENTS
MACHINE NUMBERS ........................................................................1
SAFETY...............................................................................................S-1
Recognize Safety Information ....................................................S-1
Understand Signal Words.............................................................S-1
Follow Safety Instructions............................................................S-2
Prepare for Emergencies...............................................................S-2
Wear Protective Clothing..............................................................S-3
Protect Against Noise ....................................................................S-3
Inspect Machine ..............................................................................S-3
General Precautions for Cab........................................................S-4
Use Handholds and Steps ............................................................S-5
Adjust Operator’s Seat...................................................................S-5
Ensure Safety Before Rising From or Leaving Operator’s
Seat .................................................................................................S-5
Fasten Your Seat Belt......................................................................S-6
Move and Operate Machine Safely...........................................S-6
Handle Starting Aids Safely .........................................................S-6
Operate Only from Operator’s Seat ..........................................S-7
Jump Starting ...................................................................................S-7
Keep Riders off Machine...............................................................S-7
Precautions for Operations..........................................................S-8
Investigate Job Site Beforehand................................................S-9
Install OPG Guard......................................................................... S-10
Restriction of Attachment Installation .................................S-10
Provide Signals for Jobs Involving Multiple Machines....S-10
Confirm Direction of Machine to be Driven ....................... S-10
Drive Machine Safely................................................................... S-11
Avoid Injury from Rollaway Accidents.................................. S-13
Avoid Injury from Back-Over and Swing Accidents......... S-14
Keep Person Clear from Working Area.................................. S-15
Never Position Bucket Over Anyone .....................................S-15
Avoid Undercutting..................................................................... S-15
Avoid Tipping................................................................................. S-16
Never Undercut a High Bank....................................................S-16
Dig with Caution........................................................................... S-17
Operate with Caution ................................................................. S-17
Avoid Power Lines........................................................................ S-18
Precautions for Lightning..........................................................S-18
Object Handling ........................................................................... S-19
Protect Against Flying Debris and Falling Object............. S-20
Park Machine Safely..................................................................... S-21
Handle Fluids Safely – Avoid Fires.......................................... S-21
Practice Safe Maintenance........................................................ S-22
Warn Others of Service Work ................................................... S-23
Support Machine Properly........................................................ S-23
Stay Clear of Moving Parts ........................................................ S-24
Prevent Parts from Flying..........................................................S-24
Avoid Injury from Attachment Falling Accident ...............S-24
Prevent Burns................................................................................. S-25
Replace Rubber Hoses Periodically........................................S-25
Avoid High-Pressure Fluids.......................................................S-26
Prevent Fires................................................................................... S-27
Evacuating in Case of Fire.......................................................... S-29
Beware of Exhaust Fumes..........................................................S-29
Precautions for Welding and Grinding .................................S-29
Avoid Heating Near Pressurized Fluid Lines....................... S-30
Avoid Applying Heat to Lines Containing Flammable
Fluids ...........................................................................................S-30
Precautions for Handling Accumulator and Gas
Damper....................................................................................... S-30
Remove Paint before Welding or Heating........................... S-31
Beware of Asbestos and Silicon Dust and Other
Contamination......................................................................... S-31
Prevent Battery Explosions.......................................................S-32
Service Air Conditioning System Safely ............................... S-32
Handle Chemical Products Safely........................................... S-33
Dispose of Waste Properly......................................................... S-33
Never Ride Attachment.............................................................. S-33
Precautions for Communication Terminal...........................S-33
Precautions for Communication Terminal Equipment
(Optional)................................................................................... S-34
Machine Fire Suppression.........................................................S-36
VISIBILITY MAP ...........................................................................S-37
SAFETY SIGNS.............................................................................. S-38
COMPONENTS NAME ..................................................................1-1
Components Name ........................................................................1-1
GETTING ON/OFF MACHINE.....................................................1-2
Getting ON/OFF Machine.............................................................1-2
HANDLING LADDER.....................................................................1-3
Using Ladder (Optional)................................................................1-3
Operating Ladder on the Ground..............................................1-4
Extending .....................................................................................1-4
Retracting .....................................................................................1-4
Operating Ladder on the Upper-Structure............................1-4
Extending .....................................................................................1-4
Retracting .....................................................................................1-4
OPERATOR’S STATION.................................................................1-5
Cab Features......................................................................................1-5
Std. Model.....................................................................................1-5
Multi Function Monitor.................................................................1-6
How to Use Screens ..................................................................1-6
Displaying Basic Screen...........................................................1-6
Outline.................................................................................................1-7
Menu Screen (19).......................................................................1-9
Hour Meter................................................................................1-10
Fuel Gauge ................................................................................1-10
Clock............................................................................................1-10
Back Monitor Selector...........................................................1-10
Menu Key...................................................................................1-11
Optional Function Key ..........................................................1-11
Return to Basic Screen Key..................................................1-11
Alarm Light................................................................................1-11
Optional Function Display...................................................1-11
Coolant Temperature Gauge ..............................................1-12
Operating Status Icon Display............................................1-12
Displaying Basic Screen by Password Input
(Optional) .............................................................................1-13
In Case of Inputting an Incorrect Password ..................1-14
Extending Password Duration Time.................................1-16
Find manuals at https://best-manuals.com

CONTENTS
Alarm Occurrence Screen.......................................................... 1-17
Contents of Alarms ......................................................................1-19
Clock Setting..................................................................................1-22
Time Adjustment ....................................................................1-22
Password Change (Optional) ..............................................1-23
Back Monitor Settings ................................................................1-26
Auto-Control: ON....................................................................1-26
Auto-Control: OFF...................................................................1-27
Maintenance Settings.................................................................1-28
Maintenance Information Display ON/OFF...................1-28
Change Interval Settings......................................................1-29
Resetting Data..........................................................................1-30
Screen Display when Maintenance Information
Display is ON .......................................................................1-31
Language Settings.......................................................................1-33
Lists of Display Language ....................................................1-34
Switch Panel................................................................................... 1-35
Engine Control Dial......................................................................1-36
Auto-Idle Switch ...........................................................................1-36
Power Mode Switch.....................................................................1-37
Travel Mode Switch .....................................................................1-37
Work Light Switch ........................................................................1-38
Wiper/Washer Switch..................................................................1-39
Switch Panel (Optional Included)...........................................1-40
Travel Alarm Deactivation Switch (Optional)................1-41
Seat Heater Switch (Optional)............................................1-41
Boom Mode Switch................................................................1-42
Level Check Switch.................................................................1-42
Lubrication Mode Switch (Optional)................................1-42
Buzzer Deactivation Switch.................................................1-42
Key Switch.......................................................................................1-43
Horn Switch....................................................................................1-43
Cigar Lighter...................................................................................1-44
Operation...................................................................................1-44
Cab Light Switch...........................................................................1-45
Step Light Switch..........................................................................1-45
Installing Fire Extinguisher (Optional)..................................1-46
Engine Fault Diagnostics Switch.............................................1-46
Pilot Control Shut-Off Lever .....................................................1-47
Fuse Box 1 .......................................................................................1-48
Fuse Box 2 .......................................................................................1-48
Air Conditioner Operation ........................................................1-49
Features:.....................................................................................1-49
Auto Air Conditioner...................................................................1-50
Distinctive Feature..................................................................1-50
Controller Part Name and Function .................................1-51
Cab Heater Operation.................................................................1-55
Cooling Operation .......................................................................1-55
Defroster Operation ....................................................................1-56
Tips for Optimal Air Conditioner Usage ............................... 1-57
For Rapid Cooling ...................................................................1-57
When Windows Become Clouded ....................................1-57
Off-Season Air Conditioner Maintenance...................... 1-57
AM/FM Radio Operation............................................................1-58
Tuning Procedure ...................................................................1-58
Station Presetting Procedure..............................................1-58
Sound Adjustment .................................................................1-59
Digital Clock Setting Procedure..............................................1-59
Cab Door Release Lever .............................................................1-60
Opening Side Windows..............................................................1-60
Emergency Exit .............................................................................1-61
Emergency Exit (Elevated Cab)................................................1-62
Emergency Escape Rope (Elevated Cab)..............................1-63
Storing Emergency Escape Rope............................................1-63
Adjusting Seat ...............................................................................1-64
Seat Height and Angle Adjustment.................................1-64
Console and Seat Fore-aft Adjustment...........................1-64
Seat Fore-Aft Adjustment ....................................................1-64
Backrest Adjustment .............................................................1-64
Armrest Adjustment ..............................................................1-65
Adjusting Seat (Heater Seat Optional)..................................1-66
Seat Height and Angle Adjustment.................................1-66
Console and Seat Fore-aft Adjustment...........................1-66
Seat Fore-Aft Adjustment ....................................................1-66
Backrest Adjustment .............................................................1-66
Armrest Adjustment ..............................................................1-67
Seat Heater Switch .................................................................1-67
Adjusting Air-Suspension Seat (Optional)...........................1-68
Seat Height and Angle Adjustment.................................1-68
Console and Seat Fore-aft Adjustment...........................1-68
Seat Fore-Aft Adjustment ....................................................1-68
Suspension Adjustment.......................................................1-68
Backrest Adjustment .............................................................1-68
Armrest Adjustment ..............................................................1-69
Seat Heater Switch .................................................................1-69
Adjusting Console Height.........................................................1-70
Adjusting Procedures ............................................................1-70
Installation and Adjustment of Mirror and Camera.........1-71
Seat Belt...........................................................................................1-72
Seat Belt......................................................................................1-72
Battery Disconnect Switch........................................................ 1-73
How to operate the disconnect switch...........................1-73
BREAK-IN...........................................................................................2-1
Observe Engine Operation Closely...........................................2-1
Every 10 Hours or Daily .................................................................2-1
After the First 50 Hours .................................................................2-1
OPERATING ENGINE.....................................................................3-1
Inspect Machine Daily Before Starting....................................3-1
Before Starting Engine ..................................................................3-2
Level Check........................................................................................3-3
Starting Engine in Ordinary Temperature ..............................3-4
Starting Engine in Cold Weather................................................3-5
Check Instruments After Starting..............................................3-6
Using Booster Batteries.................................................................3-7
Stopping Engine..............................................................................3-9
Engine Stop Switch......................................................................3-10
DRIVING MACHINE .......................................................................4-1
Drive Machine Carefully................................................................4-1
Steering Machine Using Pedals..................................................4-2
Steering Machine Using Levers..................................................4-3
Travel Mode Switch ........................................................................4-4
Find manuals at https://best-manuals.com

CONTENTS
Travel Alarm (Optional) .................................................................4-4
Operating on Soft Ground...........................................................4-5
Raise One Track Using Boom and Arm ....................................4-5
Towing Machine a Short Distance.............................................4-6
Operating in Ground Condition.................................................4-7
Parking Machine on Slopes .........................................................4-8
Parking Machine..............................................................................4-8
OPERATING MACHINE.................................................................5-1
Control Lever (ISO Pattern Backhoe)........................................5-1
Control Lever (ISO Pattern Loading Shovel) ..........................5-2
Bucket Open-Close Pedals (Loading Shovel) ........................5-3
Control Lever (Hitachi Pattern Backhoe) (Optional) ...........5-4
Control Lever (Hitachi Pattern Loading Shovel)
(Optional)......................................................................................5-5
Pilot Control Shut-Off Lever ........................................................5-6
Warming-Up Operation ................................................................5-7
Auto-Idle.............................................................................................5-8
Engine Speed Control....................................................................5-9
Power Mode ................................................................................... 5-10
E (Economy) Mode.......................................................................5-11
P (Power) Mode.............................................................................5-12
H/P (High Power) Mode .............................................................5-13
Heavy Lift.........................................................................................5-14
Operating Backhoe......................................................................5-15
Grading Operation....................................................................... 5-15
Avoid Abusive Operation .......................................................... 5-16
Avoid Side Load the Bucket......................................................5-16
Operating Tips...............................................................................5-17
Select Correct Track Shoes ........................................................5-17
Operating Loading Shovel........................................................5-18
Prohibited Operation.................................................................. 5-18
Object Handling --- If Equipped.............................................. 5-21
Overnight Storage Instructions............................................... 5-22
TRANSPORTING.............................................................................6-1
Transporting......................................................................................6-1
MAINTENANCE...............................................................................7-1
Correct Maintenance and Inspection Procedures...............7-1
Check Hour Meter Regularly .......................................................7-2
Use Correct Fuels and Lubricants..............................................7-2
Maintenance Guide Table.............................................................7-3
Prepare Machine for Maintenance............................................7-6
Hood and Access Covers...............................................................7-8
Use Electrical Outlet (Optional)..................................................7-8
Construction Outline .....................................................................7-9
Hydraulic System..........................................................................7-11
Loading Shovel..............................................................................7-12
Backhoe ...........................................................................................7-13
Electrical Circuit ............................................................................7-14
EX1200-6 Electrical Circuit Diagram......................................7-15
Periodic Replacement of Parts.................................................7-17
Periodic Replacement of Rubber Hoses...............................7-18
Maintenance Interval Guide.....................................................7-21
A. Greasing......................................................................................7-25
Front Joint Pins ........................................................................7-26
Swing Bearing..........................................................................7-30
Lubricator ..................................................................................7-31
Swing Internal Gear................................................................7-33
Fan Pulley and Tension Pulley ............................................7-34
B. Engine..........................................................................................7-35
Check Engine Oil Level..........................................................7-36
Change Engine Oil..................................................................7-37
Replace Engine Oil Filter.......................................................7-37
C. Transmission..............................................................................7-39
Pump Transmission ................................................................7-40
Swing Reduction Gear ..........................................................7-43
Travel Reduction Gear...........................................................7-45
D. Hydraulic System.....................................................................7-47
Inspection and Maintenance of Hydraulic
Equipment ...........................................................................7-48
Check Hydraulic Oil Level ....................................................7-50
Drain Hydraulic Oil Tank Sump ..........................................7-51
Change Hydraulic Oil............................................................. 7-52
Suction Filter Cleaning..........................................................7-55
Replace Drain Filter ................................................................7-56
Replace Full-Flow Filter Element .......................................7-58
Replace Pilot Oil Filter............................................................7-60
Replace High-Pressure Filter Element ............................. 7-62
Replace Tank Air Breather Element...................................7-63
Check Hoses and Lines .........................................................7-64
E. Fuel System................................................................................7-70
Drain Fuel Tank Sump............................................................7-72
Drain Fuel Pre-Filter Sediment (Optional)......................7-73
Replace Fuel Pre-Filter Element (Optional).................... 7-74
Drain Fuel Filter Sediment................................................... 7-75
Replace Fuel Filter................................................................... 7-76
Check Fuel Hoses ....................................................................7-77
Clean Fuel Cooler Core..........................................................7-79
F. Air Cleaner...................................................................................7-80
Clean Air Cleaner Outer Element ......................................7-80
Replace Air Cleaner Outer and Inner Elements............7-80
G. Cooling System........................................................................ 7-82
Check Coolant Level ..............................................................7-83
Check DCA4 Concentration in Coolant........................... 7-84
Replace Coolant Filter ...........................................................7-92
Change Coolant.......................................................................7-93
Check Fan Belt for Wear........................................................7-94
Clean Radiator, Inter Cooler and Oil Cooler Core ........7-95
Clean Inter Cooler Front Screen......................................... 7-95
Clean Oil Cooler Front Screen.............................................7-95
H. Air Conditioner.........................................................................7-96
Recirculation Air Filter...........................................................7-96
Ventilation Air Filter ............................................................... 7-97
Check Refrigerant Quantity.................................................7-98
Check Compressor Belt Tension ........................................ 7-99
Clean Condenser Core ..........................................................7-99
Check Tightening Torque...................................................7-100
Seasonal Maintenance........................................................7-101
I. Electrical System......................................................................7-102
Batteries ...................................................................................7-103
Replacing Fuses.....................................................................7-107
Check Power Source Terminal..........................................7-109
Find manuals at https://best-manuals.com

CONTENTS
Check Electrical Cables and Wire Harnesses for
Short Circuits.....................................................................7-110
J. Miscellaneous ..........................................................................7-112
Check Bucket Teeth..............................................................7-113
Change Bucket (Backhoe)..................................................7-118
Check and Replace Seat Belt.............................................7-119
Check Windshield Washer Fluid Level...........................7-119
Check Track Sag.....................................................................7-120
Auto-Lubrication System ...................................................7-122
Check Tightening Torque of Bolts and Nuts................7-126
Check O-rings in Bucket Joints ........................................7-140
Check Handrails.....................................................................7-141
MAINTENANCE UNDER SPECIAL ENVIRONMENTAL
CONDITIONS....................................................................................9-1
Maintenance Under Special Environmental Conditions...9-1
STORAGE........................................................................................10-1
Storing Machine............................................................................10-1
Removing Machine from Storage ..........................................10-2
Transporting Machine ................................................................10-2
TROUBLESHOOTING.................................................................11-1
Engine Troubleshooting ............................................................11-1
How to Read Engine Fault Codes............................................11-2
Engine...............................................................................................11-3
Electrical System...........................................................................11-6
Mode Selection............................................................................. 11-8
Control Levers................................................................................11-8
Hydraulic System..........................................................................11-9
SPECIFICATIONS .........................................................................12-1
Specifications.................................................................................12-1
Working Range (Backhoe).........................................................12-3
Working Range (BE Backhoe)...................................................12-4
Working Range (Loading Shovel)...........................................12-5
Backhoe Shoe Types and Applications.................................12-6
Sound Level Results.....................................................................12-7
Electric Fans....................................................................................12-7
INDEX............................................................................................... 14-1
Find manuals at https://best-manuals.com

The manufacturing Nos. explained in this group is the
individual number (serial No.) given to each machine and main
components. These numbers are requested when inquiring
any information on the machine and/or components. Fill these
serial Nos. in the blank spaces in this group to immediately
make them available upon request.
Machine
1. MODEL/TYPE
2. Product Identification Number
3. Year of Manufacturing
4. Operating mass (standard version)
5. Engine power in kW according to ISO14396 ; 2002
MODEL/TYPE:
PRODUCT
IDENTIFICATION
NUMBER:
M142-12-001
Product Identification Number
PRODUCT
IDENTIFICATION
NUMBER:
fNOTE:
*HCM18J00A00001001*
Marks to indicate the
start and end of the PIN
PRODUCT IDENTIFICATION
NUMBER (PIN) M142-12-001
MACHINE NUMBERS
MZX5-00-001EN-EU
5 4
1 2 3
Find manuals at https://best-manuals.com

MACHINE NUMBERS
Engine
TYPE:
MFG. NO.:
Travel Motor
TYPE:
MFG. NO.: (LEFT)
MFG. NO.: (RIGHT)
Swing Motor
TYPE:
MFG. NO.: (FRONT)
MFG. NO.: (REAR)
Hydraulic Pump
TYPE:
MFG. NO.: (NO.1)
MFG. NO.: (NO.2)
MFG. NO.: (NO.3)
M142-12-003
M142-12-004
M18E-01-008
M183-01-001
Find manuals at https://best-manuals.com

MACHINE NUMBERS
Boom
TYPE:
MFG. NO.:
Arm
TYPE:
MFG. NO.:
Bucket
TYPE:
MFG. NO.:
M116-12-004
M111-12-005
M17V-00-005

MACHINE NUMBERS
MEMO
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................

Recognize Safety Information
These are the SAFETY ALERT SYMBOLS.
•When you see these symbols on your machine or in this
manual, be alert to the potential for personal injury.
•Follow recommended precautions and safe operating
practices.
Understand Signal Words
On machine safety signs, signal words designating the
degree or level of hazard - DANGER, WARNING, or CAUTION
- are used with the safety alert symbol.
•DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
•WARNING indicates a potentially hazardous situation
which, if not avoided, could result in death or serious
injury.
•CAUTION indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
•DANGER or WARNING safety signs are located near
specific hazards. General precautions are listed on
CAUTION safety signs.
•Some safety signs do not use any of the designated signal
words above after the safety alert symbol are occasionally
used on this machine.
To avoid confusing machine protection with personal
safety messages, a signal word IMPORTANT indicates a
situation which, if not avoided, could result in damage to
the machine.
fNOTE indicates an additional explanation for an
element of information.
S-1
SAFETY
SA-2644
SA-1223

Follow Safety Instructions
•Carefully read and follow all safety signs on the machine
and all safety messages in this manual.
•Safety signs should be installed, maintained and replaced
when necessary.
• If a safety sign or this manual is damaged or missing,
order a replacement from your authorized dealer in the
same way you order other replacement parts (be sure to
state machine model and serial number when ordering).
•Learn how to operate the machine and its controls correctly
and safely.
•Allow only trained, qualified, authorized personnel to
operate the machine.
•Keep your machine in proper working condition.
• Unauthorized modifications of the machine may impair
its function and/or safety and affect machine life.
• Do not modify any machine parts without authorization.
Failure to do so may deteriorate the part safety, function,
and/or service life. In addition, personal accident,
machine trouble, and/or damage to material caused by
unauthorized modifications will void Hitachi Warranty
Policy.
• Do not use attachments and/or optional parts or
equipment not authorized by Hitachi. Failure to do so
may deteriorate the safety, function, and/or service life
of the machine. In addition, personal accident, machine
trouble, and/or damage to material caused by using
unauthorized attachments and/or optional parts or
equipment will void Hitachi Warranty Policy.
•The safety messages in this SAFETY chapter are intended
to illustrate basic safety procedures of machines. However
it is impossible for these safety messages to cover every
hazardous situation you may encounter. If you have any
questions, you should first consult your supervisor and/or
your authorized dealer before operating or performing
maintenance work on the machine.
Prepare for Emergencies
•Be prepared if a fire starts or if an accident occurs.
• Keep a first aid kit and fire extinguisher on hand.
• Thoroughly read and understand the label attached on
the fire extinguisher to use it properly.
• To ensure that a fire extinguisher can be always used
when necessary, check and service the fire extinguisher
at the recommended intervals as specified in the fire
extinguisher manual.
• Establish emergency procedure guidelines to cope with
fires and accidents.
• Keep emergency numbers for doctors, ambulance
service, hospital, and fire department posted near your
telephone.
SAFETY
S-2
SA-003
SA-437

Wear Protective Clothing
•Wear close fitting clothing and safety equipment
appropriate to the job.
You may need:
A hard hat
Safety shoes
Safety glasses, goggles, or face shield
Heavy gloves
Hearing protection
Reflective clothing
Wet weather gear
Respirator or filter mask
Be sure to wear the correct equipment and clothing for the
job. Do not take any chances.
• Avoid wearing loose clothing, jewelry, or other items that
can catch on control levers or other parts of the machine.
•Operating equipment safely requires the full attention of
the operator. Do not wear radio or music headphones while
operating the machine.
Protect Against Noise
•Prolonged exposure to loud noise can cause impairment or
loss of hearing.
• Wear a suitable hearing protective device such as
earmuffs or earplugs to protect against objectionable or
uncomfortably loud noises.
Inspect Machine
•Inspect your machine carefully each day or shift by walking
around it before you start it to avoid personal injury.
• In the walk-around inspection be sure to cover all
points described in the“MAINTENANCE”chapter in the
operator’s manual.
SAFETY
S-3
SA-438
SA-434
SA-435

General Precautions for Cab
• Before entering the cab, thoroughly remove all dirt and/or
oil such as mud, grease, soil or stones that may mess up
the cab from the soles of your work boots. If any controls
such as a pedal is operated while with dirt and/or oil on
the soles of the operator’s work boots, the operator’s foot
may slip off the pedal, possibly resulting in a personal
accident.
• Do not mess up around the operator’s seat with parts,
tools, soil, stones, obstacles that may fold up or turn
over, cans or lunch box. The levers or pedals become
inoperable if obstacle jams in operation stroke of the
travel levers/pedals, pilot control shut-off lever or control
levers/pedals, which may result in serious injury or death.
• Avoid storing transparent bottles in the cab. Do not
attach any transparent type window decorations on
the windowpanes as they may focus sunlight, possibly
starting a fire.
• Refrain from listening to the radio, or using music
headphones or mobile telephones in the cab while
operating the machine.
• Keep all flammable materials and/or explosives away
from the machine.
• After using the ashtray, always cover it to extinguish the
match and/or tobacco.
• Do not leave cigarette lighters in the cab. When the
temperature in the cab increases, the lighter may
explode.
• Use proper floor mat dedicated to the machine. If another
floor mat is used, it may be displaced and contact with
the travel pedals or control pedals during operation,
resulting in serious injury or death.
SAFETY
S-4

Use Handholds and Steps
•Falling is one of the major causes of personal injury.
• When you get on and off the machine, always face the
machine and maintain a three-point contact with the
steps and handrails.
• Do not use any controls as hand holds.
• Never jump on or off the machine. Never mount or
dismount a moving machine.
• Be careful of slippery conditions on platforms, steps, and
handrails when leaving the machine.
• Never get on and off the machine with tools in your
hands.
Adjust Operator’s Seat
•A poorly adjusted seat for either the operator or the
work at hand may quickly fatigue the operator leading to
misoperations.
• The seat should be adjusted whenever changing the
operator for the machine.
• The operator should be able to fully depress the pedals
and to correctly operate the control levers with his back
against the seat back.
• If not, move the seat forward or backward, and check
again.
• Adjust the rear view mirror position so that the best rear
visibility is obtained from the operator’s seat. If the mirror
is broken, immediately replace it with a new one.
Ensure Safety Before Rising From or Leaving
Operator’s Seat
• Before rising from the operator’s seat to open/close either
side window or to adjust the seat position, be sure to
first lower the front attachment to the ground and then
move the pilot control shut-off lever to the LOCK position.
Failure to do so may allow the machine to unexpectedly
move when a body part unintentionally comes in contact
with control levers/pedals, possibly resulting in serious
personal injury or death.
• Before leaving the machine, be sure to first lower the
front attachment to the ground and then move the pilot
control shut-off lever to the LOCK position. Turn the key
switch OFF to stop the engine.
• Before leaving the machine, close all windows, doors, and
access covers and lock them up.
SAFETY
S-5
SA-439
SA-378

Fasten Your Seat Belt
•If the machine should overturn, the operator may become
injured and/or thrown from the cab. Additionally the
operator may be crushed by the overturning machine,
resulting in serious injury or death.
• Prior to operating the machine, thoroughly examine
webbing, buckle and attaching hardware. If any item is
damaged or worn, replace the seat belt or component
before operating the machine.
• Be sure to remain seated with the seat belt securely
fastened at all times when the machine is in operation to
minimize the chance of injury from an accident.
• We recommend that the seat belt is replaced every three
years regardless of its apparent condition.
Move and Operate Machine Safely
•Bystanders can be run over.
• Take extra care not to run over bystanders. Confirm the
location of bystanders before moving, swinging, or
operating the machine.
• Always keep the travel alarm and horn in working
condition (if equipped). It warns people when the
machine starts to move.
• Use a signal person when moving, swinging, or operating
the machine in congested areas. Coordinate hand signals
before starting the machine.
• Use appropriate illumination. Check that all lights are
operable before operating the machine. If any faulty
illumination is present, immediately repair it.
• Ensure the cab door, windows, doors and covers are
securely locked.
• Check the mirror and the monitors in the CAB for
problems. If there are, replace the problem parts or clean
the mirror, camera and monitor.
Refer to Back Monitor Settings section on the cleaning of
the camera and monitor.
Handle Starting Aids Safely
Starting fluid:
•Starting fluid is highly flammable.
• Keep all sparks and flame away when using it.
• Keep starting fluid well away from batteries and cables.
• Remove container from machine if engine does not need
starting fluid.
• To prevent accidental discharge when storing a
pressurized container, keep the cap on the container, and
store it in a cool, well-protected location.
• Do not incinerate or puncture a starting fluid container.
SAFETY
S-6
SA-237
SA-426
SA-293

Operate Only from Operator’s Seat
•Inappropriate engine starting procedures may cause the
machine to runaway, possibly resulting in serious injury or
death.
• Start the engine only when seated in the operator’s seat.
• Do not start engine by shorting across starter terminals.
• Before starting the engine, confirm that all control levers
are in neutral.
• Before starting the engine, confirm the safety around the
machine and sound the horn to alert bystanders.
Jump Starting
•Battery gas can explode, resulting in serious injury.
• If the engine must be jump started, be sure to follow the
instructions shown in the “OPERATING ENGINE”chapter in
the operator’s manual.
• The operator must be in the operator’s seat so that the
machine will be under control when the engine starts.
Jump starting is a two-person operation.
• Never use a frozen battery.
• Failure to follow correct jump starting procedures could
result in a battery explosion or a runaway machine.
Keep Riders off Machine
•Riders on machine are subject to injury such as being struck
by foreign objects and being thrown off the machine.
• Only the operator should be on the machine. Keep riders
off.
• Riders also obstruct the operator’s view, resulting in the
machine being operated in an unsafe manner.
SAFETY
S-7
SA-444
SA-032
SA-379

Precautions for Operations
•Investigate the work site before starting operations.
• Be sure to wear close fitting clothing and safety
equipment appropriate for the job, such as a hard hat,
etc. when operating the machine.
• Clear all persons and obstacles from area of operation and
machine movement.
Do not permit persons other than the operator to enter
areas where there is danger such as flying objects.
Always beware of the surroundings while operating.
When working in a small area surrounded by obstacles,
take care not to hit the upperstructure against obstacles.
• When loading onto trucks, bring the bucket over the truck
beds from the rear side. Take care not to swing the bucket
over the cab or over any person.
SAFETY
S-8
M117-05-006
