Hitachi SJ700-2 Series User manual

HITACHI INVERTER
SJ700-2 SERIES
SERVICE MANUAL
After reading this manual, keep it handy for future reference.
NTS204X

Revision History
No. Revision content Date of issue Manual code
1 First edition Octover 2007 NTS204X
- The current edition of this Instruction Manual also includes some corrections of simple misprints,
missing letters, misdescriptions and certain added explanations other than those listed in the above
Revision History table.

iii
Table of contents
Chapter 1 Investigation of the inverter
1.1 Spesification label(Model name,manufacturing number:MFG) ················································1 - 1
1.1.1 Model name, ················································································································1 - 1
1.1.2 MFG number················································································································1 - 1
1.2 Precautions for Data Setting·····································································································1 - 2
1.2.1 Monitor Mode···············································································································1 - 2
1.2.2 Function Mode·············································································································1 - 3
1.2.3 Extended Function Mode ····························································································1 - 4
1.3 Code display system and key operations ·················································································1 - 20
1.3.1 Example of operation in basic display mode(“b037”=”04”[factory setting])·················1 - 21
1.3.2 Example of operation in full display mode(“b037”=”00”[factory setting])·····················1 - 23
1.3.3 Code/data display and key operator in extended function mode U ····························1 - 24
Chapter 2 Troubleshooting
2.1 Inverter trip contents,remedy,advise·························································································2 - 1
2.2 Option board error codes··········································································································2 - 5
2.2.1 Error indications by protective functions with the feedback option board (SJ-FB) mounted
·································································································································2 - 5
2.2.2 Error indications by protective functions with the digital option board (SJ-DG) mounted
·································································································································2 - 6
2.2.3 Error indications by protective functions with the DeviceNet option board (SJ-DN) mounted
·································································································································2 - 7
2.2.4 Error indications by protective functions with the easy sequence function used ········2 - 8
2.3 Trip conditions monitoring ········································································································2 - 9
2.4 Warning Codes·························································································································2 -10
2.5 Initialization setting················································································································2 -11
Chapter 3 Debug Mode
3.1 Monitor Modes ··························································································································3 - 1
3.2 Function Modes ························································································································3 - 2
3.3 How To Reference the Data Area (d105) Corresponding to Trip History··································3 - 2
3.4 Inverter Setting ·························································································································3 - 3
3.4.1 Setting procedure ········································································································3 - 3
3.4.2 Confirming the completion of initialization···································································3 - 4
Chapter 4 The check of control power supply voltage and a control signal
4.1 Control power supply ················································································································4 - 1
4.2 Control signal····························································································································4 - 1
Chapter 5 Maintenance and Inspection
5.1 Precautions for Maintenance and Inspection ···········································································5 - 1
5.1.1 Daily inspection············································································································5 - 1
5.1.2 Cleaning·······················································································································5 - 1
5.1.3 Periodic inspection·······································································································5 - 1
5.2 Daily and Periodic Inspections·································································································5 - 2
5.3 Ground Resistance Test with a Megger ···················································································5 - 3
5.4 Withstand Voltage Test·············································································································5 - 3
5.5 Method of Checking the Inverter and Converter Circuits·························································5 - 4
5.6 Replacing Parts························································································································5 - 5
5.7 Inverter Replacement···············································································································5 - 8

iv
Appendix
Circuit Diagram····························································································································6 - 1
Internal block diagram ·················································································································6 - 2
Structure figure ····························································································································6 - 15

1 - 1
1. Investigation of the inverter
1.1 Specification label(Model name,Manufacturing number:MFG)
･There is a specification label attached to the inverter as shown in Figure 1-1.
Figure 1-1 Location of the specifications label
･Please confirm the model name and MFG number from the specification label as follows.
Figure 1-2 Contents of the specifications label
1.1.1 Model name
SJ700-150 H F F 2
2:type2
F:with EMC filter
F:with digital operator
L:3Ø200V class
H:3Ø400V class
Applicable motor(150:15kW)
Model name
1.1.2 MFG number
77 A T12345 7 001
SerialNo.(001-999)
Year of production(7:2007)
ProductionNo.
REV.No.(1charactoror2character)
Production year & month(78:2007/August)
Specification
label
kW/(HP): 15/(20)
Model: SJ700-150HFF2
50Hz,60Hz 380-480V 3 Ph 35A
Output/Sortie: 0 -400Hz 380-480V 3 Ph 32A
Input/Entree: 50Hz,60Hz V 1 Ph A
MFGNo. 77AAT12345 A 001 Date: 0707
Hitachi Industrial Equipment
Systems Co.,Ltd. MADE IN JAPAN NE
Inverter model
Maximum applicable motor capacity
Input ratings
Output ratings
Serial number

1 - 2
1.2 Precautions for Data Setting
The default display mode limits the screens (parameters) that can be displayed on the monitor. To enable the display
of all parameters, specify "00" (full display) for the function code display restriction (b037).
To enable the parameters to be changed while the inverter is operating, specify "10" for the software lock mode
selection (b031).
1.2.1 Monitoring Mode
Code Function name Monitored data or setting Default
Note
d001 Output frequency monitoring 0.00 to 99.99, 100.0 to 400.0 (Hz) 
d002 Output current monitoring 0.0 to 999.9, 1000 to 9999 (A) 
d003 Rotation direction minitoring F (forward rotation), o (stopped), r (reverse rotation) 
d004 Process variable (PV), PID feedback
monitoring 0.00 to 99.99, 100.0 to 999.9, 1000. to 9999.
1000 to 9999 (10000 to 99990), 100 to 999 (100000 to 999000) 
d005 Intelligent input terminal status (Example)
Terminals FW, 7, 2, and 1: ON
Terminals 8, 6, 5, 4, and 3: OFF

d006 Intelligent output terminal status (Example)
Terminals 12 and 11: ON
TerminalsAL, 15, 14, and 13: OFF

d007 Scaledoutputfrequency monitoring 0.00 to 99.99, 100.0 to 999.9, 1000. to 9999., 1000 to 3996 (10000 to 39960) 
d008 Actual-frequency monitoring -400. to -100., -99.9 to 0.00 to 99.99, 100.0 to 400.0 (Hz) 
d009 Torque command monitoring -200. to +200. (%) 
d010 Torque bias monitoring -200. to +200. (%) 
d012 Torque monitoring -200. to +200. (%) 
d013 Output voltage monitoring 0.0 to 600.0 (V) 
d014 Power monitoring 0.0 to 999.9 (kW) 
d015 Cumulative power monitoring 0.0 to 999.9, 1000. to 9999.
1000 to 9999 (10000 to 99990), 100 to 999 (100000 to 999000) 
d016 Cumulative operation RUN time
monitoring 0. to 9999., 1000 to 9999 (10000 to 99990), 100 to 999 (100000 to 999000) (hr) 
d017 Cumulative power-on time monitoring 0. to 9999., 1000 to 9999 (10000 to 99990), 100 to 999 (100000 to 999000) (hr) 
d018 Heat sink temperature monitoring -020. to 200.0 (C) 
d019 Motor temperature monitoring -020. to 200.0 (C) 
d022 Life-check monitoring 1: Capacitor on main circuit board
2: Cooling-fan speed drop

d023 Program counter 0 to 1024 
d024 Program number monitoring 0000 to 9999 
FW
8 7 6 5 4 3 2 1
AL 1514 1312 11
2 1
ON
OFF

1 - 3
Code Function name Monitored data or setting Default Note
d025 User monitor 0 -2147483647 to 2147483647 (upper 4 digits including “-“) −
d026 User monitor 1 -2147483647 to 2147483647 (upper 4 digits including “-“) −
d027 User monitor 2 -2147483647 to 2147483647 (upper 4 digits including “-“) −
d028 Pulse counter 0 to 2147483647 (upper 4 digits) −
d029 Position setting monitor -1073741823 to 1073741823 (upper 4 digits including “-“) −
d030 Position feedback monitor -1073741823 to 1073741823 (upper 4 digits including “-“) −
d080 Trip Counter 0. to 9999., 1000 to 6553 (10000 to 65530) (times) −
d081 Trip monitoring 1 Factor, frequency (Hz), current (A), voltage across P-N (V), running time (hours),
power-on time (hours) −
d082 Trip monitoring 2 Factor, frequency (Hz), current (A), voltage across P-N (V), running time (hours),
power-on time (hours) −
d083 Trip monitoring 3 Factor, frequency (Hz), current (A), voltage across P-N (V), running time (hours),
power-on time (hours) −
d084 Trip monitoring 4 Factor, frequency (Hz), current (A), voltage across P-N (V), running time (hours),
power-on time (hours) −
d085 Trip monitoring 5 Factor, frequency (Hz), current (A), voltage across P-N (V), running time (hours),
power-on time (hours) −
d086 Trip monitoring 6 Factor, frequency (Hz), current (A), voltage across P-N (V), running time (hours),
power-on time (hours) −
d090 Programming error monitoring Warning code −
d102 DC voltage monitoring 0.0 to 999.9 (V) −
d103 BRD load factor monitoring 0.0 to 100.0 (%) −
d104 Electronic thermal overload monitoring 0.0 to 100.0 (%) −
1.2.2 Function Mode
Default
Code Function name Monitored data or setting
_FF _FEF _FUF
F001
Output frequency setting 0.0, "start frequency" to "maximum frequency" (or maximum frequency,
2nd/3rd motors) (Hz)
0.0 to 100.0 (when PID function is enabled)
0.00
F002 Acceleration (1) time setting 0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s) 30.00
F202 Acceleration (1) time setting, 2nd
motor
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s) 30.00
F302 Acceleration (1) time setting, 3rd
motor
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s) 30.00
F003 Deceleration (1) time setting 0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s) 30.00
F203 Deceleration time setting, 2nd motor 0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s) 30.00
F303 Deceleration time setting, 3rd motor 0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s) 30.00
F004 Keypad Run key routing 00 (forward rotation), 01 (reverse rotation) 00

1 - 4
1.2.3 Extended Function Mode
Default
Code Function name Monitored data or setting
_FF _FEF _FUF
Note
A001
Frequency source setting 00 (keypad potentiometer) (*1), 01 (control circuit terminal block), 02 (digital
operator), 03 (RS485), 04 (option 1), 05 (option 2), 06 (pulse-string input), 07
(easy sequence), 10 (operation function result)
02 01 01
A002 Run command source setting 01 (control circuit terminal block), 02 (digital operator), 03 (RS485), 04 (option
1), 05 (option 2) 02 01 01
A003 Base frequency setting 30. to "maximum frequency " (Hz) 60. 50. 60.
A203 Base frequency setting, 2nd
motor
30. to "maximum frequency, 2nd motor" (Hz) 60. 50. 60.
A303 Base frequency setting, 3rd
motor
30. to "maximum frequency, 3rd motor" (Hz) 60. 50. 60.
A004 Maximum frequency setting 30. to 400. (Hz) 60. 50. 60.
A204 Maximum frequency setting, 2nd
motor
30. to 400. (Hz) 60. 50. 60.
Basic settings
A304 Maximum frequency setting, 3rd
motor
30. to 400. (Hz) 60. 50. 60.
A005
[AT] selection 00 (switching between O and OI terminals), 01 (switching between O and O2
terminals), 02 (switching between O terminal and keypad potentiometer) (*1),
03 (switching between OI terminal and keypad potentiometer) (*1), 04
(switching between O2 and keypad potentiometer) (*1)
00
A006
[O2] selection 00 (single), 01 (auxiliary frequency input via O and OI terminals)
(nonreversible), 02 (auxiliary frequency input via O and OI terminals)
(reversible), 03 (disabling O2 terminal)
03
A011 [O]-[L] input active range start
frequency
0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
A012 [O]-[L] input active range end
frequency
0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
A013 [O]-[L] input active range start
voltage
0. to "[O]-[L] input active range end voltage" (%) 0.
A014 [O]-[L] input active range end
voltage
"[O]-[L] input active range start voltage" to 100. (%) 100.
A015 [O]-[L] input active range start
frequency selection
00 (external start frequency), 01 (0 Hz) 01
A016 External frequency filter time
const.
1. to 30. or 31. (500 ms filter ±0.1 Hz with hysteresis) 31.
Analog input and others
A017 Easy sequence function
selection
00 (disabling), 01 (enabling) 00
A019 Multispeed operation selection 00 (binary: 16 speeds selectable with 4 terminals), 01 (bit: 8 speeds selectable
with 7 terminals) 00
A020 Multispeed frequency setting 0.0 or “start frequency” to “maximum frequency” (Hz) 0.00
A220 Multispeed frequency setting,
2nd motor
0.0 or “start frequency” to “maximum frequency, 2nd motor” (Hz) 0.00
A320 Multispeed frequency setting,
3rd motor
0.0 or “start frequency” to “maximum frequency, 3rd motor” (Hz) 0.00
A021 Multispeed 1 setting 0.0 or “start frequency” to “1st maximum frequency” (Hz) 0.00
A022 Multispeed 2 setting 0.0 or “start frequency” to “2nd maximum frequency” (Hz) 0.00
A023 Multispeed 3 setting 0.0 or “start frequency” to “3rd maximum frequency” (Hz) 0.00
A024 Multispeed 4 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
A025 Multispeed 5 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
A026 Multispeed 6 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
A027 Multispeed 7 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
A028 Multispeed 8 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
A029 Multispeed 9 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
A030 Multispeed 10 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
A031 Multispeed 11 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
A032 Multispeed 12 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
A033 Multispeed 13 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
A034 Multispeed 14 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
A035 Multispeed 15 setting 0.0 or “start frequency” to “n-th maximum frequency” (Hz) 0.00
A038 Jog frequency setting "Start frequency" to 9.99 (Hz) 1.00
Multispeed operation and jogging
A039 Jog stop mode
00 (free-running after jogging stops [disabled during operation]), 01
(deceleration and stop after jogging stops [disabled during operation]), 02 (DC
braking after jogging stops [disabled during operation]), 03 (free-running after
jogging stops [enabled during operation]), 04 (deceleration and stop after
jogging stops [enabled during operation]), 05 (DC braking after jogging stops
[enabled during operation])
00
.

1 - 5
Default
Code Function name Monitored data or setting
_FF _FEF _FUF
Note
A041 Torque boost method selection 00 (manual torque boost), 01 (automatic torque boost) 00
A241 Torque boost method selection,
2nd motor 00 (manual torque boost), 01 (automatic torque boost) 00
A042 Manual torque boost value 0.0 to 20.0 (%) 1.0
A242 Manual torque boost value, 2nd
motor 0.0 to 20.0 (%) 1.0
A342 Manual torque boost value, 3rd
motor 0.0 to 20.0 (%) 1.0
A043 Manual torque boost frequency
adjustment 0.0 to 50.0 (%) 5.0
A243 Manual torque boost frequency
adjustment, 2nd motor 0.0 to 50.0 (%) 5.0
A343 Manual torque boost frequency
adjustment, 3rd motor 0.0 to 50.0 (%) 5.0
A044 V/F characteristic curve
selection, 1st motor
00 (VC), 01 (VP), 02 (free V/f), 03 (sensorless vector control), 04 (0Hz-range
sensorless vector), 05 (vector with sensor) 00
A244 V/F characteristic curve
selection, 2nd motor
00 (VC), 01 (VP), 02 (free V/f), 03 (sensorless vector control), 04 (0Hz-range
sensorless vector) 00
A344 V/F characteristic curve
selection, 3rd motor 00(VC), 01(VP) 00
A045 V/f gain setting 20. to 100. (%) 100.
A046
Voltage compensation gain
setting for automatic torque
boost. 1st motor
0. to 255. 100.
A246
Voltage compensation gain
setting for automatic torque
boost, 2nd motor
0. to 255. 100.
A047
Slippage compensation gain
setting for automatic torque
boost, 1st motor
0. to 255. 100.
V/f characteristic
A247
Slippage compensation gain
setting for automatic torque
boost, 2nd motor
0. to 255. 100.
A051 DC braking enable 00 (disabling), 01 (enabling), 02 (set frequency only) 00
A052 DC braking frequency setting 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.50
A053 DC braking wait time 0.0 to 5.0 (s) 0.0
A054 DC braking force during
deceleration 0. to 100. (%) 0.
A055 DC braking time for deceleration 0.0 to 60.0 (s) 0.0
A056 DC braking/edge or level
detection for [DB] input 00 (edge operation), 01 (level operation) 01
A057 DC braking force for starting 0. to 100.(%) 0.
A058 DC braking time for starting 0.0 to 60.0(s) 0.0
DC braking
A059 DC braking carrier frequency
setting 0.5 to 15.0(kHz) 5.0
A061 Frequency upper limit setting 0.00 or "1st minimum frequency limit" to "maximum frequency" (Hz) 0.00
A261 Frequency upper limit setting,
2nd motor 0.00 or "2nd minimum frequency limit" to "maximum frequency, 2nd motor" (Hz) 0.00
A062 Frequency lower limit setting 0.00 or "start frequency" to "maximum frequency limit"
(Hz) 0.00
A262 Frequency lower limit setting,
2nd motor
0.00 or "start frequency" to "maximum frequency, 2nd motor limit"
(Hz) 0.00
A063 Jump (center) frequency setting
1 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
A064 Jump (hysteresis) frequency
width setting 1 0.00 to 10.00 (Hz) 0.50
A065 Jump (center) frequency setting
2 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
A066 Jump (hysteresis) frequency
width setting 2 0.00 to 10.00 (Hz) 0.50
A067 Jump (center) frequency setting
3 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
A068 Jump (hysteresis) frequency
width setting 3 0.00 to 10.00 (Hz) 0.50
A069 Acceleration stop frequency
setting 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
Frequency upper/lower limit and jump frequency
A070 Acceleration stop time frequency
setting 0.0 to 60.0 (s) 0.0
A071 PID Function Enable 00 (disabling), 01 (enabling), 02 (enabling inverted-data output) 00
A072 PID proportional gain 0.2 to 5.0 1.0
A073 PID integral time constant 0.0 to 999.9, 1000. to 3600. (s) 1.0
A074 PID derivative gain 0.00 to 99.99, 100.0 (s) 0.00
A075 PV scale conversion 0.01 to 99.99 1.00
A076 PV source setting 00 (input via OI), 01 (input via O), 02 (external communication), 03 (pulse-string
frequency input), 10 (operation result output) 00
A077 Output of inverted PID deviation 00(OFF), 01 (ON) 00
A078 PID variation range 0.0 to 100.0 (%) 0.00
PID control
A079 PID feed forward selection 00 (disabled), 01 (O input), 02 (OI input), 03 (O2 input) 00

1 - 6
Default
Code Function name Monitored data or setting
_FF _FEF _FUF
Note
A081 AVR function select 00 (always on), 01 (always off), 02 (off during deceleration) 02 00 00
AVR
A082 AVR voltage select 200 V class: 200, 215, 220, 230, 240 (V)
400 V class: 380, 400, 415, 440, 460, 480 (V) 200/400 230/400 230/460
A085 Operation mode selection 00 (normal operation), 01 (energy-saving operation), 02 (fuzzy operation) 00
A086 Energy saving mode tuning 0.1 to 100.0 50.0
A092 Acceleration (2) time setting 0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s) 15.00
A292 Acceleration (2) time setting,
2nd motor 0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s) 15.00
A392 Acceleration (2) time setting,
3rd motor 0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s) 15.00
A093 Deceleration (2) time setting 0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s) 15.00
A293 Deceleration (2) time setting,
2nd motor 0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s) 15.00
A393 Deceleration (2) time setting,
3rd motor 0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s) 15.00
A094 Select method to switch to
Acc2/Dec2 profile
00 (switching by 2CH terminal), 01 (switching by setting), 02 (switching only
when rotation is reversed) 00
A294 Select method to switch to
Acc2/Dec2, 2nd motor
00 (switching by 2CH terminal), 01 (switching by setting), 02 (switching only
when rotation is reversed) 00
A095 Acc1 to Acc2 frequency
transition point 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
A295 Acc1 to Acc2 frequency
transition point, 2nd motor 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
A096 Dec1 to Dec2 frequency
transition point 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
A296 Dec1 to Dec2 frequency
transition point, 2nd motor 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
A097 Acceleration curve selection 00 (linear), 01 (S curve), 02 (U curve), 03 (inverted-U curve), 04 (EL-S curve) 00
Operation mode and acceleration/deceleration function
A098 Deceleration curve setting 00 (linear), 01 (S curve), 02 (U curve), 03 (inverted-U curve), 04 (EL-S curve) 00
A101 [OI]-[L] input active range start
frequency 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
A102 [OI]-[L] input active range end
frequency 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
A103 [OI]-[L] input active range start
current 0. to "[OI]-[L] input active range end current" (%) 20.
A104 [OI]-[L] input active range end
current "[OI]-[L] input active range start current" to 100. (%) 100.
A105 [OI]-[L] input start frequency
enable 00 (external start frequency), 01 (0 Hz) 00
A111 [O2]-[L] input active range start
frequency -400. to -100., -99.9 to 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
A112 [O2]-[L] input active range end
frequency -400. to -100., -99.9 to 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
A113 [O2]-[L] input active range start
voltage -100. to 02 end-frequency rate (%) -100.
External frequency adjustment
A114 [O2]-[L] input active range end
voltage "02 start-frequency rate" to 100. (%) 100.
A131 Acceleration curve constants
setting 01 (smallest swelling) to 10 (largest swelling) 02
n and
deceleratio
A132 Deceleration curve constants
setting 01 (smallest swelling) to 10 (largest swelling) 02
A141 Operation-target frequency
selection 1
00 (digital operator), 01 (keypad potentiometer), 02 (input via O), 03 (input via
OI), 04 (external communication), 05 (option 1), 06 (option 2), 07 (pulse-string
frequency input)
02
A142 Operation-target frequency
selection 2
00 (digital operator), 01 (keypad potentiometer), 02 (input via O), 03 (input via
OI), 04 (external communication), 05 (option 1), 06 (option 2), 07 (pulse-string
frequency input)
03
A143 Operator selection 00 (addition: A141 + A142), 01 (subtraction: A141 - A142), 02 (multiplication:
A141 x A142) 00
A145 Frequency to be added 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
Operation-target frequency
A146 Sign of the frequency to be
added 00 (frequency command + A145), 01 (frequency command - A145) 00
A150 EL-S-curve acceleration
ratio 1 0. to 50. (%) 25.
A151 EL-S-curve acceleration
ratio 2 0. to 50. (%) 25.
A152 EL-S-curve deceleration
ratio 1 0. to 50. (%) 25.
Acceleration and
deceleration
A153 EL-S-curve deceleration
ratio 2 0. to 50. (%) 25.

1 - 7
Default
Code Function name Monitored data or setting
_FF _FEF _FUF
Note
b001 Selection of restart mode
00 (tripping), 01 (starting with 0 Hz), 02 (starting with matching frequency), 03
(tripping after deceleration and stopping with matching frequency), 04
(restarting with active matching frequency)
00
b002 Allowable under-voltage power
failure time 0.3 to 25.0 (s) 1.0
b003 Retry wait time before motor restart 0.3 to 100.0 (s) 1.0
b004
Instantaneous power
failure/under-voltage trip alarm
enable
00 (disabling), 01 (enabling), 02 (disabling during stopping and decelerating
to stop) 00
b005 Number of restarts on power
failure/under-voltage trip events 00 (16 times), 01 (unlimited) 00
b006 Phase loss detection enable 00 (disabling), 01 (enabling) 00
b007 Restart frequency threshold 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
b008 Selection of retry after tripping
00 (tripping), 01 (starting with 0 Hz), 02 (starting with matching frequency), 03
(tripping after deceleration and stopping with matching frequency), 04
(restarting with active matching frequency)
00
b009 Selection of retry after undervoltage 00 (16 times), 01 (unlimited) 00
b010 Selection of retry count after
overvoltage or overcurrent 1 to 3 (times) 3
Restart after instantaneous power failure or tripping
b011 Retry wait time after tripping 0.3 to 100.0 (s) 1.0
b012
Electronic thermal setting
(calculated within the inverter from
current output)
0.20 x "rated current" to 1.00 x "rated current" (A) Rated current of inverter
b212
Electronic thermal setting
(calculated within the inverter from
current output), 2nd motor
0.20 x "rated current" to 1.00 x "rated current" (A) Rated current of inverter
b312
Electronic thermal setting
(calculated within the inverter from
current output), 3rd motor
0.20 x "rated current" to 1.00 x "rated current" (A) Rated current of inverter
b013 Electronic thermal characteristic 00 (reduced-torque characteristic), 01 (constant-torque characteristic), 02
(free setting) 00 01 01
b213 Electronic thermal characteristic, 2nd
motor
00 (reduced-torque characteristic), 01 (constant-torque characteristic), 02
(free setting) 00 01 01
b313 Electronic thermal characteristic, 3rd
motor
00 (reduced-torque characteristic), 01 (constant-torque characteristic), 02
(free setting) 00 01 01
b015 Free setting, electronic thermal
frequency (1) 0. to 400. (Hz) 0.
b016 Free setting, electronic thermal
current (1) 0.0 to rated current (A) 0.0
b017 Free setting, electronic thermal
frequency (2) 0. to 400. (Hz) 0.
b018 Free setting, electronic thermal
current (2) 0.0 to rated current (A) 0.0
b019 Free setting, electronic thermal
frequency (3) 0. to 400. (Hz) 0.
Electronic thermal function
b020 Free setting, electronic thermal
current (3) 0.0 to rated current (A) 0.0
b021 Overload restriction operation mode
00 (disabling), 01 (enabling during acceleration and deceleration), 02
(enabling during constant speed), 03 (enabling during acceleration and
deceleration (increasing the speed during regeneration))
01
b022 Overload restriction setting 0.20 x "rated current" to 1.00 x "rated current" (A) Rated current of inverter x
1.50
b023 Deceleration rate at overload
restriction 0.10 to 30.00 (s) 1.00
b024 Overload restriction operation mode
(2)
00 (disabling), 01 (enabling during acceleration and deceleration), 02
(enabling during constant speed), 03 (enabling during acceleration and
deceleration (increasing the speed during regeneration))
01
b025 Overload restriction setting (2) 0.20 x "rated current" to 2.00 x "rated current" (A) Rated current of inverter x
1.50
b026 Deceleration rate at overload restriction
(2) 0.10 to 30.00 (s) 1.00
b027 Overcurrent suppression enable 00 (disabling), 01 (enabling) 01
b028 Active frequency matching, scan
start frequency 0.20 x "rated current" to 2.00 x "rated current" (A) Rated current of inverter
b029 Active frequency matching,
scan-time constant 0.10 to 30.00 (s) 0.50
Overload restriction and overcurrent restraint
b030 Active frequency matching, restart
frequency select
00 (frequency at the last shutoff), 01 (maximum frequency), 02 (set
frequency) 00
Software
lock
b031 Software lock mode selection
00 (disabling change of data other than "b031" when SFT is on), 01 (disabling
change of data other than "b031" and frequency settings when SFT is on), 02
(disabling change of data other than "b031"), 03 (disabling change of data
other than "b031" and frequency settings), 10 (enabling data changes during
operation)
01

1 - 8
Default
Code Function name Monitored data or setting
_FF _FEF _FUF
Note
b034 Run/power-on warning time 0. to 9999. (0 to 99990), 1000 to 6553 (10000 to 655300) (hr) 0.
b035 Rotational direction restriction 00 (enabling both forward and reverse rotations), 01 (enabling only
forward rotation), 02 (enabling only reverse rotation) 00
b036 Reduced voltage start selection 0 (minimum reduced voltage start time) to 255 (maximum reduced voltage
start time) 6
b037 Function code display restriction 00 (full display), 01 (function-specific display), 02 (user setting), 03 (data
comparison display), 04 (basic display) 04
b038 Initial-screen selection 00 (screen displayed when the STR key was pressed last), 01 (d001), 02
(d002), 03 (d003), 04 (d007), 05 (F001) 01
Others
b039 Automatic user-parameter
setting function enable 00 (disabling), 01 (enabling) 00
b040 Torque limit selection 00 (quadrant-specific setting), 01 (switching by terminal), 02 (analog
input), 03 (option 1), 04 (option 2) 00
b041 Torque limit (1) (forward-driving
in 4-quadrant mode) 0. to 200. (%), no (disabling torque limitation) 150.
b042
Torque limit (2)
(reverse-regenerating in
4-quadrant mode)
0. to 200. (%), no (disabling torque limitation) 150.
b043 Torque limit (3) (reverse-driving
in 4-quadrant mode) 0. to 200. (%), no (disabling torque limitation) 150.
b044
Torque limit (4)
(forward-regenerating in
4-quadrant mode)
0. to 200. (%), no (disabling torque limitation) 150.
b045 Torque limit LADSTOP enable 00 (disabling), 01 (enabling) 00
Torque limitation
b046 Reverse Run protection enable 00 (disabling), 01 (enabling) 00
b050 Controller deceleration and stop
on power loss
00 (disabling), 01 (nonstop deceleration to stop), 02 (DC voltage constant
control, with resume), 03 ( without resume) 00
b051 DC bus voltage trigger level
during power loss 0.0 to 999.9, 1000. (V) 220/440
b052 Over-voltage threshold during
power loss 0.0 to 999.9, 1000. (V) 360/720
b053 Deceleration time setting during
power loss 0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s) 1.00
b054 Initial output frequency decrease
during power loss 0.00 to 10.00 (Hz) 0.00
b055 Proportional gain setting for
nonstop operation at power loss 0.00 to 2.55 0.20
Non-stop operation at momentary power
failure
b056 Integral time setting for nonstop
operation at power loss 0.000 to 9.999 /10.00 to 65.53 (s) 0.100
b060 Maximum-limit level of window
comparators O 0. to 100. (lower limit : b061 + b062 / 2) (%) 100
b061 Minimum-limit level of window
comparators O 0. to 100. (lower limit : b060 - b062 / 2) (%) 0
b062 Hysteresis width of window
comparators O 0. to 10. (lower limit : b061 - b062 / 2) (%) 0
b063 Maximum-limit level of window
comparators OI 0. to 100. (lower limit : b064 + b066 / 2) (%) 100
b064 Minimum-limit level of window
comparators OI 0. to 100. (lower limit : b063 - b066 / 2) (%) 0
b065 Hysteresis width of window
comparators OI 0. to 10. (lower limit : b063 - b064 / 2) (%) 0
b066 Maximum-limit level of window
comparators OI -100. to 100. (lower limit : b067 + b068 / 2) (%) 100
b067 Minimum-limit level of window
comparators O/OI/O2 -100. to 100. (lower limit : b066 - b068 / 2) (%) 0
b068 Hysteresis width of window
comparators O/OI/O2 0. to 10. (lower limit : b066 - b067 / 2) (%) 0
b070 Operation level at O
disconnection 0. to 100. (%) or "no" (ignore) no
b071 Operation level at OI
disconnection 0. to 100. (%) or "no" (ignore) no
Window comparator
b072 Operation level at O2
disconnection -100. to 100. (%) or "no" (ignore) no

1 - 9
Default
Code Function name Monitored data or setting
_FF _FEF _FUF
Note
b078 Cumulative input power data
clearance Clearance by setting "01" and pressing the STR key 00
b079 Cumulative input power display
gain setting 1. to 1000. 1.
b082 Start frequency adjustment 0.10 to 9.99 (Hz) 0.50
b083 Carrier frequency setting 0.5 to 15.0 (kHz) (subject to derating) 5.0
b084 Initialization mode (parameters or
trip history)
00 (clearing the trip history), 01 (initializing the data),
02 (clearing the trip history and initializing the data) 00
b085 Country code for initialization 00 (Japan), 01 (EU), 02 (U.S.A.) 00 01 02
b086 Frequency scaling conversion
factor 0.1 to 99.0 1.0
b087 STOP key enable 00 (enabling), 01 (disabling), 02 (disabling only the function to stop) 00
b088 Restart mode after FRS 00 (starting with 0 Hz), 01 (starting with matching frequency), 02 (starting
with active matching frequency) 00
b089 Automatic carrier frequency
reduction 00: invalid, 01: valid 00
b090 Dynamic braking usage ratio 0.0 to 100.0 (%) 0.0
b091 Stop mode selection 00 (deceleration until stop), 01 (free-run stop) 00
b092 Cooling fan control 00 (always operating the fan), 01 (operating the fan only during inverter
operation [including 5 minutes after power-on and power-off]) 00
b095 Dynamic braking control 00 (disabling), 01 (enabling [disabling while the motor is topped]), 02
(enabling [enabling also while the motor is topped]) 00
b096 Dynamic braking activation level 330 to 380, 660 to 760(V) 360/
720
b098 Thermistor for thermal protection
control
00 (disabling the thermistor), 01 (enabling the thermistor with PTC), 02
(enabling the thermistor with NTC) 00
Others
b099 Thermal protection level setting 0. to 9999. (Ω) 3000.
b100 Free-setting V/f frequency (1) 0. to "free-setting V/f frequency (2)" (Hz) 0.
b101 Free-setting V/f voltage (1) 0.0 to 800.0 (V) 0.0
b102 Free-setting V/f frequency (2) 0. to "free-setting V/f frequency (3)" (Hz) 0.
b103 Free-setting V/f voltage (2) 0.0 to 800.0 (V) 0.0
b104 Free-setting V/f frequency (3) 0. to "free-setting V/f frequency (4)" (Hz) 0.
b105 Free-setting V/f voltage (3) 0.0 to 800.0 (V) 0.0
b106 Free-setting V/f frequency (4) 0. to "free-setting V/f frequency (5)" (Hz) 0.
b107 Free-setting V/f voltage (4) 0.0 to 800.0 (V) 0.0
b108 Free-setting V/f frequency (5) 0. to "free-setting V/f frequency (6)" (Hz) 0.
b109 Free-setting V/f voltage (5) 0.0 to 800.0 (V) 0.0
b110 Free-setting V/f frequency (6) 0. to "free-setting V/f frequency (7)" (Hz) 0.
b111 Free-setting V/f voltage (6) 0.0 to 800.0 (V) 0.0
b112 Free-setting V/f frequency (7) 0. to 400. (Hz) 0.
Free setting of V/f characteristic
b113 Free-setting V/f voltage (7) 0.0 to 800.0 (V) 0.0
b120 Brake Control Enable 00 (disabling), 01 (enabling) 00
b121 Brake Wait Time for Release 0.00 to 5.00 (s) 0.00
b122 Brake Wait Time for Acceleration 0.00 to 5.00 (s) 0.00
b123 Brake Wait Time for Stopping 0.00 to 5.00 (s) 0.00
b124 Brake Wait Time for Confirmation 0.00 to 5.00 (s) 0.00
b125 Brake Release Frequency Setting 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
b126 Brake Release Current Setting 0.0 to 2.00 x "rated current" Rated current of inverter
b127 Braking frequency 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
b130 Overvoltage suppression enable 00 (disabling the restraint), 01 (controlled deceleration), 02 (enabling
acceleration) 00
b131 Overvoltage suppression level 330 to 390 (V) (200 V class model), 660 to 780 (V) (400 V class model) 380/
760
b132 Acceleration and deceleration
rate at overvoltage suppression 0.10 to 30.00 (s) 1.00
b133 Overvoltage suppression
propotional gain 0.00 to 2.55 0.50
Others
b134 Overvoltage suppression Integral
time 0.000 to 9.999 / 10.00 to 65.53 (s) 0.060

1 - 10
Default
Code Function name Monitored data or setting
_FF _FEF _FUF
Note
C001 Terminal [1] function (*2) 18
(*2)
C002 Terminal [2] function 16
C003 Terminal [3] function (*2) 06
(*2)
C004 Terminal [4] function 11
C005 Terminal [5] function 09
C006 Terminal [6] function 03 03 13
C007 Terminal [7] function 02
C008 Terminal [8] function
01 (RV: Reverse RUN), 02 (CF1: Multispeed 1 setting), 03 (CF2: Multispeed 2
setting), 04 (CF3: Multispeed 3 setting), 05 (CF4: Multispeed 4 setting), 06 (JG:
Jogging), 07 (DB: external DC braking), 08 (SET: Set 2nd motor data), 09 (2CH:
2-stage acceleration/deceleration), 11 (FRS: free-run stop), 12 (EXT: external trip),
13 (USP: unattended start protection), 14: (CS: commercial power source enable),
15 (SFT: software lock), 16 (AT: analog input voltage/current select), 17 (SET3: 3rd
motor control), 18 (RS: reset), 20 (STA: starting by 3-wire input), 21 (STP: stopping
by 3-wire input), 22 (F/R: forward/reverse switching by 3-wire input), 23 (PID: PID
disable), 24 (PIDC: PID reset), 26 (CAS: control gain setting), 27 (UP: remote
control UP function), 28 (DWN: remote control DOWN function), 29 (DWN: remote
control data clearing), 31 (OPE: forcible operation), 32 (SF1: multispeed bit 1), 33
(SF2: multispeed bit 2), 34 (SF3: multispeed bit 3), 35 (SF4: multispeed bit 4), 36
(SF5: multispeed bit 5), 37 (SF6: multispeed bit 6), 38 (SF7: multispeed bit 7), 39
(OLR: overload restriction selection), 40 (TL: torque limit enable), 41 (TRQ1: torque
limit selection bit 1), 42 (TRQ2: torque limit selection bit 2), 43 (PPI: P/PI mode
selection), 44 (BOK: braking confirmation), 45 (ORT: orientation), 46 (LAC: LAD
cancellation), 47 (PCLR: clearance of position deviation), 48 (STAT: pulse train
position command input enable), 50 (ADD: trigger for frequency addition [A145]), 51
(F-TM: forcible-terminal operation), 52 (ATR: permission of torque command input),
53 (KHC: cumulative power clearance), 54 (SON: servo-on), 55 (FOC: forcing), 56
(MI1: general-purpose input 1), 57 (MI2: general-purpose input 2), 58 (MI3:
general-purpose input 3), 59 (MI4: general-purpose input 4), 60 (MI5:
general-purpose input 5), 61 (MI6: general-purpose input 6), 62 (MI7:
general-purpose input 7), 63 (MI8: general-purpose input 8), 65 (AHD: analog
command holding), 66 (CP1: multistage position settings selection 1 ), 67 (CP2:
multistage position settings selection 2), 68 (CP3: multistage position settings
selection 3), 69 (ORL: Zero-return limit function), 70 (ORG: Zero-return trigger
function), 71 (FOT: forward drive stop), 72 (ROT: reverse drive stop), 73 (SPD:
speed / position switching), 74 (PCNT: pulse counter), 75 (PCC: pulse counter
clear), no (NO: no assignment)
01
C011 Terminal [1] active state 00 (NO) / 01 (NC) 00
C012 Terminal [2] active state 00 (NO) / 01 (NC) 00
C013 Terminal [3] active state 00 (NO) / 01 (NC) 00
C014 Terminal [4] active state 00 (NO) / 01 (NC) 00
C015 Terminal [5] active state 00 (NO) / 01 (NC) 00
C016 Terminal [6] active state 00 (NO) / 01 (NC) 00
C017 Terminal [7] active state 00 (NO) / 01 (NC) 00
C018 Terminal [8] active state 00 (NO) / 01 (NC) 00
Intelligent input terminals
C019 Terminal [FW] active state 00 (NO) / 01 (NC) 00

1 - 11
Default
Code Function name Monitored data or setting
_FF _FEF _FUF
Note
C021 Terminal [11] function 01
C022 Terminal [12] function 00
C023 Terminal [13] function 03
C024 Terminal [14] function 07
C025 Terminal [15] function 40
Intelligent output terminals
C026 Alarm relay terminal function
00 (RUN: running), 01 (FA1: constant-speed reached), 02 (FA2: set
frequency overreached), 03 (OL: overload notice advance signal (1)), 04
(OD: output deviation for PID control), 05 (AL: alarm signal), 06 (FA3: set
frequency reached), 07 (OTQ: over-torque), 08 (IP: instantaneous power
failure), 09 (UV: undervoltage), 10 (TRQ: torque limited), 11 (RNT:
operation time over), 12 (ONT: plug-in time over), 13 (THM: thermal alarm
signal), 19 (BRK: brake release), 20 (BER: braking error), 21 (ZS: 0 Hz
detection signal), 22 (DSE: speed deviation maximum), 23 (POK:
positioning completed), 24 (FA4: set frequency overreached 2), 25 (FA5:
set frequency reached 2), 26 (OL2: overload notice advance signal (2)), 27
(Odc: Analog O disconnection detection), 28 (OIDc: Analog OI
disconnection detection), 29 (O2Dc: Analog O2 disconnection detection),
31 (FBV: PID feedback comparison), 32 (NDc: communication line
disconnection), 33 (LOG1: logical operation result 1), 34 (LOG2: logical
operation result 2), 35 (LOG3: logical operation result 3), 36 (LOG4: logical
operation result 4), 37 (LOG5: logical operation result 5), 38 (LOG6: logical
operation result 6), 39 (WAC: capacitor life warning), 40 (WAF: cooling-fan
speed drop), 41 (FR: starting contact signal), 42 (OHF: heat sink overheat
warning), 43 (LOC: low-current indication signal), 44 (M01:
general-purpose output 1), 45 (M02: general-purpose output 2), 46 (M03:
general-purpose output 3), 47 (M04: general-purpose output 4), 48 (M05:
general-purpose output 5), 49 (M06: general-purpose output 6), 50 (IRDY:
inverter ready), 51 (FWR: forward rotation), 52 (RVR: reverse rotation), 53
(MJA: major failure), 54(WCO: window comparator O), 55(WCOI: window
comparator OI), 56 (WCO2: window comparator O2)
(When alarm code output is selected for "C062", functions "AC0" to "AC2"
or "AC0" to "AC3" [ACn: alarm code output] are forcibly assigned to
intelligent output terminals 11 to 13 or 11 to 14, respectively.)
05
C027 [FM] siginal selection
00 (output frequency), 01 (output current), 02 (output torque), 03 (digital
output frequency), 04 (output voltage), 05 (input power), 06 (electronic
thermal overload), 07 (LAD frequency), 08 (digital current monitoring), 09
(motor temperature), 10 (heat sink temperature), 12 (general-purpose
output YA0)
00
C028 [AM] siginal selection
00 (output frequency), 01 (output current), 02 (output torque), 04 (output
voltage), 05 (input power), 06 (electronic thermal overload), 07 (LAD
frequency), 09 (motor temperature), 10 (heat sink temperature), 11 (output
torque [signed value]), 13 (general-purpose output YA1)
00
C029 [AMI] siginal selection
00 (output frequency), 01 (output current), 02 (output torque), 04 (output
voltage), 05 (input power), 06 (electronic thermal overload), 07 (LAD
frequency), 09 (motor temperature), 10 (heat sink temperature), 14
(general-purpose output YA2)
00
Analog monitoring
C030 Digital current monitor reference
value
0.20 x "rated current" to 2.00 x "rated current" (A)
(Current with digital current monitor output at 1,440 Hz)
Rated current of
inverter
C031 Terminal [11] active state 00 (NO) / 01 (NC) 00
C032 Terminal [12] active state 00 (NO) / 01 (NC) 00
C033 Terminal [13] active state 00 (NO) / 01 (NC) 00
C034 Terminal [14] active state 00 (NO) / 01 (NC) 00
C035 Terminal [15] active state 00 (NO) / 01 (NC) 00
Intelligent output
terminals
C036 Alarm relay active state 00 (NO) / 01 (NC) 01

1 - 12
Default
Code Function name Monitored data or setting
_FF _FEF _FUF
Note
C038 Low-current indication signal
output mode selection
00 (output during acceleration/deceleration and constant-speed operation),
01 (output only during constant-speed operation) 01
C039 Low-current indication signal
detection level 0.0 to 2.00 x "rated current" (A) Rated current of inverter
C040 Overload signal output mode 00 (output during acceleration/deceleration and constant-speed operation),
01 (output only during constant-speed operation) 01
C041 Overload level setting 0.0 to 2.00 x "rated current" (A) Rated current of
inverter
C042 Frequency arrival setting for accel. 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
C043 Frequency arrival setting for decel. 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
C044 PID deviation level setting 0.0 to 100.0 (%) 3.0
C045 Frequency arrival setting for
acceleration (2) 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
C046 Frequency arrival setting for
deceleration (2) 0.00 to 99.99, 100.0 to 400.0 (Hz) 0.00
C052 Maximum PID feedback data 0.0 to 100.0 (%) 100.0
C053 Minimum PID feedback data 0.0 to 100.0 (%) 0.0
C055 Over-torque (forward-driving) level
setting 0. to 200. (%) 100.
C056 Over-torque (reverse
regenerating) level setting 0. to 200. (%) 100.
C057 Over-torque (reverse driving) level
setting 0. to 200. (%) 100.
C058 Over-torque (forward
regenerating) level setting 0. to 200. (%) 100.
C061 Electronic thermal warning level
setting 0. to 100. (%) 80.
C062 Alarm code output 00 (disabling), 01 (3 bits), 02 (4 bits) 00
C063 Zero speed detection level 0.00 to 99.99, 100.0 (Hz) 0.00
Levels and output terminal status
C064 Heat sink overheat warning level 0. to 200.0 (°C) 120.
C071 Communication speed selection 02 (loopback test), 03 (2,400 bps), 04 (4,800 bps), 05 (9,600 bps), 06
(19,200 bps) 04
C072 Node allocation 1. to 32. 1.
C073 Communication data length
selection 7 (7 bits), 8 (8 bits) 7
C074 Communication parity selection 00 (no parity), 01 (even parity), 02 (odd parity) 00
C075 Communication stop bit selection 1 (1 bit), 2 (2 bits) 1
C076 Selection of the operation after
communication error
00 (tripping), 01 (tripping after decelerating and stopping the motor), 02
(ignoring errors), 03 (stopping the motor after free-running), 04
(decelerating and stopping the motor)
02
C077 Communication timeout limit
before tripping 0.00 to 99.99 (s) 0.00
C078 Communication wait time 0. to 1000. (ms) 0.
Communication function
C079 Communication mode selection 00(ASCII), 01(Modbus-RTU) 00
C081 [O] input span calibration 0. to 9999., 1000 to 6553(10000 to 65530) Factory setting
C082 [OI] input span calibration 0. to 9999., 1000 to 6553(10000 to 65530) Factory setting
C083 [O2] input span calibration 0. to 9999., 1000 to 6553(10000 to 65530) Factory setting
C085 Thermistor input tuning 0.0 to 999.9, 1000. Factory setting
Adjustment
C091 Debug mode enable (Do not change this parameter, which is intended for factory adjustment.) 00
C101 Up/Down memory mode selection 00 (not storing the frequency data), 01 (storing the frequency data) 00
C102 Reset mode selection 00 (resetting the trip when RS is on), 01 (resetting the trip when RS is off), 2
(enabling resetting only upon tripping [resetting when RS is on]) 00
Others
C103 Restart mode after reset 00 (starting with 0 Hz), 01 (starting with matching frequency), 02 (restarting
with active matching frequency),03(resetting only trip) 00
C105 FM gain adjustment 50. to 200. (%) 100.
C106 AM gain adjustment 50. to 200. (%) 100.
C107 AMI gain adjustment 50. to 200. (%) 100.
C109 AM bias adjustment 0. to 100. (%) 0.
Meter
adjustment
C110 AMI bias adjustment 0. to 100. (%) 20.

1 - 13
Default
Code Function name Monitored data or setting
_FF _FEF _FUF
Note
Ter m
inal
C111 Overload setting (2) 0.0 to 2.00 x "rated current" (A) Rated current of
inverter
C121 [O] input zero calibration 0. to 9999., 1000 to 6553 (10000 to 65530) Factory setting
C122 [OI] input zero calibration 0. to 9999., 1000 to 6553 (10000 to 65530) Factory setting
Adjust
ment
C123 [O2] input zero calibration 0. to 9999., 1000 to 6553 (10000 to 65530) Factory setting
C130 Output 11 on-delay time 0.0 to 100.0 (s) 0.0
C131 Output 11 off-delay time 0.0 to 100.0 (s) 0.0
C132 Output 12 on-delay time 0.0 to 100.0 (s) 0.0
C133 Output 12 off-delay time 0.0 to 100.0 (s) 0.0
C134 Output 13 on-delay time 0.0 to 100.0 (s) 0.0
C135 Output 13 off-delay time 0.0 to 100.0 (s) 0.0
C136 Output 14 on-delay time 0.0 to 100.0 (s) 0.0
C137 Output 14 off-delay time 0.0 to 100.0 (s) 0.0
C138 Output 15 on-delay time 0.0 to 100.0 (s) 0.0
C139 Output 15 off-delay time 0.0 to 100.0 (s) 0.0
C140 Output RY on-delay time 0.0 to 100.0 (s) 0.0
C141 Output RY off-delay time 0.0 to 100.0 (s) 0.0
C142 Logical output signal 1 selection 1 Same as the settings of C021 to C026 (except those of LOG1 to LOG6) 00
C143 Logical output signal 1 selection 2 Same as the settings of C021 to C026 (except those of LOG1 to LOG6) 00
C144 Logical output signal 1 operator
selection 00 (AND), 01 (OR), 02 (XOR) 00
C145 Logical output signal 2 selection 1 Same as the settings of C021 to C026 (except those of LOG1 to LOG6) 00
C146 Logical output signal 2 selection 2 Same as the settings of C021 to C026 (except those of LOG1 to LOG6) 00
C147 Logical output signal 2 operator
selection 00 (AND), 01 (OR), 02 (XOR) 00
C148 Logical output signal 3 selection 1 Same as the settings of C021 to C026 (except those of LOG1 to LOG6) 00
C149 Logical output signal 3 selection 2 Same as the settings of C021 to C026 (except those of LOG1 to LOG6) 00
C150 Logical output signal 3 operator
selection 00 (AND), 01 (OR), 02 (XOR) 00
C151 Logical output signal 4 selection 1 Same as the settings of C021 to C026 (except those of LOG1 to LOG6) 00
C152 Logical output signal 4 selection 2 Same as the settings of C021 to C026 (except those of LOG1 to LOG6) 00
C153 Logical output signal 4 operator
selection 00 (AND), 01 (OR), 02 (XOR) 00
C154 Logical output signal 5 selection 1 Same as the settings of C021 to C026 (except those of LOG1 to LOG6) 00
C155 Logical output signal 5 selection 2 Same as the settings of C021 to C026 (except those of LOG1 to LOG6) 00
C156 Logical output signal 5 operator
selection 00 (AND), 01 (OR), 02 (XOR) 00
C157 Logical output signal 6 selection 1 Same as the settings of C021 to C026 (except those of LOG1 to LOG6) 00
C158 Logical output signal 6 selection 2 Same as the settings of C021 to C026 (except those of LOG1 to LOG6) 00
Output terminal operation function
C159 Logical output signal 6 operator
selection 00 (AND), 01 (OR), 02 (XOR) 00
C160 Input terminal response time
setting 1 0. to 200. ( ¯2ms) 1
C161 Input terminal response time
setting 2 0. to 200. ( ¯2ms) 1
C162 Input terminal response time
setting 3 0. to 200. ( ¯2ms) 1
C163 Input terminal response time
setting 4 0. to 200. ( ¯2ms) 1
C164 Input terminal response time
setting 5 0. to 200. ( ¯2ms) 1
C165 Input terminal response time
setting 6 0. to 200. ( ¯2ms) 1
C166 Input terminal response time
setting 7 0. to 200. ( ¯2ms) 1
C167 Input terminal response time
setting 8 0. to 200. ( ¯2ms) 1
Input terminal response
C168 Input terminal response time
setting FW 0. to 200. ( ¯2ms) 1
Other
C169 Multistage speed/position
determination time 0. to 200. ( ¯10ms) 0

1 - 14
Default
Code Function name Monitored data or setting
_FF _FEF _FUF
Note
H001 Auto-tuning Setting 00 (disabling auto-tuning), 01 (auto-tuning without rotation), 02 (auto-tuning
with rotation) 00
H002 Motor data selection, 1st motor 00 (Hitachi standard data), 01 (auto-tuned data),
02 (auto-tuned data [with online auto-tuning function]) 00
H202 Motor data selection, 2nd motor 00 (Hitachi standard data), 01 (auto-tuned data),
02 (auto-tuned data [with online auto-tuning function]) 00
H003 Motor capacity, 1st motor 0.20 to 75.00 (kW) Factory setting
H203 Motor capacity, 2nd motor 0.20 to 75.00 (kW) Factory setting
H004 Motor poles setting, 1st motor 2, 4, 6, 8, 10 (poles) 4
H204 Motor poles setting, 2nd motor 2, 4, 6, 8, 10 (poles) 4
H005 Motor speed constant, 1st motor 0.001 to 9.999, 10.00 to 80.00 (10.000 to 80.000) 1.590
H205 Motor speed constant, 2nd motor 0.001 to 9.999, 10.00 to 80.00 (10.000 to 80.000) 1.590
H006 Motor stabilization constant, 1st
motor 0. to 255. 100.
H206 Motor stabilization constant, 2nd
motor 0. to 255. 100.
H306 Motor stabilization constant, 3rd
motor 0. to 255. 100.
H020 Motor constant R1, 1st motor 0.001 to 9.999, 10.00 to 65.53 (Ω) Depending on motor capacity
H220 Motor constant R1, 2nd motor 0.001 to 9.999, 10.00 to 65.53 (Ω) Depending on motor capacity
H221 Motor constant R2, 1st motor 0.001 to 9.999, 10.00 to 65.53 (Ω) Depending on motor capacity
H221 Motor constant R2, 2nd motor 0.001 to 9.999, 10.00 to 65.53 (Ω) Depending on motor capacity
H222 Motor constant L, 1st motor 0.01 to 99.99, 100.0 to 655.3 (mH) Depending on motor capacity
H222 Motor constant L, 2nd motor 0.01 to 99.99, 100.0 to 655.3 (mH) Depending on motor capacity
H223 Motor constant Io 0.01 to 99.99, 100.0 to 655.3 (A) Depending on motor capacity
H223 Motor constant Io, 2nd motor 0.01 to 99.99, 100.0 to 655.3 (A) Depending on motor capacity
H224 Motor constant J 0.001 to 9.999, 10.00 to 99.99, 100.0 to 999.9, 1000. to 9999. Depending on motor capacity
H224 Motor constant J, 2nd motor 0.001 to 9.999, 10.00 to 99.99, 100.0 to 999.9, 1000. to 9999. Depending on motor capacity
H030 Auto constant R1, 1st motor 0.001 to 9.999, 10.00 to 65.53 (Ω) Depending on motor capacity
H230 Auto constant R1, 2nd motor 0.001 to 9.999, 10.00 to 65.53 (Ω) Depending on motor capacity
H231 Auto constant R2, 1st motor 0.001 to 9.999, 10.00 to 65.53 (Ω) Depending on motor capacity
H231 Auto constant R2, 2nd motor 0.001 to 9.999, 10.00 to 65.53 (Ω) Depending on motor capacity
H232 Auto constant L, 1st motor 0.01 to 99.99, 100.0 to 655.3 (mH) Depending on motor capacity
H232 Auto constant L, 2nd motor 0.01 to 99.99, 100.0 to 655.3 (mH) Depending on motor capacity
H233 Auto constant Io, 1st motor 0.01 to 99.99, 100.0 to 655.3 (A) Depending on motor capacity
H233 Auto constant Io, 2nd motor 0.01 to 99.99, 100.0 to 655.3 (A) Depending on motor capacity
H234 Auto constant J, 1st motor 0.001 to 9.999, 10.00 to 99.99, 100.0 to 999.9, 1000. to 9999. Depending on motor capacity
Control constants
H234 Auto constant J, 2nd motor 0.001 to 9.999, 10.00 to 99.99, 100.0 to 999.9, 1000. to 9999. Depending on motor capacity

1 - 15
Default
Code Function name Monitored data or setting
_FF _FEF _FUF
Note
H050 PI proportional gain for 1st motor 0.0 to 999.9, 1000. 100.0
H250 PI proportional gain for 2nd motor 0.0 to 999.9, 1000. 100.0
H051 PI integral gain for 1st motor 0.0 to 999.9, 1000. 100.0
H251 PI integral gain for 2nd motor 0.0 to 999.9, 1000. 100.0
H052 P proportional gain setting for 1st
motor 0.01 to 10.00 1.00
H252 P proportional gain setting for 2nd
motor 0.01 to 10.00 1.00
H060 Zero LV lmit for 1st motor 0.0 to 100.0 100.0
H260 Zero LV lmit for 2nd motor 0.0 to 100.0 100.0
H061 Zero LV starting boost current for
1st motor 0. to 50. (%) 50.
H261 Zero LV starting boost current for
2nd motor 0. to 50. (%) 50.
H070 Terminal selection PI proportional
gain setting 0.0 to 999.9, 1000. 100.0
H071 Terminal selection PI integral gain
setting 0.0 to 999.9, 1000. 100.0
H072 Terminal selection P proportional
gain setting 0.00 to 10.00 1.00
Control constants
H073 Gain switching time 0. to 9999. (ms) 100.

1 - 16
Default
Code Function name Monitored data or setting
_FF _FEF _FUF
Note
P001 Operation mode on expansion card
1 error 00 (tripping), 01 (continuing operation) 00
P002 Operation mode on expansion card
2 error 00 (tripping), 01 (continuing operation) 00
P011 Encoder pulse-per-revolution
(PPR) setting 128. to 9999., 1000 to 6553(10000 to 65535) (pulses) 1024.
P012 Control pulse setting 00 (ASR), 01 (APR), 02 (APR2), 03 (HAPR) 00
P013 Pulse train mode setting 00 (mode 0), 01 (mode 1), 02 (mode 2) 00
P014 Home search stop position setting 0. to 4095. 0.
P015 Home search speed setting "start frequency" to "maximum frequency" (up to 120.0) (Hz) 5.00
P016 Home search direction setting 00 (forward), 01 (reverse) 00
P017 Home search completion range
setting 0. to 9999., 1000 (10000) (pulses) 5.
P018 Home search completion delay
time setting 0.00 to 9.99 (s) 0.00
P019 Electronic gear set position
selection 00 (feedback side), 01 (commanding side) 00
P020 Electronic gear ratio numerator
setting 0. to 9999. 1.
P021 Electronic gear ratio denominator
setting 0. to 9999. 1.
P022 Feed-forward gain setting 0.00 to 99.99, 100.0 to 655.3 0.00
P023 Position loop gain setting 0.00 to 99.99, 100.0 0.50
P024 Position bias setting -204 (-2048.) / -999. to 2048. 0.
P025 Temperature compensation
thermistor enable 00 (no compensation), 01 (compensation) 00
P026 Over-speed error detection level
setting 0.0 to 150.0 (%) 135.0
P027 Speed deviation error detection
level setting 0.00 to 99.99, 100.0 to120.0 (Hz) 7.50
P028 Numerator of motor gear ratio 0. to 9999. 1.
P029 Denominator of motor gear ratio 0. to 9999. 1.
P031 Accel/decel time input selection 00 (digital operator), 01 (option 1), 02 (option 2), 03 (easy sequence) 00
P032 Positioning command input
selection 00 (digital operator), 01 (option 1), 02 (option 2) 00
P033 Torque command input selection 00 (O terminal), 01 (OI terminal), 02 (O2 terminal), 03 (digital operator) 00
P034 Torque command setting 0. to 200. (%) 0.
P035 Polarity selection at the torque
command input via O2 terminal 00 (as indicated by the sign), 01 (depending on the operation direction) 00
P036 Torque bias mode 00 (disabling the mode), 01 (digital operator), 02 (input via O2 terminal) 00
P037 Torque bias value -200. to +200. (%) 0.
P038 Torque bias polarity selection 00 (as indicated by the sign), 01 (depending on the operation direction) 00
P039 Speed limit for torque-controlled
operation (forward rotation) 0.00 to "maximum frequency" (Hz) 0.00
P040 Speed limit for torque-controlled
operation (reverse rotation) 0.00 to "maximum frequency" (Hz) 0.00
P044 DeviceNet comm watchdog timer 0.00 to 99.99 (s) 1.00
P045 Inverter action on DeviceNet comm
error
00 (tripping), 01 (tripping after decelerating and stopping the motor), 02
(ignoring errors), 03 (stopping the motor after free-running), 04
(decelerating and stopping the motor)
01
P046 DeviceNet polled I/O: Output
instance number 20, 21, 100 21
P047 DeviceNet polled I/O: Input
instance number 70, 71, 101 71
P048 Inverter action on DeviceNet idle
mode
00 (tripping), 01 (tripping after decelerating and stopping the motor), 02
(ignoring errors), 03 (stopping the motor after free-running), 04
(decelerating and stopping the motor)
01
P049 DeviceNet motor poles setting for
RPM
0, 2, 4, 6, 8, 10, 12, 14, 16, 18, 20, 22, 24, 26, 28, 30, 32, 34, 36, 38
(poles) 0
P055 Pulse-string frequency scale 1.0 to 50.0 (kHz) 25.0
P056 Time constant of pulse-string
frequency filter 0.01 to 2.00 (s) 0.10
P057 Pulse-string frequency bias -100. to +100. (%) 0.
Optional functions
P058 Pulse-string frequency limit 0. to 100. (%) 100.
